H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-1
Chapter 1 802.1x Configuration
Note:
zThe online user handshaking function is added. See Configuring Basic 802.1x
Functions.
zThe configuration of 802.1x re-authentication is added. See Configuring 802.1x
Re-Authentication.
zThe configuration of the 802.1x re-authentication interval is added. See Configuring
the 802.1x Re-Authentication Timer.
zThe configuration of Quick EAD deployment is added. See Quick EAD Deployment
Configuration.
When configuring 802.1x, go to these sections for information you are interested in:
zIntroduction to 802.1x
zIntroduction to 802.1x Configuration
zBasic 802.1x Configuration
zAdvanced 802.1x Configuration
zDisplaying and Maintaining 802.1x Configuration
zConfiguration Example
1.1 Introduction to 802.1x
The 802.1x protocol (802.1x for short) was developed by IEEE802 LAN/WAN
committee to address security issues of wireless LANs. It was then used in Ethernet as
a common access control mechanism for LAN ports to address mainly authentication
and security problems.
802.1x is a port-based network access control protocol. It authenticates and controls
devices requesting for access in terms of the ports of LAN access devices. With the
802.1x protocol employed, a user-side device can access the LAN only when it passes
the authentication. Those fail to pass the authentication are denied when accessing the
LAN.
This section covers these topics:
zArchitecture of 802.1x Authentication
zThe Mechanism of an 802.1x Authentication System
zEncapsulation of EAPoL Messages
z802.1x Authentication Procedure

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-2
zTimers Used in 802.1x
z802.1x Implementation on an S3100-52P Switch
1.1.1 Architecture of 802.1x Authentication
As shown in Figure 1-1, 802.1x adopts a client/server architecture with three entities: a
supplicant system, an authenticator system, and an authentication server system.
Figure 1-1 Architecture of 802.1x authentication
zThe supplicant system is an entity residing at one end of a LAN segment and is
authenticated by the authenticator system at the other end of the LAN segment.
The supplicant system is usually a user terminal device. An 802.1x authentication
is triggered when a user launches client program on the supplicant system. Note
that the client program must support the extensible authentication protocol over
LAN (EAPoL).
zThe authenticator system is another entity residing at one end of a LAN segment.
It authenticates the connected supplicant systems. The authenticator system is
usually an 802.1x-supported network device (such as a H3C series switch). It
provides the port (physical or logical) for the supplicant system to access the LAN.
zThe authentication server system is an entity that provides authentication service
to the authenticator system. Normally in the form of a RADIUS server, the
authentication server system serves to perform Authentication, Authorization, and
Accounting (AAA) services to users. It also stores user information, such as user
name, password, the VLAN a user belongs to, priority, and the Access Control
Lists (ACLs) applied.
The four basic concepts related to the above three entities are PAE, controlled port and
uncontrolled port, the valid direction of a controlled port and the way a port iscontrolled.
I. PAE
A port access entity (PAE) is responsible for implementing algorithms and performing
protocol-related operations in the authentication mechanism.

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-3
zThe authenticator system PAE authenticates the supplicant systems when they
log into the LAN and controls the status (authorized/unauthorized) of the
controlled ports according to the authentication result.
zThe supplicant system PAE responds to the authentication requests received from
the authenticator system and submits user authentication information to the
authenticator system. It also sends authentication requests and disconnection
requests to the authenticator system PAE.
II. Controlled port and uncontrolled port
The authenticator system provides ports for supplicant systems to access a LAN.
Logically, a port of this kind is divided into a controlled port and an uncontrolled port.
zThe uncontrolled port can always send and receive packets. It mainly serves to
forward EAPoL packets to ensure that a supplicant system can send and receive
authentication requests.
zThe controlled port can be used to pass service packets when it is in authorized
state. It is blocked when not in authorized state. In this case, no packets can pass
through it.
zControlled port and uncontrolled port are two properties of a port. Packets
reaching a port are visible to both the controlled port and uncontrolled port of the
port.
III. The valid direction of a controlled port
When a controlled port is in unauthorized state, you can configure it to be a
unidirectional port, which sends packets to supplicant systems only.
By default, a controlled port is a unidirectional port.
IV. The way a port is controlled
A port of a H3C series switch can be controlled in the following two ways.
zPort-based authentication. When a port is controlled in this way, all the supplicant
systems connected to the port can access the network without being
authenticated after one supplicant system among them passes the authentication.
And when the authenticated supplicant system goes offline, the others are denied
as well.
zMAC-based authentication. All supplicant systems connected to a port have to be
authenticated individually in order to access the network. And when a supplicant
system goes offline, the others are not affected.
1.1.2 The Mechanism of an 802.1x Authentication System
IEEE 802.1x authentication system uses the Extensible Authentication Protocol (EAP)
to exchange information between the supplicant system and the authentication server.

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-4
Figure 1-2 The mechanism of an 802.1x authentication system
zEAP protocol packets transmitted between the supplicant system PAE and the
authenticator system PAE are encapsulated as EAPoL packets.
zEAP protocol packets transmitted between the authenticator system PAE and the
RADIUS server can either be encapsulated as EAP over RADIUS (EAPoR)
packets or be terminated at system PAEs. The system PAEs then communicate
with RADIUS servers through Password Authentication Protocol (PAP) or
Challenge-Handshake Authentication Protocol (CHAP) packets.
zWhen a supplicant system passes the authentication, the authentication server
passes the information about the supplicant system to the authenticator system.
The authenticator system in turn determines the state (authorized or unauthorized)
of the controlled port according to the instructions (accept or reject) received from
the RADIUS server.
1.1.3 Encapsulation of EAPoL Messages
I. The format of an EAPoL packet
EAPoL is a packet encapsulation format defined in 802.1x. To enable EAP protocol
packets to be transmitted between supplicant systems and authenticator systems
through LANs, EAP protocol packets are encapsulated in EAPoL format. The following
figure illustrates the structure of an EAPoL packet.
Figure 1-3 The format of an EAPoL packet
In an EAPoL packet:
zThe PAE Ethernet type field holds the protocol identifier. The identifier for 802.1x
is 0x888E.
zThe Protocol version field holds the version of the protocol supported by the
sender of the EAPoL packet.
zThe Type field can be one of the following:

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-5
00: Indicates that the packet is an EAP-packet, which carries authentication
information.
01: Indicates that the packet is an EAPoL-start packet, which initiates the
authentication.
02: Indicates that the packet is an EAPoL-logoff packet, which sends logging off
requests.
03: Indicates that the packet is an EAPoL-key packet, which carries key
information.
04: Indicates that the packet is an EAPoL-encapsulated-ASF-Alert packet, which
is used to support the alerting messages ofAlerting Standards Forum (ASF).
zThe Length field indicates the size of the Packet body field. A value of 0 indicates
that the Packet Body field does not exist.
zThe Packet body field differs with the Type field.
Note that EAPoL-Start, EAPoL-Logoff, and EAPoL-Key packets are only transmitted
between the supplicant system and the authenticator system. EAP packets are
encapsulated by RADIUS protocol to allow them successfully reach the authentication
servers. Network management-related information (such as alarming information) is
encapsulated in EAPoL-Encapsulated-ASF-Alert packets, which are terminated by
authenticator systems.
II. The format of an EAP packet
For an EAPoLpacket with the value of the Type field being EAP-packet, its Packet body
field is an EAP packet, whose format is illustrated in Figure 1-4.
015
Code
Data
Length
7
Identifier 2
4
N
Figure 1-4 The format of an EAP packet
In an EAP packet:
zThe Code field indicates the EAP packet type, which can be Request, Response,
Success, or Failure.
zThe Identifier field is used to match a Response packet with the corresponding
Request packet.
zThe Length field indicates the size of an EAP packet, which includes the Code,
Identifier, Length, and Data fields.
zThe Data field carries the EAP packet, whose format differs with the Code field.
ASuccess or Failure packet does not contain the Data field, so the Length field of it is 4.

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-6
Figure 1-5 shows the format of the Data field of a Request packet or a Response
packet.
Figure 1-5 The format of the Data field of a Request packet or a Response packet
zThe Type field indicates the EAP authentication type. A value of 1 indicates
Identity and that the packet is used to query the identity of the peer. A value of 4
represents MD5-Challenge (similar to PPP CHAP) and indicates that the packet
includes query information.
zThe Type Date field differs with types of Request and Response packets.
III. Newly added fields for EAP authentication
Two fields, EAP-message and Message-authenticator, are added to a RADIUS
protocol packet for EAP authentication. (Refer to the Introduction to RADIUS protocol
section in the AAA Operation for information about the format of a RADIUS protocol
packet.)
The EAP-message field, whose format is shown in Figure 1-6, is used to encapsulate
EAP packets. The maximum size of the string field is 253 bytes. EAP packets with their
size larger than 253 bytes are fragmented and are encapsulated in multiple
EAP-message fields. The type code of the EAP-message field is 79.
Figure 1-6 The format of an EAP-message field
The Message-authenticator field, whose format is shown in Figure 1-7, is used to
prevent unauthorized interception to access requesting packets during authentications
using CHAP, EAP, and so on.A packet with the EAP-message field must also have the
Message-authenticator field. Otherwise, the packet is regarded as invalid and is
discarded.
Figure 1-7 The format of an Message-authenticator field

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-7
1.1.4 802.1x Authentication Procedure
A H3C S3100-52P Ethernet switch can authenticate supplicant systems in EAP
terminating mode or EAP relay mode.
I. EAP relay mode
This mode is defined in 802.1x. In this mode, EAP packets are encapsulated in higher
level protocol (such as EAPoR) packets to enable them to successfully reach the
authentication server. Normally, this mode requires that the RADIUS server support the
two newly-added fields: the EAP-message field (with a value of 79) and the
Message-authenticator field (with a value of 80).
Four authentication ways, namely EAP-MD5, EAP-TLS (transport layer security),
EAP-TTLS (tunneled transport layer security), and Protected ExtensibleAuthentication
Protocol (PEAP), are available in the EAP relay mode.
zEAP-MD5 authenticates the supplicant system. The RADIUS server sends MD5
keys (contained in EAP-request/MD5 challenge packets) to the supplicant system,
which in turn encrypts the passwords using the MD5 keys.
zEAP-TLS allows the supplicant system and the RADIUS server to check each
other’s security certificate and authenticate each other’s identity, guaranteeing
that data is transferred to the right destination and preventing data from being
intercepted.
zEAP-TTLS is a kind of extended EAP-TLS. EAP-TLS implements bidirectional
authentication between the client and authentication server. EAP-TTLS transmit
message using a tunnel established using TLS.
zPEAP creates and uses TLS security channels to ensure data integrity and then
performs new EAP negotiations to verify supplicant systems.
Figure 1-8 describes the basic EAP-MD5 authentication procedure.

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-8
Supplicant system
PAE RADUIS
server
EAPOL EAPOR
EAPOL-Start
EAP- Request/Identity
EAP- Response /Identity
EAP- Request/MD5 challenge
EAP-Success
EAP- Response/MD5 challenge
RADIUS Access-Request
(EAP- Response /Identity)
RADIUS Access -Challenge
(EAP- Request/MD5 challenge)
RADIUS Access-Accept
(EAP-Success)
RADIUS Access - Request
(EAP- Response /MD5 challenge)
Port authorized
Handshake timer
Handshake request
[ EAP- Request /Identity]
Handshake response
[ EAP-Response / Identity]
EAPOL-Logoff
......
Port unauthorized
Authenticator system
PAE
Figure 1-8 802.1x authentication procedure (in EAP relay mode)
The detailed procedure is as follows:
zA supplicant system launches an 802.1x client to initiate an access request by
sending an EAPoL-start packet to the switch, with its user name and password
provided. The 802.1x client program then forwards the packet to the switch to start
the authentication process.
zUpon receiving the authentication request packet, the switch sends an
EAP-request/identity packet to ask the 802.1x client for the user name.
zThe 802.1x client responds by sending an EAP-response/identity packet to the
switch with the user name contained in it. The switch then encapsulates the packet
in a RADIUS Access-Request packet and forwards it to the RADIUS server.
zUpon receiving the packet from the switch, the RADIUS server retrieves the user
name from the packet, finds the corresponding password by matching the user
name in its database, encrypts the password using a randomly-generated key,
and sends the key to the switch through an RADIUS access-challenge packet.
The switch then sends the key to the 802.1x client.

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-9
zUpon receiving the key (encapsulated in an EAP-request/MD5 challenge packet)
from the switch, the client program encrypts the password of the supplicant
system with the key and sends the encrypted password (contained in an
EAP-response/MD5 challenge packet) to the RADIUS server through the switch.
(Normally, the encryption is irreversible.)
zThe RADIUS server compares the received encrypted password (contained in a
RADIUS access-request packet) with the locally-encrypted password. If the two
match, it will then send feedbacks (through a RADIUS access-accept packet and
an EAP-success packet) to the switch to indicate that the supplicant system is
authenticated.
zThe switch changes the state of the corresponding port to accepted state to allow
the supplicant system to access the network.
zThe supplicant system can also terminate the authenticated state by sending
EAPoL-Logoff packets to the switch. The switch then changes the port state from
accepted to rejected.
Note:
In EAP relay mode, packets are not modified during transmission. Therefore if one of
the four ways are used (that is, PEAP, EAP-TLS, EAP-TTLS or EAP-MD5) to
authenticate, ensure that the authenticating ways used on the supplicant system and
the RADIUS server are the same. However for the switch, you can simply enable the
EAP relay mode by using the dot1x authentication-method eap command.
II. EAP terminating mode
In this mode, EAP packet transmission is terminated at authenticator systems and the
EAP packets are converted to RADIUS packets. Authentication and accounting are
carried out through RADIUS protocol.
In this mode, PAP or CHAP is employed between the switch and the RADIUS server.
Figure 1-9 illustrates the authentication procedure (assuming that CHAP is employed
between the switch and the RADIUS server).

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-10
Supplicant
system
PAE
Authenticator
system PAE RADIUS server
EAPOL RADIUS
EAPOL-Start
EAP- Request/Identity
EAP- Response/Identity
EAP- Request/MD5 Challenge
EAP- Success
EAP-Response/MD5Challenge
RADIUS Access-Request
( CHAP-Response/MD5 Challenge)
RADIUS Access-Accept
(CHAP-Success)
Port
authorized
Handshake timer
Handshake request
[EAP- Request/Identity]
Handshake response
[EAP- Response/Identity]
EAPOL-Logoff
......
Port
unauthorized
Figure 1-9 802.1x authentication procedure (in EAP terminating mode)
The authentication procedure in EAP terminating mode is the same as that in the EAP
relay mode except that the randomly-generated key in the EAP terminating mode is
generated by the switch, and that it is the switch that sends the user name, the
randomly-generated key, and the supplicant system-encrypted password to the
RADIUS server for further authentication.
1.1.5 Timers Used in 802.1x
In 802.1 x authentication, the following timers are used to ensure that the supplicant
system, the switch, and the RADIUS server interact in an orderly way.
zHandshake timer (handshake-period). This timer sets the handshake period and
is triggered after a supplicant system passes the authentication. It sets the interval
for a switch to send handshake request packets to online users. You can set the
maximum number of transmission attempts by using the dot1x retry command.
An online user will be considered offline when the switch has not received any

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-11
response packets after the maximum number of handshake request transmission
attempts is reached.
zQuiet-period timer (quiet-period). This timer sets the quiet-period. When a
supplicant system fails to pass the authentication, the switch quiets for the set
period (set by the quiet-period timer) before it processes another authentication
request re-initiated by the supplicant system. During this quiet period, the switch
does not perform any 802.1x authentication-related actions for the supplicant
system.
zRe-authentication timer (reauth-period). The switch initiates 802.1x
re-authentication at the interval set by the re-authentication timer.
zRADIUS server timer (server-timeout). This timer sets the server-timeout period.
After sending an authentication request packet to the RADIUS server, the switch
sends another authentication request packet if it does not receive the response
from the RADIUS server when this timer times out.
zSupplicant system timer (supp-timeout). This timer sets the supp-timeout period
and is triggered by the switch after the switch sends a request/challenge packet to
a supplicant system. The switch sends another request/challenge packet to the
supplicant system if the switch does not receive the response from the supplicant
system when this timer times out.
zTransmission timer (tx-period). This timer sets the tx-period and is triggered by
the switch in two cases. The first case is when the client requests for
authentication. The switch sends a unicast request/identity packet to a supplicant
system and then triggers the transmission timer. The switch sends another
request/identity packet to the supplicant system if it does not receive the reply
packet from the supplicant system when this timer times out. The second case is
when the switch authenticates the 802.1x client who cannot request for
authentication actively. The switch sends multicast request/identity packets
periodically through the port enabled with 802.1x function. In this case, this timer
sets the interval to send the multicast request/identity packets.
zClient version request timer (ver-period). This timer sets the version period and is
triggered after a switch sends a version request packet. The switch sends another
version request packet if it does receive version response packets from the
supplicant system when the timer expires.
1.1.6 802.1x Implementation on an S3100-52P Switch
In addition to the earlier mentioned 802.1x features, an S3100-52P switch is also
capable of the following:
zChecking supplicant systems for proxies, multiple network adapters, and so on
(This function needs the cooperation of a CAMS server.)
zChecking client version
zThe guest VLAN function

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-12
Note:
H3C's CAMS Server is a service management system used to manage networks and to
secure networks and user information. With the cooperation of other networking
devices (such as switches) in the network, a CAMS server can implement the AAA
functions and rights management.
I. Checking the supplicant system
An S3100-52P switch checks:
zSupplicant systems logging on through proxies
zSupplicant systems logging on through IE proxies
zWhether or not a supplicant system logs in through more than one network
adapters (that is, whether or not more than one network adapters are active in a
supplicant system when the supplicant system logs in).
In response to any of the three cases, a switch can optionally take the following
measures:
zOnly disconnects the supplicant system but sends no Trap packets.
zSends Trap packets without disconnecting the supplicant system.
This function needs the cooperation of 802.1x client and a CAMS server.
zThe 802.1x client needs to be capable of detecting multiple network adapters,
proxies, and IE proxies.
zThe CAMS server is configured to disable the use of multiple network adapters,
proxies, or IE proxies.
By default, an 802.1x client program allows use of multiple network adapters, proxies,
and IE proxies. In this case, if the CAMS server is configured to disable use of multiple
network adapters, proxies, or IE proxies, it prompts the 802.1x client to disable use of
multiple network adapters, proxies, or IE proxies through messages after the supplicant
system passes the authentication.
Note:
zThe client-checking function needs the support of H3C’s 802.1x client program.
zTo implement the proxy detecting function, you need to enable the function on both
the 802.1x client program and the CAMS server in addition to enabling the client
version detecting function on the switch by using the dot1x version-check
command.

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-13
II. Checking the client version
With the 802.1x client version-checking function enabled, a switch checks the version
and validity of an 802.1x client to prevent unauthorized users or users with earlier
versions of 802.1x client from logging in.
This function makes the switch to send version-requesting packets again if the 802.1x
client fails to send version-reply packet to the switch when the version-checking timer
times out.
Note:
The 802.1x client version-checking function needs the support of H3C’s 802.1x client
program.
III. The guest VLAN function
The guest VLAN function enables supplicant systems that are not authenticated to
access network resources in a restrained way.
The guest VLAN function enables supplicant systems that do not have 802.1x client
installed to access specific network resources. It also enables supplicant systems that
are not authenticated to upgrade their 802.1x client programs.
With this function enabled:
zThe switch sends authentication triggering request (EAP-Request/Identity)
packets to all the 802.1x-enabled ports.
zAfter the maximum number retries have been made and there are still ports that
have not sent any response back, the switch will then add these ports to the guest
VLAN.
zUsers belonging to the guest VLAN can access the resources of the guest VLAN
without being authenticated. But they need to be authenticated when accessing
external resources.
Normally, the guest VLAN function is coupled with the dynamic VLAN delivery function.
Refer to AAA Operation for detailed information about the dynamic VLAN delivery
function.
IV. Enabling 802.1x re-authentication
802.1x re-authentication is timer-triggered or packet-triggered. It re-authenticates users
who have passed authentication. With 802.1x re-authentication enabled, the switch can
monitor the connection status of users periodically. If the switch receives no
re-authentication response from a user in a period of time, it tears down the connection

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-14
to the user. To connect to the switch again, the user needs to initiate 802.1x
authentication with the client software again.
Note:
zWhen re-authenticating a user, a switch goes through the complete authentication
process. It transmits the username and password of the user to the server. The
server may authenticate the username and password, or, however, use
re-authentication for only accounting and user connection status checking and
therefore does not authenticate the username and password any more.
zAn authentication server running CAMS authenticates the username and password
during re-authentication of a user in the EAP authentication mode but does not in
PAP or CHAP authentication mode.
PC
Internet
PC PC
RADIUS
Server
Switch
Figure 1-10 802.1x re-authentication
802.1x re-authentication can be enabled in one of the following two ways:
zThe RADIUS server has the switch perform 802.1x re-authentication of users. The
RADIUS server sends the switch an Access-Accept packet with the
Termination-Action attribute field of 1. Upon receiving the packet, the switch
re-authenticates the user periodically.
zYou enable 802.1x re-authentication on the switch. With 802.1x re-authentication
enabled, the switch re-authenticates users periodically.

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-15
Note:
802.1x re-authentication will fail if a CAMS server is used and configured to perform
authentication but not accounting. This is because a CAMS server establishes a user
session after it begins to perform accounting. Therefore, to enable 802.1x
re-authentication, do not configure the accounting none command in the domain.This
restriction does not apply to other types of servers.
1.2 Introduction to 802.1x Configuration
802.1x provides a solution for authenticating users. To implement this solution, you
need to execute 802.1x-related commands. You also need to configure AAA schemes
on switches and specify the authentication scheme (RADIUS or local authentication
scheme).
ISP domain
configuration AAA scheme
Local
authentication
RADIUS
scheme
802.1x
configuration ISP domain
configuration AAA scheme
Local
authentication
RADIUS
scheme
802.1x
configuration
Figure 1-11 802.1x configuration
z802.1x users use domain names to associate with the ISP domains configured on
switches
zConfigure the AAA scheme (a local authentication scheme or a RADIUS scheme)
to be adopted in the ISP domain.
zIf you specify to use a local authentication scheme, you need to configure the user
names and passwords manually on the switch. Users can pass the authentication
through 802.1x client if they provide user names and passwords that match those
configured on the switch.
zIf you specify to adopt the RADIUS scheme, the supplicant systems are
authenticated by a remote RADIUS server. In this case, you need to configure
user names and passwords on the RADIUS server and perform RADIUS
client-related configuration on the switches.
zYou can also specify to adopt the RADIUS authentication scheme, with a local
authentication scheme as a backup. In this case, the local authentication scheme
is adopted when the RADIUS server fails.
Refer to the AAA Operation for detailed information about AAA scheme configuration.

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-16
1.3 Basic 802.1x Configuration
1.3.1 Configuration Prerequisites
zConfigure ISP domain and the AAA scheme to be adopted. You can specify a
RADIUS scheme or a local scheme.
zEnsure that the service type is configured as lan-access (by using the
service-type command) if local authentication scheme is adopted.
1.3.2 Configuring Basic 802.1x Functions
Follow these steps to configure basic 802.1x functions:
To do… Use the command… Remarks
Enter system view system-view —
Enable 802.1x globally dot1x Required
By default, 802.1x is disabled
globally.
In system
view dot1x interface
interface-list
interface interface-type
interface-number
dot1x
Enable
802.1x for
specified
ports In port
view
quit
Required
By default, 802.1x is disabled
on all ports.
In system
view
dot1x port-control
{ authorized-force |
unauthorized-force |
auto } [ interface
interface-list ]
interface interface-type
interface-number
dot1x port-control
{authorized-force |
unauthorized-force |
auto }
Set port
access
control
mode for
specified
ports In port
view
quit
Optional
By default, an 802.1x-enabled
port operates in the auto
mode.
dot1x port-method
{ macbased |
portbased } [ interface
interface-list ]
Set port
access
method for
specified
ports
interface interface-type
interface-number
Optional
The default port access
method is
MAC-address-based (that is,
the macbased keyword is
used by default).

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-17
To do… Use the command… Remarks
dot1x port-method
{ macbased |
portbased }
quit
Set authentication
method for 802.1x
users
dot1x
authentication-method
{chap |pap |eap }
Optional
By default, a switch performs
CHAP authentication in EAP
terminating mode.
Enable online user
handshaking dot1x handshake
enable
Optional
By default, online user
handshaking is enabled.
Enter Ethernet port
view interface interface-type
interface-number —
Enable the handshake
packet protection
function
dot1x handshake
secure
Optional
By default, the handshake
packet protection function is
disabled.

Operation Manual – 802.1x and System Guard
H3C S3100-52P Ethernet switch Chapter 1 802.1x Configuration
1-18
Caution:
z802.1x configurations take effect only after you enable 802.1x both globally and for
specified ports.
zThe settings of 802.1x and MAC address learning limit are mutually exclusive.
Enabling 802.1x on a port will prevent you from setting the limit on MAC address
learning on the port and vice versa.
zThe settings of 802.1x and aggregation group member are mutually exclusive.
Enabling 802.1x on a port will prevent you from adding the port to an aggregation
group and vice versa.
zWhen a device operates as an authentication server, its authentication method for
802.1x users cannot be configured as EAP.
zWith the support of the H3C proprietary client, handshake packets are used to test
whether or not a user is online.
zAs clients that are not of H3C do not support the online user handshaking function,
switches cannot receive handshake acknowledgement packets from them in
handshakingperiods. To prevent users being falsely considered offline, you need to
disable the online user handshaking function in this case.
zThe handshake packet protection function requires the cooperation of the client and
the authentication server. If either of the two ends does not support the function, you
need to disable it on the other one.
1.3.3 Timer and Maximum User Number Configuration
Follow these steps to configure 802.1x timers and the maximum number of users:
To do… Use the command... Remarks
Enter system view system-view —
In system
view
dot1x max-user
user-number [ interface
interface-list ]
interface interface-type
interface-number
dot1x max-user
user-number
Set the
maximum
number of
concurrent
on-line
users for
specified
ports
In port
view
quit
Optional
By default, a port can
accommodate up to 256
users at a time.
