H3C S6805 Switch Series
Hardware Information and Specifications
Document version: 6W100-20220510
Copyright © 2022 New H3C Technologies Co., Ltd. All rights reserved.
No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of
New H3C Technologies Co., Ltd.
Except for the trademarks of New H3C Technologies Co., Ltd., any trademarks that may be mentioned in this document
are the property of their respective owners.
The information in this document is subject to change without notice

i
Contents
1 Product models and technical specifications············································1-2
Product models···············································································································································1-2
Technical specifications··································································································································1-2
2 Chassis views··························································································2-5
S6805-54HF····················································································································································2-5
S6805-54HT····················································································································································2-6
3 FRUs and compatibility matrixes······························································3-8
Power supplies················································································································································3-8
Fan trays·························································································································································3-9
4 Ports and LEDs······················································································4-11
Ports······························································································································································4-11
Console port··········································································································································4-11
Management Ethernet port ···················································································································4-11
USB port················································································································································4-12
SFP+ port··············································································································································4-12
QSFP28 port·········································································································································4-14
1/10GBASE-T autosensing Ethernet port·····························································································4-17
LEDs ·····························································································································································4-18
System status LED································································································································4-18
SFP+ port LED······································································································································4-18
QSFP28 port LED·································································································································4-19
1/10GBASE-T autosensing Ethernet port LEDs ···················································································4-19
Management Ethernet port LEDs··········································································································4-19
Fan tray alarm LEDs ·····························································································································4-20
5 Cooling system······················································································5-21

1-2
1 Product models and technical
specifications
Product models
The S6805 switch series includes the following models:
Product code Product model
LS-6805-54HF S6805-54HF
LS-6805-54HT S6805-54HT
Technical specifications
Table1-1 Technical specifications
Item S6805-54HF S6805-54HT
Dimensions
(H × W × D) 44 × 440 × 400 mm (1.73 × 17.32 × 15.75 in) 44 × 440 × 460 mm (1.73 × 17.32 × 18.11 in)
Weight ≤10 kg (22.05 lb) ≤10 kg (22.05 lb)
Console port •1 × mini USB console port
•1 × serial console port
•1 × mini USB console port
•1 × serial console port
Management
Ethernet port
•1 × 10M/100M/1000MBASE-T
copper port
•1 × SFP port
•1 × 10M/100M/1000MBASE-T copper
port
•1 × SFP port
USB port 1 1
1/10GBASE-T
autosensing
Ethernet port N/A 48
SFP+ port 48 N/A
QSFP28 port 6 6
Fan tray slot 5 5
Power supply
slot 2 2
Input voltage
PSR250-12A/PSR250-12A1:
•AC input
Rated voltage range: 100 to 240
VAC @ 50/60 Hz
Max voltage range: 90 to 290
VAC @ 47 to 63 Hz
•High-voltage DC input
Rated voltage range: 240 VDC

Max voltage range: 180 to 320
N/A

1-3
Item S6805-54HF S6805-54HT
VDC
PSR450-12A/PSR450-12A1:
•AC input
Rated voltage range: 100 to 240 VAC @ 50/60 Hz
Max voltage range: 90 to 290 VAC @ 47 to 63 Hz
•High-voltage DC input
Rated voltage range: 240 VDC
Max voltage range: 180 to 320 VDC
PSR450-12AHD:
•AC input
Rated voltage range: 100 to 240 VAC @ 50/60 Hz
Max voltage range: 90 to 290 VAC @ 47 to 63 Hz
•High-voltage DC input
Rated voltage range e: 240 to 380 VDC
Max voltage range: 180 to 400 VDC
PSR450-12D:
•Rated voltage range: –48 to –60 VDC
•Max voltage range: –36 to –72 VDC
Minimum
power
consumption
(For the power
consumption
data collection
standard, see
Table1-2)
PSR250-12A/PSR250-12A1:
•Single AC input: 82 W
•Dual AC inputs: 90 W
PSR450-12A/PSR450-12A1:
•Single AC input: 82 W
•Dual AC inputs: 90 W
PSR450-12AHD:
•Single DC input: 89 W
•Dual DC inputs: 96 W
PSR450-12D:
•Single DC input: 91 W
•Dual DC inputs: 95 W
PSR450-12A/PSR450-12A1:
•Single AC input: 93 W
•Dual AC inputs: 100 W
PSR450-12AHD:
•Single DC input: 91 W
•Dual DC inputs: 102 W
PSR450-12D:
•Single DC input: 94 W
•Dual DC inputs: 101 W
Typical power
consumption
(For the power
consumption
data collection
standard, see
Table1-2)
PSR250-12A/PSR250-12A1:
•Single AC input: 120 W
•Dual AC inputs: 127 W
PSR450-12A/PSR450-12A1:
•Single AC input: 120 W
•Dual AC inputs: 127 W
PSR450-12D:
•Single DC input: 130 W
•Dual DC inputs: 135 W
PSR450-12A/PSR450-12A1:
•Single AC input: 174 W
•Dual AC inputs: 181 W
PSR450-12D:
•Single DC input: 177 W
•Dual DC inputs: 188 W
Maximum
power
consumption
(For the power
consumption
data collection
standard, see
Table1-2)
PSR250-12A/PSR250-12A1:
•Single AC input: 208 W
•Dual AC inputs: 213 W
PSR450-12A/PSR450-12A1:
•Single AC input: 208 W
•Dual AC inputs: 213 W
PSR450-12AHD:
•Single DC input: 202 W
•Dual DC inputs: 214 W
PSR450-12A/PSR450-12A1:
•Single AC input: 222 W
•Dual AC inputs: 229 W
PSR450-12AHD:
•Single DC input: 225 W
•Dual DC inputs: 233 W
PSR450-12D:
•Single DC input: 230 W
•Dual DC inputs: 236 W

1-4
Item S6805-54HF S6805-54HT
PSR450-12D:
•Single DC input: 207 W
•Dual DC inputs: 217 W
Chassis
leakage
current
compliance
UL60950-1/EN60950-1/IEC60950-1/GB4943
Melting
current of
power supply
fuse
PSR250-12A/PSR250-12A1:
•6.3 A @ 250 VAC
•6.3 A @ 250 VDC N/A
PSR450-12A/PSR450-12A1:
•10 A @ 250 VAC
•10 A @ 310 VDC
PSR450-12D: 20 A @ 125 V
PSR450-12AHD: 10 A @ 420 V
Sound
pressure level
at 27°C
(80.6°F)
53.6 dB(A) 53.7 dB(A)
Operating
temperature 0°C to 45°C (32°F to 113°F)
Operating
humidity 5% RH to 95% RH, noncondensing
Fire
resistance
compliance UL60950-1/EN60950-1/IEC60950-1/GB4943
Table1-2 Power consumption data collection standard
Item Minimum power
consumption Typical power consumption Maximum power consumption
Configuration
•Two power modules
•No transceiver
modules/cables
installed in ports
•Two power modules
•Fully configured with
copper cables
•Two power modules
•Fully configured with
transceiver modules
Load N/A 50% load 100% load

2-5
2 Chassis views
S6805-54HF
Figure2-1 Front panel
(1) SFP+ port
(2) SFP+ port LED
(3) QSFP28 port
(4) QSFP28 port LED
Figure2-2 Rear panel
(1) Fiber management Ethernet port
(2) Console port
(3) Mini USB console port
(4) USB port
(5) Fan tray 1
(6) Fan tray 2
(7) Fan tray 3
(8) Fan tray 4
(9) Fan tray 5
(10) Power supply 1
(11) Power supply 2
(12) System status LED (SYS)
(13) Serial label pull tab
(14) Copper management Ethernet port LED (LINK/ACT)
(15) Copper management Ethernet port
(16) Fiber management Ethernet port LED (LINK/ACT)
The S6805-54HF switch has a serial label pull tab on the rear panel. It provides the ESN and MAC
address of the switch.
The switch comes with power supply slot PWR1 empty and power supply slot PWR2 installed with a
filler panel. In Figure2-2, two PSR450-12A power supplies are installed on the switch.
The switch comes with the five fan tray slots empty. You must install five fan trays of the same model
for the switch. In Figure2-2, five LSPM1FANSA fan trays are installed on the switch.

2-6
Figure2-3 Left side panel
(1) Primary grounding point
(2) Auxiliary grounding point
S6805-54HT
Figure2-4 Front panel
(1) 1/10GBASE-T autosensing Ethernet port
(2) 1/10GBASE-T autosensing Ethernet port LED
(3) QSFP28 port
(4) QSFP28 port LED
Figure2-5 Rear panel
(1) Fiber management Ethernet port
(2) Console port
(3) Mini USB console port
(4) USB port
(5) Fan tray 1
(6) Fan tray 2
(7) Fan tray 3
(8) Fan tray 4
(9) Fan tray 5
(10) Power supply 1
(11) Power supply 2
(12) System status LED (SYS)
(13) Serial label pull tab
(14) Copper management Ethernet port LED (LINK/ACT)
(15) Copper management Ethernet port
(16) Fiber management Ethernet port LED (LINK/ACT)
The S6805-54HT switch has a serial label pull tab on the rear panel. It provides the ESN and MAC
address of the switch.
The switch comes with power supply slot PWR1 empty and power supply slot PWR2 installed with a
filler panel. In Figure2-5, two PSR450-12A power supplies are installed on the switch.

2-7
The switch comes with the five fan tray slots empty. You must install five fan trays of the same model
for the switch. In Figure2-5, five LSPM1FANSA fan trays are installed in the fan tray slots.
Figure2-6 Left side panel
(1) Primary grounding point
(2) Auxiliary grounding point

3-8
3 FRUs and compatibility matrixes
CAUTION:
•
Select fan trays and power supplies with airflow directions that meet the ventilation requiremen
ts
at the installation site. As a best practice, make sure the power supplies and fan trays have the
same airflow direction.
•
Do not install fan trays of different models on the same switch. To guarantee adequate heat
dissipation, install five fan trays of the same model on the switch.
•
Do not install power supplies of different models on the same switch. As a best practice, install
two power supplies of the same model on the switch for 1+1 power supply redundancy.
Table3-1 Compatibility matrix between the FRUs and S6805 switches
FRUs Part No. S6805-54HF S6805-54HT
Power supplies
PSR250-12A 0231A6M0 Yes No
PSR250-12A1 0231A8FP Yes No
PSR450-12A 0231A6N9 Yes Yes
PSR450-12A1 0231A6NC Yes Yes
PSR450-12AHD 0231A6NA Yes Yes
PSR450-12D 0231A6NB Yes Yes
Fan trays
LSPM1FANSA 0231A2VT Yes in Release 6616 and later Release versions. For the support of ESS and Feature versions, contact H3C
Support.
LSPM1FANSB 0231A2VU Yes in Release 6616 and later Release versions. For the support of ESS and Feature versions, contact H3C
Support.
LSPM1FANSA-SN
(support electronic label
information reading) 0231AG9E Yes
LSPM1FANSB-SN
(support electronic label
information reading) 0231AG9F Yes
Power supplies
CAUTION:
When the
switch has two power supplies in 1+1 redundancy, you can replace one of them without
powering off the switch.
To avoid device damage and body injury, make sure the power supply
to be
replaced is powered off before you replace it.

3-9
Table3-2 Power supply specifications
Power supply Specifications Remarks
PSR250-12A (with an
airflow direction from
the power supply side
to the port side)
PSR250-12A1 (with
an airflow direction
from the port side to
the power supply
side)
•AC input:
Rated input voltage range: 100 to 240 VAC @
50/60 Hz
Max input voltage range: 90 to 290 VAC @ 47 to
63 Hz
Max output power: 250 W
•High-voltage DC input:
Rated input voltage range: 240 VDC
Max input voltage range: 180 to 320 VDC
Max output power: 250 W
For more information
about the power
supplies, see H3C
PSR250-12A &
PSR250-12A1 Series
Power Modules User
Manual.
PSR450-12A (with an
airflow direction from
the power supply side
to the port side)
PSR450-12A1 (with
an airflow direction
from the port side to
the power supply
side)
•AC input:
Rated input voltage range: 100 to 240 VAC @
50/60 Hz
Max input voltage range: 90 to 290 VAC @ 47 to
63 Hz
Max output power: 450 W
•High-voltage DC input:
Rated input voltage range: 240 VDC
Max input voltage range: 180 to 320 VDC
Max output power: 450 W For more information
about the power
supplies, see H3C
PSR450 Power
Module Series User
Manual.
PSR450-12AHD (with
an airflow direction
from the port side to
the power supply
side)
•AC input
Rated input voltage range: 100 to 240 VAC @
50/60 Hz
Max input voltage range: 90 to 290 VAC @ 47 to
63 Hz
Max output power: 450 W
•High-voltage DC input
Rated input voltage range: 240 to 380 VDC
Max input voltage range: 180 to 400 VDC
Max output power: 450 W
PSR450-12D (with an
airflow direction from
the port side to the
power supply side)
•Rated input voltage range: –48 to –60 VDC
•Max input voltage range: –36 to –72 VDC
•Max output power: 450 W
Fan trays
Table3-3 Fan tray specifications
Item Specifications
LSPM1FANSA/LSPM1FANSA-SN
Dimensions 41 × 40 × 105 mm (1.61 × 1.57 × 4.13 in), including the handle
Fan number 1
Fan speed 20000 R.P.M
Max airflow 20 CFM (0.57 m3/min)
Airflow direction From the power supply side to the port side

3-10
Item Specifications
Input voltage 12 V
Maximum power
consumption 9.8 W
Documentation
reference H3C LSPM1FANSA & LSPM1FANSB Fan Trays User Guide and H3C
LSPM1FANSA-SN & LSPM1FANSB-SN Fan Trays User Guide
LSPM1FANSB/LSPM1FANSB-SN
Dimensions 41 × 40 × 105 mm (1.61 × 1.57 × 4.13 in), including the handle
Fan number 1
Fan speed 20000 R.P.M
Max airflow 20 CFM (0.57 m3/min)
Airflow direction From the port side to the power supply side
Input voltage 12 V
Maximum power
consumption 9.8 W
Documentation
reference H3C LSPM1FANSA & LSPM1FANSB Fan Trays User Guide and H3C
LSPM1FANSA-SN & LSPM1FANSB-SN Fan Trays User Guide

4-11
4 Ports and LEDs
Ports
IMPORTANT:
•
As a best practice, use H3C transceiver modules and cables for the switch.
•
The H3C transceiver modules and cables are subject to change over time. For the most
up-to-date list of H3C transceiver modules and cables, contact H3C Support or marketing staff.
•
For more information about H3C transceiver modules and cables, see
H3C Transceiver Modules
User Guide.
Console port
The switch has two console ports: serial console port and Mini USB console port.
Table4-1 Console port specifications
Item Console port Mini USB console port
Connector type RJ-45 USB mini-Type B
Compliant
standard EIA/TIA-232 USB 2.0
Transmission
baud rate 9600 bps (default) to 115200 bps
Services
•Provides connection to an ASCII
terminal.
•Provides connection to the serial port of
a local or remote (through a pair of
modems) PC running terminal
emulation program.
•Provides connection to an ASCII
terminal.
•Provides connection to the USB
port of a local PC running terminal
emulation program.
Management Ethernet port
The switch provides a copper and a fiber management Ethernet port.
You can connect this port to a PC or management station for loading and debugging software or
remote management.
Table4-2 Copper management Ethernet port specifications
Item Specification
Connector type RJ-45
Connector quantity 1
Port transmission rate and duplex
mode 10/100/1000 Mbps, half/full duplex
Transmission medium and max
transmission distance 100 m (328.08 ft) over category-5 twisted pair cable

4-12
Item Specification
Functions and services Software and Boot ROM upgrade and network management
Table4-3 Fiber management Ethernet port specifications
Item Specification
Connector type LC
Connector quantity 1
Port transmission rate 100/1000 Mbps, full duplex
Transmission medium and max
transmission distance See Table4-4 and Table4-5.
Functions and services Software upgrade and network management
Table4-4 FE SFP transceiver modules
FE SFP transceiver
module
Central
wavelength
(nm) Connector Fiber type and
diameter (µm) Max transmission distance
SFP-FE-SX-MM1310-
A 1310 LC Multi-mode, 50/125 2 km (1.24 miles)
Multi-mode, 62.5/125
SFP-FE-LX-SM1310-A 1310 LC Single-mode, 9/125 15 km (9.32 miles)
SFP-FE-LH40-SM131
0 1310 LC Single-mode, 9/125 40 km (24.86 miles)
USB port
The switch has one OHC-compliant USB2.0 port that can upload and download data at a rate up to
480 Mbps. You can use this USB port to access the file system on the flash file system of the switch,
for example, to upload or download application and configuration files.
IMPORTANT
:
•
USB devices from different vendors vary in compatibility and driver. H3C does not guarantee
correct operation of all USB devices on the switch.
If a USB device fails to operate on the switch,
replace it with one from another vendor.
•
The USB port on the switch is designed to output current in strict accordance with the USB 2.0
standard. For a USB storage device to be identified by the USB port, make sure the USB device
fully complies with USB 2.0.
SFP+ port
An S6805-54HF switch provides 48 SFP+ ports. The SFP+ ports support the following transceiver
modules and cables:
•
Gigabit SFP transceiver modules in Table4-5.
•
10-Gigabit SFP+ transceiver modules in Table4-6.
•
10-Gigabit SFP+ copper cables in Table4-7.
•
10-Gigabit SFP+ fiber cables in Table4-8.

4-13
IMPORTANT:
•
To use a Gigabit SFP transceiver module except for an SFP-GE-T or SFP-GE-T-D transceiver
module to connect an SFP+ port on the switch to the peer end, disable autonegotiation on the
peer end.
•
Installed with an SFP-GE-T or SFP-GE-T-D transceiver module, an SFP+
port can operate only
at 1 Gbps.
Table4-5 Gigabit SFP transceiver modules available for the SFP+ ports
Gigabit SFP
transceiver
module
Central
wavelength
(nm) Connector Cable/Fiber
type and
diameter (µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
SFP-GE-T
SFP-GE-T-D N/A RJ-45 Twisted pair
cable N/A 100 m (328.08 ft)
SFP-GE-SX-M
M850-A
SFP-GE-SX-M
M850-D
850 LC
Multi-mode,
50/125 500 550 m (1804.46 ft)
400 500 m (1640.42 ft)
Multi-mode,
62.5/125 200 275 m (902.23 ft)
160 220 m (721.78 ft)
SFP-GE-LX-SM
1310-A 1310 LC
Single-mode,
9/125 N/A 10 km (6.21 miles)
Multi-mode,
50/125 500 or 400 550 m (1804.46 ft)
Multi-mode,
62.5/125 500 550 m (1804.46 ft)
SFP-GE-LX-SM
1310-D 1310 LC Single-mode, 9/125 N/A 10 km (6.21 miles)
SFP-GE-LH40-
SM1310
SFP-GE-LH40-
SM1310-D
1310 LC Single-mode,
9/125 N/A 40 km (24.86 miles)
SFP-GE-LH40-
SM1550 1550 LC Single-mode, 9/125 N/A 40 km (24.86 miles)
SFP-GE-LH80-
SM1550
SFP-GE-LH80-
SM1550-D
1550 LC Single-mode,
9/125 N/A 80 km (49.71 miles)
SFP-GE-LH100
-SM1550 1550 LC Single-mode,
9/125 N/A 100 km (62.14
miles)
Table4-6 10-Gigabit SFP+ transceiver modules available for the SFP+ ports
10-Gigabit
SFP+
transceiver
module
Central
waveleng
th (nm) Connector Fiber type and
diameter (µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
SFP-XG-SX-MM
850-A 850 LC Multi-mode, 50/125 2000 300 m (984.25 ft)
500 82 m (269.03 ft)

4-14
10-Gigabit
SFP+
transceiver
module
Central
waveleng
th (nm) Connector Fiber type and
diameter (µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
400 66 m (216.54 ft)
Multi-mode,
62.5/125 200 33 m (108.27 ft)
160 26 m (85.30 ft)
SFP-XG-LX-SM1
310 1310 LC Single-mode, 9/125 N/A 10 km (6.21 miles)
SFP-XG-LH40-S
M1550
SFP-XG-LH40-S
M1550-D
1550 LC Single-mode,
9/125 N/A 40 km (24.86 miles)
SFP-XG-LH80-S
M1550
SFP-XG-LH80-S
M1550-D
1550 LC Single-mode,
9/125 N/A 80 km (49.71 miles)
Table4-7 SFP+ copper cables available for the SFP+ ports
SFP+ copper cable Max transmission distance
LSWM1STK 0.65 m (2.13 ft)
LSWM2STK 1.2 m (3.94 ft)
LSWM3STK 3 m (9.84 ft)
LSTM1STK 5 m (16.40 ft)
Table4-8 SFP+ fiber cables available for the SFP+ ports
SFP+ fiber cable Max transmission distance Data rate
SFP-XG-D-AOC-7M 7 m (22.97 ft)
10.31 Gbps
SFP-XG-D-AOC-10M 10 m (32.81 ft)
SFP-XG-D-AOC-20M 20 m (65.62 ft)
QSFP28 port
Only interfaces numbered 51 and 52 on an S6805-54HT switch can be split into four interfaces. Only
interfaces numbered 27 and 28 on an S6805-54HF switch can be split into four interfaces. Only
Release 6635 and later versions support port splitting. QSFP28 ports support the following
transceiver modules and cables:
•
QSFP28 transceiver modules in Table4-9.
•
QSFP28 copper cables in Table4-10.
•
QSFP28 fiber cables in Table4-11.
•
QSFP28 to 4 × 25G SFP28 copper cables in Table4-12.
•
QSFP+ transceiver modules in Table4-13.
•
QSFP+ copper cables in Table4-14.

4-15
•
QSFP+ fiber cables in Table4-15.
•
QSFP+ to 4 × 10G SFP+ copper cables in Table4-16.
Table4-9 100G QSFP28 transceiver modules available for the QSFP28 ports
Model Central
wavelength
(nm) Connector Cable/Fiber
type and
diameter (µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
QSFP-100G-S
R4-MM850 850 MPO (PC
polished,
12-fiber)
Multi-mode,
50/125
2000 70 m (229.66 ft)
4700 100 m (328.08 ft)
QSFP-100G-BI
DI-MM850 (end
of sale)
Two lanes:
•855
•908 LC Multi-mode,
50/125
2000 70 m (229.66 ft)
4700 100 m (328.08 ft)
QSFP-100G-eS
R4-MM850 850 MPO (PC
polished,
12-fiber)
Multi-mode,
50/125 4700 300 m (984.25 ft)
QSFP-100G-S
WDM4-MM850
Four lanes:
•850
•880
•910
•940
LC Multi-mode,
50/125
2000 75 m (246.06 ft)
4700 100 m (328.08 ft)
QSFP-100G-PS
M4-SM1310 1295 to 1325 MPO (APC
polished,
12-fiber)
Single-mode,
9/125 N/A 0.5 km (0.31 miles)
QSFP-100G-LR
4-WDM1300
QSFP-100G-LR
4-WDM1300-A
Four lanes:
•1295
•1300
•1304
•1309
LC Single-mode,
9/125 N/A 10 km (6.21
miles)
QSFP-100G-LR
4L-WDM1300
Four lanes:
•1271
•1291
•1311
•1331
LC Single-mode,
9/125 N/A 2 km (1.24 miles)
QSFP-100G-E
R4L-WDM1300
Four lanes:
•1295.56
•1300.05
•1304.58
•1309.14
LC Single-mode,
9/125 N/A 40 km (24.86 miles)
QSFP-100G-C
WDM4-SM1300
-A
Four lanes:
•1271
•1291
•1311
•1331
LC Single-mode,
9/125 N/A 2 km (1.24
miles)
Table4-10 QSFP28 copper cables available for the QSFP28 ports
Model Max transmission distance
QSFP-100G-D-CAB-1M 1 m (3.28 ft)

4-16
Model Max transmission distance
QSFP-100G-D-CAB-3M 3 m (9.84 ft)
QSFP-100G-D-CAB-5M 5 m (16.40 ft)
Table4-11 QSFP28 fiber cables available for the QSFP28 ports
QSFP28 fiber cable Max transmission distance Data rate
QSFP-100G-D-AOC-7M 7 m (22.97 ft)
100 Gbps
QSFP-100G-D-AOC-10M 10 m (32.81 ft)
QSFP-100G-D-AOC-20M 20 m (65.62 ft)
Table4-12 100G QSFP28 to 4 × 25G SFP28 copper cables available for the QSFP28 ports
QSFP28 fiber cable Max transmission distance
QSFP-100G-4SFP-25G-CAB-1M 1 m (3.28 ft)
QSFP-100G-4SFP-25G-CAB-3M 3 m (9.84 ft)
QSFP-100G-4SFP-25G-CAB-5M 5 m (16.40 ft)
Table4-13 40GE QSFP+ transceiver modules available for the QSFP28 ports
QSFP+
transceiver
module
Central
wavelength
(nm) Connector Fiber type
and diameter
(µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
QSFP-40G-SR
4-MM850 850 MPO (PC
polished,
12-fiber)
Multi-mode,
50/125
2000 100 m (328.08 ft)
4700 150 m (492.12 ft)
QSFP-40G-CS
R4-MM850 850 MPO (PC
polished,
12-fiber)
Multi-mode,
50/125
2000 300 m (984.25 ft)
4700 400 m (1312.33 ft)
QSFP-40G-LR4
-PSM1310 1310 MPO (PC
polished,
12-fiber)
Single-mode,
9/125 N/A 10 km (6.21 miles)
QSFP-40G-BID
I-SR-MM850 850 LC Multi-mode,
50/125 2000 100 m (328.08 ft)
4700 150 m (492.12 ft)
QSFP-40G-BID
I-WDM850
Four lanes:
•850
•880
•910
•940
LC Multi-mode,
50/125
2000 240 m (787.40 ft)
4700 350 m (1148.29 ft)
QSFP-100G-E
R4L-WDM1300
Four lanes:
•1295.56
•1300.05
•1304.58
•1309.14
LC Single-mode,
9/125 N/A 40 km (24.86 miles)
QSFP-40G-LR4
-WDM1300 Four lanes:
•1271 LC Single-mode,
9/125 N/A 10 km (6.21 miles)

4-17
QSFP+
transceiver
module
Central
wavelength
(nm) Connector Fiber type
and diameter
(µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
•1291
•1311
•1331
QSFP-40G-LR4
L-WDM1300
Four lanes:
•1271
•1291
•1311
•1331
LC Single-mode,
9/125 N/A 2 km (1.24 miles)
Table4-14 QSFP+ copper cables available for the QSFP28 ports
QSFP+ copper cable Max transmission distance
LSWM1QSTK0 1 m (3.28 ft)
LSWM1QSTK1 3 m (9.84 ft)
LSWM1QSTK2 5 m (16.40 ft)
Table4-15 QSFP+ fiber cables available for the QSFP28 ports
QSFP+ fiber cable Max transmission distance Data rate
QSFP-40G-D-AOC-3M 3 m (9.84 ft)
40 Gbps
QSFP-40G-D-AOC-7M 7 m (22.97 ft)
QSFP-40G-D-AOC-10M 10 m (32.81 ft)
QSFP-40G-D-AOC-20M 20 m (65.62 ft)
Table4-16 40G QSFP+ to 4 × 10G SFP+ copper cables available for the QSFP28 ports
QSFP+ fiber cable Max transmission distance
LSWM1QSTK3 1 m (3.28 ft)
LSWM1QSTK4 3 m (9.84 ft)
LSWM1QSTK5 5 m (16.40 ft)
1/10GBASE-T autosensing Ethernet port
An S6805-54HT switch provides forty-eight 1/10GBASE-T autosensing Ethernet ports.
When a 10GBase-T Ethernet interface on an S6805-54HT switch operates at 1 Gbps, you must
configure the speed 1000 command on the local end.
If you execute the speed and duplex commands or their undo forms on a 10GBase-T Ethernet
interface on an S6805-54HT switch or its peer interface, the interface will go down and then come
up.

4-18
Table4-17 1/10GBASE-T autosensing Ethernet port specifications
Item Specification
Connector type RJ-45
Port transmission rate, duplex
mode, and auto-MDIX 1/10 Gbps, full duplex, MDI/MDIX autosensing
Transmission medium and max
transmission distance
•55 m (180.45 ft) over category-6 unshielded twisted pair cable
•100 m (328.08 ft) over category-6 shielded twisted pair cable
•100 m (328.08 ft) over category-6A or above twisted pair cable
Compatible standards •IEEE 802.3ab
•IEEE 802.3an
To avoid interference between cables, layer cables as follows:
•
Use category-6A or above cables and connectors.
•
Do not bundle cables in their first 20 m (65.62 ft).
•
Separate power cords and twisted pair cables at and around the distribution frame.
•
For ports adjacent to one another on the device, the peer ports on the distribution frame are
preferably not adjacent, for example:
If the device connects to one distribution frame, connect port 1 on the device to port 1 on the
distribution frame, port 2 on the device to port 3 on the distribution frame, and port 3 on the
device to port 5 on the distribution frame.
If the device connects to two distribution frames, connect port 1 on the device to port 1 on
distribution frame 1, port 2 on the device to port 1 on distribution frame 2, and port 3 on the
device to port 2 on distribution frame 1.
LEDs
System status LED
The system status LED shows the operating status of the switch.
Table4-18 System status LED description
LED mark Status Description
SYS
Steady green The switch is operating correctly.
Flashing green The switch is performing power-on self test (POST).
Steady red The system has failed POST, or a fault has occurred.
Flashing red Some ports have failed POST.
Flashing blue (3 Hz) Helps you to locate the device.
To locate the device, execute the locator blink command on
the device. Then the SYS LED will be in this state.
Off The switch is powered off or has failed to start up.
SFP+ port LED
Each SFP+ port has a status LED to show its operating status and activities.

4-19
Table4-19 SFP+ port LED description
LED status Description
Steady green A transceiver module or cable has been correctly installed. The port has a link
and is operating at 10 Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow A transceiver module or cable has been correctly installed. The port has a link
and is operating at 1 Gbps.
Flashing yellow (3 Hz) The port is sending or receiving data at 1 Gbps.
Off No transceiver module or cable has been installed or no link is present on the
port.
QSFP28 port LED
Each QSFP28 port has a status LED to show its operating status and activities.
Table4-20 QSFP28 port LED description
LED status Description
Steady green A transceiver module or cable has been correctly installed. The port has a link
and is operating at 100 Gbps.
Flashing green The port is sending or receiving data at 100 Gbps.
Steady yellow A transceiver module or cable has been correctly installed. The port has a link
and is operating at 40 Gbps.
Flashing yellow (3 Hz) The port is sending or receiving data at 40 Gbps.
Off No transceiver module or cable has been installed or no link is present on the
port.
1/10GBASE-T autosensing Ethernet port LEDs
Table4-21 1/10GBASE-T autosensing Ethernet port LED description
Status Description
Steady green The port has a link and is operating at 10 Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow The port has a link and is operating at 1 Gbps.
Flashing yellow The port is sending or receiving data at 1 Gbps.
Off No link is present on the port.
Management Ethernet port LEDs
The switch provides a LINK/ACT LED for each management Ethernet port. To view the description
for the copper management Ethernet port LED, see Table4-22. To view the description for the fiber
management Ethernet port LED, see Table4-23.
