GULPA AP1211 User manual

Air Purifier
AP1211

1
Thank you for choosing our products. Please read the
instruction manual carefully for safe and efficient use of this
product.
First of all, thank you for choosing the Air Purifier. I hope you
have a healthy and comfortable living environment.
The problem of indoor air pollution is serious, and indoor air
pollution mainly comes from natural air pollution, pollen, dust
mites, Harmful gases (formaldehyde, second-hand smoke,
sweaty body odor and other substances and odors.)
Because of the existence of these sources of pollution,
people often have adverse reactions such as dizziness,
drowsiness, cough, and nausea. Air quality of the room is
important to your health.
We hope that by using the Air Purifier, you and your family
will have a healthier and more comfortable living environment.
Dear user:
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of
Warning

2
the appliance in a safe way and understand the hazards
involved . Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
Prior to cleaning or other maintenance, the appliance must
be disconnected from the supply mains.
Safety Precautions
In order to prevent damage to users and other personnel
and to avoid property damage, please be sure to observe
the following:
Never use liquids to clean air purifiers such as water,
detergents or flammable solvents.
When cleaning the air purifier, Please disconnect the
purifier from the power source. Wipe it only with a soft rag.
This air purifiers use precision components. Please use it
properly to prevent it from falling or being damaged!
Keep the air purifiers around unobstructed. Do not cover
the Air Purifier’s air inlet and outlet.
For the environmental protection to do a part of your
effort. Never discard the purifier with household waste.
Bring the purifier to a nearby official garbage collection
center. Filters are classified as household rubbish

3
1
2
3
4
Product usage guide
product structure
(As shown below）
1. Main body 2. HEPA Filter
3. Aromatherapy sponge 4. Bottom cover

4
Function introduction
1. Control Panel
Icon Function Description
Power on/off
Negative ion button
Filter reset
Timing adjustment 1H→2H→4H→8H
Wind speed adjustment“Low”→“High” → “Auto” → “Sleep”
2.Standby
Insert the plug of air purifier into power source, the buzzer will ring, and all the
indicators will lighten. After three seconds, air purifier is in standby mode, “power
button” indicator lights up, and the other icons do not lights up.
3. Power on/off
Tap the top power icon to switch the power on and off, the default wind speed is
low, negative ion off.
4. Speed button
Wind speed adjustment “Low”→ “High” → “Auto”→ “Sleep”, Loop in
turn.
5. Negative ions
Touch the negative ion icon to turn the negative ion function on or off. The full
light of the icon light turns off the negative ion function, and the icon light flashes to
turn on the negative ion function.
4h
8h
1h
2h
Sleep
Low
High
Auto

5
6. Replace the filter
When the air purifier is turned on, it will count down, turn off the air purifier and restart,
it will continue to count down. When the filter replacement is accumulated for 2000
hours, the replacement filter indicator light will flash, and the buzzer will beep. After
replacing the new filter, keep pressing the filter reset icon for three seconds icons light
fully light up and do not flash. At the same time the buzzer is turned off.
7.Timing Function
Touch the timing icon , adjust the countdown shutdown time 1H 2H 4H 8H Loop
in turn.
8. Sleep stalls
Touch the wind speed adjustment icon , adjust to the sleep gear position, enter the
sleep mode, all the lights are off, only the wind speed icon light and the sleep gear light
are half bright, touch the wind speed icon to exit the sleep mode.
Instructions
※Before you turn on the machine for the first time, be sure to remove the filter bag
before you use it.
1、Air purifier filter installation
Grasp the bottom cover handle by hand (the position shown by the arrow in Figure 1)
and turn the bottom cover in the direction of unlocking. Then take out the filter (the
item shown by the arrow in Figure 2), remove the filter bag, and put the filters back,
then insert the bottom cover into the fuselage and turn it in the direction of the lock.
Bottom cover rotating handle
Filter bag
Figure 1 Figure 2

6
2、Aromatherapy function
There are two special perfume sponges inside the bottom cover of the machine. You
can drop the perfume of your favorite scent onto the sponge (as shown by the arrow
in Picture 3). When the machine is working, there will be a trace of wind passing
through this area, and the scent will slowly emanate with the breeze, giving you a
more comfortable living environment. You can also choose to put the fragrance
particles your own preferences into it. Remove the sponge when using the fragrance
particles (as shown by the arrow in Picture 4).
Air quality indicator
1. The machine is equipped with a high-precision particle sensor. After starting the
machine, it automatically checks the content of particles in the air near the machine.
At the same time, it is displayed by the light in the machine after the chip is convert-
ed (as shown by the arrow in Picture 5).
2. There are 4 colors of air quality indicator, which are blue, green, purple and red.
Blue means that the harmful gas content in the air is very low (air quality is excel-
lent), green means less harmful air in the air (air quality is good), and purple means
that the harmful gas content in the air has not reach to standard (air quality
"Medium"), red means harmful gases in the air excessive content (poor air quality)
Two perfume sponges
Two perfume sponges
Picture 3 Picture 4

7
Picture 5
Air quality indicator
Sensor detection port

8
FAQ
Press the power button does not turn on
Is the power plug plugged in?
Is the fuse in your home broken?
Is it a power outage?
Is the front cover installed correctly or stuck in wrong
place?
Please contact customer service center for other
abnormalities or malfunctions.
The sound is very noisy
Whether the machine is placed has deflection
Uneven floor
Whether the filter is blocked or needs to be replaced
The air inlet is blocked
Please contact customer service center for other
abnormalities or malfunctions.
Please make sure to check the long-term used air purifier
There is burnt smell, power cord, plug
abnormal heat
High operating noise
Frequent start of leakage insurance
Other abnormalities or malfunctions
Are
there
any
such
phno
mena?
Please cut off the power,
unplug and contact the
dealer.

9
Precautions when place
1. Use in a flat and strong place to avoid short circuit, electric leakage, fire,
etc. due to dumping during use.
2. Use in places where water is not easily accessible, avoiding the cause of
short circuit and fire
3. Do not place containers such as vases of water on the body of the machine
to avoid insulation cracking after seepage into the machine, causing leakage,
short circuit, fire and damage to this product.
4. It is not used in places where oil or flammable gas may leak, so as to avoid
leakage and concentrated around the machine, which may cause fire or fire.
5. It is used indoors and is not used in places where there is direct sunlight and
is exposed to rain.
Precautions when using
1.Please do not block the air inlet and outlet of the product to avoid
overheating inside the machine and damage the product.
2. Not placed next to the heating appliance, there is a possibility that
the melting body will cause a fire.
3. Do not dismantle the product for renovation, to avoid fire, electric
leakage, injury.
4. In the case of long-term no use, remove the plug from the socket
for safety.
5. Do not move the product while the machine is working, to avoid leakage.
6. Unplug the power cord when cleaning the product, replacing or
cleaning the filter.
7. After the machine has stopped running for 3 minutes, the front panel
can be opened to prevent the wind wheel from being damaged by inertia.
8. Do not sit on the body of the machine to avoid injury from tilting or
tipping over.
9. Does not cause damage to the power cord, the weight, clamping,
and lifting will cause the power cord to break, causing short circuit,
poor contact, fire, etc.
Note
Warning
Product name：Air Purifier
Model：AP1211
Rated voltage：220V-240V
Rated power：50Hz-60Hz
Rated power：30W
Dimension：228*228*324mm
Weight：2.5kg
Technical Parameters
