Grundfos MAGNA1 C User manual

GRUNDFOS INSTRUCTIONS
MAGNA1, Model C
Installation and operating instructions
(all available languages)
http://net.grundfos.com/qr/i/99209952
MAGNA1
Model C
Safety instructions and other important information

Table of contents
2
MAGNA1
English (GB)
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Български (BG)
Инструкции за безопасност . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Čeština (CZ)
Bezpečnostní pokyny . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Deutsch (DE)
Sicherheitshinweise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Dansk (DK)
Sikkerhedsanvisninger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Eesti (EE)
Ohutusjuhised . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Español (ES)
Instrucciones de seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Suomi (FI)
Turvallisuusohjeet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Français (FR)
Consignes de sécurité. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Ελληνικά (GR)
Οδηγίες ασφαλείας . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Hrvatski (HR)
Sigurnosne upute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Magyar (HU)
Biztonsági utasítások . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Italiano (IT)
Istruzioni di sicurezza . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Lietuviškai (LT)
Saugos nurodymai . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Latviešu (LV)
Drošības instrukcijas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Nederlands (NL)
Veiligheidsinstructies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222
Polski (PL)
Zasady bezpieczeństwa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Português (PT)
Instruções de segurança . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

Table of contents
3
MAGNA1
Română (RO)
Instrucţiuni de siguranţă . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Srpski (RS)
Sigurnosna uputstva . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 283
Русский (RU)
Указания по технике безопасности . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297
Svenska (SE)
Säkerhetsinstruktioner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 315
Slovensko (SI)
Varnostna navodila . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 329
Slovenčina (SK)
Bezpečnostné pokyny . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 342
Türkçe (TR)
Güvenlik talimatları . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 357
Українська (UA)
Інструкція з техніки безпеки . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370
中文 (CN)
安全指导 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 386
日本語(JP)
安全上の注意 ...................................................... 398
한국어 (KO)
안전지침 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .411
Македонски (MK)
Упатства за безбедност . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 424
Norsk (NO)
Sikkerhetsinstruksjoner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 440
Íslenska(IS)
Öryggisleiðbeiningar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 453
ﺔﻳﺑﺭﻌﻟﺍ (AR)
ﺔﻣﻼﺳﻟﺍ ﺕﺎﻣﻳﻠﻌﺗ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 479
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .480
Declaration of conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .481
Declaration of conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .485
Руководство по эксплуатации ЕАС . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .487
Declaration of conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .489

English (GB)
4
English (GB) Safety instructions
Original safety instructions
These safety instructions give a quick
overview of the safety precautions to be
taken in connection with any work on this
product.
Observe these safety instructions during
handling, installation, operation,
maintenance, service and repair of this
product.
These safety instructions are a
supplementary document, and all safety
instructions will appear again in the relevant
sections of the installation and operating
instructions.
Keep these safety instructions at the
installation site for future reference.

English (GB)
5
General warning
Read this document and the quick
guide before installing the product.
Installation and operation must comply
with local regulations and accepted
codes of good practice.
This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or lack
of experience and knowledge if they
have been given supervision or
instruction concerning use of the
appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.

English (GB)
6
Type key
CodeExample (D) 40 -80 (F) (N) 220
Type range
MAGNA1
DSingle-head pump
Twin-head pump
Nominal diameter
(DN) of inlet and
outlet ports [mm]
Maximum head [dm]
F
Pipe connection
Threaded
Flange
N
Pump housing material
Cast iron
Stainless steel
Port-to-port length [mm]

English (GB)
7
Lifting the product
Installing the product
Observe local regulations concerning
limits for manual lifting or handling.
Do not lift the pump head by the
control box, i.e. the red area of the
pump.
CAUTION
Pressurised system
Minor or moderate personal injury
- Pay special attention to any
escaping vapour when loosening
the clamp.
CAUTION
Crushing of feet
Minor or moderate personal injury
- Do not drop the pump head when
loosening the clamp.

English (GB)
8
Electrical installation
Fit and tighten the screw holding the
clamp to 8 Nm ± 1 Nm. Do not apply
more torque than specified even
though water is dripping from the
clamp. The condensed water is most
likely coming from the drain hole under
the clamp.
Check the position of the clamp before
you tighten it. Incorrect position of the
clamp will cause leakage from the
pump and damage the hydraulic parts
in the pump head.
WARNING
Electric shock
Death or serious personal injury
- Lock the main switch in position 0.
Type and requirements as specified
in EN 60204-1, 5.3.2.
8Nm!

English (GB)
9
WARNING
Electric shock
Death or serious personal injury
- Connect the pump to an external
main switch with a minimum contact
gap of 3 mm in all poles.
- Use earthing or neutralisation for
protection against indirect contact.
-For plug-connected versions: In
case of an insulation fault, the fault
current may be a pulsating DC.
Observe national legislation about
requirements for and selection of
Residual Current Device (RCD)
when installing the pump.
For terminal-connected versions:
In case of an insulation fault, the
fault current may be a DC or
pulsating DC. Observe national
legislation about requirements for
and selection of Residual Current
Device (RCD) when installing the
pump.

English (GB)
10
Handling and storing the product
Make sure that the fuse is
dimensioned according to the
nameplate and local legislation.
Connect all cables in accordance with
local regulations.
Make sure that all cables are
heat-resistant up to 70 °C.
Install all cables in accordance with
EN 60204-1 and EN 50174-2.
WARNING
Electric shock
Minor or moderate personal injury
- Separate wires connected to supply
terminals, outputs NC, C and
start-stop input from each other and
from the supply by means of
reinforced insulation.
Observe local regulations concerning
limits for manual lifting or handling.
