Gurin GSI-110 User manual

1
Steam Inhaler
Model Number: GSI-110
Gurin Products, LLC
2522 Chambers Road, Suite 100
Tustin, CA-92780
www.gurinproducts.com
To properly use and maintain your Steam Inhaler, please read these instructions
and keep them handy for future reference.
Soft, Flexible Mask
Variable Steam Control
Slide the bar up and down to
increase/decrease steam
Extension Tube
Drain Tank
Power-on Light
Aromatherapy Tank

2
INDEX
Introduction --------------------------------------------------------------- Page 2
Product Identifications ------------------------------------------------- Page 2
Important Safeguards -------------------------------------------------- Page 2
Cleaning and Maintenance ------------------------------------------- Page 3
Operating Your Steam Inhaler --------------------------------------- Page 4
Troubleshooting --------------------------------------------------------- Page 5
Specifications ------------------------------------------------------------ Page 6
INTRODUCTION
Thank you for purchasing the Gurin Steam Inhaler. With proper care and use, your steam inhaler will provide
you many years of therapeutic relief.
This unit operates on standard AC power. Treatments are delivered quickly, safely and conveniently with the
use of tap water.
We encourage you to thoroughly read this guidebook to learn about the features of this product. Any use of
this product other than its intended use should always be avoided.
PRODUCT IDENTIFICATION
Mask
Top Cover
Cover
Nozzle Internal Water heater Tank
Main Body
Suction Tube
Power Cord
Aromatherapy
Tank
IMPORTANT SAFEGUARD
Note:
1. Read all instructions carefully before use
2. The following basic precautions are needed when using an electrical product:
Product cautions:
•To avoid electrical shock: Keep the unit away from water. Do not immerse the power cord or the unit in
liquid. Do not use while bathing. Do not reach for a unit that has fallen into water – immediately unplug the
unit.
Drain Tank
Nozzle Pin
Extension Tube

3
•Never operate the unit if it has any damaged parts (including power cord), if it has been dropped or
submersed in water. Promptly send it to a service center for examination and repair.
•Open top cover during operation is prohibited as it may cause severe injury.
•This unit should not be used where flammable gas, oxygen, or aerosol spray products are being used.
•Never use without water in the water heater tank and unit should not be left unattended while plugged in.
•Disconnect the unit from the electrical outlet before cleaning, filling and after each use.
•Do not use other attachments unless recommended by manufacturer.
•Never add medicine or aromatherapy liquids to the water heater tank
Operating Cautions:
1. Connect this product to an appropriate voltage outlet for your model.
2. Do not run this product unattended.
3. The maximum capacity of aromatherapy tank is 60ml and should not be over filled.
4. The maximum capacity of water heater tank is 25ml and should not be over filled.
5. Change the water in water tanks after each use.
6. If any abnormality occurs, discontinue use immediately until the unit has been examined and repaired.
7. Do not put your eyes on mask when steam is generated.
8. Do not block the vent holes on both sides of mask.
9. Always unplug the product immediately after use.
10. If any discomfort or abnormality occurs, stop using the unit immediately.
Storage Cautions:
1. Do not store the unit under direct sunlight, high temperature or humidity.
2. Keep the unit out of reach of small children.
3. Always keep the unit unplugged while not in use.
4. To store the unit for an extended period of time, open heater cover to keep the heater tank air dry.
Cleaning Cautions:
1. Check the mask, extension tube, tank, suction tube and any other optional components before each use.
Dirty or worn parts should be replaced.
2. Do not immerse the unit in water. It may damage the unit.
3. Disconnect the unit from electrical outlet before cleaning.
4. Clean all necessary parts after each use as instructed in this guidebook.
CLEANING AND MAINTENANCE:
Note: Always disconnect the unit from electrical outlet and never immerse the unit in water.
Important: Do not open the heater tank cover right after use, as the cover might be very hot. Wait for
approximate 10 minutes to allow it to completely cool.
Cleaning the parts:
1. Remove top cover.
2. Carefully remove the one-piece aromatherapy/drain tank from the unit.
3. Rinse one-piece aromatherapy/drain tank with hot tap water.
4. Empty any remaining water from water heater tank (Open tank by turning Water Heater Tank Nozzle
anticlockwise).
5. Wipe out heater tank with a soft, lint-free cloth or allow to completely air dry.
6. Reassemble the Steam inhaler and store in a cool, dry place
Cleaning the main unit:
The main unit should be cleaned with a soft cloth moistened with a non-abrasive cleanser and water.

4
OPERATING YOUR STEAM INHALER
It is important to clean the unit before the first time of use and after each use. For details, see “Cleaning and
Maintenance” in this guidebook.
1. Place the unit on a rigid and flat surface with mask facing
towards you.
2. Gently pull straight up on the cover of the inhaler to remove lid.
3. Remove the nozzle to the water heater tank by turning it
counterclockwise. Fig 3.
Fig 3
4. Using the included measuring cup, fill the water heater tank
with approximately 25ml of tap water. Do not overfill the water
above the five square shaped vents on the wall of the water
heater tank. Note: Do not use anything except water in the
water heater tank. See Fig 4.
5. Reattach heater cover. Make sure it is tightly placed to avoid
leakage of steam.
Fig 4
6. If desired, remove the aromatherapy/drain tank from the unit.
Fill the aromatherapy tank with up to 60 ml of saline or
aromatherapy water. See Fig 5
7. Replace top cover on main body. Make sure the suction tube is
connected to the nozzle and inserted into aromatherapy tank.
Note: Avoid bending the suction tube to allow smooth flow of
water into the nozzle.
Fig 5
8. Position the extension tube to a comfortable position by
manually extending or retracting the tube
9. Place the mask on top cover.
10. Plug power cord into an appropriate electrical outlet for your
model. Make sure the power switch on power cord is at “OFF”
status before plugging.
11. Press on power switch to begin treatment. The lamp at the
bottom of unit will be lit.
12. Adjust the extension tube for a comfortable treatment.
a. Slide the extension tube down for smaller particle size
of steam. This is more comfortable for the inhalation of

5
nose.
b. Slide the extension tube up for bigger particle size of
steam, This is more comfortable for the inhalation of
mouth.
13. After approx. 6-9 minutes, when the steam output becomes
less and weaker, press power switch to shut off the unit.
14. Unplug the unit from electrical outlet.
15. For next use, please wait for 10 minutes to allow the unit to
cool down.
TROUBLESHOOTING:
Should any problems persist after you have made the following checks, return the unit to a nearest service
center for examination and repair.
Condition Checking points Corrective actions
1. Lamp is not lit ▲Check whether power cord is well ▲Firmly insert power cord
connected to the electrical outlet
▲Check whether power switch is at ▲Press on power switch
“ON” status
2. No steam output ▲Check whether lamp is lit ▲Insert power cord and press on
power switch
▲Check if there is no water in heater ▲Fill water
or aromatherapy tank
▲Check if the suction tube is bending ▲Straighten the tube
▲Check if the nozzles are blocked ▲Use attached nozzle pin to make
them through
3. Water leakage ▲Check if the aromatherapy tank is overfilled ▲Pour out some water
▲Check if the unit is tilted. ▲Set flat the unit
4. Steam leakage ▲Check if the heater tank cover is ▲Lock the heater tank cover firmly
firmly locked
▲Check if nozzle is firmly locked ▲Lock the nozzle firmly
Attaching the Nozzle Pin (If there is no steam generated, See below)
Occasionally, the nozzle that directs the steam into the extension tube may become obstructed, nozzle needs
to be cleaned in that case. If there is no steam generated from the heater tank, or water from aromatherapy
tank cannot be pulled, a) shut off the unit and b) unplug it from the mains. Then carefully use the attached
nozzle pin (Nozzle pin is attached at the bottom of the unit) to insert into the nozzles of heater tank and/or
furnish tank to make them through as shown on figure 6.
Nozzle Pin
Fig 6

6
SPECIFICATIONS
Power: 120V/60Hz
Power consumption: Max 300W
Internal Heater tank capacity: 25ml
Aromatherapy tank capacity: 60ml
Water boiling time (waiting time): Around 60 seconds
Treatment time: 6~9 minutes
Overheat auto-cutoff: By thermo-fuse
Safety valves: Dual valves on heater tank cover
Weight: 1 lb 5 oz.
Dimension: 5-1/8” x 3-3/4” x 10”
