Guardian Telecom ACR-11-V Setup guide

Ph: 403.258.3100 \ email:[email protected]om \ www.guardiantelecom.com
VoIP Handset Telephones
Setup & Configuration
P007402 Rev H 171110 11/14/2017 11:32 AM

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 2
VoIP Setup & Configuration P007402 Rev. H (applicable to firmware V3.0.0 and higher)
COPYRIGHT NOTICE:
© 2017, Guardian Telecom, ALL RIGHTS RESERVED.
This manual and related material is the copyrighted property of Guardian Telecom No part of this manual or related materials
may be reproduced or transmitted, in any form or by any means (except for internal use by licensed customers), without prior
express written permission of Guardian Telecom This manual, and the products, software, firmware, and/or hardware
described in this manual are the property of Guardian Telecom provided under the terms of an agreement between Guardian
Telecom and the recipient of this manual, and their use is subject to that agreement and its terms.
DISCLAIMER: Except as expressly and specifically stated in a written agreement executed by Guardian Telecom, Guardian
Telecom makes no representation or warranty, express or implied, including any warranty or merchantability or fitness for any
purpose, with respect to this manual or the products, software, firmware, and/or hardware described herein, and Guardian
Telecom assumes no liability for damages or claims resulting from any use of this manual or such products, software,
firmware, and/or hardware. Guardian Telecom reserves the right to make changes, without notice, to this manual and to any
such product, software, firmware, and/or hardware.
OPEN SOURCE STATEMENT: Certain software components included in Guardian products are subject to the GNU General
Public License (GPL) and Lesser GNU General Public License (LGPL) “open source" or “free software" licenses. Some of this
Open Source Software may be owned by third parties. Open Source Software is not subject to the terms and conditions of the
Guardian COPYRIGHT NOTICE or software licenses. Your right to copy, modify, and distribute any Open Source Software is
determined by the terms of the GPL, LGPL, or third party, according to who licenses that software.
Software or firmware provided by Guardian that is unrelated to Open Source Software is copyrighted by Guardian, subject to
the terms of Guardian licenses, and may not be copied, modified, reverse-engineered, or otherwise altered without explicit
written permission from Guardian Telecom
TRADEMARK NOTICE: Guardian Telecom and the Guardian Telecom logos are trademarks of Guardian Telecom Other
product names, trademarks, and service marks may be the trademarks or registered trademarks of their respective owners.
Toll-free 1-800-363-8010
Phone [phone]
Fax. [phone]
www.guardiantelecom.com
E-mail: [email protected]

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 3
IMPORTANT Installation Step
It is important to register this VoIP product with Guardian Telecom to ensure it has the
most current version of software and to receive notification of software updates.
Registering Your VoIP Product
To register your VoIP product send an email to [e-mail].
Be sure to include “Guardian VoIP Registration" in the subject field of your email.
Include the following information:
Company Name of End User (Req'd)
Address of End User (Optional)
Device Model (Req'd)
Serial Number (Req'd) - Found on the Exterior Label
Date of purchase (Req'd)
Name of Supplier (Req'd)
Prime Contact name and e-mail (Req'd)
Secondary Contact name and e-mail (Optional)
Phone Info: (Optional)
It is very important that we receive e-mail contact information of the person responsible
for maintaining the installed Guardian Equipment, in order to ensure optimum
performance of the device.
Contact information will remain confidential and will not be used for third-party
marketing purposes.

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 4
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Install in accordance with the manufacturer's instructions.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
7. Only use attachments/accessories specified by the manufacturer.
8. Refer all servicing to qualified service personnel.
9. Prior to installation, consult local building and electrical code requirements.

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 5
Table of Contents
1. Typical System Installation.........................................................................................7
2. Operation....................................................................................................................7
3. Supported Protocols...................................................................................................7
4. Supported SIP Servers...............................................................................................7
5. Features.....................................................................................................................8
6. Models........................................................................................................................8
7. Getting Started .........................................................................................................10
8. RESET Switch..........................................................................................................10
9. Configure the Telephone Parameters.......................................................................10
9.1. Telephone Web Page Navigation..................................................................11
9.2. Log in to the Configuration Home Page........................................................12
9.3. Configure the Device Parameters.................................................................14
9.4. Configure the Network Parameters...............................................................17
9.5. Configure the SIP Parameters......................................................................19
9.6. Configure the Audio Parameters...................................................................23
9.6.1. User-created Audio Files......................................................................25
9.7. Configure the Event Parameters...................................................................27
9.8. Configure the Autoprovisioning Parameters..................................................31
9.9. Updating Firmware........................................................................................33
9.9.1. Reboot the Telephone..........................................................................33
10. Setting up a TFTP Server.........................................................................................34
10.1. In a LINUX Environment ...............................................................................34
10.2.In a Windows Environment ...........................................................................34
11. Frequently Asked Questions.....................................................................................35
12. Product Specifications..............................................................................................37
13. Appendix A Time Zone Settings...............................................................................38
Figures
Figure 1 - Typical Installation..............................................................................................7
Figure 2 - Startup Screen..................................................................................................10
Figure 3 - Home Page.......................................................................................................12
Figure 4 - Device Configuration Page...............................................................................14
Figure 5 - Network Configuration Page.............................................................................17
Figure 6 - SIP Configuration Page ....................................................................................19
Figure 7 - Audio Configuration Page.................................................................................23
Figure 8 - Audacity 1.........................................................................................................25
Figure 9 - Audacity 2.........................................................................................................25
Figure 10 - WAV (Microsoft) signed 16 bit PCM................................................................26
Figure 11 - Event Configuration Page...............................................................................27
Figure 12 - Autoprovisioning Configuration Page..............................................................31
Figure 13 - Update Firmware Page...................................................................................33

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 6
Tables
Table 1 - Factory Default Settings.....................................................................................10
Table 2 - Telephone Web Page Navigation.......................................................................11
Table 3 - Home Page Overview........................................................................................13
Table 4 - Device Configuration Parameters ......................................................................16
Table 5 - Network Configuration Parameters....................................................................18
Table 6 - SIP Configuration Parameters............................................................................22
Table 7 - Audio Configuration Parameters........................................................................24
Table 8 - Event Configuration............................................................................................30
Table 9 - Autoprovisioning Configuration Parameters.......................................................32
Table 10 - Firmware Upgrade Parameters........................................................................33
Acronyms
DHCP Server
Dynamic Host Configuration Protocol
DHCPD
Dynamic Host Configuration Protocol Daemon
DTMF
Dual-tone Multi-frequency
HTTP
Hypertext Transfer Protocol
IP Address
Internet Protocol Address
LAN
Local Area Network
LINUX
Unix-like computer operating system
MAC Address
Media Access Control address
PBX
Private Branch Exchange
PC
Personal Computer
PCM
Pulse-Code Modulation
PCMA
Paired Carrier Multiple Access
PCMU
Pulse Code Modulation mu-law
PoE
Power over Ethernet
POST
Power On Self Test
RIFF
A short, repeated musical phrase
RTP
Real-time Transport Protocol
RTP Port
Real-time Transport Protocol port
AVP
Audio Video Profile
SIP
Session Initiation Protocol
TFTP
Trivial File Transfer Protocol
URL
Uniform Resource Locator
VoIP
Voice Over Internet Protocol
WAV
Waveform Audio File Format
WAVE
Waveform Audio File Format
XML File
Extensible Markup Language

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 7
1. Typical System Installation
The Voice-over-IP (VoIP) Telephone is a Power-over-Ethernet (PoE 802.3af) and Voice-over-IP (VoIP) two-way
communications device that easily connects into existing local area networks (LANs) with a single cable connection. The
telephone is compatible with most SIP-based IP PBX servers that comply with SIP RFC 3261.
Figure 1 illustrates how VoIP Telephones can be installed as part of a VoIP phone system.
Figure 1 - Typical Installation
2. Operation
Once your VoIP Telephone has been properly installed and energized, operation is identical to most other single line
telephones.
3. Supported Protocols
The VoIP Telephone with Keypad supports:
●SIP (Session Initiation Protocol)
●HTTP Web-based configuration
Provides an intuitive user interface for easy system configuration and verification of a VoIP Telephone.
●DHCP Client
Dynamically assigns IP addresses in addition to the option to use static addressing.
●TFTP Client
Facilitates hosting for the Autoprovisioning configuration file.
●RTP
Facilitates autoprovisioning configuration values on boot
●Audio Encodings
PCMU (G.711 µ -law)
PCMA (G.711 A-law)
G.722.1 (SIREN 7)
G.722.2 (ANR-WB)
Packet Time 20 ms
4. Supported SIP Servers
As a SIP device, this product will operate with most IP PBX servers. Contact Guardian Sales to determine the
interoperability of any server or visit the Guardian Website to view the Interoperability Guide.

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 8
5. Features
Standard Features on All Models
•PoE 802.3af enabled (Power-over-Ethernet) or alternate power source.
•Control Relay – network configurable auxiliary relay.
•Compatible with most SIP-based IP-PBX servers that comply with SIP RFC 3261.
•Network web management.
•Guardian Discovery Utility makes it easy to detect, locate and launch the web based configuration screens.
•Product self diagnostic testing available through web interface.
•Network adjustable volume and microphone sensitivity.
•Network downloadable firmware.
•Remote programming provides network management from a central location.
•Night ringer mode.
6. Models
Standard Industrial VoIP Telephones
Model
Part No.
Description
ACR-11-V
P5434
Aluminum Cast Ringdown VoIP Telephone with Coil Cord
ACR-41-V
P5435
Aluminum Cast Ringdown VoIP Telephone with Armored Cord
ACT-30-V
P5432
Aluminum Cast Keypad VoIP Telephone with Coil Cord
ACT-40-V
P5433
Aluminum Cast Keypad VoIP Telephone with Armored Cord
CIR-41-V
P6967
Correctional Institute Ringdown Telephone with Armored Cord
CIT-40-V
P6966
Correctional Institute Keypad Telephone with Armored Cord
DTR-51-V
P3042
Desktop Ringdown VoIP Telephone with Coil Cord
DTR-61-V
P3043
Desktop Ringdown VoIP Telephone with Armored Cord
DTT-50-V
P3040
Desk Top Keypad VoIP Telephone with Coil Cord
DTT-60-V
P3041
Desk Top Keypad VoIP Telephone with Armored Cord
MFR-11-V P5441
Telephone Panel Insert for locking or non-locking door enclosure without internal ribs
on right side. Volume control handset and Coil cord.
MFR-11N-V P5443
Telephone Panel Insert for earlier Northern Telecom, locking door enclosure with
internal ribs on right side. Volume control handset and Coil cord.
MFR-41-V P5440
Telephone Panel Insert for locking or non-locking door enclosure without internal ribs
on right side. Volume control handset and armored cord.
MFT-30-V P5438
Telephone Panel Insert for locking or non-locking door enclosure without internal ribs
on right side. Metal keypad, volume control handset and Coil cord.
MFT-30N-V P5442
Telephone Panel Insert for earlier Northern Telecom, locking door enclosure with
internal ribs on right side. Metal keypad, volume control handset and Coil cord.
MFT-40-V P5439
Telephone Panel Insert for locking or non-locking door enclosure without internal ribs
on right side. Metal keypad, volume control handset and armored cord.
SCR-11-V
P6087
Steel Compact Ringdown VoIP Telephone with Coil Cord
SCR-41-V
P6088
Steel Compact Ringdown VoIP Telephone with Armored Cord
SCT-10-V
P6083
Steel Compact Keypad VoIP Telephone with Coil Cord
SCT-30-V
P6085
Steel Compact Keypad VoIP Telephone with Coil Cord
SCT-40-V
P6086
Steel Compact Keypad VoIP Telephone with Armored Cord
WRR-11-V
P6304
Weather Resistant Ringdown VoIP Telephone with Coil Cord
WRR-41-V
P6305
Weather Resistant Ringdown VoIP Telephone with Armored Cord
WRT-10-V
P6300
Weather Resistant Keypad VoIP Telephone with Coil Cord
WRT-30-V
P6302
Weather Resistant Keypad VoIP Telephone with Coil Cord
WRT-40-V
P6303
Weather Resistant Keypad VoIP Telephone with Armored Cord
WTR-11-V
P5310
Weather Tight Ringdown VoIP Telephone with Coil Cord
WTR-41-V
P5311
Weather Tight Ringdown VoIP Telephone with Armored Cord
WTT-30-V
P5308
Weather Tight Keypad VoIP Telephone with Coil Cord
WTT-40-V
P5309
Weather Tight Keypad VoIP Telephone with Armored Cord

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 9
Hazardous Area VoIP Telephones
Model
Part No.
Description
DTR-51-V-H
P3048
Hazardous Area Desktop Ringdown VoIP Telephone with Coil Cord
DTR-61-V-H
P3049
Hazardous Area Desktop Ringdown VoIP Telephone with Armored Cord
DTT-50-V-H
P3046
Hazardous Area Desk Top Keypad VoIP Telephone with Coil Cord
DTT-60-V-H
P3047
Hazardous Area Desk Top Keypad VoIP Telephone with Armored Cord
SCR-11-V-H
P6091
Hazardous Area Steel Compact Ringdown VoIP Telephone with Coil Cord
SCR-41-V-H
P6092
Hazardous Area Steel Compact Ringdown VoIP Telephone with Armored Cord
SCT-10-V-H
P6084
Hazardous Area Steel Compact Keypad VoIP Telephone with Coil Cord
SCT-30-V-H
P6089
Hazardous Area Steel Compact Keypad VoIP Telephone with Coil Cord
SCT-40-V-H
P6090
Hazardous Area Steel Compact Keypad VoIP Telephone with Armored Cord
WRR-11-V-H
P6308
Hazardous Area Weather Resistant Ringdown VoIP Telephone with Coil Cord
WRR-41-V-H
P6309
Hazardous Area Weather Resistant Ringdown VoIP Telephone with Armored Cord
WRT-10-V-H
P6301
Hazardous Area Weather Resistant Keypad VoIP Telephone with Coil Cord
WRT-30-V-H
P6306
Hazardous Area Weather Resistant Keypad VoIP Telephone with Coil Cord
WRT-40-V-H
P6307
Hazardous Area Weather Resistant Keypad VoIP Telephone with Armored Cord
WTR-11-V-H
P5314
Hazardous Area Weather Tight Ringdown VoIP Telephone with Coil Cord
WTR-41-V-H
P5315
Hazardous Area Weather Tight Ringdown VoIP Telephone with Armored Cord
WTT-30-V-H
P5312
Hazardous Area Weather Tight Keypad VoIP Telephone with Coil Cord
WTT-40-V-H
P5313
Hazardous Area Weather Tight Keypad VoIP Telephone with Armored Cord

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 10
7. Getting Started
The Installation manual for the telephone provides information on installing and connecting the device to the server.
This manual describes the steps required to customize the telephone to suit the individual's preferences.
The Discovery Utility is available on Guardian’s website at https://www.guardiantelecom.com/resources/voip-support/ and
needs to be installed manually by copying the executable file to a local drive.
To access a VoIP phone for programming:
•Install the Guardian Discovery Utility onto the network server or SIP server.
•Start the Utility by double clicking the icon.
•Click on “Refresh List".
•Click on the device to be programmed to highlight it.
•Click on “Launch Browser".
Figure 2 - Startup Screen
8. RESET Switch
The RESET switch is used to get the IP address of the device or to reset to factory defaults.
• To get the IP address of the device press and release the RESET switch within a 5 second window and it will
speak the IP address through the handset earpiece.
• To reset to factory defaults press and hold the RESET switch for more than 10 seconds until it indicates that it is
restoring defaults and rebooting the board.
9. Configure the Telephone Parameters
To configure the Telephone online use a standard web browser.
All Telephones are initially configured with the following default IP settings:
Parameter Factory Default Setting
IP Addressing DHCP
IP Addressa10.10.10.10
Web Access Username admin
Web Access Password admin
Subnet Maska255.0.0.0
Default Gatewaya10.0.0.1
Table 1 - Factory Default Settings
a. Default if there is not a DHCP server present.
When configuring more than one Telephone attach the Telephones to the network and configure one at a time to avoid IP
address conflicts.

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 11
9.1. Telephone Web Page Navigation
Table 2Table 2 shows the navigation buttons that you will see on every Telephone web page.
Web Page Item Description
Link to the Home page.
Link to the Device Configuration page.
Link to the Networking page.
Link to the SIP Configuration page.
Link to the Audio Configuration page.
Link to the Event Configuration page.
Link to the Autoprovisioning Configuration page.
Link to the Update Firmware page.
Table 2 - Telephone Web Page Navigation

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 12
9.2. Log in to the Configuration Home Page
1. Open your browser to the Telephone's IP address. If you do not know the IP address, you can use the “Discovery
Utility" to detect all VoIP devices on the network. When opened the Discovery Utility scans the network for VoIP devices,
specifically Guardian VoIP devices.Individually select the device and launch the browser. Another method to obtain the IP
address is to press the RESET switch for approximately three to five seconds. The phone will speak the address through
the handset earpiece. The physical location of a telephone can be determined by comparing the MAC Address, IP
Address or Serial Number shown on the Discovery Utility screen with the information on the unit.
Note:If the network does not have access to a DHCP server, the device will default to an IP address of
10.10.10.10.
Note:Make sure that the PC is on the same IP network as the Telephone.
2. When prompted, use the following default Web Access Username and Web Access Password to access the Home
Page (See Figure 3).
Web Access Username: admin
Web Access Password: admin (Iower case)
3. On the Home Page, review the setup details and navigation buttons described in Table 3.
Note: The Screen Captures shown are only examples; refer to the tables for definitions.
Figure 3 - Home Page

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 13
Web Page Item Description
Device Settings
Device Name: Change the device name as required.
Change Username: Type in this field to change the username.
Change Password: Type in this field to change the password.
Re-enter Password: Type the password again in this field to confirm the new password.
Current Settings
Serial Number: Shows the device serial number.
Mac Address: Shows the device MAC address.
Firmware Version: Shows the current firmware version.
IP Addressing: Shows the current IP addressing setting (DHCP or Static).
IP Address: Shows the current IP address.
Subnet Mask: Shows the current subnet mask address.
Default Gateway: Shows the current default gateway address.
DNS Server 1: Shows the current DNS Server 1 address.
DNS Server 2: Shows the current DNS Server 2 address.
Speaker Volume: Shows the current speaker volume level.
Handset Volume: Shows the current handset receiver volume level.
Microphone Gain: Shows the current hands free microphone gain level.
Handset Gain: Shows the current handset microphone gain level.
SIP Mode is: Shows the current SIP Mode status.
Event Reporting is: Shows the current Event Reporting status.
Nightringer is: Ringtone broadcast when enabled and extension is called.
Primary SIP Server: Primary SIP Server
Backup Server 1: Redundant SIP Server “1"
Backup Server 2: Redundant SIP Server “2"
Import/Export Settings
Choose File Select a configuration file to import to the device.
Import Configuration
Click to import the selected configuration file. The configuration file allows the
user to set up a custom default configuration for the VoIP products and import
into multiple devices to save time.
Export Configuration
Click to export the current configuration to a file. The export file can then be
used to confirm, share or modify and re-import back into the VoIP devices.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the device.
Table 3 - Home Page Overview

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 14
9.3. Configure the Device Parameters
1. Click the Device Configuration button to open the Device Configuration page. (See Figure 4).
Figure 4 - Device Configuration Page
2. On the Device Configuration page, you may enter values for the parameters indicated in Table 4.
3. After changing the parameters, click the Save button followed by Reboot to complete.

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 15
Web Page Item Description
Volume Settings
The volume settings describe the volume set on reboot. The user can change the
volume by using the up and down arrows, but this change is temporary and the
volume will be reset when the device is rebooted.
Hands Free Speaker Volume:
The speaker volume sets the initial volume of the device on boot. Valid values are 0-9.
Test the speaker volume using the ‘Test Audio' button below. Saving changes to the
speaker volume will take effect immediately (it does not require a restart).
Hands Free Microphone Gain:
The microphone gain sets the initial input gain of the on board microphone. Valid
values are 0-9. Test the speaker volume using the ‘Test Microphone' button below.
Saving changes to the speaker volume will take effect immediately (it does not require
a restart).
Handset Volume:
The handset volume sets the initial volume of the handset on boot. Valid values are 0-
9. Saving changes to the handset volume will take effect immediately (it does not
require a restart).
Handset Gain:
The range of the handset gain is limited by the hardware and there are only three
volume levels available (low, medium, and high).
Ringer Volume
The ringing volume which is heard on the speaker of the phone. Valid values are 0-9.
This setting is for units that use the speaker as a ringer. It will not affect units with a
fixed buzzer.
Relay Settings
Activate Relay with DTMF Code:
When this option is enabled the device will activate the relay when it receives a DTMF
code (rfc2833).
DTMF Activation Code: This 25 character field can be used a set a DTMF code used to activate the relay.
DTMF Activation Duration (in
seconds):
When the relay is activated with a DTMF code, it will remain active for this duration in
seconds. Valid values are 1-9.
NOTE: A DTMF activation of 0will toggle the relay indefinitely or until the activation
code is sent again.
Activate Relay During Ring:
When this option is enabled the relay will activate when the device has received a call
and is playing a ringtone.
Activate Relay During Night Ring:
When this option is enabled the relay will activate when the device has received a call
to the night ring extension.
Pulse Relay when Ringing:
When a “ring" is present the relay will pulse with a cadence of 2 seconds on, 3
seconds off.
Pulse Buzzer when Ringing:
When a “ring" is present the internal ringer will pulse with a cadence of 2 seconds on,
3 seconds off.
Activate Relay While Call Active:
When this option is enabled the relay will activate when a call is established with
another SIP device. It will remain active for the duration of the call.
Activate Relay While Off Hook When this option is enabled the relay closes while the handset is off hook.
NTP Settings
NTP Server
Use this field to set the address (in IPv4 dotted decimal notation or as a canonical
name) for the NTP Server. This field can accept canonical names of up to 64
characters in length.
Posix Timezone String
Allows the device to access a local network based time server or a global internet
server to allow the device to auto set/update the device clock. See Appendix A.
Set Time with external NTP server
on boot
When selected, the time is set with an external the NTP server when the device
restarts.
Periodically update with time server
When selected, the time is periodically updated with the NTP server at the configured
interval below.
Time update period (in hours)
The time interval after which the device will contact the NTP server to update the time.
Enter up to 4 digits.
Set time from NTP Server Clicking on this button will immediately set the time.

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 16
Current Time
Current Time in 24 hour format
(HHMMSS):
Allows you to input the current time manually. (6 character limit)
Current Date (MMDDYY): Allows you to input the current date manually. (6 character limit)
Set Clock Clicking on this button will immediately set the clock format.
Miscellaneous Settings
Disable HTTPS (NOT
recommended):
Disables the encrypted connection to the webpage. Depending on network security
enable / disable as required.
Auto-Answer Incoming Calls:
When this option is enabled the device will automatically answer incoming calls. When
the handset is on hook, the call will be established using the hands free speaker and
microphone.
Backlight On:This option sets the normal state of the backlight after the device has booted.
This button will play an audio test message and can be used to test the volume level.
When this button is pressed the device will record 3 seconds of audio, beep, and then
play back the recorded audio. This can be used to test the microphone gain level.
This button will activate the relay for the DTMF activation Duration (in seconds).
When this button is toggled, it will put the device into button test mode. In this mode,
the handset or hands free speaker will play an audio file when a button is pressed on
the device. For normal keypad input (keys 0-9) it will speak the associated file from the
audio configuration page. For the other keypad keys, (*, #, any other function keys) it
will play a DTMF tone while the button is depressed. The button press mode will time
out after 60 seconds.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the device.
Table 4 - Device Configuration Parameters

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 17
9.4. Configure the Network Parameters
1. Click the Networking button to open the Network Configuration page (See Figure 5).
Figure 5 - Network Configuration Page
2. On the Network Configuration page, enter values for the parameters indicated in Table 5.
3. After changing the parameters, click Save to store the settings before going to the other configuration pages. If no other
changes are required beyond this state, click Reboot to reset the device for other changes to take effect.
The new settings will not take effect if Reboot is clicked without saving first.
4. Connect the Telephone to the target network.
5. From a computer on the same network as the Telephone, open a browser with the new IP address of the Telephone.
Note: If changing from DHCP to STATIC Only: Once the reboot button has been selected, the webpage will show a
countdown timer. The timer will hit zero and will reset and continue with countdown. At this point the web page can be
shutdown and re-started. The web page will not automatically restart when switching from DHCP to STATIC.

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 18
Web Page Item Description
Stored Network Settings Shows the settings stored in non-volatile memory.
Addressing Mode:
Select either DHCP IP Addressing or Static Addressing by marking the
appropriate radio button. DHCP Addressing mode is enabled on default and the
device will attempt to resolve network addressing with the local DHCP server
upon boot. If DHCP Addressing fails, the device will revert to the last known IP
address or the factory default address if no prior DHCP lease was established.
See Table 1 for factory default settings. Be sure to click Save and Reboot to
store changes when configuring a Static address.
Hostname: This is the hostname provided by the DHCP server. See the DHCP/DNS server
documentation for more information. Enter up to 64 characters.
IP Address: The IPV4 static IP address in standard dotted decimal notation.
Subnet Mask: The IPV4 routing prefix in standard dotted decimal notation.
Default Gateway: This is the node to go to when an IP address does not match any routes in the
routing table. This requires standard quad-dotted decimal notation.
DNS Server 1:
DNS Server 2: The DNS server configuration is used to setup the primary and secondary name servers for the network. These use standard dotted decimal notation.
DHCP Timeout in seconds*:
*A value of –1 will retry
forever
Specify the desired time-out duration (in seconds) that the device will wait for a
response from the DHCP server before reverting back to the stored static IP
address. The stored static IP address may be the last known IP address or the
factory default address if no prior DHCP lease was established. Enter up to 8
characters. A value of -1 will retry forever.
VLAN Settings Shows the current VLAN settings.
VLAN ID (0-4095): Specify the IEEE 802.1Q VLAN ID number. Enter up to 4 digits. Note: The device supports 802.1Q VLAN tagging support. The switch port connected to
the device will need to be in “trunking mode” for the VLAN tags to propagate.
VLAN Priority (0-7): Specify the IEEE 802.1p VLAN priority level. Enter 1 digit. A value of 0 may
cause the VLAN ID tag to be ignored.
Current Network Settings Shows the current network settings.
IP Address: Shows the current Static IP address.
Subnet Mask: Shows the current Subnet Mask address.
Default Gateway: Shows the current Default Gateway address.
DNS Server 1: Shows the current DNS Server 1 address.
DNS Server 2: Shows the current DNS Server 2 address.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the device.
Table 5 - Network Configuration Parameters

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 19
9.5. Configure the SIP Parameters
1. Click SIP Config to open the SIP Configuration page (See Figure 6).
Note:Guardian VoIP telephones are compatible with most SIP servers.
Figure 6 - SIP Configuration Page
2. On the SIP Configuration page, enter values for the parameters indicated in Table 6.
3. After changing the parameters, click Save.

Guardian Telecom VoIP Telephones
Setup & Configuration
Page 20
Web Page Item Description
Enable SIP Operation: When this option is enabled, the device will initialize the SIP engine and try to register with a SIP server or listen for incoming SIP
connections.
SIP Settings
Register with a SIP Server:
When enabled, the device will attempt to register to the configured
SIP Server(s) on this page. To configure the device to send and
receive point-to-point SIP calls, enable SIP Operation and disable
Register with a SIP Server.
Use Cisco SRST: When enabled, the backup servers are handled according to Cisco SRST (Survivable Remote Site Telephony). It is required for use in
clustered Cisco Unified Communications Manager topologies.
Primary SIP Server:
Enter the SIP server address as an IPv4 address in dotted decimal
notation or a fully qualified domain name. This parameter also
becomes the host portion of the SIP-URI for the device's extension
on the primary SIP server. This field can accept entries of up to 255
characters in length.
Primary SIP User ID: Specify the SIP User ID for the Primary SIP Server. This parameter becomes the user portion of the SIP-URI for the device's extension
on the primary SIP server. Enter up to 64 alphanumeric characters.
Primary SIP Auth ID: Specify the Authenticate ID for the Primary SIP Server. This parameter is required for SIP registration authentication. Enter up to
64 alphanumeric characters.
Primary SIP Auth Password: Specify the Authenticate Password for the Primary SIP Server. This parameter is required for SIP registration authentication. Enter up to
64 alphanumeric characters.
Backup SIP Server 1:
Enter the backup SIP server address as an IPv4 address in dotted
decimal notation or a fully qualified domain name. This parameter
also becomes the host portion of the SIP-URI for the device's
extension on the backup SIP server. This field can accept entries of
up to 255 characters in length.
Backup SIP User ID 1:
Specify the SIP User ID for the first backup SIP Server. This
parameter becomes the user portion of the SIP-URI for the device's
extension on the first backup SIP server. Enter up to 64
alphanumeric characters.
Backup SIP Auth ID 1: Specify the Authenticate ID for the first backup SIP server. This parameter is required for SIP registration authentication. Enter up to
64 alphanumeric characters.
Backup SIP Auth Password 1: Specify the Authenticate Password for the first backup SIP server. This parameter is required for SIP registration authentication. Enter
up to 64 alphanumeric characters.
Backup SIP Server 2:
Enter a second backup SIP server address as an IPv4 address in
dotted decimal notation or a fully qualified domain name. This
parameter also becomes the host portion of the SIP-URI for the
device's extension on the second backup SIP server. This field can
accept entries of up to 255 characters in length.
Backup SIP User ID 2:
Specify the SIP User ID for the second backup SIP Server. This
parameter becomes the user portion of the SIP-URI for the device's
extension on the second backup SIP server. Enter up to 64
alphanumeric characters.
Backup SIP Auth ID 2: Specify the Authenticate ID for the second backup SIP server. This parameter is required for SIP registration authentication. Enter up to
64 alphanumeric characters.
