guzzle H2O STEALTH User manual

INSTALLATION / OPERATION MANUAL
GUZZLE H20 STEALTH
REV C
pure water. no trash.
GUZZLE H2O LLC WWW.GUZZLEH2O.COM [email protected]
4103 CLOUDVIEW CT, HOOD RIVER OR, 97031 USA
[phone]

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 1
STEALTH USERS MANUAL
STEALTH USERS MANUAL
TABLE OF CONTENTS
CONTENTS PAGE
TABLE OF CONTENTS 1
HAZARD WARNING 2
PART IDENTIFICATION 3
SYSTEM OVERVIEW 5
INSTALLATION 6
WIRING DIAGRAM 7
OPERATION 8
INDICATOR LIGHTS 9
CHANGING THE CARBON BLOCK CARTRIDGE 10
WINTERIZATION 11
TIPS AND TROUBLESHOOTING 12
SYSTEM SPECIFICATIONS 13
-END OF MANUAL-

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 2
STEALTH USERS MANUAL
MICROBIOLOGICAL HAZARD
Human consumption of untreated water can lead to exposure to harmful microorganisms and an
increased risk of gastrointestinal illness. Operating this filtration and purification device incorrectly
increases your risk of exposure to harmful microorganisms and increases your risk of gastrointestinal
illness. Reduce your chances of becoming sick by following the warnings and instructions in the
operator’s manuals.
Guzzle H2O products are designed to reduce unwanted bad taste & odor, chlorine, VOCs, lead,
mercury, and other contaminant particles as small as 0.5 micron in size. Guzzle H2O products are 3rd
party tested in accordance with US EPA Guidlines for Ultraviolet Disinfection to inactivate 99.99% of
viruses, protozoa, and bacteria. Guzzle H20 products do not remove toxins, heavy metals, or treat
chemically contaminated water, and will not make potable water from sources with these
contaminants. The inlet hose, and prefilter apparatus should be kept away from the outlet hose to
avoid cross contamination. When in doubt, treated drinking water should be tested by the user to
verify its safety to consume.
WARNING


STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 3
STEALTH USERS MANUAL
STEALTH PART IDENTIFICATION
ITEM NO. DESCRIPTION QTY.
1 MOUNTING PLATE, BIDIRECTIONAL, STEALTH 2.0, ALUMINUM, ANODIZED, BLACK 1
3 5 INCH FILTER HOUSING CANNISTER 1
4 CARBON BLOCK CARTRIDGE 1
8 INLET, 3/8 PUSH TO CONNECT 1
9 OUTLET, 360 DEGREE SWIVEL, 3/8 PUSH TO CONNECT 1
10 MOUNTING BRACKET, ANGLE AL, ANODIZED BLACK 1
12 WASHER, FLAT BLACK OX SST 4
13 HEX NUT, NYLOCK, 10-24, 18-8 SST BLACK OX 2
15 WOOD SCREW, PHIL HEAD, NO 10, 0.75 LG, 316 SST 2
17 SHCS, 0.190-24, 0.625 LG, 18-8 SST, BLACK OX 2
24 POWER CABLE, 15'
25 STRAIGHT ADAPTER, .375 TUBE X .5 BARB 2
26 STRAIGHT ADAPTER, .375 TUBE X .375 BARB 2
27 HOSE CLAMP, WORM DRIVE, SST 2
28 O-RING, FILTER CANNISTER SEAL 1

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 4
STEALTH USERS MANUAL




;

;

;

;

;

;

;



;

;


25
25
PART IDENTIFICATION (CONTINUED)

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 5
STEALTH USERS MANUAL
STEALTH SYSTEM OVERVIEW
System layout:
The Stealth should be installed on the cold water line between the pump or pressure tank and the
point of use faucet. Ideally the Stealth should be the last thing the water passes through before
the faucet. Water should enter through the Inlet (8). Water exits through the Outlet Elbow Swivel
(9).
Mounting:
The Mounting Bracket Angle (10) may be attached to the Mounting Plate (1) on either side to
accommodate the inlet connection (8) on either the right hand or left hand side to accommodate
the incoming plumbing configuration. The Outlet Elbow (9) may be swiveled 360 degrees to
leave acommodate outlet plumbing.
Electrical Supply
The Stealth requires 12v power supply, drawing 2 amps when activated. A 2 amp fuse is recom-
mended. See Page 8 for Wiring Diagram.
Operation:
The Stealth has a flow sensing switch which detects water flow and instantly turns itself on. The
Stealth will sense that water is moving when you open the faucet. It draws minimal power when
it is in standby mode. LED technology allows it to instantly switch on the UV chamber with no
warm up necessary.

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 6
STEALTH USERS MANUAL
STEALTH INSTALLATION
1) Turn off water supply, and/or all pumps supplying pressure to the water system.
2) Determine plumbing layout. Stealth may be mounted with inlet (8) on the right or
le hand side of the unit. Outlet elbow (9) may swivel 360 degrees to accommodate
outlet plumbing. Plan for adequate space for inlet and outlet plumbing to have a clean
approach, and to be secured to minimize movement and vibration when installation is
complete.
3) Install Mounting Bracket (10) to mounting surface. Using the Mounting Bracket as a
template, mark 2 screw locations and drill pilot holes with a 3/32 (0.094) inch drill bit.
Install Mounting Bracket (10) with provided Wood Screws (15). If mounting in a materi-
al other than wood or plastic, substitute appropriate fasteners.
4) Unscrew the Filter Housing Cannister (5) and set aside.
5) Using Socket Head Cap Screw (17), Washers (12), and Hex Nuts (13) attach the
Mounting Plate (1) to the Mounting Bracket Angle (10). The Stealth may be mounted
using the holes on either side to orient the inlet and outlet appropriately for the installa-
tion plumbing.
6) Select appropriate size barbed fitting (25 or 26) for inlet and outlet hose. Install the
Barbed Fittings (25 or 26) into inlet and outlet hoses. Use provided hose camps (27) to
secure hose on barbed fittings.
7) Connect power cable cable (15) to power supply. Cable with dashed grey stripe
connects to positive (+) terminal (see page 8). Blank cable connects to negative (-)
terminal. Connect barrel plug to underside of UV unit. Green indicator LED shows UV
is connected to power and in STANDBY mode.
8) Install Carbon Block Cartridge (4) and Cartridge Housing (3) making sure O-ring
(28) seats in groove in cannister (3). Tighten firmly by hand.
9) Turn on water supply. Determine that there are no leaks.
10) Test operation. Blue indicator LED should illuminate when water flows, indicating
UV system is active. Blue LED should turn off when water flow stops.

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 7
STEALTH USERS MANUAL
WIRINGDIAGRAM
WIRING DIAGRAM
POWER CABLE 2 X 16 AWG (ITEM 24)
BLACK W/ GREY DASH POSITIVE (+)
BLACK NEGETIVE (--)

STEALTH OPERATION
When power is connected to the Stealth, the green indicator LED illuminates to indicate
it is on STANDBY MODE (see page 8). In this mode, the Stealth is ready to purify water,
but has not yet activated the UV purification chamber.
The UV purification function of the Stealth activates automatically by sensing water flow
and activating the UV purification chamber when water is moving. A few seconds aer
the water stops, the Stealth turns the purification chamber off. Water flow typically is
started and stopped by using your faucet. UV purification activity is indicated by the
BLUE LED indicator light.
LED technology allows the UV purification chamber to instantly activate and perform at
full effectiveness. The UV chamber does not require any time to “warm up.”
The Stealth can be le on STANDBY MODE indefinitely. The UV function should only
activate when water is running.
STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 8
STEALTH USERS MANUAL

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 9
STEALTH USERS MANUAL
INDICATOR LIGHTS
COLOR: BLUE
UV ACTIVE
COLOR: GREEN
POWER ON
STANDBY MODE

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 10
STEALTH USERS MANUAL
CHANGING THE CARBON BLOCK CARTRIDGE
Carbon block filters should be changed aer 1000 gallons of use. Actual capacity may
vary depending upon quality of water filtered. Reduced water flow rate through filter
or at the faucet is an indication that the carbon block filter element should be changed.
HOW TO CHANGE CARBON BLOCK CARTRIDGE
Turn off water pump, and open faucet to drain and depressurize water line. Place a
bucket or towel below Stealth to catch any water that may drain. Unscrew carbon
block filter cannister (3). Use a filter wrench if necessary. Locate the o-ring (28) on the
perimeter of the cannister. Drain water and remove carbon block element (4) . Place
new carbon block filter element in the cannister. Make sure cannister o-ring (28) is
properly seated and cartridge gaskets are in place. Thread the cannister onto filter
housing base. Make sure top and bottom of filter cartridge is centered on mounting
See below for list of acceptable replacement filters. Tighten cannister firmly, making
sure o-ring seals. Turn on water pump, let water run. Run 5 gallons of water through
system to dislodge and remove any loose carbon fines. Close faucet and check for
leaks.
Replacement Carbon Block Cartridges
Guzzle H2O 5” Carbon Block Cartridge
Pentek CB-5
LED CHAMBER LIFESPAN
The LED UV chamber has a lifespan of 10,000 hours of activated operation. It does not
need to be replaced as a maintenance item. Contact Guzzle H2O should you require
replacement.

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 11
STEALTH USERS MANUAL
WARNING

FREEZING TEMPERATURES CAN DAMAGE STEALTH AND CAUSE
WATER SYSTEM LEAKS AND DAMAGE
Temperatures below 32 degrees F (0 degrees C) can damage the
Stealth causing leaks and loss of peformance. Follow
WINTERIZATION PROCEDURES to prepare Stealth for freezing
conditions.
WINTERIZATION PROCEDURES
In below freezing temperatures, water MUST be removed from the Stealth. Unscrew
the carbon block filter canister and remove the carbon block cartridge. Open faucet.
Use an air compressor to inject air into the outlet hole in the center of the filter housing.
Pulse air into the outlet hole until no more water comes out of the faucet. Reinstall the
filter cannister without the carbon block element. Allow carbon block element to dry,
and store for reinstallation.

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 12
STEALTH USERS MANUAL
STEALTH SYSTEM TRICKS AND TROUBLE SHOOTING
1) Secure all hoses and cables connecting to the Stealth. Loose and vibrating connections can
lead to water leaks and faulty electrical connections.
2) After replacing carbon filter cartridge with a new filter, some visible black carbon fines may be
dislodged in new carbon filter. This is normal, allow approximately 5 gallons of water to pass to
remove carbon fines.
3) For best performance, filter and purify water as close to point of use as possible. The Stealth
should be the last thing your drinking water passes through before faucet. For whole system
filtration, consult Guzzle H2O.
4) Carbon filter will cause a pressure drop in line pressure as it filters water. This may cause
automatic pressure water pumps to cycle on and off as pressure limit is reached. This is normal.
Adjust pump pressure to accommodate, or consult Guzzle H2O for higher flow options.
5) Stealth should be installed in a protected, watertight area. It is not made for outdoor installa-
tion.
6) To disconnect push to connect inlet and outlet fittings, depress collar around tube, and pull
tubing insert.
7) Periodically clean onboard water tanks by shock treating with bleach or chlorine. This will
reduce buildup of contaminants. The carbon block filters will do an excellent job of removing any
residual chlorine from cleaning efforts.
8) The Stealth requires water to be running while it is activated in order to cool internal LED com-
ponents.

STREAM OPERATION AND
MAINTENANCE MANUAL
PAGE 13
STEALTH USERS MANUAL
PRODUCT SPECIFICATIONS AND CAPACITIES
MAXIMUM FLOW RATE; TAP WATER: 1.1 GALLONS (4 LITRES) / MIN
MAXIMUM FLOW RATE; PUMPING WATER: .7 GALLONS (2.7 LITRES) / MIN
FLOW RATES AND CAPACITIES ARE FOR IDEAL CONDITIONS. FLOW RATES AND CAPACITIES MAY
BE REDUCED BY CARBON BLOCK FILTER AGE, WATER PRESSURE, HEAVY SILT
ACTIVATED CARBON BLOCK FILTER 0.5 MICRON NOMINAL
4.95 X 2.875 INCH SIZE
REDUCES: sediment, chlorine taste and odor, VOCs, NSF 41 emerging contaminants, lead, mercury, and other
chemical contaminants. Will not remove heavy metals or toxins
1000 gallon capacity
LED UV-C PURIFICATION: 99.99% REDUCTION IN PROTOZOA, BACTERIAL, AND VIRUSES
Based on 3rd Party Testing to US EPA Ultraviolet Disinfection Guidance Manual
Tested and Certified by NSF International against NSF Standard 55 for Materials and Structural Integrity
10,000 hour lifespan
MAXIMUM SYSTEM PRESSURE 120 PSI
MINIMUM SYSTEM PRESSURE 30 PSI
POWER DRAW ACTIVE 2 AMP
POWER DRAW STANDBY MODE 0.1 AMP
NSF LISTED AND FDA APPROVED MATERIALS
