Gude Expert Bypass Switch 8701 Series User manual

Expert Bypass Switch 8701
© 2016 Gude Analog- und
Digitalsysteme GmbH
Manual Ver. 1.0.1
Manual

3
Expert BypassSwitch 8701 ©2016 Gude Analog-und DigitalsystemeGmbH
Table of contents
1. Device Description 4
1.1 Security Advice .............................................................................................................. 5
1.2 Content of Delivery ........................................................................................................ 5
1.3 Description ..................................................................................................................... 5
1.4 Installation ...................................................................................................................... 6
1.5 Technical Specifications ................................................................................................ 8
2. Operating 9
2.1 Operating the device ................................................................................................... 10
3. Support 11
3.1 Contact .......................................................................................................................... 12
3.2 Declaration of Conformity .......................................................................................... 13
0
Index

Device Description

5
Expert BypassSwitch 8701 ©2016 Gude Analog-und DigitalsystemeGmbH
Device Description
1Device Description
1.1 Security Advice
·The device must be installed only by qualified personnel according to the following in-
stallation and operating instructions.
·The manufacturer does not accept responsibility in case of improper use of the device
and particularly any use of equipment that may cause personal injury or material dam-
age.
·The device contains no user-maintenable parts. All maintenance has to be performed
by factory trained service personnel.
·This device contains potentially hazardous voltages and should not be opened or dis-
assembled.
·The device can be connected only to 230V AC (50 Hz or 60 Hz) power supply sock-
ets.
·The power cords, plugs and sockets have to be in good condition. Always connect the
device to properly grounded power sockets.
·The device is intended for indoor use only. Do NOT install them in an area where ex-
cessive moisture or heat is present.
·Because of safety and approval issues it is not allowed to modify the device without
our permission.
·Please note the safety advises and manuals of connected devices, too.
·The device is NOT a toy. It has to be used or stored out or range of children.
·Care about packaging material. Plastics has to be stored out of range of children.
Please recycle the packaging materials.
·In case of further questions, about installation, operation or usage of the device, which
are not clear after reading the manual, please do not hesitate to ask our support team.
·Please, never leave connected equipment unattended, that can cause damage.
·Connect only electrical devices that do not have limited on-time. I.e. in case of failure,
all connected appliances have to cope with a continuous on-time without causing
damage.
1.2 Content of Delivery
The package includes:
·Expert Bypass Switch 8701
·CD-ROM with Manual
1.3 Description
The Expert Bypass Switch 8701 is a mechanical bypass switch for uninterrupted re-
placement of UPS systems
·Uninterrupted replacement or maintenance of UPS systems through selection switch
without shutdown of connected loads
·Switch position „Netz“: Connected loads are operated with mains voltage directly

6
Expert BypassSwitch 8701 ©2016 Gude Analog-und DigitalsystemeGmbH
Device Description
·Switch position „USV“: Connected loads are operated with UPS system voltage
·Clearly visible LED display for switch status
·Low internal power consumption
·Developed and manufactured in Germany
1.4 Installation
Connectors on the rear panel (EBS 8701-1)
Expert Bypass Switch 8701-1
1. Load input "von Netz" (IEC C14, max. 10 A)
2. Load output "zur USV" (IEC C13, max. 10 A)
3. Load input "von USV" (IEC C14, max. 10 A)
4. 6 xLoad outputs "zur Last" to consumer (IEC C13, max. 10 A)
5. 10 Afuse for load output (1 xIEC C19, max.16 A)
6. 1xLoad output "zur Last" to consumer (IEC C19, max. 16 A)
Block diagram

7
Expert BypassSwitch 8701 ©2016 Gude Analog-und DigitalsystemeGmbH
Device Description
Connectors on the rear panel (EBS 8701-2)
1. Load input "von Netz" (IEC C20, max. 16 A)
2. Load output "zur USV" (IEC C19, max. 16 A)
3. Load input "von USV" (IEC C20, max. 16 A)
4. 6 xLoad outputs "zur Last" to consumer (IEC C13, max. 10 A)
5. 1xLoad output "zur Last" to consumer (IEC C19, max. 16 A)
Block diagram
Start-up the device
·Connect the load input "von Netz" to the mains supply.
·Connect the load output "zur USV" with the input of the UPS.
·Connect the load input "von USV" with the output of the UPS.
·Connect the load outputs "zur Last" with the consumer.
The 16 A lead plug IEC C19 or IEC C20 are secured as regards their type against
unintentional loosening. They must be inserted up to the stop, otherwise there is no se-
cure connection. The plug must not wobble in the socket, or there is no tight connection.

8
Expert BypassSwitch 8701 ©2016 Gude Analog-und DigitalsystemeGmbH
Device Description
1.5 Technical Specifications
Interfaces
1 x Ethernet port (RJ45)
1 x Mains supply (IEC C14, max.10 A)
4 x Load inputs (IEC C120, max. 16 A)
4 x Load outputs (IEC C19, max. 16 A)
2 x RJ45 for external sensor
Environment
·Operating temperature
·Storage temperature
·Humidity
0°C - 50 °C
-20°C - 70 °C
0% - 95% (non-condensing)
Case
powder coated, galvanized steel sheet
Measurements
19" (inches), 1 Rack Unit, (Depth 165
mm)
Weight
approx. 2.2 kg

Operating

10
Expert BypassSwitch 8701 ©2016 Gude Analog-und DigitalsystemeGmbH
Operating
2 Operating
2.1 Operating the device
1. Switch between "USV" and "LED"
2. LED indicator "USV" (UPS)
3. LED indicator "NETZ" (Mains)
Settings
In normal operation the switch is set to "USV" and the terminals are powered by the
connected UPS. If you want to replace the UPS for maintenance purposes, turn the
switch from "USV" to "Netz". Caution: When turning the switch a greater force is neces-
sary, this is normal. In the "Netz" setting the devices are directly supplied from the
mains . See the block diagrams in chapter Installation .
6

Support

12
Expert BypassSwitch 8701 ©2016 Gude Analog-und DigitalsystemeGmbH
Support
3 Support
If you have further questions about installation or operation of the unit, please contact our
support team. Furthermore, we present in our support wiki at www.gude.info/wiki FAQs
and configuration examples.
3.1 Contact
Gude Analog- und Digitalsysteme GmbH
Eintrachtstraße 113
50668 Cologne
Germany
Phone: [phone]
Fax: [phone]
E-Mail: [e-mail]
Internet: www.gude.info
shop.gude.info
Managing Director: Dr.-Ing. Michael Gude
District Court: Köln, HRB-Nr. 17 7 84
WEEE-number: DE 58173350
Value added tax identification number (VAT): DE 122778228

13
Expert BypassSwitch 8701 ©2016 Gude Analog-und DigitalsystemeGmbH
Support
