Pandora Camper Mini User manual

Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC
Pandora would like to thank you for
choosing our service-security system
Pandora Camper Mini is a telemetric service-security system built for motorhomes with on-board
voltage of 12V. It is a complex engineering device, which includes unique and modern technological
software and hardware solutions.
When building the Pandora Camper Mini we were using the most up-to-date electronics from
world’s best manufacturers. The device is built using high-precision mounting and controling
machinery, thus we guarantee highest possible quality, reliability and stable technical characteristics
for the whole operation period.
The Pandora Camper Mini has a cryptographically strong authorization code with unique dialog
algorithm and individual encryption key on every device. It guarantees protection form electronic
hacking for the whole operation period.
The system is built for your convenience: it’s ergonomic, reliable, has the highest security and
service characteristics, 3 years unconditional warranty and free service and support. We are happy to
provide any support we can – feel free to use our online support.
! WARNING! ItIs stRoNGly AdvIsed to hAve pRofessIoNAl INstAllAtIoN of the system. ANy cAR electRoNIcs INstAlleR should be Able to
INstAll the system usING INstAllAtIoN scheme IN thIs mANuAl ANd the AlARm studIo softWARe. most feAtuRes ARe hIGhly depeNdeNt of
competeNt INstAllAtIoN. ouR systems ARe thoRouGhly tested foR quAlIty, so If AfeAtuRe fAIls to pRoduce expected Result, most lIkely the
pRoblem Is IN ImpRopeR INstAllAtIoN.
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in
temperatures outside -40 to +85° C range. All system components must be installed only in a car interior.
The base unit, remote control and radio tags fulfil with the IP40 category of protection against water.
Our web-site: pandorainfo.com
Customer support: [email protected]

3
2USER MANUALPANDORA CAMPER MINI
Table of contents
General information 4
System set 4
Read before using 5
PIN codes of the system 6
Owner’s personal card 6
External VALET button 7
System modules layout 7
Base unit 8
Information signals of the system 10
System functions and modes 12
Security mode 12
Security zones 12
Remote and automatic engine starts 13
Stay Home mode 14
Slave mode 14
Owner authorization devices and functions 15
Checking the number of paired devices 16
Remote control (D-043) 17
Switch on/off the remote control 18
LED indicator of the remote control signals 18
Charging the remote control 18
Updating firmware of the remote control 18
Icons of the remote control 19
Quick access functions of the remote control 20
Immobilizer radio tag 21
Function of the button 21
Light indication of SEND LED 22
Replacing an immobilizer tag battery 22
Updating firmware of the tag 23
Control the system by a phone 24
Changing settings via a phone 26
Online-service and mobile application 29
Control the system 32
Arming 32
Activating Stay Home mode 33
Disarming 34
Locking/unlocking doors when ignition is on 35
Car search function 36
PANIC mode 36
Remote engine start 37
Service mode 38
Control the system in case of emergency 40
Emergency disarming 41
Emergency control of the anti-theft functions 41
Additional devices 43
Warranty obligations 45
Installation certificate 47
Acceptance certificate 48
Warranty Card 48

5
4USER MANUALPANDORA CAMPER MINI
System set
1. Remote control 1
2. Radio tag 1
3. Owner’s personal card 1
4. External VALET button 1
5. Beeper 1
6. Base unit 1
7. Blocking relay 1
8. Door Sensor DMS-100BT 2
9. External temperature sensors 1
10. Wires and fastening kit 1
11. Piezo siren PS-330 1
12. User manual 1
13. Wiring diagram 1
14. Packaging 1
! the mANufActuReR ReseRves the RIGht to chANGe the system set ANd coNstRuctIoN of the pRoduct to
ImpRove Its techNoloGIcAl ANd opeRAtIoNAl pARAmeteRs WIthout ANotIfIcAtIoN.
Read before using
Carefully read this manual before starting installation and using the security-service system. Pay
attention to text marked with !
! the secuRIty ANd telemetRIc system Is Acomplex techNIcAl pRoduct. system INstAllAtIoN ANd coNfIGuRAtIoN must be
cARRIed out oNly by AskIlled pRofessIoNAl.
! feAtuRes ANd system modes, coNtRol of the vehIcles zoNes depeNds oN the type of coNNectIoN ANd system settINGs,
oRIGINAl vehIcle opeRAtIoN loGIc ANd tRIm.
! the system set INcludes the “oWNeR’speRsoNAl cARd”. thIs cARd coNtAINs INfoRmAtIoN uNdeR ApRotectIve lAyeR
thAt Is INteNded oNly foR the oWNeR of the system. mAke suRe thAt the pRotectIve lAyeR oN the oWNeR’splAstIc cARd Is
INtAct AfteR the INstAllAtIoN of the system. ReAd the “oWNeR’speRsoNAl cARd” sectIoN of thIs mANuAl befoRe eRAsING
the pRotectIve lAyeR.
! WheN system INstAllAtIoN Is fINIshed:
• check the system opeRAtIoN ANd fuNctIoNs WIth AspecIAlIst.
• WeRecommeNd thAt you mARk eAch WoRkING fuNctIoN WIth AsIGN IN the “coNtRol the system” sectIoN
• check thAt the “INstAllAtIoN ceRtIfIcAte” ANd “WARRANty cARd” ARe fIlled out. these documeNts mAy be RequIRed foR
coNtActING the customeR suppoRt.
• Ask AN INstAlleR to mARk the lAyout of the system compoNeNts oN the dIAGRAm. thIs INfoRmAtIoN mAy be RequIRed foR
dIAGNostIc/coNfIGuRING oR emeRGeNcy deActIvAtIoN of the system.
WeRecommeNd thAt you chANGe the defAult vAlue of the pIN-codes of the system. you cAN WRIte doWN the chANGed
pIN-codes IN the “pIN-codes of the system” sectIoN.

7
6USER MANUALPANDORA CAMPER MINI
PIN-codes of the system
The “Secret PIN-code”
(is written on the “Owner’s personal card”)
The “Service PIN-code”
(default value is 1-1-1-1)
The “Guest PIN-code”
(default value is 1-2-3-4)
The “Immobilizer PIN-code”
(is used for the Validator (pin-to-drive) function)
! ItIs RecommeNded thAt you WIll WRIte doWN the chANGed oR cReAted vAlues of All pIN-codes. elImINAte thIRd-pARty
Access to thIs INfoRmAtIoN.
Owner’s personal card
! eRAse the pRotectIve lAyeR cARefully. doNot use ANy shARp objects to AvoId dAmAGING of hIddeN INfoRmAtIoN uNdeR
the pRotectIve lAyeR.
The owner’s personal card contains private information under a protective layer:
• PIN (the“Secret PIN-code”) is a 4-digit number.This code can be used
to disarm the system and to deactivate immobilizer functions and
to activate service mode. It can be also used to enter programming
mode.
• LOGIN is a 10-digit number. This information is used to add the
system to the online service and mobile applications.
• PASS contains 8 characters and can consist of digits, lower and
upper case letters). This information is used to add the system to the
online service and mobile applications.
• Phone number is a phone number of the built-in SIM-chip.
CANNOT BE CHANGED
+7-9хх-ххх-хх-хх
1070000000 / Y34aC4vJ
2-2-2-2
LOGIN / PASS
PIN PHONE NUMBER
System modules layout
External VALET button
(VALET button via CAN)
Button for the immobilizer
PIN
Circuit being blocked
Base unit
DMS-100BT
1
2
3
4
5
6
7
External VALET button
An external VALET button with a three-color status LED indicator is placed
inside a vehicle (see the system modules layout).
The button is used for programing the system, arming/disarming,
activating/deactivating immobilizer mode.

9
8USER MANUALPANDORA CAMPER MINI
!WARNING! dms-100bt seNsoRs fRom the kIt ARe AlReAdy pAIRed WIth the bAse uNIt. AccoRdING to the INstAllAtIoN
plAce you cAN chANGe the defAult loGIc of the AlARm zoNes IN AlARm studIo oR pANdoRA specIAlIst: «AdvANced
settINGs»-»INputs ANd outputs»-»INputs settINGs». fIll the tAble WIth the ActuAl loGIc:
DMS1 Window DMS6
DMS2 Window DMS7
DMS3 DMS8
DMS4 DMS9
DMS5 DMS10
Base unit
Built-in GSM modem (2G/3G/4G LTE) provides a connection with our online-service pandora-on.
com and mobile application (Pandora Connect), allows to control the system by a phone using DTMF-
commands, voice and SMS notifications, automatic date and time detection. The modem operates in a
mobile network using the built-in SIM-chip or/and a nano-SIM.
Built-in SIM-chip is and integrated SIM-card chip that it used to work with the built-in GSM modem.
The built-in SIM-chip has a tariff plan for Russia (phone number is written on the “Owner’s personal
card”).
Built-in slot for a nano-SIM is used for owner’s SIM-card (nano-SIM). If both the SIM-chip and SIM-
card are used in the system, there is a function that allows to automatically switch between the SIM-chip
and the SIM-card if there is no internet connection.
!ItIs RequIRed to INstAll AN AddItIoNAl sIm-cARd IN the NANo-sIm slot foR the AutomAtIc mode.
Built-in GPS/GLONASS-receiver is designed to determine current location and to automatically
determine UTS date and time.
2.4GHz radio channel, Bluetooth 5.0 protocol (BT5.0) - supports up to 14 additional Bluetooth
devices (see the“Additional devices”section), including a mobile phone.
Built-in 3D accelerometer is used to detect shock/motion/tilt including 2 separate zones of shock
sensor (alarm and warning), the system allows to adjust sensitivity of each zone, to use data from the
accelerometer to block the engine and close the central lock on movement.
Temperature sensors allow the system to measure temperature of different zones to send
this information to the remote control or mobile apps. The following zones are available: interior
temperature – built in sensor of the main unit, engine temperature – external temperature sensor (see
the “System set”), outside temperature – digital car protocol*
The system setting allow you to reassign sensor to different zones and use information from external
additional devices (PS-331BT, CIM-03 BT, DMS-100 BT); to implement automatic engine or engine pre-
heater starts and stops by temperature.
Built-in digital 2хCAN* interface allows the system to read status end exucute commands via
digital buses.
Built-in digital IMMO-KEY port and immobilzer bypass* – hardware and software algortihms
with the special Pandora CLONE server allow the system to bypass original immobilizers for automatic
and remote engine starts.This port can be also used to control Webasto Thermo Top Evo  Eberspacher
Hydronic/2 heaters.
Built-in micro-USB port – update and configuration of the system using a PC and Pandora Alarm
Studio.
! *moRe INfoRmAtIoN Is AvAIlAble oN loAdeR.pANdoRAINfo.com

11
10 USER MANUALPANDORA CAMPER MINI
Information signals of the system
LED INDICATOR SIGNALS
SIGNALS DESCRIPTION
THE SYSTEM IS ARMED
Short red ashes System is armed
Short green ashes System is armed
(an authorization device is in the coverage zone)
Fast red ashes Alarm
THE SYSTEM IS DISARMED
Faded System is disarmed
Red System is preparing for automatic or delayed arming
Green (when ignition is on) System is in service mode
Green ashes
(when switching on the ignition) Conrms the number of paired radio tags
Red ash
(when switching on the ignition) Conrms a paired mobile device
WHEN ENTERING THE“SECRET PIN-CODE”OR THE“SERVICE PIN-CODE”
Orange ash Conrms a VALET button press
Short red ash Conrms a digit input
PIN-code is incorrect
Red and green ashes Conrms correct PIN code
SOUND AND LIGHT SIGNALIZATION
SIGNALS
(sound / light) DESCRIPTION
1х /1х Arming
2х /2х Disarming
5х /5х Car search
30 sec. /30 sec. Alarm, PANIC mode
3х /1х Warning level of a sensor is triggerd
4х /4х
Sensors were triggered’signal when disarming /
Parking light is not turned o notication /
‘Sensors are triggered”signal when arming
25 sec. /25 sec. Engine blocking warning in Anti-Hi-Jack mode
BEEPER SOUND SIGNALS
SINGNAL DESCRIPTION
1 sound signal Activating service mode
2 sound signals Deactivating service mode
1 sound signal Correct input of the“Immobilizer PIN-code”
3 sound signals/3 times A battery in a radio tag is discharged
4 sound signals/4 times Absence of a an authorization device when you switch
on ignition
Fast sound signals Engine blocking warning

13
12 USER MANUALPANDORA CAMPER MINI
SYSTEM FUNCTIONS AND MODES
Security mode
The system confirms arming with 1х sound and 1х light signals. When the system is armed, the
system monitors security zones with separated warning and alarm level of triggering:
• Warning mode - this mode activates when there is a slight impact on the shock sensor or additional
senor. It is accompanied with 1х light and 3х sound signals;
• Alarm mode - this mode activates when a sensor or one of the security zones is triggered.
It is 30 sec. light and 30 sec. sound signals. he alarm signals can be
• canceled by an arming or disarming command.
If one of the security zones is triggered the system:
• records this event in its non-volatile memory;
• activates the alarm or warning mode;
• informs an owner by all available means;
• blocks the engine (in accordance with the settings and connections).
• If one of the security zones is opened at the moment of arming, the system will produce 4х
sound and 4х light warning signals.
If one of the security zones fails, the system will forcibly turn off this zone. If a switch triggers
more than 9 times in a row, it will be disabled until the next arming. The shock/tilt/motion sensor is
temporarily deactivated (15 sec.) if it has been triggered more than 3 times in a row.
The system confirms disarming with 2х sound and 2х light signals. The system deactivate
engine blocking (if the immobilizer function and additional blocking are not used). If there were alarm
events during the armed period, the system will produce 4х sound and 4х light warning
signals. The system continues to display all zones when it is disarmed, but the information is not saved
in the memory.
Security zones
• Interior temperature (status)
• Engine temperature (status)
• Outside temperature (status)*
• Voltage of the on-board circuits (status)
• Engine operation control - RPM (status)
• Heater operating control (status)
• Fuel level (status)
• Parking (automatic gearbox) /Handbrake (manual gearbox) status
• Parking light is not turned off” notification (status)
• Shock sensor (security zone – alarm and warning level)
• Motion sensor (security zone – alarm level)
• Tilt sensor (security zone – alarm level)
• OE alarm system status via CAN, additional sensor (status, security zone – alarm and warning level)
• Turning ignition on (status, security zone – alarm level)
• Opening front doors (status, security zone – alarm level)
• Opening side doors (status, security zone – alarm level)
• Opening camper windows (status, security zone – alarm level)
• Opening camper sunroofs (status, security zone – alarm level)
• Opening a trunk (status, security zone – alarm level)
• Opening a hood (status, security zone – alarm level)
• Pressing brake (status, security zone – alarm level)
!*outsIde tempeRAtuRe Is AvAIlAble by AN AddItIoNAl devIce (see the “AddItIoNAl devIces” sectIoN) oR by cAN-bus dAtA
(see loAdeR.pANdoRAINfo.com).
Remote and automatic engine starts
The system allows for remote engine start using the “remote engine start” command from a remote
control, mobile application or preconfigured automatic engine start function. Remote start can be used
to heat engine and interior, charge battery or to cool the interior with air conditioning.
Remote and automatic starts can only be used when the system is armed. While the system is in
remote or automatic start mode, it keeps performing all security functions of all of the security zones
excluding a shock sensor (the system can be configured to not disable the shock sensor during a remote
engine start). To compensate it, the motion sensor sensitivity and responsiveness will be increased. If
any security zone will be triggered, the engine will be immediately stopped and alarm mode will be
triggered.
When using the remote and automatic engine start functions, make sure that a car is secured with
handbrake or some other means of fixating the car on a parking position.
Remote and automatic engine start on automatic transmission cars will only occur, if a transmission
selector lever was left in the «P» position.
If a car has manual transmission, remote or automatic start will only occur if the program neutral
procedure was followed when the car was arming.

15
14 USER MANUALPANDORA CAMPER MINI
AN EXAMPLE OF THE PROGRAM NETURAL PROCEDURE
1. When the engine is running, fixate the car with the handbrake and put gear lever to the neutral
position. Program neutral procedure will be switched on automatically (by default system settings).
2.Turn the key in the ignition lock to the OFF position (the engine should still be running) and take
it out of the lock (skip this step for cars with a Start/Stop button).
3.Leave the car, close the doors.
4.Arm the system - the engine will be stopped. Now the system is ready to perform remote and
automatic engine start.
Automatic starts
The system allows configuring automatic engine start and stop conditions. Automatic starts can be
configured using a remote control or mobile application. The following conditions can be specified for
automatic engine starts: schedule, time period, engine temperature, voltage. The engine will be stopped
automatically after specified time or when the engine temperature reaches a specified value. The engine
can be also stopped by a user command
! AutomAtIc eNGINe stARts ANd stops by tempeRAtuRe ARe AvAIlAble oNly If AtempeRAtuRe seNsoR Is coNNected. Remote
ANd AutomAtIc eNGINe stARts ARe Not AvAIlAble If the tRuNk Is opeN.
Stay Home mode
This mode is used to control the outer perimeter of a vehicle during parking when passengers are inside
the vehicle. This mode allows the system to protect your vehicle against intrusion through the parts of
the vehicle that can be open.
• The system will be armed silently when you activate the “Stay Home” mode, it will be confirmed
with 1х light signal. The system controls vehicle security zones and an additional gas sensor (it is
not included in the set) in this mode, built-in sensors (shock/tilt/motion) are disabled in this mode.
The system will be disarmed when you deactivate the“Stay Home”mode, it will be confirmed with 2х
sound and 1х light signals.
Slave mode
This mode allows arming and disarming using original vehicle control – an original key, button/
sensor of a keyless access entry system.
Slave mode can be implemented using analog connections or a digital protocol of a vehicle.
!thIs mode Is dIsAbled by defAult foR AdIGItAl pRotocol. moRe INfoRmAtIoN oN loAdeR.pANdoRAINfo.com. ItIs
RecommeNded to ActIvAte the “pRohIbIt dIsARmING WheN AtAG Is AbseNt” to INcReAse secuRIty feAtuRes of the slAve
mode. IfthIs mode Is ActIvAted, It WIll be possIble to dIsARm the system oNly WheN AtAG Is IN the coveRAGe zoNe oR usING
the “secRet pIN-code”.
Owner authorization devices and functions
Authorization devices
Authorization devices are Bluetooth devices paired with the system (radio tags, remote control D030,
mobile phone with the app). The devices are used to recognize an owner in the radio coverage zone
of the base unit to arm/disarm the system (Hands Free mode) and to implement immobilizer or Anti-
Hi-Jack functions.
!INstAll the beepeR If you use AuthoRIzAtIoN devIces.
Hands Free mode
This mode is used for automatic arming/disarming when an owner with an authorization device is
distancing or approaching a vehicle.
!thIs mode Is dIsAbled by defAult. ItIs RequIRed to mAke AddItIoNAl settINGs usING the mobIle ApplIcAtIoN oR pANdoRA
AlARm studIo to use thIs mode. quIck Access commANds to mANAGe hANds fRee mode: 223* - ActIvAte hANds fRee
ARmING, 224* - ActIvAte hANds fRee dIsARmING, 222* - deActIvAte All hANds fRee modes.
Immobilizer mode
This mode is used to recognize an owner using authorization devices when the system is disarmed.
When turning on the ignition, the base unit performs a search for authorization devices in the
radiocoverage zone. If there is no any authorization device in the radio coverage zone, the system
will block the engine. Engine blocking will occur immediately or at the time a motion sensor detects
movement, it depends on the system settings. When an authorization device appears in the coverage
zone, the system will exit blocking mode and will continue to work in normal mode.
!thIs mode Is eNAbled by defAult. ItIs RequIRed to mAke AddItIoNAl coNNectIoNs foR thIs mode.
ANTI-HI-JACK-1/2 modes
The Anti-Hi-Jack modes help to prevent aggressive seizure of a vehicle when authorization in case
of disappearance of authorization devices from the radio coverage zone when system is disarmed.

17
16 USER MANUALPANDORA CAMPER MINI
ANTI-HI-JACK-1 mode – The base unit checks if an authorization device is in the radio coverage zone
each time when ignition is on and a door is opened/closed.
ANTI-HI-JACK-2 mode – The base unit constantly checks if an authorization device is in the radio
coverage zone when ignition is on.
If the system cannot detect an authorization device, the base unit will perform a delayed engine
blocking. The siren will play the ‘Engine blocking warning’ ringtone before blocking. The engine will
be blocked immediately or at the time the car starts moving, it depends on the system settings. When
an authorization device appears in the coverage zone, the system will exit blocking mode and will
continue to work in normal mode.
!thIs mode Is dIsAbled by defAult. thIs mode cAN be set oNly by ApRofessIoNAl specIAlIst
Multi-button code immobilizer (pin-to-drive)
• Multi-button code immobilizer (pin-to-drive) is a function that allows disarming, disabling blocking
and controlling service mode and time channels using original vehicle controls (button, lever or
pedal) and a pre-programmed PIN-code (the “Immobilizer PIN-code”).
AN EXAMPLE OF USING THE FUNCTION
• Turn on the ignition to disable engine blocking or enable service mode, turning on the ignition is not
required if you want to disarm the system or control time channels.
• Enter the “Immobilizer PIN-code”. Press a programmed button/lever/pedal the number of times
equals to the first digit. Pauses between presses should not exceed 1 second. More than 1 second
pause will be interpreted as the start of the next digit input. The immobilizer code can consist max
of 4 digits from 1 to 9.
• The system will confirm the correct input by a sound signal of the beeper and a programmed
• function will be performed.
!thIs mode Is dIsAbled by defAult. thIs mode cAN be set oNly by ApRofessIoNAl specIAlIst.
Checking the number of paired devices
The number of paired radio tags/mobile device can be checked by the number of flashes of the
LED indicator. The number of tags/mobile device can be checked when switching on the ignition (the
system must be disarmed). The number of green flashes will indicate the number of paired radio tags, a
following red flash will indicate a paired mobile device.
You can also check the number of paired radio tags/mobile device by taking off and putting back on
battery terminal. The system will emit short sound signals from a siren :
• First series of the siren signals – indicates the number of paired radio tags;
• The second long signal after a pause of 2 seconds indicates a paired mobile devices.
REMOTE CONTROL D030
A remote control is a device used to control and monitor vehicle/system state. The remote control is
also used as an authorization device for “Immobilizer/Anti-Hijack/HandsFree” modes. It works in the
Bluetooth coverage zone. Each event is displayed as an icon on the OLED-display and is accompanied
with a sound and vibro indication.
! All coNtRol commANds ARe tRANsmItted vIA RAdIo chANNel, foR mAxImum effectIveNess ANd RANGe It Is RecommeNded
Not to shIeld AeRIAl AReA (see pIctuRe) WIth fINGeRs WheN usING ARemote coNtRol.
• OLED – display
• 3 control buttons
• Built-in sound indicator (16 ringtones)
• Built-in vibro indicator
• Built-in LED SEND/ALARM indicator
• 2,4 GHz radio interface (Bluetooth protocol)
• Dialog coding of commands (AES-128 encryption)
• Built-in battery
• Built-in micro-USB port
OLED
micro-USB
SEND/ALARM

19
18 USER MANUALPANDORA CAMPER MINI
Switch on/o the remote control
Press and hold the button for 3 seconds to switch on/off the remote control.
LED indicator of the remote control signals
RED indicator “ALARM” Green indicator “SEND”
Flashes frequently if there is any notication Flashes if there is a connection with the base unit
Flashes occasionally when there is no connection Goes dark when there is no connection with the base
unit
Charging the remote control
There is an indication of the battery charge level . on the display. Charge the battery if the
remote control does not turn on or the charge level indicator displays the last segment . The battery
is charged using a standard micro-USB cable.
Updating rmware of the remote control
• Download the Pandora BT application (for Android or iOS devices equipped with a Bluetooth 4.0 Low
Energy or higher module).
• Press and hold the button. Connect the micro-USB cable to the remote control whule holding the
button. Release the button after the connection.
• Open the mobile app and find the remote control, select the device and select one of the update
option: FILE MANAGER – firmware will be uploaded from the phone storage (only for Android).
INTERNET – firmware will be uploaded by an internet connection.
Icons of the remote control
Additional sensor/
OE alarm status
Security zone
(alarm level)
Additional sensor/
OE alarm status
Security zone
(warning level)
Tilt sensor
Security zone
Motion sensor
Security zone
Ignition
Security zone
Doors security zone
Trunk security zone
Low voltage security zone
Brake pedal security zone
Heater operation icon
Connected to the base unit
Security mode status
Current time
Battery charge level
Engine temperature
Interior temperature
Outside temperature
Vehicle battery voltage
Fuel level
Shock sensor Security zone
(Warning level)
Shock sensor Security sensor
(alarm level)
12 48
90
°
22
°
-18 С
°
55
P
1
2
.
0
V

21
20 USER MANUALPANDORA CAMPER MINI
Quick access functions of the remote control
System is disarmed System is armed
(no alarm events)
Ignition is on Ignition is o
(short press) Lock doors without
arming Arming with sound confrmation Search mode – flashes of turn signals with sound signals for 5
seconds
(1 sec.) Activate “Stay Home”
mode Search mode – flashes of turn signals with sound signals for 5
seconds
(short press) Unlock doors Unlock doors Disarming with sound
conrmation
(1 sec.) Disarming without sound
conrmation
(short press) Switch on the display
(1 sec.) Open side door
(2 sec.) Switch on/o time channel
(3 sec.) Switch on/o the remote control
+
(short press)
PANIC mode
+
(short press)
Arming when the engine
is running with sound
conrmation
Arming in 30 seconds
With sound notication
+ (1 sec.) Arming when the engine
is running with sound
conrmation
Arming in 30 seconds
without sound
notication
IMMOBILIZER RADIO TAG
A radio tag is a device used to control a vehicle/system. The tag is also used as an authorization device
for “Immobilizer/Anti-Hijack/HandsFree” modes. It works in the Bluetooth coverage zone. The radio tag
has: a control button for arming/disarming and activating/deactivating service mode; a built-in
accelerometer allows the tag to go into energy saving mode when there is no movement; an LED indicator
SEND.
- 2.4GHz,
Bluetooth 4.2 Low Energy
- Control button
SEND - LED indicator
CR 2032 - Battery
3D - Accelerometer
The tag should be operated
in temperatures range from-10 to +40°C,
IP40 category.
!AvoId moIstuRe oN the RAdIo tAG. doNot plAce the RAdIo tAG NeAR mAGNets oR pRoducts WIth self-mAGNetIc fIelds
Functions of the button
ACTION FUNCTION
- briey (ignition is o) Arm/disarm
- hold for 2 seconds (system is
disarmed) Activating «StayHome» mode/Change the «Main owner’s phone number»
- hold for 3 seconds (ignition is on) Activate/deactivate Service mode
- hold for 6 seconds Pair a tag with the base unit
- hold for 10 seconds Firmware update
SEND
Radio tag ВТ-760 Radio tag ВТ-770
3D

23
22 USER MANUALPANDORA CAMPER MINI
Light indication of SEND LED
SIGNAL DESCRIPTION
1 ash Arming/disarming
Conrmation of arming
Low battery level (when installing a battery)
2 ash Conrmation of disarming
3 ash Battery is charged (when installing a battery)
Faded Battery is discharged (when installing a battery, when pressing the
button)
Replacing an immobilizer tag battery
When replacing the battery you must carefully follow the following steps:
Radio tag BT-760
Carefully open the cover of the tag’s battery compartment (fig. 1). Extract discharged battery and
insert a new one keeping in mind the correct polarity (fig. 2). Replacing a battery will not cause a loss of
tag code information, as authorization data is stored in the non-volatile memory of the MCU. Carefully
close the cover of the tag’s battery compartment. All elements of construction should be rigidly locked
in places.
If it is so, the tag can be operated as usually.
Open here
g.1
Battery
СR 2032
Plus side (+)
+
СR2032
g.2
Radio tag BT-770
• Unscrew the screw with a Philips PH00 screwdriver (fig.1);
• Slide the battery cover in the direction shown by the arrow (fig. 2);
• Remove the battery and install a new one in accordance with the correct polarity;
• The SEND indicator will produce 3 red lights if a quality battery is installed;
• Assemble the tag in the reverse order.
The tag can be operated as usually after finishing the procedure.
Updating rmware of the tag
• Download the Pandora BT application (for Android or iOS devices equipped with a Bluetooth 4.0 Low
Energy or higher module).
• Open the mobile app Pandora BT.
• Press and hold the button of the radio tag until the 10th flash of the SEND indicator, then
release the button.
• Select the found device and select one of the update option: FILE MANAGER – firmware will be
uploaded from the phone storage (only for Android). INTERNET – firmware will be uploaded by an
internet connection.
CR 2032
Battery
Minus side (-)
SEND – 3 ashes
-
СR2032
g. 1
CR 2032
Battery
Minus side (-)
SEND – 3 ashes
-
СR2032
g. 2

25
24 USER MANUALPANDORA CAMPER MINI
CONTROL THE SYSTEM BY A PHONE
! foR the coRRect opeRAtIoN of the Gsm fuNctIoNs, AN oWNeR should moNItoR the stAtus/bAlANce of the sIm cARd
INstAlled IN the system. Ifthe sIm cARd Is blocked oR defectIve, Gsm fuNctIoNs of the system WIll be uNAvAIlAble.
Call the system’s phone number. When it answers, enter a command code
*ItIs RequIRed to eNteR the “secRet pIN-code” AfteR dIAlING AcommANd.
DTMF commands.
For example: To have simple access to engine start function, create a new contact in the contact
list of your phone, name it ‘Engine start’, for instance, and add the number in the following format:
+XXXXXXXXXXX,123*,297* where “+XXXXXXXXXXX” – the system phone number, “,” - pause is a feature
of the phone (can be displayed as the‘P’, see the instructions of the phone),“123*” - remote engine start
1
10 00 0*
*
1
12 23 3*
*
5
5
1
1*
*Tow truck mode
Request GSM account balance
Start the engine/prolong heating
3
32 21 1*
*Stop the engine
3
33 33 3*
*Switch on add. function using F via CAN
5
50 00 0*
*
4
45 56 6*
*
6
65 54 4
*
*
7
75 53 3*
*
Request current coordinates
Switch on additional channel
Switch o additional channel
#
#
9
9*
*
*
*
1
15 59 9*
*
Return to previous menu
Repeat the last message
Silent arming
Help
0
0
0
0*
*
0
0
1
1*
*
Unlocking trunk
Silent disarming
1
1*
*Arming
0
0*
*Disarming
Force connection to the server
2
25 58 8*
*System information
1
15 56 6*
*
6
65 51 1*
*
Switch on engine preheater
Switch o engine preheater
6
66 66 6*
*
9
99 99 9*
*
Enable engine blocking
Disable authorization devices*
9
99 98 8*
*
8
88 88 8*
*
Отключение устройств авторизации*
4
42 24 4
*
*
Fuel level calibration
Enable authorization devices
2
22 22 2*
*Disable Hands Free mode
2
22 23 3*
*Enable Hands Free arming
2
22 24 4*
*Enable Hands Free disarming
2
22 25 5*
*Enable Hands Free disarming
only with autom. start
7
78 89 9*
*Enable automatic engine start
9
98 87 7*
*Disable automatic engine start
2
29 97 7*
*End call
5
55 51 1*
*Enable service mode (see description below)*
5
55 52 2*
*Disable service mode
DTMF command, “297*” - end call DTMF command. Contact can be added as a speed dial to any of the
free button.To have simple access to engine start function a phone other than the main owner’s phone,
create contact in the following format: +XXXXXXXXXXX,1234,123*,297* where‘1234’ – guest PIN-code.
Activate/Deactivate service mode
1. Call the system number. Wait for the answer.
2. Turn on the ignition, an authorization device (a radio tag, a remote control, a paired mobile phone
with the app installed) must be in the coverage zone, enter the “Immobilizer PIN-code” (if the “Code
immobilizer” function is enabled).
3. To activate service mode, dial the 551* DTMF command — “Activate service mode”, then enter the
“Secret PIN-code”from the owner’s personal card.
4. To deactivate service mode, dial the 552* DTMF command — “Deactivate service mode”.
Voice help
The system has a voice help menu. During a voice call to the system, dial 9* and listen to the information
about system control commands.
To end the session, hang up the phone.
Repeat the last message
To repeat any message, press *during a voice call to the system.
Arming/Disarming
1. Call the system number. Wait for the answer.
2. Dial 1* to arm, and 0* to disarm. For silent arming dial 10* or 00* for silent disarming
3. The system will confirm arming/disarming.To end the session, hang up the phone. Enabling/disabling
automatic engine starts Pandora systems have a function of prompt disabling automatic engine start:
1. Call the system number and wait for the answer.
2. Dial 987* to disable all automatic engine starts or 789* to enable.
3.The system will confirm execution of the command.To end the session, hang up the phone. Automatic
starts can be enabled again by dialing 789* (all previous settings will remain intact).
Request current coordinates
1. Call the system number. Wait for the answer.
2. Dial 500*.

27
26 USER MANUALPANDORA CAMPER MINI
3. The system will confirm: ‘Current coordinates are sent via text message’ and will send text message
with coordinates and a web link to a map to your phone.
To end the session, hang up the phone.
Request GSM balance
1. Call the system number. Wait for the answer.
2. Dial 100*.
3. The system will confirm:‘Balance information is sent via text message’and will send text message with
account balance information to your phone.
To end the session, hang up the phone.
Tow truck mode
This mode is intended for car transportation with preservation of arming function. Tow truck mode
can be activated only when the system is armed, it will be deactivated automatically when disarming.
1. Call the system number. If the system is in PANIC mode, receive an emergency call. Wait for the answer.
2. Dial 15*, to enable the “Tow truck” mode, the system will disable motion, shock and tilt sensors. To
end the session, hung up the phone.
3. To disable this mode, disarm the system.
Activating/Deactivating engine blocking
You can block a car engine using any phone. The engine will remain blocked until phone command
‘Unlock engine’will be sent and the “Secret PIN-code”will be entered. This blocking cannot be disabled
using a remote control or VALET button.
1. Call the system number and wait for the answer.
2. Dial 666* to block an engine or 999* to unlock it (after dialing 999* you should enter the“Secret PIN
code”that is located on the owner’s card).
!All otheR commANds cAN be eNteRed IN the sAme mANNeR.
Changing settings via a phone
Disarm the system, call the system number, wait for the answer, switch on the ignition for 1-3 seconds
(but no more than 5 seconds), then switch it off. The system will enter the settings mode.
An example of changing the owner’s system number:
1.Enter the setting menu via a phone according to the instruction above;
2.Dial DTMF command 1*(phone number settings) and 1*(owner’s system number);
3.Enter new owner’s number in the format *XXXXXXXXXXX # (the system recognizes‘*’ as ‘+’);
4. To confirm, dial 1*.
!theRe ARe 3 WAys to chANGe mAIN oWNeR’sphoNe NumbeR:
1. vIA AphoNe, usING dtmf commANds settINGs mode.
2. usING RAdIo tAGs: tuRN oN the IGNItIoN WheN the system Is dIsARmed ANd cAll the system phoNe NumbeR. WAIt foR the
ANsWeR, dIAl the “Guest pIN-code” (defAult vAlue Is 1-2-3-4) If you ARe cAllING Not fRom the mAIN oWNeR’sNumbeR,
theN pRess ANd hold the buttoN oN the RAdIo tAG foR 2 secoNds (uNtIl the secoNd flAsh of the seNd INdIcAtoR).
ReleAse the buttoN, the system WIll RecoGNIze the INcomING phoNe NumbeR As the “mAIN oWNeR’sphoNe NumbeR.
3. usING the pANdoRA AlARm studIo oR pANdoRA bt ApplIcAtIoNs.

29
USER MANUAL
System’s number -> «#»
5
5
*
*
Set up date
Set up time
1
1
*
*
2
2
*
*
Phone
number settings
Owner's number -> #
Additional owner's number -> #
Second additional owner's
number -> #
Account balance inquiry number -> #
1
1
*
*
1
1
*
*
2
2
*
*
3
3
*
*
4
4
*
*
Automatic
engine start
settings
By time
Set up time for automatic start
By voltage
Set up voltage for automatic start
1
1
*
*
2
2
*
*
3
3
*
*
4
4
*
*
By temperature
Set up temperature for automatic
start
5
5
*
*
6
6
*
*
By period
Set up period for automatic start
7
7
*
*
8
8
*
*
6
6
*
*
Sensor
sensitivity settings
Settings of the warning level of the
shock sensor sensitivity
Settings of the alarm level of the
shock sensor sensitivity
Settings of the motion sensor
sensitivity
1
1
*
*
2
2
*
*
3
3
*
*
4
4
*
*
Settings of the tilt sensor sensitivity
Settings of the warning level of the
supplementary sensor sensitivity
5
5
*
*
Settings of the alarm level of the
supplementary sensor sensitivity
6
6
*
*
7
7
*
*
Settings
of the voice calls
Voice calls on alarm
Voice calls on triggering warning
level of the sensors
Voice calls on engine start
Voice calls on engine stop
1
1
*
*
2
2
*
*
3
3
*
*
4
4
*
*
Voice calls on restoring GSM
connection
Voice calls on disarming
5
5
*
*
6
6
*
*
Voice calls on entering
programming mode
Voice calls when radio relay
connection is lost
7
7
*
*
8
8
*
*
Voice calls when on-board voltage
is low
9
9
*
*
Voice calls on accident
0
0
*
*
2
2
*
*
Settings
of the text messages
Text messages on alarm
Text messages on triggering warning
level of the sensors
Text messages on engine start
Text messages on engine stop
Text messages on restoring GSM
connection
Text messages on disarming
1
1
*
*
2
2
*
*
3
3
*
*
4
4
*
*
5
5
*
*
6
6
*
*
Text messages on entering
programming mode
Text messages when radio relay
connection is lost
7
7
*
*
8
8
*
*
Text messages when on-board
voltage is low
9
9
*
*
Text messages on accident
0
0
*
*
3
3
*
*
Immobilizer
settings
Immobilizer (on/o)
Antihijack
1
1
*
*
2
2
*
*
4
4
*
*
Additional
settings
Changing guest PIN-code
Entering as guest
Remote blocking
1
1
*
*
2
2
*
*
3
3
*
*
Set threshold voltage for sending
text message
5
5
*
*
5
5
*
*
Settings
of saving mode
GSM connection
Money saving mode of the GSM
connection
Voice calls in roaming service
1
1
*
*
2
2
*
*
3
3
*
*
8
8
*
*
Current time
and date settings
9
9
*
*
NOTE: Engine start via temperature is available
only if temperature sensor is connected. The sensor
availability depends on the system set
ONLINE SERVICE AND MOBILE APPLICATION
Telemetric function of the system allows you to
control your vehicle using the online service pandora-
on.com or mobile apps – Pandora Connect.
The Pandora Connect application can work via a
Bluetooth channel when there is no connection to the
server. To get these functions, the mobile phone must
be paired with the system.
!foR the coRRect opeRAtIoN of the Gsm fuNctIoNs, AN oWNeR
should moNItoR the stAtus/bAlANce of the sIm cARd INstAlled
IN the system. Ifthe sIm cARd Is blocked oR defectIve, Gsm
fuNctIoNs of the system WIll be uNAvAIlAble.
Before using the online-service, It is required to
create an account (Registration), login to your account
(using your email and password created on the
registration step) and add the system to your account
(enter information from the“Owner’s personal card”).
Registration
Visit the website or open the mobile app to create an
account.
Web-service:
https://pandora-on.com.
Mobile apps:
Pandora Connect for iOS is available in the AppStore;
Pandora Connect for Android is available on the Play
Market (Google Play).
!mINImum RequIRemeNts: ANdRIod v4.4; Ios v10
You will create the data to sign in: LOGIN – your email, PASSWORD – a password entered during the
registration.You will receive an email with a confirmation link. Click the link to complete the registration
procedure.
pandora-on.com
LOGIN
PASS
e-mail
********
LOGIN
PASS
e-mail
********

31
30 USER MANUALPANDORA CAMPER MINI
Login
After completing of the registration process, you can login to the online service via a computer’s web
browser or via the mobile apps Pandora Pro or Pandora Online. Use your previously created login/
password to login:
Adding a system to your account
The created account can support up to 3 telemetry systems. Use the information from the“Owner’s
personal card”to add the system to your account.
Go to the “Add a device/Add a system” window and enter the LOGIN and PASS from the “Owner’s
personal card”, create a name for your car and click “Add”.
!eRAse the pRotectIve lAyeR cARefully. doNot use ANy shARp objects to AvoId dAmAGING of hIddeN INfoRmAtIoN uNdeR
the pRotectIve lAyeR.
After this, you will be able to control, change setting and get information about the vehicle state
through the online-service.
!NumbeR of eveNts IN the hIstoRy Is lImIted. eveNts ARe stoRed foR At leAst oNe moNth.
Control via Bluetooth
The Pandora Pro and Pandora Online applications can work via a Bluetooth channel when there is
no connection to the server. This type of connection allows you to control the system, receive status
information and use your mobile phone as an authorization device.
To get access to these functions, pair a mobile device in the system:
I. ENTER THE PROGRAMMING MODE
Use the VALET button to enter the “Service PIN-code” (default value is 1-1-1-1). See the detailed
instruction of code entering in the “Control the system in case of emergency”section.
II. ENTER THE“PAIRING A MOBILE PHONE”PROGRAMMING LEVEL
After entering programming mode, press and hold the VALET button for 5 seconds (until the fifth
signal of the Siren/Beeper”). The system will enter the“Pairing a mobile phone”programming level. The
LED indicator will light green, the system is ready for pairing.
!the pRevIously pAIRed devIce WIll be eRAsed fRom the system memoRy AfteR eNteRING the level.
III. PAIR A MOBILE PHONE
Turn on Bluetooth on your mobile phone and open the mobile application. Go to : Settings -> Bluetooth
control -> Bluetooth device/ Not specified (Android)» -> + (iOS)/ Add (Android». Select the found system in
the search window, the system and the mobile device will be automatically paired. The system will confirm
pairing with the series of green and red flashes of the LED and a sound signal of the siren.
! IftheRe Is No AutomAtIc pAIRING, eNAble the “pIN Request foR phoNe
pAIRING”Item IN the “RAdIo tAG ANd mobIle devIce fuNctIoNs”sett INGs ANd mAke the pAIRING pRoceduRe AGAIN. A mobIle
devIce WIll Request ApIN-code (fActoRy pRe-set Is 0-0-1-1-1-1 WheRe 4 lAst dIGIts ARe the “seRvIce pIN-code”.
IV. EXIT PROGRAMMING MODE
Turn on the ignition and then turn off to exit programming mode.
!the system suppoRts oNly oNe mobIle devIce.

33
32 USER MANUALPANDORA CAMPER MINI
CONTROL THE SYSTEM
Arming
To arm the system when the ignition is off, use one of the methods described below. The system
will confirm the command with 1 short sound signal 1х and 1 flash of light signalization
1х .
Remote control
Shortly press the , button on the remote control when you are in the radio coverage zone. The
remote control will play “ARMING” ringtone and security mode status icon (the lock) will be changed
to .
To arm the system without a sound notification press and hold the button for more than 1
seconds.
Radio tag
A radio tag must be in the Bluetooth coverage area. Shortly press the control button , on the tag.
Slave mode
Shortly press the“Lock”button on an original remote control or use a sensor/button on a door handle
(for cars with an intelligent access system).
Phone
Call the system number. Wait for the answer. Dial the 1 * . command. To arm the system without siren
signals dial the 1 0 * .
doors locking
system arming
SLAVE
HANDS FREE
PANDORA BT
1x /1x
SLAVE
HANDS FREE
MOBILE APP
1 *
Online-service PRO.P-ON.RU
Login to the PANDORA-ON.COM, when the system is online (there is an Internet connection) press the
button on the control panel.
Mobile application Pandora Connect
Open the mobile application. When the system is online (there is an Internet or Bluetooth connection),
press and hold the button on the control panel until the scale is fully loaded.
HandsFree mode
Move with an authorization device away from your vehicle .
VALET button
Press and hold the VALET button for 3 seconds. The system will be armed in 30 seconds. The LED
indicator is lighting red during the countdown.
!theRe Is AN optIoN IN the system settINGs thAt AlloWs to ARm the system WIth dIsAbled seNsoRs (shock/tIlt/motIoN
ANd AddItIoNAl seNsoRs). the settING “sWItch off seNsoRs WheN ARmING usING vAlet butt oN” Is AvAIlAble IN the AlARm
studIo (“mAIN settINGs” -> “seNsoRs settINGs”).
Activating Stay Home mode
To activate Stay Home mode when the ignition is off, use one of the methods described below.
The system will confirm the command with 1 flash of light signalization .
Remote control
Press and hold the button on the remote control for 1 second (until a sound signal/flash of the
SEND/ALARM indicator) when you are in the radio coverage zone.The remote control will play“ARMING”
ringtone and security mode status icon (the lock) will be changed to .
Mobile application
Open the mobile application. When the system is online (there is an Internet or Bluetooth
connection), press and hold the button on the control panel until the scale is fully loaded. The
security mode status icon will be changed to .

35
34 USER MANUALPANDORA CAMPER MINI
Radio tag
A radio tag must be in the Bluetooth coverage area. Press and hold the control button on the tag
for 2 seconds (until the second flash of the «SEND» indicator).
Disarming
To disarm the system, use one of the methods described below. The system will confirm the
command with 2 short sound signals 2х and 2 flashes of turn indicators 2х .
Remote control
Press and hold the , button on the remote control when you are in the radio coverage zone. The
remote control will play“DISARMING” ringtone and security mode status icon (the lock) will be changed
to .
To disarm the system without sound confirmation press and hold the button for 1 second
or more.
Radio tag
Radio tag must be in the Bluetooth coverage area. Shortly press the control button on the tag.
Slave mode
Shortly press the “Unlock” button on an original remote control or use a sensor/button on a door handle
(for cars with an intelligent access system.
Phone
Call the system number. Wait for the answer. Dial the 0 * command. To disarm the system without siren
signals dial the 0 *0 command.
doors unlocking
system disarming
2x /2x
SLAVE
HANDS FREE
MOBILE APP
0 *
Online service
Login to the PANDORA-ON.COM, when the system is online (there is an Internet connection) press the
button on the control panel.
Mobile application Pandora Connect
Open the mobile application. When the system is online (there is an Internet or Bluetooth connection),
press and hold the button on the control panel until the scale is fully loaded.
HandsFree mode
Move toward the vehicle with an authorization device .
VALET button
Enter the ”Secret PIN-code”(see the ”Emergency disarming using the VALET button” section)
Locking/unlocking doors when ignition is on
The system allows you to lock and unlock doors when ignition is on. To do this, use one of the
methods described below.
Remote control
Press the button to lock doors or the button to unlock doors when you are in the radio
coverage zone.
Mobile application Pandora Connect
Open the mobile application. When the system is online (you are in the radio coverage area), press and
hold the button to lock doors or the button to unlock doors on the control panel until the scale
is fully loaded.
Automatic modes
There are automatic lock modes that will lock the doors at the car movement or on switching on the
ignition. When using doors locking mode on car movement start, the system will detect car moving
and perform doors locking (it depends on speed status in a digital CAN-bus or motion sensor sensitivity
settings). When using doors locking mode on switching on the ignition, the doors will be locked
automatically 5 seconds after the ignition was switched on. If any door was opened after the ignition

37
36 USER MANUALPANDORA CAMPER MINI
had been switched on, automatic locking will be disabled to prevent locking the keys inside the car.
Doors can be automatically unlocked when the ignition is switched off.
!these modes ARe dIsAbled by defAult, use the pANdoRA AlARm studIo to eNAble these settINGs.
Car search function
To easily find your vehicle on a massive parking, shortly press the , button when the car is
armed. The system will sound the siren 5х and flash turn signals 5х .
To use this function without sound signals press and hold the button for 1 second .
PANIC mode
If your car or you are in danger and you want to draw attention to your car, you can use PANIC mode. In
this mode the siren will sound and turn signals will flash repeatedly for 30 seconds. To activate
this mode, use one of the methods described below.
Remote control
To activate the PANIC mode, press the and buttons simultaneously. To switch it off, press
either or button.
Mobile application Pandora Connect
Open the mobile application. When the system is online (there is an Internet or Bluetooth connection),
press and hold the button on the control panel until the scale is fully loaded. To switch this function
off press and hold the button on the control panel until the scale is fully loaded.
Remote engine start
If the system is prepared for remote start, use one of the methods described below to start the
engine.
Remote Control
• To start the engine, press and hold the button for 3 seconds (the remote control must be in
the radio coverage zone). Sound signal will confirm the command, LCD will show flashing the“engine is
running” icon signifying preparation to the engine start. In a few seconds the engine will be started,
the remote will play the“ENGINE START”ringtone and show spinning engine operation icon .
The remote will give notification 1 minute before designated engine stop the icon will flash
and the “ENGINE STOP IN 1 MINUTE”ringtone will play every 10 seconds. Sending the “REMOTE ENGINE
START”command (press and hold the
button for 3 seconds) while the“ENGINE STOP IN 1 MINUTE”
ringtone is playing will extend its operation period by 10 minutes. This procedure can be repeated
multiple times.
• To stop the engine, press and hold the button for 2 seconds or more (the remote control
must be in the radio coverage zone. The engine will be immediately stopped and it will be confirmed by
remote playing the“ENGINE STOP” ringtone and the “Engine is running”icon .
arming engine started
engine stopped
3 ashes
engine start
START
ENGINE
START
ENGINE
STOP
ENGINE
STOP
ENGINE
extension of launch
(10 min.)
321 *
321 *
123 *
3 sec.
3 sec.
2 sec.

39
38 USER MANUALPANDORA CAMPER MINI
Original key
The system reads digital information from a car, this allows you to start and stop the engine by an original key:
• To start the engine, press the“LOCK”button 3 times within 5 seconds (the key must be in the radio
coverage zone)
• To stop the engine, press the“LOCK”button 3 times within 5 seconds (the key must be in the radio
coverage zone).
!Remote eNGINe stARt by AN oRIGINAl key doesN’tRequIRed ANy AddItIoNAl settINGs. check If the fuNctIoN AvAIlAble foR
youR cAR IN loAdeR.pANdoRAINfo.com
!the fuNctIoN becomes AvAIlAble oNly 30 secoNds AfteR ARmING.
Phone
To start the engine, call the system number, wait for the answer. Dial the command. If you
repeat the command when the engine is running, it will prolong the operation period by 10
minutes (this procedure can be repeated multiple times).
•To stop the engine, call the system number, wait for the answer. Dial the command.
Online service
• To start the engine, login to the PANDORA-ON.COM, when the system is online (there is an Internet
connection) press the START ENGINE button on the control panel. In a few seconds the engine will be
started, it will be confirmed with the spinning icon.
• To stop the engine, press the STOP ENGINE button on the control panel. In a few seconds the
engine will be stopped and the spinning icon will be faded.
Mobile application Pandora Connect
• To start the engine, open the mobile application. When the system is online (there is an Internet
or Bluetooth connection) press and hold the START ENGINE button on the control panel until the scale
is fully loaded
• In a few seconds the engine will be started, it will be confirmed with the spinning icon.
• To stop the engine, press and hold the STOP ENGINE button on the control panel until the scale
is fully loaded. In a few seconds the engine will be stopped and the spinning icon will be faded.
Service mode
It is recommended to put the system into the service mode before handing it to a car service or valet
parking. When this mode is switched on, security system stops interfering with built-in electronics and
disables all functions to ease maintenance.
To switch on this mode, disarm the system, turn on the ignition, an authorization device (a
radio tag, a remote control, a mobile phone) must be in the coverage zone, enter the“Immobilizer
PIN-code” (if the “Code immobilizer” function is used) and use one of the method described
below:
Remote control
See the “REMOTE CONTROL MENU” –> “VALET MODE”description.
Radio tag
To activate/deactivate service mode, press and hold the button on a radio tag for 3 seconds
(until the third flash of the LED), release the button.
Phone
Call the system number wait for the answer.
• To activate service mode, dial the DTMF command and then dial the “Secret PIN-code”
from the Owner’s personal card.
• To deactivate service mode dial the DTMF command.
Mobile application Pandora Connect
To activate/deactivate service mode, open the mobile application. When the system is online (there
is an Internet or Bluetooth connection), press and hold the button on the control panel until
the scale is fully loaded.
!tochANGe buttoNs lAyout oR Add NeW buttoNs oN the coNtRol pANel, Go to “settINGs coNtRol buttoNs“.
Immobilizer buttons
• To activate service mode, enter the “Immobilizer PIN-code” and press the immobilizer button
10 times within 20 seconds.
• To deactivate service mode, turn on the ignition and enter the“Immobilizer PIN-code”.
Service mode indication
• Activated Service mode is indicated by: an icon in the mobile application, constant green LED
when the ignition is on, long sound signal of a Beeper at the moment you activate the mode.
• Deactivated Service mode is indicated by: no “Service mode” icon in the mobile application
in the mobile application, no constant green LED when the ignition is on, two long sound signal of a
Beeper at the moment you deactivate the mode.
