H3C S5500-EI series User manual

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Table of Contents
i
Table of Contents
Chapter 1 LLDP Configuration.....................................................................................................1-1
1.1 Introduction to LLDP..........................................................................................................1-1
1.1.1 Overview .................................................................................................................1-1
1.1.2 LLDP Fundamental.................................................................................................1-1
1.1.3 TLV Types...............................................................................................................1-2
1.1.4 Protocols and Standards.........................................................................................1-4
1.2 LLDP Configuration Tasks List..........................................................................................1-4
1.3 Performing Basic LLDP Configuration...............................................................................1-5
1.3.1 Enabling LLDP ........................................................................................................1-5
1.3.2 Setting LLDP Operating Mode................................................................................1-6
1.3.3 Configuring LLDPDU TLVs.....................................................................................1-6
1.3.4 Enable LLDP Polling ...............................................................................................1-8
1.3.5 Configuring the Parameters Concerning LLDPDU Sending...................................1-8
1.4 Configuring LLDP Trap......................................................................................................1-9
1.5 Displaying and Maintaining LLDP....................................................................................1-10
1.6 LLDP Configuration Example ..........................................................................................1-11
1.6.1 LLDP Configuration Example................................................................................1-11

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-1
Chapter 1 LLDP Configuration
When configuring LLDP, go to these sections for information you are interested in:
zIntroduction to LLDP
zLLDP Configuration Tasks List
zPerforming Basic LLDP Configuration
zConfiguring LLDP Trap
zDisplaying and Maintaining LLDP
zLLDP Configuration Example
1.1 Introduction to LLDP
1.1.1 Overview
Link Layer Discovery Protocol (LLDP) operates on data link layer. It stores and
maintains theinformation about the local device and the devices directly connected to it
for network administrators to manage networks through NMS (network management
systems). In LLDP, device information is encapsulated in LLDPDUs in the form of TLV
(meaning type, length, and value) triplets and is exchanged between directly connected
devices. Information in LLDPDUs received is restored in standard MIB (management
information base).
1.1.2 LLDP Fundamental
I. LLDP operating mode
LLDP can operate in one of the following modes.
zTxRx mode. A port in this mode sends and receives LLDPDUs.
zTx mode. A port in this mode only sends LLDPDUs.
zRx mode. A port in this mode only receives LLDPDUs.
zDisable mode. A port in this mode does not send or receive LLDPDUs.
LLDP is initialized when an LLDP-enabled port changes to operate in another LLDP
operating mode. To prevent LLDP from being initialized too frequently, LLDP
undergoes a period before being initialized on an LLDP-enabled port when the port
changes to operate in another LLDP operating mode. The period is known as
initialization delay, which is determined by the re-initialization delay timer.
II. Sending LLDPDUs
An LLDP-enabled device operating in the TxRx mode or Tx mode sends LLDPDUs to
its directly connected devices periodically. It also sends LLDPDUs when the local
configuration changes to inform the neighboring devices of the change timely. In any of

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-2
the two cases, an interval exists between two successive operations of sending
LLDPDUs. This prevents the network from being overwhelmed by LLDPDUs even if the
LLDP operating mode changes frequently.
To enable the neighboring devices to be informed of the existence of a device or an
LLDP operating mode change (from the disable mode to TxRx mode, or from the Rx
mode to Tx mode) timely, a device can invoke the fast sending mechanism. In this case,
the interval to send LLDPDUs changes to one second. After the device sends specific
number of LLDPDUs, the interval restores to the normal. (A neighbor is discovered
when a device receives an LLDPDU and no information about the sender is locally
available.)
III. Receiving LLDPDUs
An LLDP-enabled device operating in the TxRx mode or Rx mode checks the TLVs
carried in the LLDPDUs it receives and saves the valid neighboring information. An
LLDPDU also carries a TTL (time to live) setting with it. The information about a
neighboring device maintained locally ages out when the corresponding TTL expires.
The TTL of the information about a neighboring device is determined by the following
expression:
TTL multiplier × LLDPDU sending interval.
You can set the TTL by configuring the TTL multiplier. Note that the TTL can be up to
65535 seconds. TTLs longer than it will be rounded off to 65535 seconds.
1.1.3 TLV Types
TLVs encapsulated in LLDPDUs fall into these categories: basic TLV, organization
defined TLV, and MED (media endpoint discovery) related TLV. Basic TLVs are the
base of device management. Organization specific TLVs and MED related TLVs are
used for enhanced device management. They are defined in standards or by
organizations and are optional to LLDPDUs.
I. Basic LLDP TLVs
Table 1-1 lists the basic LLDP TLV types that are currently in use.

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-3
Table 1-1 Basic LLDP TLVs
Type Description Remarks
End of LLDPDU TLV Marks the end of an LLDPDU.
Chassis ID TLV Carries the bridge MAC address of the
sender
Port ID TLV
Carries the sending port. For devices
that do not send MED TLVs, port ID
TLVs carry sending port name. For
devices that send MED TLVs, port ID
TLVs carry the MAC addresses of the
sending ports or bridge MAC addresses
(if the MAC addresses of the sending
ports are unavailable).
Time To Live TLV Carries the TTL of device information
Required
for LLDP
Port Description TLV Carries Ethernet port description
System Name TLV Carries device name
System Description TLV Carries system description
System Capabilities TLV Carries information about system
capabilities
Management Address
TLV
Carries the management address, the
corresponding port number, and OID
(object identifier).
If the management address is not
configured, it is the IP address of the
interface of the VLAN with the least
VLAN ID among those permitted on the
port. If the IP address of the VLAN
interface is not configured, IP address
127.0.0.1 is used as the management
address.
Optional to
LLDP
II. Organization defined LLDP TLVs
1) LLDP TLVs defined in IEEE802.1 include the following:
zPort VLAN ID TLV, which carries port VLAN ID.
zPort and protocol VLAN ID TLV, which carries port protocol VLAN ID.
zVLAN name TLV, which carries port VLAN name.
zProtocol identity TLV, which carries types of the supported protocols.
Note:
Currently, protocol identity TLVs can only be received on H3C devices.

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-4
2) IEEE 802.3 defined LLDP TLVs include the following:
zMAC/PHY configuration/status TLV, which carries port configuration, such as port
speed, duplex state, whether port speed auto-negotiation is supported, the stateof
auto-negotiation, current speed , and current duplex state.
zPower via MDI TLV, which carries information about power supply capabilities.
zLink aggregation TLV, which carries the capability and state of link aggregation.
zMaximum frame size TLV, which carries the maximum frame size supported,
namely, MTU (maximum transmission unit).
III. MED related LLDP TLVs
zLLDP-MED capabilities TLV, which carries the MED type of the current device and
the types of the LLDP MED TLVs that can be encapsulated in LLDPDUs.
zNetwork policy TLV, which carries port VLAN ID, supported applications (such as
voice and video services), application priority, and the policy adopted.
zExtended power-via-MDI TLV, which carries the information about the power
supply capability of the current device.
zHardware revision TLV, which carries the hardware version of an MED device.
zFirmware revision TLV, which carries the firmware version of an MED device.
zSoftware revision TLV, which carries the software version of an MED device.
zSerial number TLV, which carries the serial number of an MED device.
zManufacturer name TLV, which carries the manufacturer name of an MED device.
zModel name TLV, which carries the model of an MED device.
zAsset ID TLV, which carries the asset ID of an MED device. Asset ID is used for
directory management and asset tracking.
zLocation identification TLV, which carries the location identification of a device.
Location identification can be used in location-based applications.
Note:
For detailed information about LLDP TLV, refer to IEEE 802.1AB-2005 and
ANSI/TIA-1057.
1.1.4 Protocols and Standards
zIEEE 802.1AB-2005, Station and Media Access Control Connectivity Discovery
zANSI/TIA-1057, Link Layer Discovery Protocol for Media Endpoint Devices
1.2 LLDP Configuration Tasks List
Complete these tasks to configure LLDP:

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-5
Task Remarks
Enabling LLDP Required
Setting LLDP Operating Mode Optional
Configuring LLDPDU TLVs Optional
Enable LLDP Polling Optional
Basic LLDP
configuration
Configuring the Parameters Concerning
LLDPDU Sending Optional
Configuring LLDP Trap Optional
1.3 Performing Basic LLDP Configuration
1.3.1 Enabling LLDP
Follow these steps to enable LLDP:
To do… Use the command… Remarks
Enter system view system-view —
Enable LLDP globally lldp enable
Required
The default global state of
LLDP varies with device
models.
Enter
Ethernet
interface
view
interface interface-type
interface-number
Enter
Ethernet
interface
view/port
group
view Enter port
group view
port-group
{aggregation agg-id |
manual
port-group-name }
Either of the two is
required.
Configuration performed
in Ethernet interface view
applies to the current port
only; configuration
performed in port group
view applies to all the
ports in the corresponding
port group.
Enable LLDP lldp enable Optional
By default, LLDP is
enabled on a port.
Note:
To make LLDP take effect, you need to enable it both globally and on the related ports.

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-6
1.3.2 Setting LLDP Operating Mode
Follow these steps to set LLDP operating mode:
To do… Use the command… Remarks
Enter system view system-view —
Set the initialization delay
period lldp timer reinit-delay
value Optional
2 seconds by default.
Enter
Ethernet
interface
view
interface interface-type
interface-number
Enter
Ethernet
interface
view/port
group
view Enter port
group view
port-group
{aggregation agg-id |
manual
port-group-name }
Either of the two is
required.
Configuration performed
in Ethernet interface view
applies to the current port
only; configuration
performed in port group
view applies to all the
ports in the corresponding
port group.
Set the LLDP operating
mode lldp admin-status {disable | rx | tx | txrx } Optional
TxRx by default.
1.3.3 Configuring LLDPDU TLVs
Follow these steps to configure LLDPDU TLVs:
To do… Use the command… Remarks
Enter system view system-view —
Set the TTL multiplier lldp hold-multiplier value Optional
4 by default.
Enter
Ethernet
interface
view
interface interface-type
interface-number
Enter
Ethernet
interface
view/port
group
view
Enter
port
group
view
port-group {aggregation
agg-id | manual
port-group-name }
Either of the two is
required.
Configuration performed
in Ethernet interface view
applies to the current port
only; configuration
performed in port group
view applies to all the
ports in the corresponding
port group.

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-7
To do… Use the command… Remarks
Enable LLDP TLV
sending for specific
types of LLDP TLVs
lldp tlv-enable {basic-tlv
{ all | port-description |
system-capability |
system-description |
system-name } | dot1-tlv
{ all | port-vlan-id |
protocol-vlan-id [ vlan-id ] |
vlan-name [ vlan-id ] } |
dot3-tlv { all |
link-aggregation |
mac-physic |
max-frame-size | power } |
med-tlv { all | capability |
location-id { civic-address
device-type country-code
{ca-type ca-value }&<1-10> |
elin-address Tel-Number } |
network-policy |
power-over-ethernet |
inventory }}
Optional
By default, all types of
LLDP TLVs except
location identification TLV
are sent.
Specify the
management address
and specify to send
the management
address through
LLDPDUs
lldp
management-address-tlv
[ ip-address ]
Optional
By default, the
management address is
sent through LLDPDUs,
and the management
address is the IP address
of the interface of the
VLAN with the least VLAN
ID among those permitted
on the port. If the IP
address of the VLAN
interface is not configured,
IP address 127.0.0.1 is
used as the management
address. Refer to VLAN
Configuration for
information about VLAN.

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-8
Note:
zTo enable MED related LLDP TLV sending, you need to enable LLDP-MED
capabilities TLV sending first. Conversely, to disable LLDP-MED capabilities TLV
sending, you need to disable the sending of other MED related LLDP TLVs.
zTo disable MAC/PHY configuration/status TLV sending, you need to disable
LLDP-MED capabilities TLV sending first.
zWhen executing the lldp tlv-enable command, specifying the all keyword for basic
LLDP TLVs and organization defined LLDP TLVs (including IEEE 802.1 defined
LLDP TLVs and IEEE 802.3 defined LLDP TLVs) enables sending of all the
corresponding LLDP TLVs. For MED related LLDP TLVs, the all keyword enables
sending of all the MED related LLDP TLVs except location identification TLVs.
zEnabling sending of LLDP-MED capabilities TLVs also enables sending of
MAC/PHY configuration/status TLVs.
1.3.4 Enable LLDP Polling
With LLDP polling enabled, a device checks for the local configuration changes
periodically. Upon detecting a configuration change, the device sends LLDPDUs to
inform the neighboring devices of the change.
Follow these steps to enable LLDP polling:
To do… Use the command… Remarks
Enter system view system-view —
Enter
Ethernet
interface
view
interface interface-type
interface-number
Enter
Ethernet
interface
view/port
group view Enter port
group view
port-group
{aggregation agg-id |
manual
port-group-name }
Either of the two is
required.
Configuration performed
in Ethernet interface view
applies to the current port
only; configuration
performed in port group
view applies to all the
ports in the corresponding
port group.
Enable LLDP polling and
set the polling interval
lldp
check-change-interval
value
Optional
Disabled by default
1.3.5 Configuring the Parameters Concerning LLDPDU Sending
I. Configuring time-related parameters
Follow these steps to set time-related parameters:

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-9
To do… Use the command… Remarks
Enter system view System-view —
Set the interval to send
LLDPDUs lldp timer tx-interval
value Optional
30 seconds by default
Set the delay period to
send LLDPDUs lldp timer tx-delay value Optional
2 seconds by default
Caution:
To enable local device information to be updated on neighboring devices before being
aged out, make sure the interval to send LLDPDUs is shorter than the TTL of the local
device information.
II. Setting the number of the LLDPDUs to be sent when a new neighboring
device is detected
Follow these steps to set the number of the LLDPDUs to be sent when a new
neighboring device is detected
To do… Use the command… Remarks
Enter system view system-view —
Set the number of the LLDPDUs to be
sent successively when a new
neighboring device is detected lldp fast-count value Optional
3 by default
1.4 Configuring LLDP Trap
LLDP trap is used to notify NMS of the events such as new neighboring devices
detected and link malfunctions.
LLDP traps are sent periodically and you can set the interval to send LLDP traps. In
response to topology changes detected, a device sends LLDP traps according to the
interval configured to inform the neighboring devices of the changes.

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-10
Follow these steps to configure LLDP trap:
To do… Use the command… Remarks
Enter system view system-view —
Enter
Ethernet
interface
view
interface interface-type
interface-number
Enter
Ethernet
interface
view/port
group
view Enter port
group view
port-group
{aggregation agg-id |
manual
port-group-name }
Either of the two is
required.
Configuration performed
in Ethernet interface view
applies to the current port
only; configuration
performed in port group
view applies to all the
ports in the corresponding
port group.
Enable LLDP trap sending lldp notification
remote-change enable Required
Disabled by default
Quit to system view quit —
Set the interval to send
LLDP traps
lldp timer
notification-interval
value
Optional
5 seconds by default
1.5 Displaying and Maintaining LLDP
To do… Use the command… Remarks
Display the global LLDP
information or the
information contained in
the LLDP TLVs to be sent
through a port
display lldp local-information
[global |interface interface-type
interface-number ]
Available in any
view
Display the information
contained in the LLDP
TLVs received through a
port
display lldp
neighbor-information
[interface interface-type
interface-number ] [ brief ]
Available in any
view
Display LLDP statistics display lldp statistics [ global |
interface interface-type
interface-number ]
Available in any
view
Display LLDP status of a
port display lldp status [interface interface-type interface-number ] Available in any view
Display the types of the
LLDP TLVs that are
currently sent
display lldp tlv-config
[interface interface-type
interface-number ]
Available in any
view

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-11
1.6 LLDP Configuration Example
1.6.1 LLDP Configuration Example
I. Network requirements
zThe NMS and Switch A are located in the same Ethernet. An MED device and
Switch B are connected to GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2 of
Switch A.
zEnable LLDP on the ports of Switch A and Switch B to monitor the link between
Switch A and Switch B and the link between Switch A and the MED device on the
NMS.
II. Network diagram
Figure 1-1 Network diagram for LLDP configuration
III. Configuration procedure
1) Configure Switch A.
# Enter system view.
<SwitchA> system-view
# Enable LLDP globally.
[SwitchA] lldp enable
# Enable LLDP on GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2, setting the LLDP
operating mode to Rx.
[SwitchA] interface GigabitEthernet1/0/1
[SwitchA-GigabitEthernet1/0/1] lldp enable
[SwitchA-GigabitEthernet1/0/1] lldp admin-status rx
[SwitchA-GigabitEthernet1/0/1] quit
[SwitchA] interface GigabitEthernet1/0/2

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-12
[SwitchA-GigabitEthernet1/0/2] lldp enable
[SwitchA-GigabitEthernet1/0/2] lldp admin-status rx
[SwitchA-GigabitEthernet1/0/2] quit
2) Configure Switch B.
# Enter system view.
<SwitchB> system-view
# Enable LLDP globally.
[SwitchB] lldp enable
# Enable LLDP on GigabitEthernet1/0/1, setting the LLDP operating mode to Tx.
[SwitchB] interface GigabitEthernet1/0/1
[SwitchB-GigabitEthernet1/0/1] lldp enable
[SwitchB-GigabitEthernet1/0/1] lldp admin-status tx
3) Verify the configuration.
# Display the global LLDP status and port LLDP status on Switch A.
<SwitchA> display lldp status
Global status of LLDP : Enable
The current number of neighbors : 2
Neighbor information last changed time : 0 days, 0 hours, 4 minutes, 40 seconds
Transmit interval : 30s
Hold multiplier : 4
Reinit delay : 2s
Transmit delay : 2s
Trap interval : 5s
Fast start times : 3
Port 0 [GigabitEthernet1/0/1] :
Port status of LLDP : Enable
Admin status : Rx_Only
Trap flag : No
Roll time : 0s
Number of neighbors : 1
Number of MED neighbors : 1
Number of sent optional TLV : 0
Number of received unknown TLV : 0
Port 1 [GigabitEthernet1/0/2] :
Port status of LLDP : Enable
Admin status : Rx_Only
Trap flag : No

Operation Manual – LLDP
H3C S5500-EI Series Ethernet Switches Chapter 1 LLDP Configuration
1-13
Roll time : 0s
Number of neighbors : 1
Number of MED neighbors : 0
Number of sent optional TLV : 0
Number of received unknown TLV : 3
# Tear down the link between Switch A and Switch B and then display the global LLDP
status and port LLDP status on Switch A.
<SwitchA> display lldp status
Global status of LLDP : Enable
The current number of neighbors : 1
Neighbor information last changed time : 0 days, 0 hours, 5 minutes, 20 seconds
Transmit interval : 30s
Hold multiplier : 4
Reinit delay : 2s
Transmit delay : 2s
Trap interval : 5s
Fast start times : 3
Port 0 [GigabitEthernet1/0/1] :
Port status of LLDP : Enable
Admin status : Rx_Only
Trap flag : No
Roll time : 0s
Number of neighbors : 1
Number of MED neighbors : 1
Number of sent optional TLV : 0
Number of received unknown TLV : 5
Port 1 [GigabitEthernet1/0/2] :
Port status of LLDP : Enable
Admin status : Rx_Only
Trap flag : No
Roll time : 0s
Number of neighbors : 0
Number of MED neighbors : 0
Number of sent optional TLV : 0
Number of received unknown TLV : 0
