Grundig WiFi USB DONGLE User manual

WiFi USB DONGLE
en

ENGLISH
8
CONTENTS-------------------------------------------------------------------------------------
9 SAFETYANDSET-UP
10 WiFiUSBDONGLE
10 Packingcontents
10 Specialfeatures
10 Connectionanduse
11 INFORMATION
11 Technicaldata
11 Dimensionsandweight
12 Serviceinformationfordealers
13 CEMarkWarning

ENGLISH 9
SAFETYANDSET-UP-----------------------------------------------------------
Pleasenotethefollowingpoints
whenusingthedevice:
7
Thedeviceisdesignedforusein
dryrooms.
7
Keepthedeviceawayfromwater,
moistureandliquids.
7
Donotplacethedevicecloseto
heatingunitsorindirectsunlight.
7
Keepflammableobjects,candles
orotheropenflamesawayfrom
thedevice.
7
Neveropenthedevicecasing
underanycircumstances.Thema-
nufactureracceptsnoliabilityfor
damageresultingfromimproper
handling.
7
Keepthedeviceoutofthereach
ofchildren.
7
Onlyusethisdeviceincombina-
tionwithGrundigTVsetswhich
areWiFi-ready.
Environmentalnote
Thisproducthasbeen
manufacturedwith
highqualityparts
andmaterialswhich
canbereusedandaresuitablefor
recycling.
Therefore,donotdisposethepro-
ductwithnormaldomesticwasteat
theendofitsservicelife.Takeittoa
collectionpointfortherecyclingof
electricalandelectronicequipment.
Thisisindicatedbythissymbolon
theproduct,intheoperatingmanual
andonthepackaging.
Pleaseconsultyourlocalauthorities
tolearnthenearestcollectionpoint.
Helpprotecttheenvironmentby
recyclingusedproducts.

ENGLISH
10
WiFiUSBDONGLE---------------------------------------------------------------
Packingcontents
1 WiFiUSBDongle
2 Usermanual
Specialfeatures
GrundigWiFiUSBDongleprovides
wirelessnetworkconnectionforyour
GrundigTVwhichisWiFiready.
Byusingthisdongle,youcaneasily
upgradeyourTV’swirelessconnec-
tivity.Onceconnected,accessthe
networkwithhigh-speedInternet
connectionwhilesharingphotos,files,
musicandvideo.
Connectionanduse
Notes:
7 TheTVmustbeswitchedoff
beforeyouconnecttheWiFi
USBdongle.
1 ConnectGrundigWiFiUSB
dongletothe»USB«or»USB
HDD«socketofyourtelevisionin
ordertoconnectthetelevisionto
awirelessnetwork.
2 Intheusermanualofyour
GrundigTVset,youcanfind
informationhowtoconnectto
yourwirelesshomenetworkand
furtherdetails.Pleasereferthe
section“HOMENETWORK-
Wirelessnetworkconnection”.
1
2

11
ENGLISH
INFORMATION------------------------------------------------------------------------
IEEEstandards:
802.11g,802.11b,802.11i,
compatiblewith802.11n
Dimensionsandweight
Dimensions(WxHxD):
89x26,4x11mm
Weight:
26gr
Technicaldata
Datatransferrates:
11n:135/121.5/108/81/
54/40.5/27/13.5Mbps
130/117/104/78/52/
39/26/13Mbps65/
58.5/52/39/26/19.5/
13/6.5Mbps(Dynamic)
11g:54/48/36/24/18/
12/9/6Mbps(Dynamic)
11b:11/5.5/2/1Mbps
(Dynamic)
Channel:
1 ˜13
Modulationtype:
OFDM/CCK/16-QAM/64-QAM
RFpower:
18dBm(max)
Sensitivity:
130M:-68dBm@10%PER
108M:-68dBm@10%PER
54M:-68dBm@10%PER
11M:-85dBm@8%PER
6M:-88dBm@10%PER
1M:-90dBm@8%PER
IEEEstandards:
WPA/WPA2,WPA-PSK/
WPA2-PSK(TKIP/AES)64/
128-bitWEPEncryption
Technicalanddesignmodifications
reserved.

ENGLISH
12
INFORMATION------------------------------------------------------------------------
Serviceinformationfor
dealers
ThisisaclassBpro-
duct.Inadomestic
environment,thispro-
ductmaycauseradio
interference,inwhichcasetheuser
mayberequiredtotakeadequate
measures.
Thisdevicecanbeoperatedinfollo-
wingcountries:
Austria,Belgium,Bulgaria,Czech
Republic,Cyprus,Denmark,Estonia,
Finland,France,Germany,Great
Britain,Greece,Hungary,Ireland,
Island,Italy,Latvia,Liechtenstein,
Lithuania,Luxembourg,Malta,Net-
herlands,Norway,Poland,Portugal,
Romania,Slovakia,Slovenia,Spain,
Sweden,Switzerland.
Thetypeplateislocatedonthe
device.
Donotopenthedevicecasingunder
anycircumstances.Nowarranty
claimsareacceptedfordamage
causedbyincorrecthandling.

13
ENGLISH
INFORMATION------------------------------------------------------------------------
CEMarkWarning
Nationalrestrictions
ThisdeviceisintendedforhomeandofficeuseinallEUcount-
ries(andothercountriesfollowingtheEUdirective1999/5/
EC)withoutanylimitationexceptforthecountriesmentioned
below:
Country Restriction Reason/remark
Bulgaria None Generalauthorizationrequiredfor
outdooruseandpublicservice.
France Outdooruse
limitedto10mW
e.i.r.p.withinthe
band2454-
2483.5MHz
MilitaryRadiolocationuse.Refarming
ofthe2.4GHzbandhasbeenongoing
inrecentyearstoallowcurrentrelaxed
regulation.Fullimplementationplanned
2012.
Italy None Ifusedoutsideofownpremises,general
authorizationisrequired.
Luxembourg None Generalauthorizationrequiredfor
networkandservicesupply(notfor
spectrum)
Norway Implemented Thissubsectiondoesnotapplyforthe
geographicalareawithinaradiusof20
kmfromthecentreofNy-Ålesund.
Russian
Federation None Onlyforindoorapplications.
Note:
7 Pleasedon’tusetheproductoutdoorsinFrance.

www.grundig.com
10/48720117460500
