h/p/cosmos venus 200/75 Service manual

original instructions for use
treadmill h/p/cosmos®200-300/75-125
IMPORTANT! READ CAREFULLY BEFORE USE!
KEEP FOR FUTURE REFERENCE!
date: 13.12.2018
rmware version: v1.08.x
article number: cos105000_200-300_75-125_en
revision: 1.03
run ahead of time®
h/p/cosmos sports & medical gmbh
The copyright of this document, media, design, software and intellectual property is owned by
h/p/cosmos sports & medical gmbh, except where explicitly stated differently.
Warning: All rights reserved. Unauthorized copying, reproduction, hiring, lending,
public performance and broadcasting prohibited.
saturn®
models
❚ venus® 200/75
❚ venus® 200/75r
❚ venus®200/100
❚ venus® 200/100r
❚ saturn® 250/75
❚ saturn® 250/75r
❚ saturn® 250/100
❚ saturn® 250/100r
❚ saturn® 250/125r
❚ saturn® 300/75
❚ saturn® 300/75r
❚ saturn®300/100
❚ saturn® 300/100r
❚ saturn® 300/125r

page 2 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
These instructions for use are only valid for the original conguration of the rst delivery of the devices pictured below.
If the device has been changed, please refer to the latest version of this document, available at:
www.hpcosmos.com
Product family: treadmill h/p/cosmos 200-300/75-125
Models:
venus® 200/75
[cos30005-01va05]
venus® 200/75r
[cos30005-01va06]
saturn® 250/75r
[cos30007-01va06]
saturn® 250/75
[cos30007-01va05]
venus®200/100
[cos30006-01va05]
saturn® 250/100
[cos30008-01va05]
saturn® 250/100r
[cos30008-01va06]
venus® 200/100r
[cos30006-01va06]
saturn® 300/75
[cos30010-01va05]
saturn® 250/125r
[cos30009-01va03]
saturn® 300/75r
[cos30010-01va06]
saturn® 300/100r
[cos30011-01va06]
saturn® 300/100
[cos30011-01va05]
saturn® 300/125r
[cos30012-01va03]
med

page 3 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
Dear customer,
Thank you for choosing this premium device.
Since its establishment in 1988, h/p/cosmos® has strongly inuenced sports, athletics,
ergometry, rehabilitation, and science through the development and distribution of new
products, software, system solutions, and application methodologies.
During this time the company, based in Traunstein, Germany, has developed into THE
German specialist for manufacturing treadmill ergometers and systems for tness, sports,
sports science, sports medicine, athletics, biomechanics, medicine, rehabilitation, therapy,
ergometry, performance diagnostics, and scientic research.
Many developments and pioneering work from h/p/cosmos® have inuenced not only product
design and functionality but also their usage and methodologies.
Your success with our devices is the primary goal of h/p/cosmos.
This is why we offer individual devices as well as comprehensive system solutions.
You will nd a wide range of options and accessories in these instructions for use and at www.
hpcosmos.com.
At h/p/cosmos, the quality and safety of our products is our highest priority.
These instructions for use include all of the information needed to operate the device correctly
and safely.
Please read them carefully before use and keep them available at all times.
We hope you will have a lot of fun and success as you work with your h/p/cosmos device.
Franz Harrer
President & CEO
h/p/cosmos sports & medical gmbh
Franz Harrer
President & CEO
h/p/cosmos sports & medical gmbh

page 4 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
Content
1 Symbols and Labels........................................................................................................................................8
1.1 Symbols used (general) ............................................................................................................................8
1.2 Symbols used (transport) ..........................................................................................................................9
1.3 Structure....................................................................................................................................................9
1.4 Labels on device .....................................................................................................................................10
2 Description.....................................................................................................................................................11
2.1 Illustration................................................................................................................................................11
2.2 Function...................................................................................................................................................11
3 Intended Use (med) .......................................................................................................................................12
3.1 Intended use............................................................................................................................................12
3.2 Intended operator....................................................................................................................................12
3.3 Intended location.....................................................................................................................................12
3.4 Intended duration ....................................................................................................................................12
3.5 Contraindications.....................................................................................................................................13
3 Intended Use (sport)......................................................................................................................................14
3.1 Intended use............................................................................................................................................14
3.2 Intended operator....................................................................................................................................14
3.3 Intended location.....................................................................................................................................14
3.4 Intended duration ....................................................................................................................................14
3.5 Contraindications.....................................................................................................................................15
4 Safety (med)...................................................................................................................................................16
4.1 Safety information – Forbidden use ........................................................................................................16
4 Safety (sport) .................................................................................................................................................18
4.1 Safety information – Forbidden use ........................................................................................................18
4.2 Fall prevention devices............................................................................................................................20
4.3 Emergency dismount...............................................................................................................................22
4.4 Emergency off .........................................................................................................................................23
4.5 Emergency stop / Quick stop ..................................................................................................................23
4.6 Unauthorized access...............................................................................................................................24
4.7 Residual risk / Side effects (med)............................................................................................................24
4.8 Fireghting...............................................................................................................................................24
4.9 All-pole disconnection..............................................................................................................................24
5 Preparation.....................................................................................................................................................25
5.1 Further preparation locomotion ...............................................................................................................26

page 5 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
6 UserTerminal..................................................................................................................................................27
6.1 Keys and displays ...................................................................................................................................27
6.2 Standard vs. “lt” devices..........................................................................................................................28
6.3 Connection of external devices / Interfaces ............................................................................................29
7 Position of Subject and Operator ................................................................................................................30
8 Operation .......................................................................................................................................................31
8.1 General application procedure ...............................................................................................................31
8.2 Overview of operation modes .................................................................................................................32
8.3 Manual mode ..........................................................................................................................................33
8.4 Prole mode ...........................................................................................................................................34
8.5 Cardio mode............................................................................................................................................36
8.7 Interfere with automatic program ............................................................................................................39
8.8 Pause function.........................................................................................................................................40
8.9 Acceleration levels...................................................................................................................................41
8.10 User Options .........................................................................................................................................42
9 Accessories / compatible devices ...............................................................................................................44
9.1 Creating Systems....................................................................................................................................44
9.2 Overview of accessories .........................................................................................................................44
9.3 Compatible devices.................................................................................................................................45
10 Disinfection / Cleaning................................................................................................................................46
11 Maintenance.................................................................................................................................................47
11.1 Intervals and competences....................................................................................................................47
11.2 Daily inspection .....................................................................................................................................47
11.3 Lubrication .............................................................................................................................................48
11.4 Adjustment of running belt .....................................................................................................................50
11.5 Issues for qualied service personnel ...................................................................................................51
11.6 Safety inspection ...................................................................................................................................51
11.7 Spare parts and consumables...............................................................................................................51
12 Troubleshooting ..........................................................................................................................................52
12.1 General troubleshooting........................................................................................................................52
12.2 RS232 troubleshooting..........................................................................................................................53
12.3 Error messages.....................................................................................................................................54

page 6 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
13 Technical data..............................................................................................................................................55
13.1 UserTerminal .........................................................................................................................................55
13.2 Dimensions............................................................................................................................................55
13.3 Loads.....................................................................................................................................................55
13.4 Emissions..............................................................................................................................................55
13.5 Essential performance characteristics...................................................................................................56
13.6 Environmental conditions ......................................................................................................................56
13.7 Technical and legal requirements..........................................................................................................56
13.8 EMC tests..............................................................................................................................................57
13.9 Classication .........................................................................................................................................57
13.10 Certicates ..........................................................................................................................................57
13.11 Interfaces (RS232, D-SUB, 9-pole) .....................................................................................................58
13.12 Voltage, Current, Performance............................................................................................................58
13.13 Software, Programs.............................................................................................................................58
13.14 All-pole disconnection..........................................................................................................................58
14 Liability and Warranty .................................................................................................................................59
15 Expected Lifetime........................................................................................................................................59
16 Disposal........................................................................................................................................................59
17 Annex I..........................................................................................................................................................60
17.1 Installation .............................................................................................................................................60
17.2 Commissioning and instruction protocol................................................................................................61
17.3 Commissioning and instruction protocol, signatures.............................................................................62
17.4 User Options OP (details) .....................................................................................................................63
18 Annex II (Pre- & self-dened tests) ............................................................................................................68
18.1 UKK walk test........................................................................................................................................68
18.2 Graded test............................................................................................................................................69
18.3 Conconi test ..........................................................................................................................................69
18.4 Bruce protocol .......................................................................................................................................70
18.5 Naughton protocol.................................................................................................................................70
18.6 Balke protocol........................................................................................................................................70
18.7 Cooper protocol.....................................................................................................................................71
18.8 Ellestad A protocol.................................................................................................................................71
18.9 Ellestad B protocol ................................................................................................................................71
18.10 Ramp prole........................................................................................................................................72
18.11 Gardner test protocol...........................................................................................................................72
18.12 Self-dened tests.................................................................................................................................73

page 7 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
19 Annex III (Accessories) ...............................................................................................................................75
PC-software para control [cos10071-v4.1.0].................................................................................................75
Additional keyboard for h/p/cosmos treadmills [cos100815, cos100680]......................................................76
Emergency stop retrotting [cos15933, cos100548, cos15294]....................................................................77
Special speed for treadmill family 200-300/75-125 [cos10028, cos00096110029, cos00096110030]..........78
Running belt for ski and spike applications [various, see below] ..................................................................79
Heart rate measurement POLAR non-coded [cos102818]............................................................................80
Heart rate measurement POLAR W.I.N.D. coded [cos100106] ....................................................................81
Heart rate measurement POLAR H10 [cos101787-01].................................................................................82
Safety arch for treadmill family 200-300/75-125 [cos10171, cos10172, cos10173] .....................................83
Handrail, separable [cos14190, cos14191, cos14192] .................................................................................84
Crossbar front rail [cos16571-01; cos15133-03; cos100947-01; cos100948-01; cos100949-01].................85
Footboard right wide for Saturn 250-300 [cos102951]..................................................................................86
Wheelchair ramp, venus / saturn [cos101060-01_xxx] .................................................................................87
Wheelchair stabilizer [cos10227, cos10226, cos00096110031]....................................................................88
Front limitation roller for cycling [cos102792]................................................................................................89
20 Contact .........................................................................................................................................................90

page 8 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
1 Symbols and Labels
1.1 Symbols used (general)
Illustration Description Reference
CE sign, proof that the essential requirements
(here with number of notied body) were met
(acc. to medical device directive 93/42/EEC
or medical device regulation EU 2017/745)
CE sign, proof that the essential requirements were met (according to machinery directive 2006/42/EC)
General warning (danger, warning or caution statements) (DIN EN ISO 7010 W001)
Warning of obstacles (stumbling) (DIN EN ISO 7010 W007)
Warning of electrical voltage (DIN EN ISO 7010 W012)
Warning of hot surface (DIN EN ISO 7010 W017)
Warning of counter rotating rollers (trapping zones) (DIN EN ISO 7010 W025)
Follow instructions for use (DIN EN ISO 7010 M002)
Potential equalization (IEC 60445)
Protection ground (IEC 60417-5019)
Chassis ground (IEC 60417-5020)
Alternating current (AC) (IEC 60417-5032)
Applied part of type B (IEC 60417-5840)
Manufacturer (ISO 15223-1)
2018-10-01
Manufacturing date (ISO 15223-1)
Separate collection for electrical and electronic equipment (2012/19/EU)

page 9 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
Illustration Description Reference
Fragile, Handle with care (ISO7000-0621)
This way up (ISO7000-0623)
Keep dry (ISO7000-0626)
Centre of gravity (ISO7000-0627)
Temperature limitations (SO7000-0632)
Do not stack (ISO7000-2402)
1.2 Symbols used (transport)
1.3 Structure
Illustration Description
sport Pages marked with the following symbol are valid for medical devices, only.
sport Pages marked with the following symbol are valid for sports devices, only.
med
sport

page 10 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
Illustration Description Reference
name plate -
UDI name plate -
label "caution danger zones" cos10508-03
label "before opening disconnect mains" cos11880
label "follow instructions" cos101380
label "potential equalization" cos101594
label “inspection 20xx” + base label cos14543-20xx + cos11787
label "adjust running belt" cos10512
label "limit running belt shaft cover" cos102466-01
label "lubrication, read manual" cos10510
label “lubrication valve” cos14678
label
“European Electric Wiring Standard” cos101119
label “caution danger zone” cos100958
label “clean light barrier and reector weekly” cos100958
label "h/p/cosmos address" cos10144-01
Umrandung nur Schnittmuster -
nicht mitdrucken
Laufgurteinstellung
Adjust running belt
Anleitung lesen
Read manual
[COS10512]
LR
www.h-p-cosmos.com
COS10512 aufkleber laufgurteinstellung.ps
M:\_Artikeldetails - Zeichnungen\COS10512 aufkleber laufgurteinstellung.cdr
Mittwoch, 22. Januar 2003 22:46:33
Farbprofil: Generisches CMYK-Druckerprofil
Komposit Standardbildschirm
1.4 Labels on device
In case of any visible or assumed wear and tear (of the device, accessories, labels, etc.), unplug device, exclude reconnection, mark
clearly and inform h/p/cosmos service personnel via telephone and writing. Do not change or remove any labels!

page 11 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
No. Description Illustration
1. UserTerminal
2. Pull cord safety stop
(ripcord / safety lanyard)
3. Emergency off
4. Crossbar-frontrail
5. Side handrail
6. Motor cover
7. Foot rail
8. Non slip surface
9. Running deck
10. Running belt
11. Rear roller
12. Rear roller protective cover
13. Marking of running surface
14. Safety arch
15. Safety harness
2.1 Illustration
2 Description
2.2 Function
The treadmill has two essential performance characteristics: Speed and elevation.
The rotation of the running belt represents the speed.
The raising of the whole treadmill frame incl. running deck enables the elevation.
Both parameters are manually adjustable on the UserTerminal.
Furthermore, operation is possible via pre- and self-dened modes.
Operation is also possible via external devices (PC, ECG, etc.).
The chapter “operation” gives a detailed description of all functions.
The chapter “technical data” shows technical details.
The treadmill is driven by powerful motors.
For that reason it is very important to follow the safety information, in order to avoid injury or death.
As previously described, the treadmill contains a number of standardized protocols.
Nevertheless, the treadmill does not provide recommendations for treatment.
The decision regarding the correct load is the responsibility of the medical doctor.
Depending on the application, the load includes speed, elevation, distance, heart rate, body weight or motion support, etc..

page 12 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
3 Intended Use (med)
3.1 Intended use
h/p/cosmos medical treadmills are intended for walking or running* in place for
❚ Recreational tness training (incl. athletes)
❚ Gait training (with or without body weight support)
h/p/cosmos medical treadmills can be used in combination with external devices for walking or running* in place as
❚ Stressing devices for neuromuscular and biomechanical measurements (e.g. EEG, EMG, motion analysis)
❚ Stressing devices for cardiovascular measurements (e.g. ECG)
❚ Stressing devices for cardiopulmonary measurements (e.g. ergospirometry)
Prescribed fall prevention for any application where falling might cause an unacceptable risk (high speed or special applications,
applications with subjects not able to jump off the running belt such as children, physically impaired, etc.)
Caution:
In which ever mode, function, program, test or feature, the treadmill does not provide any kind of medical treatment proposal nor
medical assessment with analysis. The treadmill is purely used as a stressing device and training equipment.
* Devices marked with an “r” or "rs" like “h/p/cosmos saturn 250/75 r” are intended for applications with wheels as well.
Applications with wheels include cycling, roller skiing, wheelchair applications, etc...
The subject of a medical application is not necessarily a patient.
Therefore these instructions for use will use the term “subject” for patients as well as for athletes under test.
h/p/cosmos medical treadmills may be operated with healthy subjects as well.
For applications with healthy subjects, please apply the instructions for use for sports devices, available at www.hpcosmos.com
3.2 Intended operator
❚ Medical staff only
❚ that has been carefully trained according to these instructions for use
❚ that is working according to the prescription of the medical doctor, where applicable and necessary
❚ The subject is not the intended operator.
But the intended operator is authorized to allow the subject to control the device according to the instructions of the intended
operator and under the permanent observation of the intended operator.
This means the operation of the device remains the responsibility of the intended operator at all times, taking the physical and
mental condition of the subject into account.
The intended operator has to be within reach of at least one emergency stop / off at all times.
3.3 Intended location
❚ Medical facilities only
❚ No use at home or in home healthcare environments (acc. to IEC 60601-1-11)
❚ No outdoor use
❚ No direct sunlight
❚ Sufciently lighted for proper readability of warning, labels, displays and operation elements
❚ Proper environmental conditions (see “Technical Data”)
❚ Stationary training equipment: Not moved during use
3.4 Intended duration
❚ Depending on the prescription of the medical doctor
med

page 13 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
3.5 Contraindications
Absolute contraindications
(have to be excluded before the treadmill is used)
❚ Acute myocardial infarction (within 2 days)
❚ Instable angina pectoris
❚ Cardiac arrhythmia pathology and/or limited hemodynamics
❚ Symptomatic massive aortic stenosis
❚ Uncompensated / uncontrolled heart insufciency
❚ Acute pulmonary embolism or pulmonary infarction
❚ Acute endocarditis, myocarditis, pericarditis
❚ Acute aortic dissection
❚ Acute coronary syndrome
❚ Acute phlebothrombosis of the lower extremities
❚ Febrile infections
❚ Pregnancy
❚ Acute thrombosis
❚ Fresh wounds e.g. after surgery
❚ Acute fracture
❚ Damaged disc or traumatic disease of the spine
❚ Epilepsy
❚ Inammations
❚ Acute migraine
Relative contraindications
(The application may be started if the possible benets exceed the risks.
The decision has to be made by the medical doctor before the treadmill is used)
❚ Left main coronary stenosis
❚ Main artery disease
❚ Cardiac valve disease of moderate severity
❚ Known electrolyte imbalance
❚ Arterial hypertonia (RR > 200 mm Hg syst. > 110 mm Hg diast.)
❚ Tachyarrhythmia or bradyarrhythmia
❚ Hypertrophic cardiomyopathy and other forms of outow tract obstruction
❚ Higher degree atrioventricular AV-blocking
❚ Anemia
❚ Physical and/or mental disabilities leading to inability to exercise adequately
❚ Partially invasive medical devices (probes, infusions, catheters, external xators, etc.)
❚ Cardiac pacemaker
❚ Visual impairment (vision < 30% acc. to WHO)
Further contraindications may occur. This has to be evaluated by the medical doctor.
In case of relative contraindications permanent observation of the subject by medical staff is obligatory.
Sources:
http://leitlinien.dgk.org (German Cardiac Society)
www.acc.org (American College of Cardiology Foundation)
www.americanheart.org (American Heart Association)
http://my.americanheart.org/idc/groups/ahaecc-internal/@wcm/@sop/documents/downloadable/ucm_423807.pdf
med

page 14 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
3 Intended Use (sport)
3.1 Intended use
h/p/cosmos sports treadmills are intended for walking or running* in place.
Do not use h/p/cosmos sports treadmills for medical applications.
Prescribed fall prevention for any application where falling might cause an unacceptable risk (high speed or special applications,
applications with subjects not able to jump off the running belt such as children, physically impaired, etc.)
Caution:
In which ever mode, function, program, test or feature, the treadmill does not provide any kind of medical treatment proposal nor
medical assessment with analysis. The treadmill is purely used as a stressing device and training equipment.
Under no circumstances should the device be used with increased risk, e.g. sprint or medical application with a high risk of falling,
unless additional safety precautions and safety equipment such as safety arch with fall stop are used.
The subject is to be secured by a safety arch with chest belt system for fall stop in the following cases:
❚ while performing sprints
❚ for max. endurance tests
❚ while training on running surfaces wider than 65 cm
❚ for children (<14 years)
❚ for subjects with all kind of disabilities, impairments (visual, hearing, balance, etc.), activity limitations and participation restrictions
❚ while running with shoes with spikes or studs
❚ during reverse belt rotation (or use the pull cord safety stop actuator)
❚ during all use with wheels (cycling, wheelchair, inline-skating or roller-ski) for the “r” models
❚ in case of severe danger
❚ subjects with long hair or wide clothes
* Devices marked with an “r” or "rs" like “h/p/cosmos saturn 250/75 r” are intended for applications with wheels as well.
Applications with wheels include cycling, roller skiing, wheelchair applications, etc...
3.2 Intended operator
❚ Persons carefully trained according to these instructions for use.
3.3 Intended location
❚ No use in medical facilities or in home healthcare environments (acc. to IEC 60601-1-11)
❚ No outdoor use
❚ No direct sunlight
❚ Sufciently lighted for proper readability of warning, labels, displays and operation elements
❚ Proper environmental conditions (see “Technical Data”)
❚ Stationary training equipment: Not moved during use
3.4 Intended duration
❚ Depending on the condition of the subject
sport

page 15 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
3.5 Contraindications
(have to be excluded before the treadmill is used)
❚ Acute myocardial infarction (within 2 days)
❚ Instable angina pectoris
❚ Cardiac arrhythmia pathology and/or limited hemodynamics
❚ Symptomatic massive aortic stenosis
❚ Uncompensated / uncontrolled heart insufciency
❚ Acute pulmonary embolism or pulmonary infarction
❚ Acute endocarditis, myocarditis, pericarditis
❚ Acute aortic dissection
❚ Acute coronary syndrome
❚ Acute phlebothrombosis of the lower extremities
❚ Febrile infections
❚ Pregnancy
❚ Acute thrombosis
❚ Fresh wounds e.g. after surgery
❚ Acute fracture
❚ Damaged disc or traumatic disease of the spine
❚ Epilepsy
❚ Inammations
❚ Acute migraine
❚ Left main coronary stenosis
❚ Main artery disease
❚ Cardiac valve disease of moderate severity
❚ Known electrolyte imbalance
❚ Arterial hypertonia (RR > 200 mm Hg syst. > 110 mm Hg diast.)
❚ Tachyarrhythmia or bradyarrhythmia
❚ Hypertrophic cardiomyopathy and other forms of outow tract obstruction
❚ Higher degree atrioventricular AV-blocking
❚ Anemia
❚ Physical and/or mental disabilities leading to inability to exercise adequately
❚ Partially invasive medical devices (probes, infusions, catheters, external xators, etc.)
❚ Cardiac pacemaker
❚ Visual impairment (vision < 30% acc. to WHO)
Sources:
http://leitlinien.dgk.org (German Cardiac Society)
www.acc.org (American College of Cardiology Foundation)
www.americanheart.org (American Heart Association)
http://my.americanheart.org/idc/groups/ahaecc-internal/@wcm/@sop/documents/downloadable/ucm_423807.pdf
Sources:
http://leitlinien.dgk.org (German Cardiac Society)
www.acc.org (American College of Cardiology Foundation)
www.americanheart.org (American Heart Association)
http://my.americanheart.org/idc/groups/ahaecc-internal/@wcm/@sop/documents/downloadable/ucm_423807.pdf
sport

page 16 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
4 Safety (med)
h/p/cosmos medical treadmills may be operated with healthy subjects as well.
For applications with healthy subjects, please apply the instructions for use for sports devices, available at www.hpcosmos.com
The safety notes, warnings and precautions have to be pointed out to every user and operator and displayed within sight of the
running machine.
4.1 Safety information – Forbidden use
Obey the following danger, warning and caution statements stricktly in order to prevent serious injury or death!
❚ Prescribed fall prevention for any application where falling might cause an unacceptable risk (high speed or special applications,
applications with subjects not able to jump off the running belt such as children, physically impaired, etc.)
❚ The automatic modes must only be performed on the prescription of the medical doctor.
❚ During stress tests a medical doctor has to be available at any time.
❚ Do not use the device with children <12 months.
❚ Exclude access of unsupervised children (< 14 years) onto or near any parts of the device (incl. accessories, packaging,
lubrication and service material).
❚ In case of application with children (> 1, < 14 years) permanent observation of the subject by medical staff is obligatory.
❚ Animals must not be in the same room with the device.
❚ Only carefully trained medical staff is allowed to use the device.
❚ Do not use the safety harness on bare skin.
❚ WARNING! Heart rate monitoring systems may be inaccurate.
❚ Incorrect or over exercising may result in serious injury or death.
❚ Advice the subject If you feel faint or dizzy stop exercising immediately and consult a medical doctor.
❚ Exclude overloading or overstressing of the subject.
❚ The subject has to be checked by a medical doctor before using the device.
❚ A debrillator must be present at any time.
❚ The intended operator has to be in reach of at least one emergency stop/off at any time.
❚ Obey all information given in these instructions for use.
❚ Do not use the device against the intended use.
❚ Do not use the device in case one or more of the listed contraindications prevail.
❚ In case of relative contraindications permanent observation of the subject by medical staff is obligatory.
❚ Neither subject nor operator must be under the inuence of alcohol, drugs or anesthetics.
❚ Start the use of the treadmill with slow walking, especially for beginners.
❚ Make sure the space under the treadmill is free from persons, body parts or objects, especially when switching on (treadmill will
lower during initialization) and when changing the elevation.
❚ Do not enter the device when running belt is rotating.
❚ Do not step on rear roller.
❚ Do not stand on or enter the running deck when device is in elevation (running belt might slip through due to gravity).
❚ Make sure no objects, sand, stones, liquids, towels, jewellery, cell phones, containers with liquid etc. can fall into the device or onto
the running surface or underneath the running belt
❚ Do not enter the device without appropriate shoes without high heels, spikes or studs. *
❚ Do not use the device with wheels (bikes, wheelchairs, inline skates, etc.). **
med
* Devices supplied with the special “running belt for ski and spike applications” (see “Annex III (Accessories)”) are intended for
application with spikes or studs as well.
** Devices marked with an “r” or “rs” like “h/p/cosmos saturn 250/75 r” are intended for applications with wheels as well. Applications
with wheels include cycling, roller skiing, wheelchair applications, etc.

page 17 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
❚ Do not turn around, walk sideways or backwards; do not jump on or off the running belt while it is in motion.
❚ Do not touch the running belt while it is in motion (besides contact with feet).
❚ Do not lean on the UserTerminal - do not apply pressure to the displays - press keys softly.
❚ Ensure assist mean, accessories, cables etc. do not extend into the running area.
❚ Do not insert any object (especially no metal objects such as a pin or a wire) into any gap or any outlet on the device.
❚ Do not touch the subject and external electrical devices at the same time.
❚ Always the latest command will be executed, regardless of whether it came via interface or from the UserTerminal during one of
the four modes. Only stop command has higher priority and cannot be overwritten.
❚ Be aware that electromagnetic interferences may cause a fail-safe mode, the running belt will stop with a pre-dened deceleration
ramp.
❚ WARNING: To avoid the risk of electric shock, this equipment must only be connected to a supply mains with protective earth.
❚ WARNING: Do not use portable high frequency communication devices in the subject environment (see “position of subject
and user”). Disregard can cause loss of performance.
❚ Free standing equipment has to be installed on a stable and levelled base.
❚ Choose proper oor, clothing and humidity, in order to prevent electrostatic discharge (also see technical data).
❚ Do not use the device without instruction by authorized personnel acc. to the instruction protocol.
❚ Regard safety area behind device of 2.0 m x width of treadmill.
❚ Operator and subject have to be aware of automatic load changes during prole, cardio and test mode.
❚ Unmeant trapping hazards: Take off ties, scarfs or other clothes that may be trapped. Secure long hair and ribbons during
maintenance and training in order to prevent being captured in trapping zones.
❚ Perform a daily visual inspection (see chapter “maintenance”).
❚ Obey the maintenance intervals claimed in chapter “maintenance”.
❚ Obey the competences claimed in chapter “maintenance”.
❚ A second person has to be present during maintenance.
❚ In case of any visible or assumed defects or malfunctions (of the device, accessories, software, etc.), unplug device, exclude
reconnection, mark clearly and inform h/p/cosmos service personnel via telephone and writing.
❚ In case of any visible or assumed wear and tear (of the device, accessories, labels, etc.), unplug device, exclude reconnection,
mark clearly and inform h/p/cosmos service personnel via telephone and writing. Do not change or remove any labels!
❚ In case of any uid entering into the device, unplug device, exclude reconnection, mark clearly and inform h/p/cosmos service
personnel via telephone and writing.
❚ Do not modify the device, congurations, accessories or software in any way.
❚ Do not connect any devices, accessories or software, not listed in “accessories / compatible devices”.
❚ Disinfect the device before and after every treatment.
❚ Disconnect the device and all accessories from mains power supply before cleaning or disinfection.
med

page 18 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
4 Safety (sport)
h/p/cosmos medical treadmills may be operated with healthy subjects as well.
The safety notes, warnings and precautions have to be pointed out to every user and operator and displayed within sight of the
running machine.
4.1 Safety information – Forbidden use
Obey the following danger, warning and caution statements stricktly in order to prevent serious injury or death!
❚ Prescribed fall prevention for any application where falling might cause an unacceptable risk (high speed or special applications,
applications with subjects not able to jump off the running belt such as children, physically impaired, etc.)
❚ Only carefully trained staff is allowed to use the device.
❚ Do not use the device with children <14 years.
❚ Exclude access of unsupervised children (< 14 years) onto or near any parts of the device (incl. accessories, packaging, lubrication
and service material).
❚ Do not use the safety harness on bare skin.
❚ WARNING! Heart rate monitoring systems may be inaccurate.
❚ Incorrect or over exercising may result in serious injury or death.
❚ Advice the subject If you feel faint or dizzy stop exercising immediately and consult a medical doctor.
❚ Exclude overloading or overstressing of the subject.
❚ The subject has to be checked by a medical doctor before using the device.
❚ A debrillator must be present at any time.
❚ The intended operator has to be in reach of at least one emergency stop/off at any time.
❚ Obey all information given in these instructions for use.
❚ Do not use the device against the intended use.
❚ Do not use the device in case one or more of the listed contraindications prevail.
❚ Neither subject nor operator must be under the inuence of alcohol, drugs or anesthetics.
❚ Start the use of the treadmill with slow walking, especially for beginners.
❚ Make sure the space under the treadmill is free from persons, body parts or objects, especially when switching on (treadmill will
lower during initialization) and when changing the elevation.
❚ Do not enter the device when running belt is rotating.
❚ Do not step on rear roller.
❚ Do not stand on or enter the running deck when device is in elevation (running belt might slip through due to gravity).
❚ Make sure no objects, sand, stones, liquids, towels, jewellery, cell phones, containers with liquid etc. can fall into the device or onto
the running surface or underneath the running belt
❚ Do not enter the device without appropriate shoes without high heels, spikes or studs.
❚ Do not use the device with wheels (bikes, wheelchairs, inline skates, etc.).
❚ Do not turn around, walk sideways or backwards; do not jump on or off the running belt while it is in motion.
❚ Do not touch the running belt while it is in motion (besides contact with feet).
❚ Do not lean on the UserTerminal - do not apply pressure to the displays - press keys softly.
❚ Ensure assist mean, accessories, cables etc. do not extend into the running area.
sport

page 19 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
❚ Do not insert any object (especially no metal objects such as a pin or a wire) into any gap or any outlet on the device.
❚ Do not touch the subject and external electrical devices at the same time.
❚ Always the latest command will be executed, regardless of whether it came via interface or from the UserTerminal during one of
the four modes. Only stop command has higher priority and cannot be overwritten.
❚ Be aware that electromagnetic interferences may cause a fail-safe mode, the running belt will stop with a pre-dened deceleration
ramp.
❚ WARNING: To avoid the risk of electric shock, this equipment must only be connected to a supply mains with protective earth.
❚ WARNING: Do not use portable high frequency communication devices in the subject environment (see “position of subject
and user”). Disregard can cause loss of performance.
❚ Free standing equipment has to be installed on a stable and levelled base.
❚ Choose proper oor, clothing and humidity, in order to prevent electrostatic discharge (also see technical data).
❚ Do not use the device without instruction by authorized personnel acc. to the instruction protocol.
❚ Regard safety area behind device of 2.0 m x width of treadmill.
❚ Animals must not be in the same room with the device.
❚ Operator and subject have to be aware of automatic load changes during prole, cardio and test mode.
❚ Unmeant trapping hazards: Take off ties, scarfs or other clothes that may be trapped. Secure long hair and ribbons during
maintenance and training in order to prevent being captured in trapping zones.
❚ Perform a daily visual inspection (see chapter “maintenance”).
❚ Obey the maintenance intervals claimed in chapter “maintenance”.
❚ Obey the competences claimed in chapter “maintenance”.
❚ A second person has to be present during maintenance.
❚ In case of any visible or assumed defects or malfunctions (of the device, accessories, software, etc.), unplug device, exclude
reconnection, mark clearly and inform h/p/cosmos service personnel via telephone and writing.
❚ In case of any visible or assumed wear and tear (of the device, accessories, labels, etc.), unplug device, exclude reconnection,
mark clearly and inform h/p/cosmos service personnel via telephone and writing. Do not change or remove any labels!
❚ In case of any uid entering into the device, unplug device, exclude reconnection, mark clearly and inform h/p/cosmos service
personnel via telephone and writing.
❚ Do not modify the device, congurations, accessories or software in any way.
❚ Do not connect any devices, accessories or software, not listed in “accessories / compatible devices”.
❚ Disinfect the device before and after every treatment.
❚ Disconnect the device and all accessories from mains power supply before cleaning or disinfection.
sport

page 20 of 90cos105000_200-300_75-125, rev. 1.03© 1988 - 2019 h/p/cosmos sports & medical gmbh
4.2 Fall prevention devices
A fall prevention device is the only effective way to protect the subject from falling.
Prescribed fall prevention for any application where falling might cause an unacceptable risk (high speed or special applications,
applications with subjects not able to jump off the running belt such as children, physically impaired, etc.)
h/p/cosmos provides fall prevention devices in the form of a safety arch or a body weight support device (airwalk).
It is up to the operator to use any other device that prevents the subject from falling and complies with IEC60601-1.
The pull-cord safety stop is not a fall prevention.
Do not use the safety harness on bare skin.
Treadmill with safety arch Body weight support device airwalk®
Further information see “Annex III (accessories)”
Description Ilustration
Put on the safety harness so that the h/p/cosmos logo is facing
outside.
The h/p/cosmos logo has to be visible in the back as well.
Close buckles.
Tighten shoulder and chest straps.
Use carabiner to connect safety harness with rope.
select desired maximum patient weight
user weight
max. 250 kg
user weight
max. 250 kg
