GVision K17TH-F User manual

Industrial A
pp
licatio
n
17" O
p
en Frame TFT LCD Monito
r
Where
Versatility
Meets
Flexibility
Where Versatility Meets Flexibility
Confi
g
uratio
n
LCD Displa
y
Pix
e
l Pit
ch
M
a
x. R
eso
l
u
ti
on
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR ꇙ 10)
Backlight
Lamp Life
Input Signals
Signal Connector Analog
Digital
Video-in
Scan Frequency
Speakers
USB HUB
Touch panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions (WxHxD)
Dimensions (Carton 2 in 1)
Weight (Net)
Certification
* Specifications are subject to change without notice.
Mechanical drawing
I/O Ports
GVision Incorporated TEL: [phone] / FAX : [phone] / www.gvision.com.twGVision Incorporated TEL: [phone] / FAX : [phone] / www.gvision.com.tw
F
eat
ir
es
:
* Hi
g
h contrast color TFT LCD open frame displa
y
support
resolution u
p
to SXGA 1280x1024. Com
p
atible with IBM,
VGA, VESA standards.
* Flexible mechanical designs for industrial application.
* Multi-signals: VGA, DVI, Composite video, s-video (Auto
detection of input signals).
* Composite video system PAL/NTSC and SECAM
compatible.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Optional touch solutions.
* Flexible Mounting Solutions - Front mounting, Racking
mounting & VESA mounting.
* Optional Industrial Power Plug.
* Hot key for AUTO adjustment.
* Space reserved under I/O port.
Optional Accessories :
• 3M 5 Wire resistive touch panel
• 3M Capacitive touch panel
• ELO 5 Wire resistive touch panel
• Anti-Glare tempered glass
• Customized touch solution acceptable.
• Front Mounting Frame.
• 19" Rack Mounting Frame.
• Built-in Industrial Power Plug
Ordering Information :
• K17TH-FA VGA only
• K17TH-FW VGA + Video-in
• K17TH-FB VGA + DVI
• K17TH-FE VGA + DVI + Video-in
K17TH
-
FA
17" TFT active matrix
p
ane
l
0.264
(
H
)
x 0.264
(
V
)
m
m
S
X
G
A 12
80
x 1
0
2
4
450:1 (typical)
250 Cd/m2(typical)
16 ms (typical)
16M
337.9 (H) x 270.3 (V)
140 (H) x 140 (V)
CCFL x 4
40,000(hr)
Analogue VGA
D-sub 15 pin (VGA)
DVI-D (Option)
RCA, S-video (Option)
H. scan 31 ~ 80 KHz,
V. scan 56 ~ 75Hz
N/A
N/A
Resistive/Capacitive - RS232 or
USB A type (Option)
Power on/off with LED, Menu,
Select, Adjustment (+, - )
0oC-50oC (32oF-122oF)
20%-80% (no condensation)
To 10,000 feet
-20oC-60oC ( -4oF-140oF )
10%-90% (no condensation)
Universal power adaptor
Input AC 100~240V, 50~60Hz;
Output DC 12V / 4A
48W
VESA DPMS Standard
439.5 x 337.5 x 51 mm
505 x 470 x 190 mm
7.2 Kg
C-UL, FCC, CE
K17TH
-
FA
K17TH FA
K17TH FA
Tou c hDC inVGADVIS-VideoVideoAudio RAudio L
Front Side Back Side
UNOT : mm
