Guardline GL5000 User manual

USER’S MANUAL
Questions?
Call Customer Service at:
[phone], 7am - 3pm Pacific
Find useful installation videos and related products at:
www.GuardlineSecurity.com
© 2016 Guardline Security
UserManual_Page 1_v5_04.25.14_actual size.indd 1 4/25/2014 4:29:37 PM
Watch this product installation video at:
www.GuardlineSecurity.com
GL5000

B. Powering your Receiver and Sensor
Adapter Plug
Receiver
Zone #
Indicators
Low Sensor
Battery LED
1 2
2. Replace the cover
and secure the four
screws.
AA
AA
AA
AA
UserManual_Page 1_v5_04.25.14_actual size.indd 2 4/25/2014 4:29:37 PM
Thank you for purchasing a Guardline Driveway Alarm! This
driveway alarm has a quarter mile range and is great for multiple
applications, including: alerting you when visitors enter your
driveway, deterring trespassers and thieves from entering your
property or building, alerting you to wildlife on your land, for use in
drive-through’s to signal that a customer pulled in, and more!
If you have questions about your Guardline, our Seattle-based
customer service is available Mon-Fri, from 7am to 3pm Pacific
Time at [phone] or online at www.GuardlineSecurity.com
Sincerely,
The Guardline team
A. An Overview of your Guardline Driveway Alarm
1. Remove the screws from the four
corners of the sensor to access the battery
compartment. BE CAREFUL! The
screws are very small, don’t lose them.
Install four (4) AA batteries as indicated.
The sensor runs on four (4) AA batteries (not included) and operates wirelessly
at a maximum distance of a quarter mile (1,300 feet) from the receiver.
Sensor
AAAA
AAAA
AAAA
AAAA
Receiver
The main power source for the receiver is the included 12v/500mA AC/DC
power adapter. Simply plug the adapter into a wall outlet, then into the side of
your receiver, near Zone 1.
Alternatively, you can power the receiver with four
(4) AAA batteries. Just slide off the back cover of
the receiver in the direction of the arrow on the
cover (it should slide up towards Zone 1), then
install the batteries as shown.
Receiver power
indicator LED Receiver
Sensor
Your Guardline receiver will
flash on the corresponding zone
and chime whenever one of your
paired sensors is activated.
You can pair up to 16 sensors to
your receiver (4 per zone)
allowing you to receive alerts for
a near-unlimited number of areas.
Sensor “eye”
Sun shade

C. Pairing your Sensors with a Receiver
3 4
UserManual_Page 1_v5_04.25.14_actual size.indd 3 4/25/2014 4:29:38 PM
1. Press and hold the “Learn” button
on your receiver until zone 1 starts to
flash.
2. If pairing your sensor to zone 1,
you can skip this step and continue to
step 3. If pairing a zone other than
zone 1, press “Next” until the zone
you wish to pair your sensor with is
flashing. Each zone can be paired
with up to four (4) sensors.
3. Press “Melody” to choose the
melody you wish to play when the
sensor is triggered. There are a total
of 32 melodies to choose from.
Melody select sequence: Melody 1 
Melody 2 ... Melody 32 Melody 1
4. After you hear the melody you
want, activate the sensor you wish to
pair by slowly walking past or waving
your hand at least one foot from the
eye. The receiver will BEEP when
successfully paired. Once you hear
this beep exit Learn mode by holding
down the “Learn” button until all
zones stop flashing.
NOTE: If you accidentally activated your sensor before step 4 you will have to
reset your zone then repeat section C. See the “Helpful Tips” section on page 6
for directions on resetting your zone.
MAIN LED
AC Power On/
Receiver Battery
Low
Zone #
Indicators
Low Sensor
Battery LED
Battery Compartment
Relay
Cable
Learn/
Next
Melody/
Battery Check
Pause/Reset
Example of how to install sensor on a driveway post.
D. Installing your Sensor
It is recommended that the motion sensor be mounted at least 3 feet from
the ground on a sturdy, non-metal surface (i.e. a wall or stiff post) with
the “eye” pointed toward and slightly down at the target sensing area.
Your sensor(s) need to be paired with a receiver before your system will
function. Have your sensor and receiver nearby and ensure the sensor is
TURNED AWAY FROM YOU until step 4. Activating your sensor before
step 4 can result in your sensor being paired with the incorrect settings.
Follow the steps below to pair your sensor(s) and receiver.
7mm
drill bit
25mm
hole
1. Mark the mounting surface with a
pencil using the four mounting holes
on the sensor mount as a guide.
2. Recommended: Use an electric drill
with a 7mm drill bit to create 25mm
screws. This will help prevent stripping
of the screws.
To install your sensor(s), follow the instructions below. Tools you will
need for installation:
- a pencil
- a Phillips screwdriver
- electric drill & 7mm electric drill bit (recommended)

5 6
UserManual_Page 1_v5_04.25.14_actual size.indd 4 4/25/2014 4:29:38 PM
1. When one or more of the sensor batteries are low, the low-battery indicator
LED will blink every 5 seconds.
2. To check which sensor has low batteries, press and hold the “Batt. Chk” button
on the side of the receiver until the “Low Battery” LED lights up, then release.
When you release, zone 1 will be flashing and you are ready to check on battery
status of sensors in zone 1.
4. Press the “Next” button to advance to the next zone, then repeat step 3 to
check battery life. Repeat steps 3 & 4 for all zones, then press next until you
exit battery check mode.
3. Press and hold the “Batt. Chk” button, the zone LED will light up to show
which sensor(s) have low battery.
Low-battery indicator LED
E. Battery Check Procedures
In this example, Sensor 2, sensor
4 paired with zone 1 are low
battery
If no LED is lit up, all sensors
paired with this zone are good
Checking Zone
#1
Checking Zone #2
Battery Check
Entering battery
check mode
Helpful Tips
1. Press and hold “Learn” for 3 seconds to enter Learn Mode.
2.
3. Press and hold “Pause/Reset” for 3 seconds to unpair all the sensors in that
zone. The receiver will BEEP when the zone has been unpaired.
4.
Resetting your Zones
If you are experiencing interference, or you have mul-
tiple receivers and/or over 16 sensors, and they utilize
the same signal code, you will need to manually change
the code in one or more of your sensor units. To do this:
AA
AA
AA
AA
Hold Test Button

Changing your Chime
If you wish to change the melody of a sensor that is already paired, refer to and
repeat steps 1-4 in section C, Pairing your sensors with a Receiver.
If you completely relocate your sensors (for example, if you were to move to a new
home and reinstall your alarm system in a different arrangement, or have incorrectly
paired your sensor(s) and receiver), follow these steps to clear sensors from a
zone so you can then re-pair the sensors in a new arrangement.
If clearing Zone 1, skip this step. If resetting a zone other than Zone 1,
press “Next” to select which zone you wish to reset.
Repeat steps 2 and 3 to reset additional zones, or hold the “Learn” button for 3
seconds to exit Learn mode.
Remove one (1) battery from the sensor, then PRESS and
HOLD the test button. While holding the test button,
re-insert the battery. Continue holding the test button
until the sensor LED flashes five times. When the LED
flashes five times, a new signal code has been generated.
NOTE: The recoded sensor(s) will NEED TO BE RE-PAIRED with a
receiver. See Section D for instructions.

7 8
UserManual_Page 1_v5_04.25.14_actual size.indd 5 4/25/2014 4:29:38 PM
Trouble Shooting
Issue SolutionCause
Check that sensor has working
batteries that are installed
properly and receiver is
plugged in or has batteries and
is turned "On"
Make sure volume wheel is
turned up (turn towards 12V
port for max volume)
Follow instruction in section
C, "Pairing your Sensors with
a Receiver"
Reset all sensor dip switches to
factory settings (see section F)
Sensor and/or receiver not
powered on
Volume not turned up
Sensor not paired with
receiver
Incorrect sensor settings
No alarms?
Reset all zones on your
receiver and re-pair your
sensor(s). See the "Helpful
Tips" section for reset
instructions.
Move sensor to new location
at least 5 feet from metal
gates, poles or structures.
Don't use receiver in building
with metal siding or stucco.
Move sensor closer to your
receiver and/or remove any
physical objects between
sensor and receiver. If using
in a heavily wooded area, your
effective range will be
Reset all sensor dip switches to
factory settings (see section F)
Replace your sensor batteries
and re-pair your sensor to your
receiver. See section "C" for
re-pairing
Sensor not paired properly
Signal Interference
End of functional range
Incorrect sensor settings
Low Batteries
Inconsistent alarms?
Move sensor and/or receiver
away from electrical
transformers or other cause of
interference
Take sensor inside, remove
backplate and let air dry for 24
hours. Ensure back plate is
securely screwed on and keep
protected from the elements
when re-installing
Sensor or Receiver are
receiving electrical
interference
Moisture inside sensor
False alarms?
Can't change
melody/wrong
melody?
Issue SolutionCause
Sensor paired with different
melody
Must follow steps in section C,
"Pairing your Sensors with a
Receiver" to change your
melody

9 10
UserManual_Page 1_v5_04.25.14_actual size.indd 6 4/25/2014 4:29:38 PM
NOTE: Your unit has been set by the manufacturer to the most com
monly used settings. It is strongly suggested that the system be used
first under its factory settings before adjusting the dip switches. If you
are connecting an external device to the receiver, consult with the ex
ternal device’s user manual for installation details and parameters.
The receiver battery cover must be removed in order to access the dip
switches and output terminals.
to move the switches to your preferred setting.
G. .. Advanced Settings: Receiver Settings & External Devices
Pause Time Setting
30 min 60 min
C
Pause Mode
EU US
D
Delay Time Setting
1 sec
5 sec
}
}
10 sec
60 sec
}
}
NO/NC Control
]
]
B
F
12V Out
+ -
NC
COM
NO
A
]
OffOn
12V Output Control
E
1
2
3
4
D. This determines what speed of objects can be picked up by your sensor. We
recommend leaving this at factory default for best results.
E. The Test Button can be pressed during setup to test that the sensor has been
correctly paired with its receiver. The Test Button is also used to recode the sensor
in cases where more than one receiver is being used (see Helpful Tips on page 6).
C. After detecting motion, the sensor can “sleep” for either 7 or 30 seconds,
allowing an object to pass through the field of vision without setting the alarm off
again.
Use a pen or other hard, narrow object to
F. Advanced Settings: Sensor Adjustments
3. Use the guide below to set the sensor according to your preferences
using a pen or other hard, narrow object to move the black switch.
1. Remove the sun shade
and the four screws
holding the sensor cover
in place.
2. Inside the sensor unit is a
battery compartment
and rows of switches which
control the sensor settings.
Test
Button**
Distance
(Sensitivity)
Speed Sensitivity
3-6.5 ft/sec.
(faster movement)
(45~90cm /sec.)
(0.9 ~2m/sec.)
(slower movement)
39ft 26ft 23ft 13ft
Night Mode
ON (night/dark)
OFF (day or night)
Interval “Sleep” Timer
7 sec.
30 sec.
(12m)(8m)(7m) (4m)
1.5-3 ft /sec.
Several switches are inside the battery compartment which regulates
various sensor functions. Follow this guide to adjust your unit to the
desired setting(s).
NOTE: Your unit is already set by the manufacturer to the most
commonly used settings. Only make adjustments to these settings if
the unit does not work as desired under factory settings.
A.
E. D.
C.
B.
A. Adjust these switches to change the distance that your sensor will “see”. Use a
shorter distance for shorter driveways or to avoid picking up objects past your
driveway
B. Turn this ON if you only want your sensor to work during low light dark
settings. In the OFF position your sensor will work in day and night settings.

11
H. Manufacturer Default Settings
Listed below are the factory settings for your driveway alarm system.
NOTE: Your system has been preset by the manufacturer to the most com-
monly used settings. It is recommended that users test the unit(s) under the
default settings before making adjustments. If you have questions about
these settings, please contact Customer Service.
Receiver Sensor
Pause Time 30 minutes Interval “Sleep”
Timer 7 seconds
Pause Mode EU OFF
Delay T ime 1 second Filter 3-6.5 (0.9~2m )/sec
12V Ou tputs all OF F Distance
Sensitivity 39 (12m)
NO /NC C ontrol all OF F
Why Change Settings?
Though your Guardline Driveway Alarm System is factory set to suit the most com-
mon user, sometimes your needs may require more complicated settings. For in-
stance, you may need to turn On the night mode to enable motion detection
if your sensing area is dark or dimly lit, or if your sensing area is only a sidewalk-width
away and not across the road, you may want to change Distance Sensitivity to just 13
feet (4m).
UserManual_v7_11.28.15_actual size_FI NAL.indd 1
Night Mode
12
A. Pause Time Setting:
B. Pause Mode: In EU Mode, the receiver will automatically turn on after the
pause has timed out. In US Mode, the receiver will BEEP when the pause time is
over, but will NOT automatically turn on.
Halts receiver operation for an extended time of either
30 or 60 minutes. Press and hold the “Pause/Reset” button on the side of the
receiver for 3 seconds to enter Pause mode.
E. 12V Output Control: Assigns a zone to the 12V Output terminal (“D”) for ex -
ternally wired devices.
F. NO/NC Control: Selects which zone will connect with the NO/NC terminals.
D. Output Terminal:
External devices, such as gate openers, door releases, or external speakers, can be
wired to the receiver using the 12V out relay.
• 12V Out: This terminal outputs 12V/300mA when the selected zone has been
triggered in cooperation with “E” (12V Output Control). This function is dis
abled when running on batteries. Select which zone relays to this output by
sliding ONE of the dip switches for zones 1, 2, 3, or 4 to the “On” position.
• NO (Normal Open): Outputs to a closed circuit when the selected zone has
been triggered.
• COM: Neutral/Grounding terminal.
• NC (Normal Closed): Outputs to an open circuit when the selected zone has
been triggered.
• The NO and NC outputs cooperate with “F” (NO/NC Control). You can select
which zone relays to these outputs by sliding ONE of the dip switches 1, 2, 3,
or 4 to the “On” position.
C. Delay Time Setting: This is primarily used in setups with multiple sensors per
zone. This setting adjusts how many seconds must pass before the receiver is able
to chime again. Ex. If you have multiple sensors installed along your driveway,
you may want to change this setting to 60 seconds so you are only notified once
when the first sensor goes off and not by any subsequent alerts for up to 60
seconds.
