H3C H3C S7500E Series Quick guide

H3C S7500E IPv6 over IPv4 Manual Tunneling
with OSPFv3 Configuration Examples
Copyright © 2015 Hangzhou H3C Technologies Co., Ltd. All rights reserved.
No part of this manual may be reproduced or transmitted in any form or by any means
without prior written consent of Hangzhou H3C Technologies Co., Ltd.
The information in this document is subject to change without notice.

i
Contents
Introduction··································································································································································· 1
Prerequisites·································································································································································· 1
Example: Configuring IPv6 over IPv4 manual tunneling with OSPFv3 ···································································· 1
Network requirements ······················································································································································1
Software version used ······················································································································································2
Configuration restrictions and guidelines·······················································································································2
Configuration procedures ················································································································································3
Configuring IPv6 over IPv4 manual tunnels···········································································································3
Configuring OSPFv3 ················································································································································5
Verifying the configuration···············································································································································6
Configuration files·····························································································································································6
Related documentation ················································································································································ 9

1
Introduction
This document provides IPv6 over IPv4 manual tunneling with OSPFv3 configuration examples.
Prerequisites
The configuration examples in this document were created and verified in a lab environment, and all the
devices were started with the factory default configuration. When you are working on a live network,
make sure you understand the potential impact of every command on your network.
This document assumes that you have basic knowledge of H3C IPv6 over IPv4 manual tunneling and
OSPFv3.
Example: Configuring IPv6 over IPv4 manual
tunneling with OSPFv3
Network requirements
As shown in Figure 1, in IPv6 networks, Device A, Device B, and Device C act as the gateways of the
headquarters, Branch 1, and Branch 2, respectively.
Configure IPv6 over IPv4 manual tunnels to ensure that the headquarters can communicate with the two
branches over IPv4 networks.
Configure OSPFv3 on the gateways to ensure that the following requirements are met:
•The gateways have routes to destination IPv6 addresses through tunnel interfaces.
•Branch 1 and Branch 2 can communicate with each other through the headquarters.

2
Figure 1 Network diagram
Table 1 Interface and IP address assignment
Device Interface IP address
Device A Vlan-int10 20.1.1.1/24
Vlan-int20 2001::1/64
Tunnel1 3001::1/64
Tunnel2 4001::1/64
Device B Vlan-int10 30.1.1.1/24
Vlan-int20 5001::1/64
Tunnel1 3001::2/64
Device C Vlan-int10 40.1.1.1/24
Vlan-int20 6001::1/64
Tunnel2 4001::2/64
Software version used
This configuration example was created and verified on S7500E-CMW710-R7150.
Configuration restrictions and guidelines
For tunnel interfaces to send and receive packets, you must configure a tunnel-type service loopback
group.
Tunnel1Tunnel1
Tunnel2
Tunnel2

3
On the device, a tunneled packet cannot be directly routed based on its destination address. It is sent to
a tunnel-type service loopback group, which then delivers the packet to the forwarding module for Layer
3 forwarding.
Configuration procedures
Make sure the gateways can reach each other at IPv4.
Configuring IPv6 over IPv4 manual tunnels
•Configure Device A:
# Configure an IP address for VLAN-interface 10.
<DeviceA> system-view
[DeviceA] vlan 10
[DeviceA-vlan10] port GigabitEthernet 1/0/1
[DeviceA-vlan10] quit
[DeviceA] interface vlan-interface 10
[DeviceA-Vlan-interface10] ip address 20.1.1.1 24
[DeviceA-Vlan-interface10] quit
# Configure IP addresses for other interfaces, as shown in Figure 1. (Details not shown.)
# Create service loopback group 1, and specify its service type as tunnel.
[DeviceA] service-loopback group 1 type tunnel
# Assign GigabitEthernet 1/0/3 to service loopback group 1.
[DeviceA] interface gigabitethernet 1/0/3
[DeviceA-GigabitEthernet1/0/3] port service-loopback group 1
[DeviceA-GigabitEthernet1/0/3] quit
# Configure an IPv6 over IPv4 manual tunnel interface Tunnel 1.
[DeviceA] interface tunnel 1 mode ipv6-ipv4
# Configure an IPv6 address for Tunnel 1.
[DeviceA-Tunnel1] ipv6 address 3001::1/64
# Specify VLAN-interface 10 as the source interface of Tunnel 1.
[DeviceA-Tunnel1] source vlan-interface 10
# Specify the destination address for Tunnel 1.
[DeviceA-Tunnel1] destination 30.1.1.1
[DeviceA-Tunnel1] quit
# Configure an IPv6 over IPv4 manual tunnel interface Tunnel 2.
[DeviceA] interface tunnel 2 mode ipv6-ipv4
# Configure an IPv6 address for Tunnel 2.
[DeviceA-Tunnel2] ipv6 address 4001::1/64
# Specify VLAN-interface 10 as the source interface of Tunnel 2.
[DeviceA-Tunnel2] source Vlan-interface 10
# Specify the destination address for Tunnel 2.
[DeviceA-Tunnel2] destination 40.1.1.1
[DeviceA-Tunnel2] quit

4
•Configure Device B:
# Configure an IP address for VLAN-interface 10.
<DeviceB> system-view
[DeviceB] vlan 10
[DeviceB-vlan10] port GigabitEthernet 1/0/1
[DeviceB-vlan10] quit
[DeviceB] interface vlan-interface 10
[DeviceB-Vlan-interface10] ip address 30.1.1.1 24
[DeviceB-Vlan-interface10] quit
# Configure IP addresses for other interfaces, as shown in Figure 1. (Details not shown.)
# Create service loopback group 1, and specify its service type as tunnel.
[DeviceB] service-loopback group 1 type tunnel
# Assign GigabitEthernet 1/0/3 to service loopback group 1.
[DeviceB] interface gigabitethernet 1/0/3
[DeviceB-GigabitEthernet1/0/3] port service-loopback group 1
[DeviceB-GigabitEthernet1/0/3] quit
# Configure an IPv6 over IPv4 manual tunnel interface Tunnel 1.
[DeviceB] interface tunnel 1 mode ipv6-ipv4
# Configure an IPv6 address for Tunnel 1.
[DeviceB-Tunnel1] ipv6 address 3001::2/64
# Specify VLAN-interface 10 as the source interface of Tunnel 1.
[DeviceB-Tunnel1] source vlan-interface 10
# Specify the destination address for Tunnel 1.
[DeviceB-Tunnel1] destination 20.1.1.1
[DeviceB-Tunnel1] quit
•Configure Device C:
# Configure an IP address for VLAN-interface 10.
<DeviceC> system-view
[DeviceC] vlan 10
[DeviceC-vlan10] port gigabitEthernet 1/0/1
[DeviceC-vlan10] quit
[DeviceC] interface vlan-interface 10
[DeviceC-Vlan-interface10] ip address 40.1.1.1 24
[DeviceC-Vlan-interface10] quit
# Configure IP addresses for other interfaces, as shown in Figure 1. (Details not shown.)
# Create service loopback group 1, and specify its service type as tunnel.
[DeviceC] service-loopback group 1 type tunnel
# Assign GigabitEthernet 1/0/3 to service loopback group 1.
[DeviceC] interface gigabitethernet 1/0/3
[DeviceC-GigabitEthernet1/0/3] port service-loopback group 1
[DeviceC-GigabitEthernet1/0/3] quit
# Configure an IPv6 over IPv4 manual tunnel interface Tunnel 2.
[DeviceC] interface tunnel 2 mode ipv6-ipv4
# Configure an IPv6 address for Tunnel 2.
[DeviceC-Tunnel2] ipv6 address 4001::2/64

5
# Specify VLAN-interface 10 as the source interface of Tunnel 2.
[DeviceC-Tunnel2] source vlan-interface 10
# Specify the destination address for Tunnel 2.
[DeviceC-Tunnel2] destination 20.1.1.1
[DeviceC-Tunnel2] quit
Configuring OSPFv3
•Configure Device A:
# Specify the router ID as 1.1.1.1.
[DeviceA] ospfv3
[DeviceA-ospfv3-1] router-id 1.1.1.1
[DeviceA-ospfv3-1] quit
# Enable OSPFv3 on Tunnel 1.
[DeviceA] interface Tunnel 1
[DeviceA-Tunnel1] ospfv3 1 area 0
[DeviceA-Tunnel1] quit
# Enable OSPFv3 on Tunnel 2.
[DeviceA] interface Tunnel 2
[DeviceA-Tunnel2] ospfv3 1 area 0
[DeviceA-Tunnel2] quit
# Enable OSPFv3 on VLAN-interface 20.
[DeviceA] interface vlan-interface 20
[DeviceA-Vlan-interface20] ospfv3 1 area 0
[DeviceA-Vlan-interface20] quit
•Configure Device B:
# Specify the router ID as 2.2.2.2.
[DeviceB] ospfv3
[DeviceB-ospfv3-1] router-id 2.2.2.2
[DeviceB-ospfv3-1] quit
# Enable OSPFv3 on Tunnel 1.
[DeviceB] interface Tunnel 1
[DeviceB-Tunnel1] ospfv3 1 area 0
[DeviceB-Tunnel1] quit
# Enable OSPFv3 on VLAN-interface 20.
[DeviceB] interface vlan-interface 20
[DeviceB-Vlan-interface20] ospfv3 1 area 0
[DeviceB-Vlan-interface20] quit
•Configure Device C:
# Specify the router ID as 3.3.3.3.
[DeviceC] ospfv3
[DeviceC-ospfv3-1] router-id 3.3.3.3
[DeviceC-ospfv3-1] quit
# Enable OSPFv3 on Tunnel 2.
[DeviceC] interface Tunnel 2

6
[DeviceC-Tunnel2] ospfv3 1 area 0
[DeviceC-Tunnel2] quit
# Enable OSPFv3 on VLAN-interface 20.
[DeviceC] interface vlan-interface 20
[DeviceC-Vlan-interface20] ospfv3 1 area 0
[DeviceC-Vlan-interface20] quit
Verifying the configuration
# Ping PC 1 from PC 2.
D:\>ping6 -s 5001::3 2001::3
Pinging 2001::3
from 5001::3 with 32 bytes of data:
Reply from 2001::3: bytes=32 time=13ms
Reply from 2001::3: bytes=32 time=1ms
Reply from 2001::3: bytes=32 time=1ms
Reply from 2001::3: bytes=32 time<1ms
Ping statistics for 2001::3:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 0ms, Maximum = 13ms, Average = 3ms
The output shows that the ping operation succeeds.
# Ping PC 3 from PC 2.
D:\>ping6 -s 5001::3 6001::3
Pinging 6001::3
from 6001::3 with 32 bytes of data:
Reply from 6001::3: bytes=32 time=13ms
Reply from 6001::3: bytes=32 time=1ms
Reply from 6001::3: bytes=32 time=1ms
Reply from 6001::3: bytes=32 time<1ms
Ping statistics for 6001::3:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 0ms, Maximum = 13ms, Average = 3ms
The output shows that the ping operation succeeds.
Configuration files
•Device A:
#

7
service-loopback group 1 type tunnel
#
ospfv3 1
router-id 1.1.1.1
area 0.0.0.0
#
vlan 10
#
vlan 20
#
interface Vlan-interface10
ip address 20.1.1.1 255.255.255.0
#
interface Vlan-interface20
ospfv3 1 area 0.0.0.0
ipv6 address 2001::1/64
#
interface GigabitEthernet1/0/1
port link-mode bridge
port access vlan 10
#
interface GigabitEthernet1/0/2
port link-mode bridge
port access vlan 20
#
interface GigabitEthernet1/0/3
port link-mode bridge
port service-loopback group 1
#
interface Tunnel1 mode ipv6-ipv4
ospfv3 1 area 0.0.0.0
source Vlan-interface10
destination 30.1.1.1
ipv6 address 3001::1/64
#
interface Tunnel2 mode ipv6-ipv4
ospfv3 1 area 0.0.0.0
source Vlan-interface10
destination 40.1.1.1
ipv6 address 4001::1/64
#
•Device B:
#
service-loopback group 1 type tunnel
#
ospfv3 1
router-id 2.2.2.2
area 0.0.0.0

8
#
vlan 10
#
vlan 20
#
interface Vlan-interface10
ip address 30.1.1.1 255.255.255.0
#
interface Vlan-interface20
ospfv3 1 area 0.0.0.0
ipv6 address 5001::1/64
#
interface GigabitEthernet1/0/1
port link-mode bridge
port access vlan 10
#
interface GigabitEthernet1/0/2
port link-mode bridge
port access vlan 20
#
interface GigabitEthernet1/0/3
port link-mode bridge
port service-loopback group 1
#
interface Tunnel1 mode ipv6-ipv4
ospfv3 1 area 0.0.0.0
source Vlan-interface10
destination 20.1.1.1
ipv6 address 3001::2/64
#
•Device C:
#
service-loopback group 1 type tunnel
#
ospfv3 1
router-id 3.3.3.3
area 0.0.0.0
#
vlan 10
#
vlan 20
#
interface Vlan-interface10
ip address 40.1.1.1 255.255.255.0
#
interface Vlan-interface20
ospfv3 1 area 0.0.0.0
ipv6 address 6001::1/64

9
#
interface GigabitEthernet1/0/1
port link-mode bridge
port access vlan 10
#
interface GigabitEthernet1/0/2
port link-mode bridge
port access vlan 20
#
interface GigabitEthernet1/0/3
port link-mode bridge
port service-loopback group 1
#
interface Tunnel2 mode ipv6-ipv4
ospfv3 1 area 0.0.0.0
source Vlan-interface10
destination 20.1.1.1
ipv6 address 4001::2/64
#
Related documentation
•H3C S7500E Switch Series Layer 3—IP Services Configuration Guide-Release 7150
•H3C S7500E Switch Series Layer 3—IP Services Command Reference-Release 7150
