GSS PMDF 1000 User manual

English
CLASS
KLASSE
PMDF 1000
Head-End Modulator FM
IP to 12xFM
GSS
Grundig SAT Systems GmbH
Beuthener Strasse 43
D-90471 Nuremberg
Phone: +49 (0) 911 / 703 8877
Fax: +49 (0) 911 / 703 9210
E-mail: [email protected]
Internet: http://www.gss.de

- 2 - PMDF 1000
Contents
1 Safety regulations and notes..............................................................................3
2 General information ..........................................................................................4
2.1 Packing contents ................................................................................ 4
2.2 Meaning of the symbols used............................................................... 4
2.3 Technical data.................................................................................... 5
2.4 Description ........................................................................................ 6
2.5 Software query .................................................................................. 7
3 Assembly ..........................................................................................................8
3.1 Installing the cassette .......................................................................... 8
3.2 EMC regulations ................................................................................ 9
3.3 Cassette overview ............................................................................ 10
3.4 Connecting the cassette..................................................................... 10
4 The control panel at a glance ...........................................................................11
4.1 Menu items...................................................................................... 11
4.2 Control panel................................................................................... 11
5 Programming ..................................................................................................12
5.1 Programming procedure.........................................................................12
5.2 Programming the cassette.................................................................. 14
Selecting the cassette........................................................................ 14
Setting the Ethernet parameters .......................................................... 15
Setting the IP address of the cassette.............................................. 15
Setting the address range............................................................. 16
Setting the address of the gateway................................................ 16
Setting the UDP port.......................................................................17
Setting the input parameters............................................................... 17
Selecting the transmission protocol................................................ 18
Setting the port number................................................................ 18
Setting the IP address of the input transport stream .......................... 19
Delete programme locations .............................................................. 20
Programme locations ........................................................................ 21
Submenus output parameters ............................................................. 21
Output frequency ........................................................................ 23
Channel selection........................................................................ 23
Language selection...................................................................... 24
Frequency deviation adjustment .................................................... 24
Kind of transmission .................................................................... 25
RDS........................................................................................... 25
Output level..................................................................................... 26
Factory reset.................................................................................... 26
Saving settings................................................................................. 27
6 Final procedures..............................................................................................28

- 3 - PMDF 1000
1 safety regulations and notes
• Assembly, installation and servicingshould be carried out byauthorised
electricians.
 • Switchofftheoperatingvoltageofthesystembeforebeginningwithassem-
bly or service work or pull out the mains plug.
 • Donotperforminstallationandserviceworkduringthunderstorms.
 • Installthesystemsoitwillnotbeabletovibrate…
 - inadust-free,dryenvironment
 - insuchamannerthatitisprotectedfrommoisture,fumes,splashingwa-
ter and dampness
- somewhere protected from direct sunlight
- not within the immediate vicinity of heat sources
- in an ambient temperature of 0 °C to +50 °C. In case of the formation of
condensation wait until the system is completely dried.
 • Ensurethatthehead-endstationisadequatelyventilated.Donotcoverthe
ventilation slots.
 • Bewareofshortcircuits
 • Noliabilityisacceptedforanydamagecausedbyfaultyconnectionsor
inappropriate handling.
 • Observetherelevantstandards,regulationsandguidelinesontheinstalla-
tion and operation of antenna systems.
 • ThestandardsIEC/EN/DINEN50083resp.IEC/EN/DINEN60728must
be observed.
 • For further information please read the assembly instructions for the head-
end station used.
• Test the software versions of the head-end station and the cassette and
update them if necessary. The current software versions can be found at
”www.gss.de”.
Take action to prevent static discharge when working on the device!
Electronic devices should never be disposed of in the household rubbish. In
accordance with directive 2002/96/EC of the European Parliament and the
European Council from January 27, 2003 which addresses old electronic and
electrical devices, such devices must be disposed of at a designated collection
facility. At the end of its service life, please take your device to one of these
public collection facilities for proper disposal.

- 4 - PMDF 1000
2 general information
2.1 PaCking Contents
1 Cassette PMDF 1000
1 LAN cable
1 Brief assembly instructions
1 Messprotokoll
2.2 meaning of the symbols used
Important note
—> General note
 •  Performingworks

- 5 - PMDF 1000
2.3 teChniCal data
The devices meet the following EU directives:
 2006/95/EC,2004/108/EC
The product fulfils the guidelines and standards for CE labelling (see page 29).
Unless otherwise noted all values are specified as “typical”.
LAN interface
Standard: .............................................................................100-BASE-T
Data rate:............................................................................... ≤80 MBit
Protocols:.......................................................... UDP(UserDataProtocol),
RTP (Real-Time Transport Protocol)
Conversion: .................................................................. MPTS to UHF FM
HF output
Frequency range .......................................... 87.50MHz…108.00MHz
Tuning steps................................................................................50 kHz
Type of modulation ............................................................................ FM
Return loss ......................................................................................8 dB
Output level .............................................................................. 93 dBμV
Signal-to-harmonics ratio ..............................................................>60 dB
Output impedance..........................................................................75 Ω
External voltage difference
Mono........................................................................................66 dB
Stereo .......................................................................................53 dB
Non-linear distortion factor
Mono.......................................................................................0,06%
Stereo ........................................................................................0,6%
Overall output frequency deviation ................................................75 kHz
FM modulator
Number of available services (programme locations) ..............................12
RDS signal processing..................................................................57 kHz
Pilot signal..................................................................................19 kHz
Preemphasis...................................................................................50 μs
Connections
LAN input.......................................................................... 1 RJ45 socket
HF output..................................................................1IECsocket,female
Connection strip ........................................................................... 10-pin
for supply voltages and control circuits
RS-232 socket: ..................................... serial interface for software update

- 6 - PMDF 1000
Remote maintenance
Remotely controllable (via PSW 1000*): ..............................................yes
Remote update (via BEflash*):.............................................................yes
(* and a corresponding management unit)
2.4 desCriPtion
The cassette converts 12 stereo audio channels from an IP data stream into 12
FM modulated stereo output signals. The RDS station code is automatically taken
from the IP data stream or can be entered manually.
Principle signal path:
HF output
LAN input IP data stream
Combiner
12 fold modulator
TPS
The cassette is controlled with the head-end station control unit.
A LED indicates whether an input signal is present or not (see figure on page 5).
LED indicator Indication
Green Signal present
Red No signal
To operate this cassette the software version of the control unit must be “V44”
or higher. You can find the current operating software for the control unit and
thecassette,thesoftware“BE-Flash”andthecurrentassemblyinstructionson
the website “www.gss.de”.
The cassette is designed for use in head-end stations of the profi line.

- 7 - PMDF 1000
2.5 software query
Control unit
 If necessary, you can activate the indication of the software version of the
control unit manually:
 • Pressanytwokeysonthecontrolunitofthehead-endstationsimultaneously
untilthedisplaygoesdarkandthesoftwareversion,e.g.“V 44” appears.
Cassette
After activating the cassette the software version of the cassette is displayed
(see page 14).

- 8 - PMDF 1000
3 assembly
3.1 installing the Cassette
– Ensure the head-end station is mounted so it will not be able to vibrate.
Avoid,forexample,mountingthehead-endstationontoaliftshaftorany
other wall or floor construction that vibrates in a similar way.
– Before installing or changing a cassette unplug the power cable from the
mains power socket.
 • Removethefasteningscrews1of an unoccupied slot from the bracket of
the head-end station.
 • Insertthecassetteinthisslotandpushitintothehousing.
 • Alignthecassetteandapplyslightpressuretoconnectittotheconnections
of the board and the HF bus bar.
 • Fastenthecassettewiththescrews1.
1
1

- 9 - PMDF 1000
3.2 emC regulations
To comply with the current EMC regulations, it is necessary to connect the lines
leading in and out of the head-end station using cable terminals.
When mounting the cassette in a head-end station which is installed in a 19”
cabinet, make sure the connections leading in and out for the 19” cabinet are
made using cable terminals.
CLASS
KLASSE
The attenuation of shielding of the connection lines for ASI and antenna must
meet the requirements for “Class A”.
 • Inserttherequirednumberofcableterminalsintheopeningsprovidedin
the head-end station or in the 19 ” cabinet.
Tighten the nuts on the cable terminals until the teeth on the lock washer have
penetrated the exterior coating and a good connection is made between the hous-
ing and cable terminals.

- 10 - PMDF 1000
3.3 Cassette overview
1
@
2
3
4
5
7
6
8
9
0
!
1D-SUB socket “RS 232“
2 not used
3 not used
4 not used
5 Status LED of the LAN interface
(yellow LED – data transfer)
6 not used
7 Status LED of the LAN interface
(green LED – network connection)
8 not used
9 Status LED of the LAN input
0 not used
! not used
@ MAC address
The operating software of the cassette can be updated via the
9-pin D-SUB socket “RS 232” using a PC or notebook and the
software “BE-Flash”. You can find the current operating software
on the website “www.gss.de”.
3.4 ConneCting the Cassette
 • PlugtheLANinputcableintotheLANinputsocket.
 • Connectthehead-endstationtothemains.
