GVS KA/D 0103.1 User manual

K-BUS®Dimming Actuators_V2.1
KA/D 0103.1
KA/D 0203.1
KA/D 0403.1
KA/D 04.T1.1
ADTV-04/16.1
KA/D 04.L1.1
ADLD-04/03.1
... ...
KNX/EIB Home and Building Control System
User Manual

Attentions
1. Please keep devices away from strong magnetic field, high
temperature, wet environment;
2. Please do not fall the device to the ground or make them get hard
impact;
3. Please do not use wet cloth or volatile reagent to wipe the device;
4. Please do not disassemble the devices.

Contents
Chapter 1 Introduction----------------------------------------------------------------------------------------------------------------5
1.1. Universal Dimming Actuator---------------------------------------------------------------------------------------------- 6
1.2. Dimming Controller, 4fold, 0~10V---------------------------------------------------------------------------------------7
1.3. Dimming Controller, 4fold, 0/1~10V------------------------------------------------------------------------------------ 8
1.4. LED Dimming Actuator, 4fold, 350mA---------------------------------------------------------------------------------9
1.5. LED Dimming Actuator, 4fold, 4A------------------------------------------------------------------------------------- 10
1.6. Dimming master, 4fold and dimming slave, 2fold, 5A---------------------------------------------------------11
1.7. Triac Dimming Actuator--------------------------------------------------------------------------------------------------- 12
Chapter 2 Technical characteristic---------------------------------------------------------------------------------------------13
2.1. Universal Dimming Actuator KA/D xx03.1------------------------------------------------------------------------- 13
2.1.1 Technical data------------------------------------------------------------------------------------------------------------13
2.1.2 Load type------------------------------------------------------------------------------------------------------------------ 14
2.1.3 Dimming operation mode------------------------------------------------------------------------------------------- 14
2.2. Dimming controller, 4fold, 0~10VKA/D 04.T1.1-------------------------------------------------------------------15
2.2.1 Technical data------------------------------------------------------------------------------------------------------------15
2.3. Dimming controller, 4fold, 0/1~10V ADTV-04/16.1-------------------------------------------------------------- 16
2.3.1 Technical data------------------------------------------------------------------------------------------------------------16
2.4. LED Dimming Actuator, 4fold, 350mAKA/D 04.L1.1------------------------------------------------------------ 17
2.4.1 Technical data------------------------------------------------------------------------------------------------------------17
2.5. LED Dimming Actuator, 4fold, 4A ADLD-04/03.1-----------------------------------------------------------------18
2.5.1 Technical data------------------------------------------------------------------------------------------------------------18
2.6. Dimming master, 4fold, KA/D 0400.1 and Dimming slave, 2fold, 5A ADDS-02/05.1----------------19
2.6.1 Technical data -- KA/D 0400.1--------------------------------------------------------------------------------------19
2.6.2 Technical data -- ADDS-02/05.1------------------------------------------------------------------------------------20
2.7. Triac Dimming Actuator KA/D xx15.S.1----------------------------------------------------------------------------- 21
2.7.1 Technical data------------------------------------------------------------------------------------------------------------21
Chapter 3 Dimension and Connection Diagram-------------------------------------------------------------------------- 22
3.1. Universal Dimming Actuator-------------------------------------------------------------------------------------------- 22
3.1.1 KA/D 0103.1--------------------------------------------------------------------------------------------------------------- 22
3.1.2 KA/D 0203.1--------------------------------------------------------------------------------------------------------------- 23
3.1.3 KA/D 0403.1--------------------------------------------------------------------------------------------------------------- 24
3.2. Dimming controller, 4fold, 0~10V KA/D 04.T1.1------------------------------------------------------------------25
3.3. Dimming controller, 4fold, 0/1~10V ADTV-04/16.1-------------------------------------------------------------- 26
3.4. LED Dimming Actuator, 4fold, 350mA KA/D 04.L1.1----------------------------------------------------------- 27
3.5. LED Dimming Actuator, 4fold, 4A ADLD-04/03.1-----------------------------------------------------------------30
3.6. Dimming master, 4fold KA/D 0400.1------------------------------------------------------------------------------- 31
3.7. Dimming slave, 2-fold, 5A ADDS-02/05.1------------------------------------------------------------------------- 32
3.8. Triac Dimming Actuator--------------------------------------------------------------------------------------------------- 33
3.1.1 KA/D 0215.S.1------------------------------------------------------------------------------------------------------------ 33
3.1.2 KA/D 0415.S.1------------------------------------------------------------------------------------------------------------ 34

Chapter 4 Application Programming Introduction----------------------------------------------------------------------- 36
4.1. Switch---------------------------------------------------------------------------------------------------------------------------- 36
4.2. Relative dimming------------------------------------------------------------------------------------------------------------ 36
4.3. Absolute dimming----------------------------------------------------------------------------------------------------------- 36
4.4. Status Report------------------------------------------------------------------------------------------------------------------37
4.5. Scene----------------------------------------------------------------------------------------------------------------------------- 37
4.6. Preset Value--------------------------------------------------------------------------------------------------------------------37
4.7. Staircase Lighting Function--------------------------------------------------------------------------------------------- 37
4.8. Reset------------------------------------------------------------------------------------------------------------------------------38
4.9. Error Report--------------------------------------------------------------------------------------------------------------------38
4.10. Normal operation signs--------------------------------------------------------------------------------------------------39
Chapter 5 Parameters Setting Description in the ETS------------------------------------------------------------------40
5.1. Introduction-------------------------------------------------------------------------------------------------------------------- 40
5.2. Parameter window “Device general”-------------------------------------------------------------------------------- 40
5.3. Parameter window “CHX general”------------------------------------------------------------------------------------ 42
5.4. Parameter window “Dimming general”----------------------------------------------------------------------------- 44
5.4.1 Parameter window “X: dimming general”---------------------------------------------------------------------44
5.4.2 Parameter window “X: dimming”---------------------------------------------------------------------------------47
5.4.3 Parameter window “X: scene page”-----------------------------------------------------------------------------49
5.4.4 Parameter window “X: preset”------------------------------------------------------------------------------------ 51
5.5. Parameter window “Staircase Lighting”--------------------------------------------------------------------------- 52
Chapter 6 Communication Object Description---------------------------------------------------------------------------- 54
6.1. Communication object of “Device General”---------------------------------------------------------------------- 54
6.2. Dimming general communication object---------------------------------------------------------------------------55
6.3. Scene communication object------------------------------------------------------------------------------------------- 56
6.4. Preset Value communication object----------------------------------------------------------------------------------57
6.5. Staircase Lighting communication object------------------------------------------------------------------------- 58

K-BUS®KNX/EIB Dimming Actuators
5
Chapter 1 Introduction
The dimming actuator (hereinafter referred to as Dimmer) is a device dimming the luminaries directly by the
data in the memory, and the data is processed in advance in the programming software according to the
distribution characteristics of the luminaries’ brightness. The control circuit of dimmer transfers the brightness
data value to output voltage or current to control the brightness of the luminaries.
The dimmers products including universal dimmers, 1-10V DC dimmer, 0/1-10V DC dimmer, 350mA LED
dimmer, 4A LED dimmer, 4 channel dimming host ,2 channel 5A dimmer slave, 2 channel and 4 channel Triac
dimmer.
The universal dimmers carry out dimming via phase modulation, which have 3 categories: 1-channel,
2-channels and 4-channels. Max. Power of each channel is 500W for 1-channel and 2-channels dimmers, and Max.
Power of each channel is 400W for 4-channels dimmer. It is able to dim one independent group of luminaries by
1-channel dimmer, 2 independent groups of luminaries by 2-channels dimmer, and 4 independent groups of
luminaries by 4-channels dimmer.
0~10V DC dimming controller with standard DC 0-10V control interface, has 4 independent channels and
one channel can control up to 23 electronic control gears (ECG), such as 23 ECG/18W, 14 ECG/36W, 11
ECG/58W or 23 ECG-T5/24W. The input need connect a 230V AC operating voltage for the device.
0/1~10V DC dimming controller with standard DC 0/1-10V control interface, has 4 independent channels
and one channel can control up to 23 electronic control gears (ECG), such as 23 ECG/18W, 14 ECG/36W, 11
ECG/58W or23 ECG-T5/24W. There is no additional voltage input.
The 350mA LED dimmer with LED constant current drive can drive LED directly, has four channels, each
channel is independent and with two independent output. The output current of each channel can be set by linked
switch current button and channel switch current button and can output 350mA/700mA or 700mA/1A.
The 4A LED dimmer with LED constant voltage drive can drive LED directly, has four channels, each
channel is independent. The input need connect a 12-24V DC operating voltage for the device, the output voltage
depends on the input voltage.
The 4CH dimming host is used with 2CH 5A dimming slave as well. The dimming slave takes the leading
edge cut phase dimming mode of SCR. A dimming master can be connected with two dimming slaves, each
output can be independently switching and dimming, and the max. Power is 1000W for per output. The load types
are similar to universal dimmers. Which make up the universal dimmer lacking in high-power lamps dimming
area.
The Triac dimmers take the leading edge cut phase dimming mode, which have 2-channels and 4-channels.
And max. power of each channel is 300W. It is mainly used to control some low-power dimmable lamps. Each
channel can be independently dimmed and switched.
The Dimmer is a modular installation device for fixed installation in dry rooms. It fits on35mm DIN rails in
power distribution boards or closed compact boxes. It can be programmed; it can be used to customize the rooms’

K-BUS®KNX/EIB Dimming Actuators
6
environment to build the various scenes, such as watch movie, entertainment, dinner and rest, and so on; it’s
brightness value can be set as any value (1-100%); it is able to set the duration time to dim up or down to the
target brightness value and the gradual change speed to extend the luminaries life and save energy and so on.
It is able to use the Engineering Tool Software ETS (ETS3 version or more) with a VD4 file to allocate the
physical address and set the parameters.
This manual describes a series of dimmers. Different dimmers apply to connect different type of lighting, but
their functions are similar, just in use you need to note the type of connected electrical load, thus reasonable
select them and note their technical performance. If the technical performance of the selected load is not
consistent with the technical performance of the dimmer, it is possible to cause damage to the dimmer or load.
This manual provides the detailed technical information about various dimmers, not only the installation and
programming details, but also the usage explanation in actual application.
1.1. Universal Dimming Actuator
The universal dimmers carry out dimming via phase modulation, have 1channel, 2channels and 4channels,
each output of them is independent, which can connect with dimming lamps, such as incandescent lamps, HV
halogen lamps, LV halogen lamps(with conventional or suitable electronic transformers), dimming energy saving
lamps and LED. These lamps can be switched, dimmed, recall scene or other operations via the bus.
The device has an integrated short-circuit and excess temperature protection.
The devices adopt screw terminals to achieve electrical connection; the connection to the KNX bus is
established via a bus connecting terminal. The input need connect a 230V AC operation voltage. The following
list provides a functional overview:
◆Switching the light
◆Relative dimming
◆Absolute dimming
◆Status report, error report
◆Setting 15 scenes
◆Staircase lighting function
◆Bus recovery (or reset) function
◆Preset value and modify preset value functions
The above function of parameters to configure and use are described in the chapter 5.

K-BUS®KNX/EIB Dimming Actuators
7
1.2. Dimming Controller, 4fold, 0~10V
0~10V DC control device with standard DC 0-10V control interface, can be connected with electronic
dimming ballast/EVG or other devices with 0-10V interface to control the lights, such as dimming, scenes,
switching and so on.
The 0-10V DC control device has embedded switching relays for 23 ECG/18W, 14 ECG/36W, 11 ECG/58W
or23 ECG-T5/24W. Each channel offers control voltage up to 23 electronic control gears (ECG).
The devices adopt screw terminals to achieve electrical connection; the connection to the KNX bus is
established via a bus connecting terminal. The input need connect a 230V AC operation voltage. The following
list provides a functional overview:
◆Switching the light
◆Relative dimming
◆Absolute dimming
◆Status report
◆Setting 15 scenes
◆Staircase lighting function
◆Preset value and modify preset value functions
The above function of parameters to configure and use are described in the chapter 5, the database file (.vd4)
of the device is the same with KA/D0403.1. But there is not the error report function for the device, and in the
normal mode, there is not reset function after bus voltage recovery, i.e. the brightness status will not restore the
last brightness value.
Note: Some lights cannot be turned off completely by dimming. In this case, you can turn off the lights
via switching.

K-BUS®KNX/EIB Dimming Actuators
8
1.3. Dimming Controller, 4fold, 0/1~10V
0/1~10V DC control device with standard DC 0/1-10V control interface, can be connected with electronic
dimming ballast/EVG or other devices with 0/1-10V interface to control the lights, such as dimming, scenes,
switching and so on.
The 0/1-10V DC control device has embedded switching relays for 23 ECG/18W, 14 ECG/36W, 11
ECG/58W or23 ECG-T5/24W. Each channel offers control voltage up to 23 electronic control gears (ECG).
The devices adopt screw terminals to achieve electrical connection; the connection to the KNX bus is
established via a bus connecting terminal. There is no additional voltage input. The following list provides a
functional overview:
◆Switching the light
◆Relative dimming
◆Absolute dimming
◆Status report
◆Setting 15 scenes
◆Staircase lighting function
◆Preset value and modify preset value functions
◆Bus recovery (or reset) function
◆Switch/relative dimming via manual buttons
The above function of parameters to configure and use are described in the chapter 5, the device has own
database file (.vd4) (ADTV-04/16.1). And to set the output voltage type in the parameter according to the interface
type of load, as 0-10V or 1-10V.
There is an electronic manual operation function in the normal dimming mode, but it is invalid in the
staircase lighting mode. Switch via a short operation of the electronic manual buttons, relative dimming via a long
operation, and in the case of the bus voltage fail the manual operation is invalid. There is also mechanical manual
operation function, and it can switch on or off the output at any time.
Note: Some lights cannot be turned off completely by dimming. In this case, you can turn off the lights
via switching.

K-BUS®KNX/EIB Dimming Actuators
9
1.4. LED Dimming Actuator, 4fold, 350mA
The dimmer with LED constant current drive can drive LED directly, has four channels, each channel is
independent and with two independent output. The output current of each channel can be set by linked switch
current button and channel switch current button and can output 350mA/700mA or 700mA/1A. ——needs
attention when the output current exceeds the rated current of the load, the load probably will burn out, for
example, cannot use a 700mA output to drive 350mA LED. Meantime, in the case of full load, if all LEDs are
350mA, the dimmer can output 8 folds, but if some LEDs are 700mA or 1A, it cannot output 8 folds in some
configuration, or the LED cannot reach expectant brightness value. The details are in section 3.4.
When the output current is set manually, its value can be known via relevant indicators, the details in section
3.4.
The output can connect with some small power dimming LED lights. These LEDs can be switched, dimmed,
recall scene or other operations via the bus.
The devices adopt screw terminals to achieve electrical connection; the connection to the KNX bus is
established via a bus connecting terminal. The input need connect a 12V~48VDC operation voltage. The
following list provides a functional overview:
◆Switching the LED light
◆Relative dimming
◆Absolute dimming
◆Status report, error report
◆Setting 15 scenes
◆Staircase lighting function
◆Bus recovery (or reset) function
◆Preset value and modify preset value functions
◆Set output current for per channel manually
◆Switch/relative dimming via manual buttons
The above function of parameters to configure and use are described in the chapter 5. The device has own
database file (.vd4) (KA/D 04.L1.1). There is added a manual operation function in the normal dimming mode, it
is invalid in the staircase lighting mode. Switch via a short operation of manual buttons, relative dimming via a
long operation, and in the case of the bus voltage fail the manual operation is invalid.

K-BUS®KNX/EIB Dimming Actuators
10
1.5. LED Dimming Actuator, 4fold, 4A
The dimmer with LED constant voltage drive can drive LED directly, has four channels, each channel is
independent.
The output can connect with some big power dimming LED lights. These LEDs can be switched, dimmed,
recall scene or other operations via the bus.
The devices adopt screw terminals to achieve electrical connection; the connection to the KNX bus is
established via a bus connecting terminal. The input need connect a 12V~24VDC operation voltage. The
following list provides a functional overview:
◆Switching the LED light
◆Relative dimming
◆Absolute dimming
◆Status report, error report
◆Setting 15 scenes
◆Staircase lighting function
◆Bus recovery (or reset) function
◆Preset value and modify preset value functions
◆Switch/relative dimming via manual buttons
The above function of parameters to configure and use are described in the chapter 5. The device has own
database file (.vd4) (ADLD-04/03.1). There is added a manual operation function in the normal dimming mode, it
is invalid in the staircase lighting mode. Switch via a short operation of manual buttons, relative dimming via a
long operation, and in the case of the bus voltage fail the manual operation is invalid.
