Guide to the Appliance
2
1. STANDBY INDICATOR: Used to visually show power state of the set top box,
the green LED will be light if turned on the set top box and the red LED will be
light if the set top box entered standby mode.
2. REMOTE CONTROL SENSOR: Used to receive the signal from the remote
control.
3. USB JACK(Optional): Used to connect to an external USB 2.0 device.
Note: Not all receivers have the USB Jack.
2 3
1
Front panel
1 2 34 5 6
1. RF IN: This socket allows you to connect your external aerial.
2. COAXIAL: This socket allows you to connect the Set Top Box to a compatible
surround sound system.
3. HDMI OUT: This socket allows you to use your HDMI cable for a premium
high definition connection.
4. VIDEO: This socket allows you to connect your Set Top Box via Composite
Video Signal.
5. AUDIO L/R: This socket allows you to connect your Set Top Box to receive the
Audio L/R signal.
6. POWER INPUT: This socket is where you connect your main power to the unit.
Rear panel

Remote control
Guide to the Appliance
1. MUTE: Mute or Restore Audio Output.
2. INFO: Displays additional channel information.
3. TTX: Displays Teletext Information.
4. SUBTITLE: Selects Subtitles Language.
5. EXIT: Exits the current Menu or returns to the
previous Menu.
6. OK: Confirms an entry or selection. Displays
the list of channels.
7. RIGHT / LEFT: Navigates through the Menus.
Increases or decreases volume.
8. TV/RADIO: Switches from TV function to Radio
function and from Radio to TV.
9. RECALL: Used to switch between the last two
viewed channels.
10. GOTO: Selects the play time of media.
11. PREV: Skips to the previous track during.
playing media and skips to the previous channel
during playing DTV.
12. NEXT: Skips to the next track during playing media
and skips to the next channel during playing DTV.
13. REPEAT: Selects Repeat or turn off Repeat mode.
14. STOP: Stops media play.
15. STANDBY: Switch the product to on or standby.
16. EPG: (Electronic Program Guide)Turns the program
guide on.
17. AUDIO: Selects an Audio Language or Audio Mode.
18. UP / DOWN: Navigates through the Menus. Selects
the next or previous Channel.
19. MENU: Turns on Main Menu.
20. FAVOURITE: Turns on Favourite Menu
21. 0-9 (Numeric Buttons): Selects a channel or setting.
22. FWD: Searches forwards during media play.
23. REV: Searches backwards during media play.
24. PLAY: Starts or resumes media play.
25. PAUSE: Pauses media play.
26. COLOUR BUTTONS: Operate different function in TEXT screen.
27. REC: Used to record the program.
28. LIST: Used to show the record program list on the current disk.
(Also used with the USB play/record functions.)
3

Caring for the Environment
Responsible disposal of the packaging
The packaging of your appliance has been selected from environmentally
friendly materials and can usually be recycled. Please ensure these are
disposed of correctly.
Plastic wrapping can be a suffocation hazard for babies and young children,
please ensure all packaging materials are out of reach and are safely disposed
of. Please ensure they are offered for recycling rather than throwing these
materials away.
Responsible disposal of the appliance
At the end of its working life, do not throw this appliance out with your
household rubbish. An environmentally friendly method of disposal will ensure
that valuable raw materials can be recovered and used again.
Electrical and electronic appliances contain materials and substances which, if
handled or disposed of incorrectly, could be potentially hazardous on the
environment and human health.
4

Safety Information and Warnings
Important safety instructions
Warning: To reduce the risk of electric shock, do not remove the cover or back.
There are no user-serviceable parts inside. Refer servicing to qualified personnel.
•Warning: To prevent fire or electric shock hazard, do not expose the unit to
rain or moisture.
•Do not expose the Adaptor and Digital Set Top Box to water (dripping or
splashing) and no objects filled with liquids, such as vases, should be placed
on the unit.
•Keep the product away from direct sunlight and heat source such as radiators
or stoves.
•Do not block the ventilation openings. Slots and openings on the unit are
provided for ventilation. The openings should never be blocked by placing
your product on a cushion, sofa or other similar surface.
•Do not place the product on unstable cart, stand, tripod, bracket or table. The
unit may fall, resulting in possible damage or injury.
•Only use the AC adapter included with product. Using any other adapter will
void your warranty.
•Unplug the power from the outlet when the unit is not in use.
•Attention should be drawn to the environmental aspects of battery disposal.
•Warning: The battery (battery or batteries or battery pack) shall not be
exposed to excessive heat such as direct sun light, fire or similar.
•Warning: Only use attachments/accessories specified provided by the
manufacturer, the product is powered by the AC adaptor.
•Please ensure enough clearance around the set top box for good ventilation.
Any objects and set top box should be at least 10 cm apart.
•No naked flame source, such as lighted candles, should be placed on the set
top box.
5

Safety Information and Warnings
The symbol indicates that dangerous voltages that may pose a risk of
electric shock are present within this unit.
The symbol indicates that there are important operating and
maintenance instructions in the literature accompanying this unit.
This symbol indicates that this product incorporates double insulation
between hazardous mains voltage and user accessible parts. when
servicing use only identical replacement parts.
Caution:
When the set top box is under certain electronic state maymalfunction
and need to be re-set by the user and need to resetby user.
The USB memory stick should be plugged in the unit directly. USB extension
cable should not be used to avoid failing of data transferring and
interference caused.
This marking indicates that this product should not be disposed with
other household waste collections.
6

Getting Started
Installing the batteries
Remove the battery cover from the remote control and put 2xAAA size
batteries inside the compartment.
The diagram inside the battery compartment shows the correct way to install
the batteries.
Using the remote control
To use the remote control, point it towards the front of the Digital Set Top Box.
The remote control has a range of up to 7 metres from the Set Top Box at an
angle of up to 60 degrees.
The remote control will not operate if its path is blocked.
Sunlight or very bright light will decrease the sensitivity of the
remote control.
7
1.Open the cover 2. Install batteries 3. Close the cover

Caution: Make sure to check the voltage specification of the wall outlet is the
same rating with the receiver. To prevent the risk of electric shock, do not open
the cover or the back of the receiver.
Getting Started
Note:
1.When connecting the receiver to other equipment, e.g., TV, VCR and amplifier,
make sure to refer to relevant user manual for instruction. Also, make sure you
disconnect all the equipments from the mains supply before the connection.
2. No video output from scart if HDMI output is connected to TV.
8

Operation Instructions
First time Installation
After all connections have been made properly, switch on TV and make sure the
receiver is connected to the Main Power. Press Power button to switch receiver
on. If you are using the receiver for the first time or restored to Factory Default,
the Main Menu will appear on your TV screen.
(1) Select [Country] and press RIGHT/LEFT key to select your country of residence.
(2) Select [Channel Search] and press RIGHT or OK key to begin Automatic
channel search.
(3) Once channel tuning is complete, you are now ready to watch TV.
Basic operation
(1) Program Manage Settings
To access the Menu, press the MENU button and select [Program].
The Menu provides options to adjust the Program Manage Settings. Select an
option and press OK or RIGHT to adjust that setting. Press the EXIT button to exit
the Menu.
(2) Program Edit
To edit your program preferences (lock, skip, favourite, move or delete), you will
need to enter the Program Edit Menu. This Menu requires a password to access.
Enter the default password '000000'.
