Grundfos SCALA2 User manual

SCALA2
Safety instructions and other important information
SCALA2
Installation and operating instructions
http://net.grundfos.com/qr/i/98880508
SCALA2
Quick guide
http://net.grundfos.com/qr/i/98501666
GRUNDFOS INSTRUCTIONS

SCALA2
English (GB)
Safety instructions................................................5
Български (BG)
Инструкции за безопасност ........................................9
Čeština (CZ)
Bezpečnostní pokyny ............................................14
Deutsch (DE)
Sicherheitshinweise .............................................19
Dansk (DK)
Sikkerhedsanvisninger............................................24
Eesti (EE)
Ohutusjuhised .................................................28
Español (ES)
Instrucciones de seguridad.........................................32
Suomi (FI)
Turvallisuusohjeet ...............................................37
Français (FR)
Consignes de sécurité ............................................41
Ελληνικά (GR)
Οδηγίες ασφαλείας ..............................................46
Hrvatski (HR)
Sigurnosne upute ...............................................51
Magyar (HU)
Biztonsági utasítások ............................................55
Italiano (IT)
Istruzioni di sicurezza ............................................60
Lietuviškai (LT)
Saugos nurodymai ..............................................65
Latviešu (LV)
Drošības instrukcijas .............................................69
Nederlands (NL)
Veiligheidsinstructies .............................................74
Polski (PL)
Zasady bezpieczeństwa...........................................79
3
Table of contents

Português (PT)
Instruções de segurança ..........................................84
Română (RO)
Instrucţiuni de siguranţă...........................................89
Srpski (RS)
Sigurnosna uputstva .............................................94
Svenska (SE)
Säkerhetsinstruktioner............................................99
Slovensko (SI)
Varnostna navodila .............................................103
Slovenčina (SK)
Bezpečnostné pokyny ...........................................108
Türkçe (TR)
  .............................................112
Українська (UA)
Інструкція з техніки безпеки ......................................117
Bosanski (BS)
Sigurnosne upute ..............................................122
Macedonian (MK)
Упатства за безбедност .........................................127
Norsk (NO)
Sikkerhetsinstruksjoner ..........................................133
(AR) 
  ...................................................137
Íslenska (IS)
Öryggisleiðbeiningar ............................................140
Declaration of conformity .......................................145
Declaration of conformity .......................................148
Declaration of conformity .......................................149
4SCALA2
Table of contents

English (GB) Safety instructions
Original safety instructions
These safety instructions give a quick overview of the
safety precautions to be taken in connection with any
work on this product. Observe these safety
instructions during handling, installation, operation,
maintenance, service and repair of this product.
These safety instructions are a supplementary
document, and all safety instructions will appear
again in the relevant sections of the installation and
operating instructions. Keep these safety instructions
at the installation site for future reference.
General information
This appliance can be
used by children aged
from 8 years and above
and persons with re-
duced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and under-
stand the hazards in-
volved.
Children shall not play
with the appliance.
Cleaning and user main-
tenance shall not be
made by children without
supervision.
Read this document be-
fore you install the prod-
uct. Installation and op-
eration must comply with
local regulations and
accepted codes of good
practice.
Location
Install the pump in such
a way that no undesira-
ble collateral damage
can arise due to leak-
age.
If the unlikely event of an
internal leakage occurs,
the liquid will be drained
through the bottom of
the pump.
System sizing
Make sure that the sys-
tem in which the pump is
incorporated is designed
for the maximum pump
pressure.
5
English (GB)

Mechanical installation
Deblocking the pump
DANGER
Electric shock
Death or serious person-
al injury
‐Switch off the power
supply before you
start any work on the
product.Make sure
that the power sup-
ply cannot be switch-
ed on accidentally.
Electrical connection
Carry out the electrical
connection according to
local regulations.
Check that the supply
voltage and frequency
correspond to the values
stated on the nameplate.
DANGER
Electric shock
Death or serious person-
al injury
‐Switch off the power
supply before you
start any work on the
product. Make sure
that the power sup-
ply cannot be switch-
ed on accidentally.
DANGER
Electric shock
Death or serious person-
al injury
‐The pump must be
earthed.
‐The pump is sup-
plied with a ground-
ing conductor and
grounding-type at-
tachment plug. To re-
duce the risk of elec-
tric shock, be certain
that the pump is con-
nected only to a
properly grounded,
grounding type re-
ceptacle (protective
earthing).
‐If national legislation
requires a Residual
Current Device
(RCD), a Ground
Fault Circuit Inter-
rupter (GFCI), or
equivalent in the
electrical installation,
this must be type B
(according to UL/IEC
61800-5-1) or better,
due to the nature of
the constant DC
leakage current.
6
English (GB)

If the power supply cable
is damaged, it must be
replaced by the manu-
facturer, his service
agent or similarly quali-
fied persons in order to
avoid hazard.
Plug connection
DANGER
Electric shock
Death or serious person-
al injury
‐Check that the power
plug delivered with
the product is in
compliance with local
regulations.
‐Make sure that the
pump is connected
only to a properly
grounded, ground-
ing-type receptacle
(protective earthing).
‐The protective earth
of the power outlet
must be connected
to the protective
earth of the pump.
The plug must there-
fore have the same
PE connection sys-
tem as the power
outlet. If not, use a
suitable adapter.
Connection without plug
The electrical connection
must be carried out by
an authorised electrician
in accordance with local
regulations.
DANGER
Electric shock
Death or serious person-
al injury
‐The pump must be
connected to an ex-
ternal main switch
with a minimum con-
tact gap of 3 mm
(0.12 inch) in all
poles.
Servicing the product
DANGER
Electric shock
Death or serious person-
al injury
‐Before starting any
work on the product,
make sure that the
power supply has
been switched off
and that it cannot be
accidentally switched
on.
7
English (GB)

Fault finding chart
DANGER
Electric shock
Death or serious person-
al injury
‐Before starting any
work on the product,
make sure that the
power supply has
been switched off
and that it cannot be
accidentally switched
on.
Technical data
Operating conditions
Temperature [°C (°F)]
Max. ambient temperature
1 x 208-230 V, 60
Hz: 45 (113)
1 x 115 V, 60 Hz: 45 (113)
1 x 200-240 V, 50/60
Hz: 55 (131)
Max. liquid temperature 45 (113)
Pressure [bar (psi)] [MPa]
Max. system pressure 10 (145) 1
Max. inlet pressure 6 (87) 0.6
Other operating data
Max. head 45 m (147 ft)
IP rating X4D (outdoor installation)
Pumped liquid Clean water
Noise level < 47 dB(A)1
147 dB(A) is measured in a typical application with pressure
control mode (2.5 bar (36 psi) and 1 m3/h). In non-typical
applications noise might increase up to 58 dB.
Disposing of the product
This product has been designed with focus on the
disposal and recycling of materials. The following
disposal values apply to all variants of Grundfos
SCALA2 pumps:
• minimum 85 % for recycling
• maximum 10 % for incineration
• maximum 5 % for depositing.
Values are percent of total weight.
This product or parts of it must be disposed of in an
environmentally sound way.
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest
Grundfos company or service workshop.
The crossed-out wheelie bin
symbol on a product means
that it must be disposed of
separately from household
waste. When a product
marked with this symbol rea-
ches its end of life, take it to a
collection point designated by
the local waste disposal au-
thorities. The separate collec-
tion and recycling of such
products will help protect the
environment and human
health.
See also end-of-life information at
www.grundfos.com/product-recycling.
8
English (GB)

Declaration of conformity
GB: EU declaration of conformity
We, Grundfos, declare under our sole responsibility
that the product SCALA2, to which the declaration
below relates, is in conformity with the Council
Directives listed below on the approximation of the
laws of the EU member states.
BG: Декларация за съответствие на EO
Ние, фирма Grundfos, заявяваме с пълна
отговорност, че продуктът SCALA2, за който се
отнася настоящата декларация, отговаря на
следните директиви на Съвета за уеднаквяване
на правните разпоредби на държавите-членки на
ЕO.
CZ: Prohlášení o shodě EU
My firma Grundfos prohlašujeme na svou plnou
odpovědnost, že výrobek SCALA2, na který se toto
prohlášení vztahuje, je v souladu s níže uvedenými
ustanoveními směrnice Rady pro sblížení právních
předpisů členských států Evropského společenství.
DE: EU-Konformitätserklärung
Wir, Grundfos, erklären in alleiniger Verantwortung,
dass das Produkt SCALA2, auf das sich diese
Erklärung bezieht, mit den folgenden Richtlinien des
Rates zur Angleichung der Rechtsvorschriften der
EU-Mitgliedsstaaten übereinstimmt.
DK: EU-overensstemmelseserklæring
Vi, Grundfos, erklærer under ansvar at produktet
SCALA2 som erklæringen nedenfor omhandler, er i
overensstemmelse med Rådets direktiver der er
nævnt nedenfor, om indbyrdes tilnærmelse til EU-
medlemsstaternes lovgivning.
EE: EÜvastavusdeklaratsioon
Meie, Grundfos, kinnitame ja kanname ainuisikulist
vastutust selle eest, et toode SCALA2, mille kohta
all olev deklaratsioon käib, on kooskõlas Nõukogu
Direktiividega, mis on nimetatud all pool vastavalt
vastuvõetud õigusaktidele ühtlustamise kohta EÜ
liikmesriikides.
ES: Declaración de conformidad de la UE
Grundfos declara, bajo su exclusiva
responsabilidad, que el producto SCALA2 al que
hace referencia la siguiente declaración cumple lo
establecido por las siguientes Directivas del
Consejo sobre la aproximación de las legislaciones
de los Estados miembros de la UE.
FI: EU-vaatimustenmukaisuusvakuutus
Grundfos vakuuttaa omalla vastuullaan, että tuote
SCALA2, jota tämä vakuutus koskee, on EU:n
jäsenvaltioiden lainsäädännön lähentämiseen
tähtäävien Euroopan neuvoston direktiivien
vaatimusten mukainen seuraavasti.
FR: Déclaration de conformité UE
Nous, Grundfos, déclarons sous notre seule
responsabilité, que le produit SCALA2, auquel se
réfère cette déclaration, est conforme aux Directives
du Conseil concernant le rapprochement des
législations des États membres UE relatives aux
normes énoncées ci-dessous.
GR: Δήλωση συμμόρφωσης ΕΕ
Εμείς, η Grundfos, δηλώνουμε με αποκλειστικά δική
μας ευθύνη ότι το προϊόν SCALA2, στο οποίο
αναφέρεται η παρακάτω δήλωση, συμμορφώνεται
με τις παρακάτω Οδηγίες του Συμβουλίου περί
προσέγγισης των νομοθεσιών των κρατών μελών
της ΕΕ.
HR: EU deklaracija sukladnosti
Mi, Grundfos, izjavljujemo s punom odgovornošću
da je proizvod SCALA2, na koja se izjava odnosi u
nastavku, u skladu s dolje navedenim direktivama
Vijeća o usklađivanju zakona država članica EU-a.
HU: EU megfelelőségi nyilatkozat
Mi, a Grundfos vállalat, teljes felelősséggel
kijelentjük, hogy a(z) SCALA2 termék, amelyre az
alábbi nyilatkozat vonatkozik, megfelel az Európai
Unió tagállamainak jogi irányelveit összehangoló
tanács alábbi előírásainak.
IT: Dichiarazione di conformità UE
Grundfos dichiara sotto la sua esclusiva
responsabilità che il prodotto SCALA2, al quale si
riferisce questa dichiarazione, è conforme alle
seguenti direttive del Consiglio riguardanti il
riavvicinamento delle legislazioni degli Stati membri
UE.
LT: ES atitikties deklaracija
Mes, Grundfos, su visa atsakomybe pareiškiame,
kad produktas SCALA2, kuriam skirta ši deklaracija,
atitinka žemiau nurodytas Tarybos Direktyvas dėl
ES šalių narių įstatymų suderinimo.
145
Declaration of conformity

LV: ES atbilstības deklarācija
Sabiedrība Grundfos ar pilnu atbildību paziņo, ka
produkts SCALA2, uz kuru attiecas tālāk redzamā
deklarācija, atbilst tālāk norādītajām Padomes
direktīvām par ES dalībvalstu normatīvo aktu
tuvināšanu.
NL: EU-conformiteitsverklaring
Wij, Grundfos, verklaren geheel onder eigen
verantwoordelijkheid dat product SCALA2, waarop
de onderstaande verklaring betrekking heeft, in
overeenstemming is met de onderstaande
Richtlijnen van de Raad inzake de onderlinge
aanpassing van de wetgeving van de EU-lidstaten.
PL: Deklaracja zgodności UE
My, Grundfos, oświadczamy z pełną
odpowiedzialnością, że nasz produkt SCALA2,
którego deklaracja niniejsza dotyczy, jest zgodny z
następującymi dyrektywami Rady w sprawie
zbliżenia przepisów prawnych państw
członkowskich.
PT: Declaração de conformidade UE
A Grundfos declara sob sua única responsabilidade
que o produto SCALA2, ao qual diz respeito a
declaração abaixo, está em conformidade com as
Directivas do Conselho sobre a aproximação das
legislações dos Estados Membros da UE.
RO: Declaraţia de conformitate UE
Noi Grundfos declarăm pe propria răspundere că
produsul SCALA2, la care se referă această
declaraţie, este în conformitate cu Directivele de
Consiliu specificate mai jos privind armonizarea
legilor statelor membre UE.
RS: Deklaracija o usklađenosti EU
Mi, kompanija Grundfos, izjavljujemo pod punom
vlastitom odgovornošću da je proizvod SCALA2, na
koji se odnosi deklaracija ispod, u skladu sa dole
prikazanim direktivama Saveta za usklađivanje
zakona država članica EU.
RU: Декларация о соответствии нормам ЕС
Мы, компания Grundfos, со всей
ответственностью заявляем, что изделие
SCALA2, к которому относится нижеприведённая
декларация, соответствует нижеприведённым
Директивам Совета Евросоюза о
тождественности законов стран-членов ЕС.
SE: EU-försäkran om överensstämmelse
Vi, Grundfos, försäkrar under ansvar att produkten
SCALA2, som omfattas av nedanstående försäkran,
är i överensstämmelse med de rådsdirektiv om
inbördes närmande till EU-medlemsstaternas
lagstiftning som listas nedan.
SI: Izjava o skladnosti EU
V Grundfosu s polno odgovornostjo izjavljamo, da je
izdelek SCALA2,na katerega se spodnja izjava
nanaša, v skladu s spodnjimi direktivami Sveta o
približevanju zakonodaje za izenačevanje pravnih
predpisov držav članic EU.
SK: ES vyhlásenie o zhode
My, spoločnosť Grundfos, vyhlasujeme na svoju
plnú zodpovednosť, že produkt SCALA2, na ktorý sa
vyhlásenie uvedené nižšie vzťahuje, je v súlade s
ustanoveniami nižšie uvedených smerníc Rady pre
zblíženie právnych predpisov členských štátov EÚ.
TR: AB uygunluk 
Grundfos olarak,   konusu olan
SCALA2  AB üye  
yakınlaştırılmasıyla  durumun  Konsey
 uyumlu olduğunu ve bununla 
olarak tüm sorumluluğun   olduğunu beyan

UA: Декларація відповідності директивам EU
Ми, компанія Grundfos, під нашу одноосібну
відповідальність заявляємо, що виріб SCALA2,
до якого відноситься нижченаведена декларація,
відповідає директивам EU, переліченим нижче,
щодо тотожності законів країн-членів ЄС.
CN: 欧盟符合性声明
我们，格兰富，在我们的全权责任下声明，产品
SCALA2 系列，其制造和性能完全符合以下所列欧盟
委员会指令。
JP: EU 適合宣言
Grundfos は、その責任の下に、SCALA2 製品が EU 加
盟諸国の法規に関連する、以下の評議会指令に適合し
ていることを宣言します。
KO: EU 적합성 선언
Grundfos는 아래의 선언과 관련된 SCALA2 제품이
EU 회원국 법률에 기반하여 아래의 이사회 지침을
준수함을 단독 책임 하에 선언합니다.
BS: Izjava o usklađenosti EU
Mi, kompanija Grundfos, izjavljujemo pod vlastitom
odgovornošću da je proizvod SCALA2, na koji se
odnosi izjava ispod, u skladu sa niže prikazanim
direktivama Vijeća o usklađivanju zakona država
članica EU.
146
Declaration of conformity
