H3C LSPM2SP2P Interface Card
User Manual-V1.03
Introduction to LSPM2SP2P
Overview
The LSPM2SP2P interface card provides two 10-Gbps SFP+
fiber ports.
Figure 1 Front panel of the LSPM2SP2P interface card

2
Table 1 SFP+ transceiver modules and SFP+ cables supported by
LSPM2SP2P
Transceiver
/Cable
Central
wavele
ngth
Conn
ector Interface cable
Max
transmiss
ion
distance
SFP-XG-SX-
MM850-A 850 nm LC 50/125 µm
multimode
optical fiber
300 m
(984.25
ft.)
SFP-XG-LX2
20-MM1310 1310 nm LC
62.5/125
µm
multimode
optical fiber
220 m
(721.78
ft.)
SFP-XG-LX-
SM1310 1310 nm LC 10 km (6.21 mi)
SFP-XG-LH
40-SM1550 1550 nm LC
9/125 µm
single
mode
optical fiber 40 km
(24.86
miles)
LSWM1STK 0.65 m
(2.13 ft.)
LSWM2STK 1.2 m
(3.94 ft.)
LSWM3STK 3 m (9.84
ft.)
LSTM1STK 5 m (16.40
ft)
LSWM4STK
— — SFP+ cable
10 m
(32.81 ft.)
Note:
H3C recommends that you use SFP+ transceiver modules
and SFP+ cables of H3C on the LSPM2SP2P.
The types of SFP+ transceiver modules and SFP+ cables
may update with time. For information about them, contact
H3C technical support or marketing staff.

3
Note:
For the models and specifications of each kind of SFP+
transceiver modules and SFP+ cables, see the H3C Low
End Series Ethernet Switches Pluggable Modules Manual
on the H3C website.
Description of LEDs
There is an LED for each port on the panel of the interface card.
Table 2 Description of LEDs on the LSPM2SP2P
LED Status Description
On The port is normally connected.
The LED blinks quickly when the
port is sending or receiving data.
Port LED of the
LSPM2SP2P
interface card Off The port is not up.
Note:
Port LED of the LSPM2SP2P interface card is not affected
by the port mode switching button on your switch. For
more information about the port mode switching button,
see the installation guide of the switch.
Installing and removing an interface card
The following tools are needed for installation and removal of an
interface card:
zPhillips screwdriver
zESD-preventive wrist strap
Note:
The installation tools are not shipped together with H3C’s
devices. Prepare them yourself.

4
Installing the interface card
Installing the interface card to the switch
Note:
The procedure of installing the LSPM2SP2P interface card
to different models of H3C switches is similar. This manual
takes the S5500-28C-EI switch as an example.
Follow these steps to install the interface card to the switch:
(1) Wear an ESD-preventive wrist strap, and make sure that the
ESD-preventive wrist strap makes good skin contact and is
properly grounded.
(2) Loosen the mounting screws of the filler panel on the interface
card slot of the switch with a Phillips screwdriver and remove the
filler panel, as shown in Figure 2 .
Figure 2 Install an interface card (I)

6
Caution:
When installing or removing an interface card, note the
following guidelines:
Do not touch the surface-mounted components directly
with your hands.
Do not use too much force in the operation.
After removing an interface card, if no new interface card
is to be installed, install the filler panel as soon as
possible to prevent dust and ensure normal ventilation in
the switch.
Installing an SFP+ transceiver module and SFP+
cable
To avoid component damage caused by improper installation,
carefully read the H3C Pluggable SFP/SFP+/XFP Transceiver
Modules Installation Guide from the H3C's website before installing
the SFP+ transceiver modules or SFP+ cables.
Verifying the installation
When the switch runs properly, check whether the interface card
is operating properly according to the status of the Port LED on the
LSPM2SP2P interface card.
