GVC SL5598 User manual

Advanced Pentium Motherboard
SL5598
USER’S MANUAL
Copyright 1998 GVC CORPORATION. ALL RIGHTS RESERVED.

DECLARATION
Rights:
No part of this manual, including but not limited to the products and
software described in it, may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated in any form or by any means
without the express written permission of GVC Corporation or BCM
Advanced Research, Inc.
Products and corporate names appearing in this manual may or may not be
registered trademarks or copyrights of their respective companies and are used
only for identification or explanation purposes without intent to infringe.
♦Intel, MMX and Pentium are registered trademarks of Intel Corporation.
♦IBM and OS/2 are registered trademarks of International Business
Machines.
♦AWARD is a registered trademark of American Megatrends Inc.
♦Winbond is a registered trademark of Winbond Electronics Inc.
Responsibility:
This manual is provided “As is” with no warranties of any kind, either expressed
or implied, including, but not limited to the implied warranties or conditions of
this product’s fitness for any particular purpose. In no event shall we be liable for
any loss of profits, business, or data, interruption of business, or indirect, special,
incidental, or consequential damages of any kind, even the possibility of such
damages arising from any defect or error in this manual or product. We reserve
the right to modify and update the user manual without prior notice.

COMPLIANCE & CERTIFICATE
ISO 9001 Certificate:
This device was produced in our plant with advanced quality
system certified by DNV QA Ltd. in accordance to ISO 9001.
This Certificate is valid for:
DESIGN & MANUFACTURE OF MOTHER BOARDS
AND PERSONAL COMPUTERS.
CE Declaration:
CE marking is a visible declaration by the manufacturer or
his authorized representatives that the electrical equipment
to which it relates to satisfy all the provisions of the 1994
Regulations.
FCC Compliance:
FCC stands for Federal Communications Commission.
This product complies with FCC Rules Part 15 and has
been tested, and complied with the EMI rules by a certified
body. In normal operation this device will not cause any
harmful interference nor shall this device accept any
interference received, including interference that may cause
undesired
operation of this product.
Microsoft Windows Compliance:
Microsoft, Windows NT, Windows, and the Windows Logo are
registered trademarks of Microsoft Corporation.

EASY INSTALLATION
The following “Easy Installation” steps are
intended for users familiar with the assembly
of a computer system. For those individuals
requiring more specific information please
refer to the more detailed descriptions located
within the later chapters of this manual.
Note: You must keep your power cable unplugged until theNote: You must keep your power cable unplugged until the
following installation steps are completed.following installation steps are completed.
Getting Started:
Touch a grounded metal surface to release static electricity
stored in your body before unpacking your motherboard. For
details please refer to Precaution section in Chapter 3.
Install the CPU by correctly aligning the CPU with the Socket7
as noted in the motherboard diagram. Once aligned, press down
on the CPU gently but firmly and lock it into place.
Install either the 3.3 volt unbuffered SDRAM into the 168 pin
DIMMs or FPM/EDO DRAM into the 72 pin SIMMs. See Sec.
3.2 & Sec. 3.3.
Set CPU speed jumper in accordance to Sec.3.2.
After completing the above 3 steps, install any expansion
cards ( PCI, ISA) into riser card and have the riser card installed
firmly into the slot for riser card on board. See Sec. 3.4.
Plug in all cables included in the package except for the
power cord. Please see Sec. 3.5.
Recheck all steps to ensure no mistakes have been
made and then plug in the power cord and turn on the
power to enter the BIOS setup, Chapter 4.
Release
Static Electricity
Couple
Connectors Of
HDD, FDD…
Install All
Expansion Slots
Set Jumpers of
CPU Speed
Insert CPU &
RAM

EASY INSTALLATION

CONTENTS
1. INTRODUCTION
How To Use This Manual Page 8
Check Your Device Items Page 8
2. FEATURES
Photo of the Motherboard Page 9
Features of the Motherboard Page 10
3. INSTALLATION
Motherboard Layout & Main Parts Page 12
Significant Parts List Page 13
Precaution before Start Page 14
3.1 Slots and Connectors Page 15
3.2 CPU Page 16
3.2.1 Install CPU
3.2.2 Arrange Jumper Settings
3.2.3 Other Jumper Settings
3.3 System Memory ( DRAM ) Page 21
3.3.1 SIMM and DIMM
3.3.2 Installation Procedure
3.3.3 Memory Module Combinations
3.4 Expansion Slots Page 24
3.5 Connectors Page 26
3.5.1 Primary IDE Connector
3.5.2 Secondary IDE Connector
3.5.3 Floppy Drive Connector
3.5.4 Power Input Connector
3.5.5 Front Panel Connectors & IrDA Connector
3.5.6 Back Panel Connectors
3.5.7 Additional Connectors

CONTENTS
Ready To Turn On Power Page 33
4. BIOS SETUP
4.1 How to Enter BIOS Setup Page 35
4.1.1 Setup Keys
4.1.2 Getting Help
4.1.3 In Case of Problems
4.2 Main Setup Menu Page 37
4.3 Standard CMOS Setup Menu Page 39
4.4 BIOS Features Setup Menu Page 43
4.5 Chipset Features Setup Menu Page 46
4.6 Power Management Setup Menu Page 47
4.7 PNP/PCI Configuration Setup Menu Page 50
4.8 Integrated Peripherals Menu Page 52
4.9 Load Setup Defaults Page 54
4.10 Supervisor Password Page 54
4.11 User Password Page 54
4.12 IDE Auto Detection Page 54
4.13 Save & Exit Setup Page 55
4.14 Exit Without Saving Page 55

1. INTRODUCTION
How To Use This Manual
This manual provides information
necessary for Original Equipment
Manufactures (OEMs) and home users to
build a PC-AT compatible system using
the Pentium PCI/ISA motherboard.
Follow the installation procedure
presented on the “EASY INSTALLATION” page. Each step refers to
another section within this manual where you will find more detailed
information if needed.
Check Your Device Items
The standard package will contain the
following items marked with a “4”, If
you find any these items missing or
damaged please contact your retailer
immediately.
4The SL5598 motherboard
41 IDE ribbon cable
41 floppy ribbon cable
41 CD-ROM Diskette with VGA Driver
8Infrared (IrDA) module with ribbon cable (optional)

2. FEATURES
Photo Of The Motherboard

2. FEATURES
Features Of The Motherboard
The SL5598 motherboard integrates the Pentium
microprocessor, memory, I/O and is designed to fit
into a standard LPX form factor chassis. Page 12
illustrates the layout for the SL5598 motherboard.
Below are the key features provided by this
motherboard:
Processor/Cache
Processor Intel/AMD 75 ~ 300 MHz
Cyrix 6X86 & 6X86L, PR120+ ~ 166+
Cyrix 6X86MX, PR133 ~ PR233
IDT-C6 150 ~ 200
Cache 0/256/512KB, Write Back or Write Through Direct Mapped organization,
Pipeline Burst Cache soldered on the motherboard.
System Memory
Memory Size 8 MB minimum to 256 MB maximum.
Memory Sites 4 SIMM Sockets, 2 DIMM Sockets, Burst Mode Read-Write support.
DRAM Type Supports EDO/FPM DRAM type can be 1M, 2M, 4M, 8M, 16M bit deep
by n bit wide DRAM’s, and both symmetrical and asymmetrical type
DRAM are supported. Suports SDRAM 1M, 2M, 4M, 8M, 16M, 32M bit
deep by n bit wide DRAMs, and both single and double sided.
Access Time 70ns or faster for FPM/EDO or 60ns or faster for SDRAM
Chipset SiS5598 Pentium PCI/ISA Chipset.
Integrated Graphics
Graphics Controller SiS5598 integrated VGA Controller.
Video Memory UMA supports 0.5M ~ 4M FPM/EDO DRAM and SDRAM.
Integrated I/O
I/O Controller Winbond W83877TF
Serial Ports Two Asynch serial ports, two 9 Pin connectors using High Speed 16550
compatible ports with 16-byte FIFOs
Infrared Interface One 6 pin infrared port with IrDA and ASKIR
Parallel Port One 25 pin supporting EPP, ECP and Centronics
Hard Disk Controller PCI Bus Mastering IDE. Native and Compatible Mode Support. IDE
Transfer with Scatter Gather. Multiword DMA Transfers Mode 0,1,2.
Enhanced IDE PIO Modes 3 & 4. Separate IDE Bus FIFOs for PCI burst
transfers. Supports Ultra DMA/33 Bus Master Programming Interface for
ATA windows 95 Compliant Controller. Plug and Play Compatible.
Hard Disk Connector 2 PCI IDE Connectors for 4 Drives Support

2. FEATURES
Floppy Controller 1.2, 1.44 and 2.88 MB support
Keyboard Port PS/2 (Integrated in the SiS5598)
Mouse Port PS/2 (Integrated in the SiS5598)
Real Time Clock Integrated in the SiS5598
Serial Bus USB (Universal Serial Bus), Microsoft and Intel spec. compliant, integrated
in the SiS5598.
Integrated Sound (Optional)
Sound Chip ESS1869 3D Audio Chip
CODEC Built-in, 16-bit Stereo
FM Synthesis Yamaha OPL3 compatibility (Included with ESS1869)
Wavetable sound ESS ES692S-100 Single Chip Wavetable (optional)
Integrated Hardware Monitor (Optional)
Hardware monitor Winbond 83781D(optional), 2 thermistor temperature sensors, 4 positive
voltage input, 2 op amps for negative voltage monitoring, 1 fan speed
monitoring
System BIOS
BIOS Type AWARD Software Inc., 2MB Flash BIOS
Hard Disk Driver IDE, Auto-configuring
Plug&Play Support Steerable DMA Channels and Interrupts. ISA Plug&Play
Special Features Windows 95 ready. Multi-Boot. PCI add-in card auto-configuration.
Power Management
Green Features APM1.2. Meets EPA Mod 2.0 (SMI, Stop Clock, HDD and Upgrade
Monitor Shutdown)
Jumpers and Front Panel Connectors
Connectors PC Speaker. HD LED. Power LED. K/B Lock, Reset Switch, Sleep Switch, CPU
FAN, Chassis Fan.
Jumpers CPU Speed. CPU Multiplier. Clear CMOS, External VGA Selection.
Headers and Rear Panel Connectors
Headers Floppy. IDE 1&2. IrDA. CD-IN. Feature connector. MIDI/AUDIO.
Connectors VGA Port. Serial 1&2. Keyboard & Mouse. Parallel port. USB 1&2. (Line
In, Line Out, Mic In, MIDI, Modem-In on Audio Paddle Card)
Mechanical
Board Style LPX form factor
Board Size/Type 9.0” x 11.0”, four layer board
Expansion Slots
Description One EISA riser slot for ISA and PCI buses

3. INSTALLATION
Motherboard Layout & Main Parts
VGA Parallel COM2 COM1 Mouse Keyboard USB USB
Power Connector WOL
Floppy
Winbond W83877TF
SRAM
Flash
BIOS
ESS
1869A
Winbond
W83781D
MIDI / Audio
Feature Conn.
CD-IN
Riser Connector
IDE Secondary
IDE Primary
ES692
SIMM1
SIMM2
SIMM3
SIMM4
DIMM1
DIMM2
Clock
Gen.
JP7
JP8 JP9
JP10 JP11 JP12
JP15
JP16
JP17
RTC
Battery
CPU SiS5598
Tag
RAM
JP4
JP5
JP13
JP14
Chassis Fan
Front Header
J21
J19
J18
J15
J12
J8
J2
J3
J6
J9
J22
J24
J25
J16
J14
JP1
JP2
JP3
J27
CPU Fan
J26
J23
J20
J17

3. INSTALLATION
Significant Parts List
Front Panel Connectors
Power LED Page 28
Keyboard Lock Page 28
Speaker Page 28
Power Switch (Optional) Page 28
4 Sec Power Switch (Optional) Page 28
Reset Page 28
Sleep Page 29
HDD LED Page 29
IrDA Page 29
Back Panel Connectors
PS/2-style keyboard and mouse connectors Page 30
USB connectors Page 30
Two serials ports Page 30
One parallel port Page 30
One VGA port Page 30
Expansion Slots/Sockets
Socket7 CPU Slot Page 16
SIMM/DIMM Sockets Page 21
Riser Card Slot Page 24
Power/IDE/FDD Connectors
IDE connectors Page 26
Power connector Page 27
FDD connector Page 27
Additional Connectors
CPU Fan Page 31
Chassis Fan Page 31
WOL Connector Page 31
MIDI/Audio (Optional) Page 31
CD-IN (Optional) Page 32
Feature Connector Page 32

3. INSTALLATION
Precaution Before Start
Static Electricity Damage:
Static electricity can easily damage your motherboard.
Observing a few basic precautions will help safeguard
against damage that could result in expensive repairs.
Please read the following before you begin installation.
1. Keep the motherboard and other system components in their anti-static
packaging until you are ready to install them.
2. Touch a grounded surface before you remove any system component from its
protective anti-static packaging. Unpacking and installation should be done
on a grounded, anti-static mat. The operator should be wearing an anti-static
wristband grounded at the same points as the anti-static mat.
3. After removing the motherboard from its original packaging, place only on a
grounded, anti-static surface, component side up. Immediately inspect the
board for damage. Due to shifting during shipping it is suggested that the
installer press down on the entire socket ICs to ensure they are properly
seated. Do this only with the board placed on a firm flat surface.
4. During configuration and installation touch a grounded surface frequently to
discharge any static electrical charge that may have built up in your body.
The best precaution, as stated above, is to wear a grounded wrist strap. When
handling the motherboard or an adapter card avoid touching its components.
Handle the motherboard and adapter cards either by the edges or by the
adapter card case-mounting bracket.
Misplaced Jumper Damage:
There are critical headers used for connectors or power
sources. These are clearly marked separately from the
jumpers listed in “Motherboard Layout”. Incorrectly setting
jumpers and connectors may lead to damage to your
motherboard. Please pay special attention to avoid
connecting these headers in the wrong directions.

3. INSTALLATION
3.1 Slots and Connectors
The SL5598 motherboard requires jumper setting for CPU type, voltage and speed.
Please refer to Jumper setting List in sec.3.2.2.
In following pages, the triangle smark indicates for pin 1 of connectors.
Slots/Connectors List
J1: DIMM2
J2: USB
J3: WOL (Optional)
J4: DIMM1
J5: SIMM4
J6: Floppy Connector
J7: SIMM3
J8: PS/2 Keyboard
J9: Power Connector (Standard)
J10: ATX Power Connector (Optional)
J11: SIMM2
J12: PS/2 Mouse
J13: SIMM1
J14: Primary IDE
J15: COM1
J16: Secondary IDE
J17: Riser Card Slot
J18: COM2
J19: Printer
J20: Chassis Fan
J21: VGA
J22: CD-In
J23: IrDA
J24: MIDI/Audio
J25: Feature Connector
J26: CPU Fan
J27: Front Panel Connectors
PIN 1
PIN 1

3. INSTALLATION
3.2 CPU (Central Processing Unit, U20)
The Pentium P54C/P55C, Cyrix 6X86L/6X86MX, IDT-C6 and AMD-K5/K6
processors have various voltage choices depending on the CPU suppliers. The
motherboard can also be upgraded with Pentium processors that run at higher speeds.
When upgrading the processor, use the BIOS configuration mode to change the
processor speed.
To complete CPU installation, please install CPU to socket firmly and arrange jumper
settings carefully, according to Section. 3.2.1 and 3.2.2.
C
3.2.1 Install CPU
The following steps install your CPU and configure the types, voltage and speed in
accordance to the Processor Jumper Setting List.
Step 1: Pull the handling bar of the socket upward to the other end to loosen the
socket’s openings.
Step 2: Place the CPU on the middle of the socket, orienting its beveled corner to
line up with the socket’s beveled corner. Make sure the pins of the CPU fit
evenly to the socket openings.
Handling
Bar
Step 1: Pull handling bar Step 2: Place CPU

3. INSTALLATION
Step 3: Replace the handling bar downward to fasten the CPU to the socket.
Warning : It is strongly recommended that a heatsink and CPU cooling fan be used to
prevent the CPU from overheating. Applying a thermal of jelly between the
CPU and the heatsink/fan will further cool the CPU.
3.2.2 Arrange Jumper Setting
Because different CPUs may require a varied configuration of Clock, CPU/BUS
speed, I/O voltage and Core voltage, please refer to the following Jumper setting list
to setup your jumper.
C
ÀCPU I/O
Voltage Selection
jumpers
(JP13, JP14)
ÁCPU Clock
Selection jumpers
(JP1, JP2, JP3)
ÂCPU/BUS Speed
selection jumpers
(JP15, JP16, JP17)
ÃCPU Core
Voltage Selection
jumpers (JP8, 9,
10, 11, 12)
Step 3: Fasten the CPU to socket.

3. INSTALLATION
Setting CPU I/O Voltage Setting CPU Clock
CPU
TYPE
(I/O
Voltage)
JP14 JP13 CPU Clock
(MHz)
JP3
(WS2) JP2 (WS1) JP1 (WS0)
P54C, K5,
6X86 50
P55C, K6,
6X86L,
M2 55
60
PIN 1
66
Setting CPU/BUS Speed
Intel CPU/BUS JP17 (BF0) JP16 (BF1) JP15 (BF2)
X1.5 / X3.5

3. INSTALLATION
X2.0
X2.5
X3.0
X4.0
Setting CPU Core Voltage
Vcore JP8 JP9 JP10 JP11 JP12
2.2V
2.8V
2.9V
3.2V
3.38V
3.52V

3. INSTALLATION
3.2.3 Other Jumper Settings
C
JP5
Cyrix Linear
Burst Mode
JP4
VGA Selection
JP7
Clear CMOS
Cyrix Linear Burst Mode (JP5)
The SL5598 has a jumper JP5, which allows you to enable L2 cache, running at linear
burst mode for Cyrix CPU. Make sure this jumper is open for normal operation for
other kind of processors.
VGA Selection (JP4)
SL5598 also has a 3-pin jumper allows you to enable or disable onboard VGA function.
Clear CMOS (JP7)
If an unknown password is set in the BIOS, it can be cleared by inserting a cap over
JP7.
Cyrix Linear Burst Mode VGA Selection Clear CMOS
Description JP5 Descripti
on JP4 Descrip tion JP7
Interleaved
Burst External VGA Default
Linear
Burst Onboard VGA Clear CMOS
