GSS HDMC 1000 FM User manual

English
CLASS
KLASSE
HDMC 1000 FM
Head-End Modulator FM
COFDM/QAM 12xFM
GSS
Grundig SAT Systems GmbH
Beuthener Strasse 43
D-90471 Nuremberg
Phone: +49 (0) 911 / 703 8877
Fax: +49 (0) 911 / 703 9210
E-mail: [email protected]
Internet: http://www.gss.de

- 2 - HDMC 1000 FM
Contents
1 Safety regulations and notes..............................................................................3
2 General information ..........................................................................................4
2.1 Packing contents ................................................................................ 4
2.2 Meaning of the symbols used............................................................... 4
2.3 Technical data.................................................................................... 4
2.4 Description ........................................................................................ 6
2.5 Software query .................................................................................. 7
3 Assembly ..........................................................................................................8
3.1 Installing the cassette .......................................................................... 8
3.2 EMC regulations ................................................................................ 9
3.3 Cassette overview ............................................................................ 10
3.4 Connecting the cassette..................................................................... 10
3.5 Retrofitting a CA module ................................................................... 11
4 The control panel at a glance ...........................................................................12
4.1 Menu items...................................................................................... 12
4.2 Control panel................................................................................... 12
5 Programming ..................................................................................................13
5.1 Programming procedure.........................................................................13
5.2 Programming the cassette.................................................................. 15
Selecting the cassette........................................................................ 15
Input parameters .............................................................................. 16
Kind of modulation...................................................................... 16
Symbol rate................................................................................ 17
Input channel / Input frequency.......................................................... 17
Operation with a CA module ....................................................... 18
PID monitoring............................................................................ 18
CA module................................................................................. 18
Delete programme locations .............................................................. 20
Programme locations ........................................................................ 21
Submenus output parameters ............................................................. 21
Output frequency ........................................................................ 23
Channel selection........................................................................ 23
Language selection...................................................................... 24
Frequency deviation adjustment .................................................... 24
Kind of transmission .................................................................... 25
RDS........................................................................................... 25
Output level..................................................................................... 26
Factory reset.................................................................................... 27
Saving settings................................................................................. 27
6 Final procedures..............................................................................................28

- 3 - HDMC 1000 FM
1 safety regulations and notes
• Assembly, installation and servicingshould be carried out byauthorised
electricians.
 • Switchofftheoperatingvoltageofthesystembeforebeginningwithassem-
bly or service work or pull out the mains plug.
 • Donotperforminstallationandserviceworkduringthunderstorms.
 • Installthesystemsoitwillnotbeabletovibrate…
 - inadust-free,dryenvironment
 - insuchamannerthatitisprotectedfrommoisture,fumes,splashingwa-
ter and dampness
- somewhere protected from direct sunlight
- not within the immediate vicinity of heat sources
- in an ambient temperature of 0 °C to +50 °C. In case of the formation of
condensation wait until the system is completely dried.
 • Ensurethatthehead-endstationisadequatelyventilated.Donotcoverthe
ventilation slots.
 • Bewareofshortcircuits
 • Noliabilityisacceptedforanydamagecausedbyfaultyconnectionsor
inappropriate handling.
 • Observetherelevantstandards,regulationsandguidelinesontheinstalla-
tion and operation of antenna systems.
 • ThestandardsEN/DINEN50083resp.IEC/EN/DINEN60728mustbe
observed.
 • For further information please read the assembly instructions for the head-
end station used.
• Test the software versions of the head-end station and the cassette and
update them if necessary. The current software versions can be found at
"www.gss.de".
Take action to prevent static discharge when working on the device!
Electronic devices should never be disposed of in the household rubbish. In
accordance with directive 2002/96/EC of the European Parliament and the
European Council from January 27, 2003 which addresses old electronic and
electrical devices, such devices must be disposed of at a designated collection
facility. At the end of its service life, please take your device to one of these
public collection facilities for proper disposal.

- 4 - HDMC 1000 FM
2 general information
2.1 PaCking Contents
1 Cassette HDMC 1000 FM 2 HF cables
1 Brief assembly instructions
2.2 meaning of the symbols used
Important note
—> General note
 •  Performingworks
2.3 teChniCal data
The devices meet the following EU directives:
 2006/95/EC,2004/108/EC
The product fulfils the guidelines and standards for CE labelling (see page 29).
Unless otherwise noted all values are specified as "typical".
HF input
Frequency range: ........................................................... 47…862MHz
Input level:.............................................................. 60dBμV…80dBμV
Symbol rate ...............................................................acc. to EN 300744
HF output
Frequency range .......................................... 87.50MHz…108.00MHz
Tuning steps................................................................................50kHz
Type of modulation ............................................................................ FM
Return loss ......................................................................................8 dB
Output level .............................................................................. 93 dBμV
Signal-to-harmonics ratio ..............................................................>60 dB
Output impedance..........................................................................75 Ω
External voltage difference
Mono........................................................................................66 dB
Stereo .......................................................................................53 dB
Non-linear distortion factor
Mono.......................................................................................0,06%
Stereo ........................................................................................0,6%
Overall output frequency deviation ................................................75kHz

- 5 - HDMC 1000 FM
FM modulator
Number of available services (programme locations) ..............................12
RDS signal processing..................................................................................57kHz
Pilot signal..................................................................................................19kHz
Preemphasis.................................................................................................. 50 μs
ASI-Schnittstelle
Standard ........................................................................DIN EN 50083-9
Format ...............................................................MPEG ISO IEC 13818-1
Impedance ......................................................................................75 Ω
User data rate..................................................................2…90Mbit/s
Level ...................................................................................... 800 mVPP
Return loss .........................................................>17dB(5…270MHz)
Anschlüsse
HF inputs: .............................................................................. 2 F sockets
HF output: ...........................................................................1 IEC socket
ASI input: .................................................................1BNCsocket,75Ω
ASI output:................................................................1BNCsocket,75Ω
LAN:................................................................................ 1 RJ-45 socket
Connection strip ........................................................................... 10-pin
For supply voltages and control circuits
Update interface............................................................... Buchse RS 232
Common Interface ................................................................................1
Several channels can be descrambled
Remote maintenance
Remotely controllable (via PSW 1000*): ..............................................yes
Remote update (via BEflash*):.............................................................yes
(* and a corresponding management unit)

- 6 - HDMC 1000 FM
2.4 desCriPtion
The cassette converts 12 stereo audio channels from two COFDM and QAM
modulated transponders and the ASI input signal into 12 FM modulated stereo
output channels.
The RDS station code is automatically taken from the station name of the trans-
ponder or can be entered manually.
Via input A and a corresponding CA module scrambled channels can be de-
scrambled.
Principle signal path:
HF output
TS A
Input ”A“ Receiving stage
"A" CA module
ASI input
TS ASI
Input ”B“ Receiving stage
"B"
TS B
Combiner
12 fold modulator
TPS
The cassette is controlled with the head-end station control unit.
Two LEDs indicate by their colour the quality of the input signals (see figure on
page 10).
LED indicator Indication
Green blinking During boot sequence
Green Signal quality is good
Yellow Signal quality is poor
Red No signal
Off No transponder selected
To operate this cassette the software version of the control unit must be "V44"
or higher. You can find the current operating software for the control unit and
thecassette,thesoftware"BE-Flash"andthecurrentassemblyinstructionson
the website "www.gss.de".
The cassette is designed for use in head-end stations of the standard line.

- 7 - HDMC 1000 FM
2.5 software query
Control unit
 If necessary, you can activate the indication of the software version of the
control unit manually:
 • Pressanytwokeysonthecontrolunitofthehead-endstationsimultaneously
untilthedisplaygoesdarkandthesoftwareversion,e.g."V44"appears.
Cassette
After activating the cassette the software version of the cassette is displayed
(see page 15).

- 8 - HDMC 1000 FM
3 assembly
3.1 installing the Cassette
– Ensure the head-end station is mounted so it will not be able to vibrate.
Avoid,forexample,mountingthehead-endstationontoaliftshaftorany
other wall or floor construction that vibrates in a similar way.
– Before installing or changing a cassette unplug the power cable from the
mains power socket.
 • Removethefasteningscrews1of an unoccupied slot from the bracket of
the head-end station.
 • Insertthecassetteinthisslotandpushitintothehousing.
 • Alignthecassetteandapplyslightpressuretoconnectittotheconnections
of the board and the HF bus bar.
 • Fastenthecassettewiththescrews1.
CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE
MESSAUSGANG
A
CLASS
KLASSE
ACHTUNG!
Vor dem Cassettenwechsel
unbedingt Netzstecker ziehen!
CAUTION!
Before changing cassettes remove
mains plug!
0°
1
1

- 9 - HDMC 1000 FM
3.2 emC regulations
To comply with the current EMC regulations, it is necessary to connect the lines
leading in and out of the head-end station using cable terminals.
When mounting the cassette in a head-end station which is installed in a 19"
cabinet, make sure the connections leading in and out for the 19" cabinet are
made using cable terminals.
CLASS
KLASSE
The attenuation of shielding of the connection lines for ASI and antenna must
meet the requirements for "Class A".
 • Inserttherequirednumberofcableterminalsintheopeningsprovidedin
the head-end station or in the 19 " cabinet.
Tighten the nuts on the cable terminals until the teeth on the lock washer have
penetrated the exterior coating and a good connection is made between the hous-
ing and cable terminals.

- 10 - HDMC 1000 FM
3.3 Cassette overview
1
2
3
4
5
6
7
8
9
1D-SUB socket "RS-232"
2 Slot for a CA module
3 not used
4 ASI input
5 LAN socket not used
(intended for additional functions)
6 HF input " A " (channel strip " A ") )
7 Status LED channel strip " A "
8 HF input " B " (channel strip " B ")
9 Status LED channel strip " B "
The operating software of the cassette can be updated via the
9-pin D-SUB socket "RS-232" using a PC or notebook and the
software "BE-Flash".
You can find the current operating software on the website
"www.gss.de".
—> The status LEDs indicate the quality of the received transport streams :
LED indicator Indication
Green blinking During boot sequence
Green Signal quality is good
Yellow Signal quality is insufficient
Red No signal
Off No transponder selected
3.4 ConneCting the Cassette
 • ConnecttheHFconnectionstotheinputs 6(channel strip " A ") and 8
(channel strip " B ") .
 • ConnecttheASIinput4and the ASI output 3to the peripheral ASI devices.

- 11 - HDMC 1000 FM
3.5 retrofitting aCa module
The cassette is equipped with a common interface. It allows you to connect a
CA module for various scrambling systems and service providers. Scrambled
stations can only be descrambled with a CA module suitable for the scram-
bling system and the corresponding smart card. The smart card contains all
theinformationforauthorisation,descramblingandsubscription.
Caution
– Check with the distributor or manufacturer of the CA module to be used to
ensure that it is suitable for descrambling several channels.
– The hardware and software of this cassette have been thoroughly prepared
and tested.
Any changes made by programme provider to the structures in the pro-
gramme data might impair or even prevent this function.
 – WhenworkingwiththeCAmodule,pleasereadthecorrespondingoperat-
ing manual from the respective provider.
 • InsertthesmartcardintotheCAmodulesothatthechip3on the smart
card 1faces the thicker side (top) of the CA module 2.
 • InserttheCAmoduleintotheslot4with the top side of the CA module
facing the RS-232 socket of the cassette.
 • PushtheCAmodulewithoutcantingintotheguiderailsoftheCAslot4
and contact it to the common interface.
34 12

- 12 - HDMC 1000 FM
4 the Control Panel at aglanCe
4.1 menu items
Programme the cassette using the buttons on the control unit of the head-end
station. The two-line display of the control unit then shows the menus.
The parameters and functions to be set are underlined.
Use the key to select the following main menu items:
– Input parameters
– Deleting services (programme locations)
– Output parameters
– Output level
– Factory reset
4.2 Control Panel
The key pad on the head-end station is used to scroll through the menus:
scrolls forward through the menus.
select parameters in the menus.
setvalues,initiateactions.
selects sub-menus.
scrolls backward through the menus.
saves all entries.
BE-Remote V44
please wait . . .

- 13 - HDMC 1000 FM
5 Programming
5.1 Programming ProCedure
nur mit CA-Modul
nur Tuner A /
only with CA module
only tuner A
*) Die angezeigte Information ist abhängig
vom verwendeten CA-Modul.
The information displayed is dependent
on the CA module used.
Bx 4A 01/05
Information *)
MENU
Bx 4A
PID Check on
CA-MENU
=>
▶
▶
▶
Ein / On
BE–Remote
please wait …
V 44
Box 4
V 3
T/C-FM
– – –
Bx 1A
C5-12,S3-24
TWIN-SAT
C07
Böx 4
C5-12,S3-24
TWIN-SAT
C07
Box 5
..............
..............
..............
Bx 4
TunerA
INPUT
OK =>
B
t > 10 s
FM 01
Bayern 1
87.50
=>
Bx 4 LEVEL
0 dB
A
FM 01
87.50
FREQ
=> auto
Senderauswahl
Station selection
Tuner A /
Tuner B /
ASI
FM 01 RA
Bayern 1
001/091
Sprachauswahl
Language selection
FM 01
01/01 ger
AUDIO
Hubanpassung
Deviation adjustment
FM 01
0.0 dB
VOLUME
<=>C
FM 01 AUDIO
AUTO
FM 01
Bayern 1
RDS-NAME
=> auto
0 … - 10 dB
Bx 4
FM =>
SERVICES
CLEAR ALL
▶
▶
Box …
………
……
……
AUTO / MONO / STEREO
M
B
A
▶
Bx 4
Defaults
FACTORY
=>
Bx 4
STORE
FACTORY
=> M
auf Werkseinstellung
zurücksetzen und
speichern
reset to factory defaults
and store
M
A
FM 01…12
FM 12…01
FM 01…12
FM 12…01
FM 01…12
FM 12…01
FM 01…12
FM 12…01
FM 01…12
FM 12…01
FM 01…12
FM 12…01
FM 01…12
FM 12…01
Bx 4
RESET
RESET
=> M
<zu klein too small
=OK
>zu groß too big
CBegrenzung clipping
Bedienhinweise
"blättert" Menüs vorwärts.
"blättert" Menüs rückwärts.
wählen die Eingabeposition
wählt Untermenü
stellen Werte ein,.
speichert alle Eingaben.
1zeigt die Eingabeposition
Operating Hints
scrolls forward through the menu.
scrolls backward through the menu.
select the enter position.
selects a submenu.
set values and triggers actions.
saves all entries.
1shows the enter position
Bx 4A/B
C55 746.00
INPUT
OK
QAM…
COFDM…
Bx 4A/B
COFDM 8MHZ
INPUT
page 14

- 14 - HDMC 1000 FM
nur mit CA-Modul
nur Tuner A /
only with CA module
only tuner A
*) Die angezeigte Information ist abhängig
vom verwendeten CA-Modul.
The information displayed is dependent
on the CA module used.
Bx 4A 01/05
Information *)
MENUBx 4A
PID Check on
CA-MENU
=>
▶
▶
▶
Ein / On
BE–Remote
please wait …
V 44
Box 4
V 3
T/C-FM
– – –
Bx 1A
C5-12,S3-24
TWIN-SAT
C07
Böx 4
C5-12,S3-24
TWIN-SAT
C07
Box 5
..............
..............
..............
Bx 4
TunerA
INPUT
OK =>
B
t > 10 s
FM 01
Bayern 1
87.50
=>
Bx 4 LEVEL
0 dB
A
FM 01
87.50
FREQ
=> auto
Senderauswahl
Station selection
Tuner A /
Tuner B /
ASI
FM 01 RA
Bayern 1
001/091
Sprachauswahl
Language selection
FM 01
01/01 ger
AUDIO
Hubanpassung
Deviation adjustment
FM 01
0.0 dB
VOLUME
<=>C
FM 01 AUDIO
AUTO
FM 01
Bayern 1
RDS-NAME
=> auto
0 … - 10 dB
Bx 4
FM =>
SERVICES
CLEAR ALL
▶
▶
Box …
………
……
……
AUTO / MONO / STEREO
M
B
A
▶
Bx 4
Defaults
FACTORY
=>
Bx 4
STORE
FACTORY
=> M
auf Werkseinstellung
zurücksetzen und
speichern
reset to factory defaults
and store
M
A
FM 01…12
FM 12…01
FM 01…12
FM 12…01
FM 01…12
FM 12…01
FM 01…12
FM 12…01
FM 01…12
FM 12…01
FM 01…12
FM 12…01
FM 01…12
FM 12…01
Bx 4
RESET
RESET
=> M
<zu klein too small
=OK
>zu groß too big
CBegrenzung clipping
Bedienhinweise
"blättert" Menüs vorwärts.
"blättert" Menüs rückwärts.
wählen die Eingabeposition
wählt Untermenü
stellen Werte ein,.
speichert alle Eingaben.
1zeigt die Eingabeposition
Operating Hints
scrolls forward through the menu.
scrolls backward through the menu.
select the enter position.
selects a submenu.
set values and triggers actions.
saves all entries.
1shows the enter position
Bx 4A/B
C55 746.00
INPUT
OK
QAM…
COFDM…
Bx 4A/B
COFDM 8MHZ
INPUT
Seite 13
Seite 13
Seite 13

- 15 - HDMC 1000 FM
5.2 Programming the Cassette
—> Pressing the button for longer than 2 seconds cancels the
programming procedure. This takes you back to the program item
"Selecting the cassette" from any menu. Any entries that have not
been saved are reset to the previous settings.
—> Entries in the menus can be saved by pressing the key. You are
taken back to the "Selecting the cassette" menu item.
—> Pressing the button returns to the previous menus.
 • Switchonthehead-endstation
Ein / On BE–Remote
please wait …
V 44
t > 10 s
—> The display shows the software version (e.g. V 44)
—> The processor reads the cassettes ‘ data (approx. 10 seconds).
seleCting the Cassette
Box 4
V 3
T/C-FM
– – –
Bx 1A
C5-12,S3-24
TWIN-SAT
C07
Böx 4
C5-12,S3-24
TWIN-SAT
C07
Box 5
..............
..............
..............
Box …
………
……
……
 • Selectthe cassette you want to program (e.g. Box 4) by repeatedly pressing
the button if necessary.
—> The display shows e.g. the menu "Box 4 T/C-FM":
"Box 4" stands for slot 4,
" T/C-FM " type of cassette
"V 3" software version of the cassette
 • Pressthe button.
—> The " Input parameters " – "INPUT" main menu is activated .

- 16 - HDMC 1000 FM
inPut Par a meters
 Inthismenuyouselecttheinput,forwhichyouwouldliketosettheinputpa-
rameters in the submenus.
Bx 4
TunerA
INPUT
OK =>
—> The indication "OK" serve for information:
OK - input signal is present at tuner A.
 • Usethe buttons to select the input ( " Tuner A " / " Tuner B "/ "ASI"),
for which you would like to set the input parameters.
—> There are no input parameter settings for the ASI input.Select"ASI",
in order to check whether a ASI input signal is present ("OK" is
displayed).
—> To skip the settings of the input parameters press the but-
ton. The "Delete programme locations" – "SERVICES" main menu is
activated (page 20).
 • Pressthe button.
—> The "Kind of modulation" – "INPUT" submenu is activated.
kind of modul ation
Bx 4A/B
COFDM 8MHz
INPUT
 • Using the buttons select the corresponding kind of modulation of the
transponder(COFDM7MHz,COFDM8MHz,QAM16…QAM256).

- 17 - HDMC 1000 FM
symbol rate
 If"QAM…"modulationisselected,thesettingforthesymbolrateappearsat
the right side.
Bx 4A/B
QAM256
INPUT
6900
 • Usethe buttons to position the cursor under the digit to be set for the
symbol rate then use to set the corresponding symbol rate.
 • Pressthe button.
—> The menu "Input channel / Input frequency" – "INPUT" is activated.
inPut Channel / inPut frequenCy
In this menu you have to set the corresponding input channel / input frequency
for the transponder to be received.
Bx 4A/B
C68 850.00
INPUT
OK
 • Usethe buttons to position the cursor under the digit to be set for
the input channel / input frequency then use to set the desired input
channel / input frequency.
—> OncetheHFreceiverhassynchronisedtotheinputsignal,"OK"is
displayed.
—> If"––"appearsinthesecondlineofthedisplay,thereisnoinput
signal present. Check the configuration of the antenna system and
the head-end station as well as the preceding settings of the cas-
sette.
 • Pressthe button.
—> Using a CA-Modul, submenu" CA settings " – "CA-MENU" is acti-
vated.
—> Not using a CA-Modul you will be r eturned to the "Input parameter"
– "INPUT" main menu (page 16).

- 18 - HDMC 1000 FM
oPeration with aCa module
 Inordertodescramblescrambledchannels,acorrespondingCAmoduleis
needed.
Pid monitoring
Ca module
In this menu you can switch off the PID monitoring and configuring the CA
module (dependent on the CA module).
Bx 4A
PID Check on
CA-MENU
=>
PID monitoring
By default the PID monitoring is switched on.
If particular PIDs are not descrambled the CI module is reset. Additionally
dropouts may occur if several stations are descrambled. To prevent this the PID
monitoring can be switched off.
Bx 4A
PID Check on
CA-MENU
=>
 • Usethe buttons to switch "off" or "on" the PID monitoring.
Configuring the CA module
 • Usethe button to activate the menu of the CA module.
The menu varies according to which CA module you are using. For this rea-
son,pleaserefertotheoperatingmanualofyourparticularCAmodule.The
relevant information is shown in the display of the head-end station. This may
appear as a fixed display or as scrolling text according to display capabilities.
Bx 4A 01/05
Information *)
MENU
Bx 4A
PID Check on
CA-MENU
=>
▶
▶

- 19 - HDMC 1000 FM
—> The display shows e.g.: Bx 4 01/05 MENU
Information
Meaning of the indicators:
"Bx 4" Slot 4
" 01/05 " The first of five menu items is activated.
" MENU " The menu of the CA module is activated.
For the explanation of further details please use the operating instructions of
the CA module used.
 • Usethe buttons to activate the menu desired.
 • Pressthe button to activate the menu.
 • Usethe buttons to select the function desired.
 • TosettheCAmoduleusethe and buttons.
 • Allsettingsaresavedbypressingthe button.
—> You will be returned to the "PID monitoring" – "CA" main menu.
—> By pressing the button you can cancel the settings in the
menu of the CA module and are returned to the "PID monitoring" –
"CA" main menu.
 • Pressthe button.
—> You will be r eturned to the "Input parameter" – "INPUT" main menu
(page 16).
 • Pressthe button.
—> The menu "Delete programme locations" – "SERVICES" is activated.

- 20 - HDMC 1000 FM
delete Programme loCations
In this menu you can delete the programme locations preset in the factory resp.
"old" programme locations (e.g. if the input parameter setting was changed).
Bx 4
FM =>
SERVICES
CLEAR ALL
 • Deletetheprogrammelocationsusingthe button.
—> Allprogrammelocationsaredeleted,thestoredFMfrequencieswill
be remain.
 Aslongasnoradiostationisassignedtoaprogrammelocation,
the transmitter is switched off.
—> A "Factory Reset" resets to the programme locations preset in the
factory.
 • Pressthe button.
—> The "Output parameters" – "FM 01" menu is activated.
