H3C S9500E Series User manual

H3C S9500E Series Routing Switches
Security Configuration Guide
Hangzhou H3C Technologies Co., Ltd.
http://www.h3c.com

Copyright © 2003-2010, Hangzhou H3C Technologies Co., Ltd. and its licensors
All Rights Reserved
No part of this manual may be reproduced or transmitted in any form or by any means without prior
written consent of Hangzhou H3C Technologies Co., Ltd.
Trademarks
H3C, , Aolynk, , H3Care, , TOP G, , IRF, NetPilot, Neocean, NeoVTL,
SecPro, SecPoint, SecEngine, SecPath, Comware, Secware, Storware, NQA, VVG, V2G, VnG, PSPT,
XGbus, N-Bus, TiGem, InnoVision and HUASAN are trademarks of Hangzhou H3C Technologies Co.,
Ltd.
All other trademarks that may be mentioned in this manual are the property of their respective owners.
Notice
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.
Environmental Protection
This product has been designed to comply with the requirements on environmental protection. The
storage, use, and disposal of this product must meet the applicable national laws and regulations.

Preface
The H3C S9500E documentation set includes 13 configuration guides, which describe the software
features for the H3C S9500E Series 10G Core Routing Switches and guide you through the software
configuration procedures. These configuration guides also provide configuration examples to help you
apply software features to different network scenarios.
This preface includes:
•Audience
•Conventions
•About the H3C S9500E Documentation Set
•Obtaining Documentation
•Documentation Feedback
Audience
This documentation is intended for:
Network planners
Field technical support and servicing engineers
Network administrators working with the S9500E series
Conventions
This section describes the conventions used in this documentation set.
Command conventions
Convention Descri
p
tion
Boldface Bold text represents commands and keywords that you enter literally as shown.
italic Italic text represents arguments that you replace with actual values.
[ ] Square brackets enclose syntax choices (keywords or arguments) that are
optional.
{ x | y | ... }
Braces enclose a set of required syntax choices separated by vertical bars, from
which you select one.
[ x | y | ... ]
Square brackets enclose a set of optional syntax choices separated by vertical
bars, from which you select one or none.
{ x | y | ... } *
Asterisk marked braces enclose a set of required syntax choices separated by
vertical bars, from which you select at least one.
[ x | y | ... ] *
Asterisk marked square brackets enclose optional syntax choices separated by

4
Convention Descri
p
tion
vertical bars, from which you may select multiple choices or none.
&<1-n> The argument or keyword and argument combination before the ampersand (&)
sign can be entered 1 to n times.
# A line that starts with a pound (#) sign is comments.
GUI conventions
Convention Descri
p
tion
< > Button names are inside angle brackets. For example, click <OK>.
[ ] Window names, menu items, data table and field names are inside square
brackets. For example, pop up the [New User] window.
/ Multi-level menus are separated by forward slashes. For example,
[File/Create/Folder].
Symbols
Convention Descri
p
tion
Means reader be extremely careful. Improper operation may cause bodily
injury.
Means reader be careful. Improper operation may cause data loss or damage
to equipment.
Means an action or information that needs special attention to ensure successful
configuration or good performance.
Means a complementary description.
Means techniques helpful for you to make configuration with ease.
Network topology icons
Convention Descri
p
tion
Represents a generic network device, such as a router, switch, or firewall.
Represents a routing-capable device, such as a router or Layer 3 switch.
Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router
that supports Layer 2 forwarding and other Layer 2 features.

5
About the H3C S9500E documentation set
Cate
g
or
y
Documents Pur
p
oses
Product description and
specifications
Marketing brochures Describe product specifications and benefits.
Technology white papers Provide an in-depth description of software features
and technologies.
Card datasheets Describe card specifications, features, and standards.
Hardware specifications
and installation
Compliance and safety
manual
Provides regulatory information and the safety
instructions that must be followed during installation.
Quick start
Guides you through initial installation and setup
procedures to help you quickly set up and use your
device with the minimum configuration.
Installation guide Provides a complete guide to hardware installation
and hardware specifications.
Card manuals Provide the hardware specifications of cards.
H3C N68 Cabinet
Installation and Remodel
Introduction
Guides you through installing and remodeling H3C
N68 cabinets.
H3C Pluggable SFP
[SFP+][XFP] Transceiver
Modules Installation
Guide
Guides you through installing SFP/SFP+/XFP
transceiver modules.
Adjustable Slider Rail
Installation Guide
Guides you through installing adjustable slider rails to
a rack.
H3C High-End Network
Products Hot-Swappable
Module Manual
Describes the hot-swappable modules available for the
H3C high-end network products, their external views,
and specifications.
Installation videos Show how to install the LSTM1PEMC and
LSTM1PEM2N AC-input power supply modules.
Software configuration
Configuration guides Describe software features and configuration
procedures.
Command references Provide a quick reference to all available commands.
Configuration examples Describe typical network scenarios and provide
configuration examples and instructions.
Operations and
maintenance
System log messages Explains the system log messages.
Trap messages Explains the trap messages.
MIB Companion Describes the MIBs for the software release.
Release notes
Provide information about the product release,
including the version history, hardware and software
compatibility matrix, version upgrade information,
technical support information, and software
upgrading.
Error code reference Explains the error codes for the QoS module.

6

7
Obtaining documentation
You can access the most up-to-date H3C product documentation on the World Wide Web at
http://www.h3c.com.
Click the links on the top navigation bar to obtain different categories of product documentation:
[Technical Support & Documents > Technical Documents] – Provides hardware installation, software
upgrading, and software feature configuration and maintenance documentation.
[Products & Solutions] – Provides information about products and technologies, as well as solutions.
[Technical Support & Documents > Software Download] – Provides the documentation released with the
software version.
Documentation feedback
You can e-mail your comments about product documentation to [e-mail].
We appreciate your comments.

8
Table of Contents
Preface ·········································································································································································· 3
Audience············································································································································································3
Conventions ·······································································································································································3
About the H3C S9500E documentation set···················································································································5
AAA configuration ·····················································································································································14
Introduction to AAA ······················································································································································· 14
Introduction to RADIUS ·················································································································································· 15
Client/Server model·············································································································································· 15
Security and authentication mechanisms ············································································································ 16
Basic message exchange process of RADIUS···································································································· 16
RADIUS packet format ·········································································································································· 17
Extended RADIUS attributes ································································································································· 22
Introduction to HWTACACS ········································································································································· 22
Differences between HWTACACS and RADIUS································································································ 22
Basic message exchange process of HWTACACS··························································································· 23
Domain-based user management································································································································· 25
AAA-across-VPNs··························································································································································· 26
Protocols and standards ················································································································································ 26
AAA configuration task list ··········································································································································· 27
Configuring AAA ··························································································································································· 28
Configuration prerequisites ·································································································································· 28
Creating an ISP domain ······································································································································· 28
Configuring ISP domain attributes······················································································································· 29
Configuring AAA authentication method for an ISP domain············································································ 30
Configuring AAA authorization methods for an ISP domain ··········································································· 31
Configuring AAA accounting methods for an ISP domain ··············································································· 33
Configuring local user attributes·························································································································· 34
Configuring user group attributes························································································································ 36
Disconnect user connections ································································································································ 37
Configuring a NAS ID-VLAN binding················································································································· 37
Displaying and maintaining AAA ································································································································ 38
Configuring RADIUS ······················································································································································ 38
Creating a RADIUS scheme ································································································································· 38
Specifying the VPN instance································································································································ 39
Specifying the RADIUS authentication/authorization servers ·········································································· 39
Specifying the RADIUS accounting servers and relevant parameters ····························································· 40
Specifying the shared keys for RADIUS packets································································································ 41
Setting the upper limit of RADIUS request retransmission attempts·································································· 42
Setting the supported RADIUS server type·········································································································· 42

9
Setting the status of RADIUS servers···················································································································· 43
Configuring attributes related to data to be sent to the RADIUS server ·························································· 44
Enabling the RADIUS trap function······················································································································ 45
Specifying the source IP address for RADIUS packets to be sent····································································· 45
Setting timers regarding RADIUS servers············································································································ 46
Specifying security policy servers························································································································ 47
Enabling the listening port of the RADIUS client ································································································ 48
Specifying to interpret RADIUS class attribute as CAR parameters ································································· 48
Displaying and maintaining RADIUS ·················································································································· 49
Configuring HWTACACS ············································································································································· 49
Creating an HWTACACS scheme ······················································································································ 50
Specifying the VPN instance································································································································ 50
Specifying the HWTACACS authentication servers ·························································································· 50
Specifying the HWTACACS authorization servers···························································································· 51
Specifying the HWTACACS accounting servers································································································ 51
Setting the shared key for HWTACACS packets······························································································· 52
Configuring attributes related to the data sent to HWTACACS server ··························································· 53
Specifying the source IP address for HWTACACS packets to be sent···························································· 53
Setting timers regarding HWTACACS servers··································································································· 54
Displaying and maintaining HWTACACS ········································································································· 55
AAA configuration examples········································································································································ 55
AAA for telnet user by an HWTACACS server·································································································· 55
AAA for telnet users by separate servers············································································································ 57
AAA for SSH users by a RADIUS server············································································································· 59
Troubleshooting AAA ···················································································································································· 62
Troubleshooting RADIUS······································································································································· 62
Troubleshooting HWTACACS······························································································································ 64
802.1X configuration ················································································································································65
802.1X overview ··························································································································································· 65
Architecture of 802.1X ········································································································································· 65
Authentication modes of 802.1X························································································································· 65
Basic concepts of 802.1X ···································································································································· 66
EAP over LAN ························································································································································ 67
EAP over RADIUS ·················································································································································· 68
802.1X authentication triggering ························································································································ 69
Authentication process of 802.1X······················································································································· 69
802.1X access control method···························································································································· 72
802.1X timers ························································································································································ 73
Features working together with 802.1X ············································································································· 73
802.1X basic configuration·········································································································································· 75
Configuration prerequisites ·································································································································· 75
Configuring 802.1X globally······························································································································· 76
Configuring 802.1X for a port ···························································································································· 77

10
Configuring the online user handshake function ········································································································ 78
Enabling the multicast trigger function························································································································· 79
Specifying a mandatory authentication domain for a port ······················································································· 79
Enabling the quiet timer················································································································································· 80
Enabling the re-authentication function························································································································ 80
Configuring a guest VLAN············································································································································ 80
Configuring an Auth-Fail VLAN···································································································································· 81
Displaying and maintaining 802.1X ··························································································································· 82
802.1X configuration example ···································································································································· 82
Guest VLAN and VLAN assignment configuration example ····················································································· 85
MAC authentication configuration····························································································································88
MAC authentication overview ······································································································································ 88
RADIUS-based MAC authentication ···················································································································· 88
Local MAC authentication ···································································································································· 88
Related concepts ···························································································································································· 89
MAC authentication timers··································································································································· 89
Quiet MAC address ·············································································································································· 89
Configuring MAC authentication ································································································································· 89
Configuration prerequisites ·································································································································· 89
Configuration procedure ······································································································································ 89
Displaying and maintaining MAC authentication ······································································································ 90
MAC authentication configuration examples·············································································································· 91
Local MAC authentication configuration ············································································································ 91
RADIUS-based MAC authentication configuration ···························································································· 92
Portal configuration····················································································································································95
Introduction to portal············································································································································· 95
Introduction to extended portal functions············································································································ 95
Portal system components····································································································································· 95
Portal authentication mode··································································································································· 97
Portal authentication process ······························································································································· 98
Basic portal configuration ············································································································································· 99
Configuration prerequisites ·································································································································· 99
Configuration procedure ······································································································································ 99
Configuring a portal-free rule ·····································································································································100
Configuring an authentication subnet························································································································101
Logging out users ·························································································································································101
Specifying a mandatory authentication domain·······································································································101
Specifying a NAS ID profile for an interface············································································································102
Setting the maximum number of online portal users ································································································103
Displaying and maintaining a portal·························································································································103
Portal configuration examples ····································································································································104
Configuring Layer 3 portal authentication········································································································104
Configuring Layer 3 portal authentication with extended functions ······························································106

11
Troubleshooting the portal ··········································································································································108
Inconsistent keys on the access device and the portal server·········································································108
Incorrect server port number on the access device··························································································108
Public key configuration ········································································································································· 110
Public key algorithm overview····································································································································110
Basic concepts ·····················································································································································110
Key algorithm types·············································································································································110
Asymmetric key algorithm applications ············································································································111
Configuring the local asymmetric key pair ···············································································································111
Creating an asymmetric key pair ······················································································································111
Displaying or exporting the local RSA or DSA host public key······································································112
Destroying an asymmetric key pair ···················································································································112
Configuring the public key of a peer·························································································································112
Displaying and maintaining public keys ···················································································································113
Public key configuration examples·····························································································································114
Configuring the public key of a peer manually ·······························································································114
Importing the public key of a peer from a public key file···············································································116
SSH2.0 configuration ············································································································································· 120
SSH2.0 overview ·························································································································································120
Introduction to SSH2.0 ·······································································································································120
Operation of SSH················································································································································120
Configuring the device as an SSH server··················································································································123
Enabling SSH server ···········································································································································123
Configuring the user interfaces for SSH clients································································································123
Configuring a client public key··························································································································124
Configuring an SSH user····································································································································125
Setting the SSH management parameters ········································································································126
Configuring the device as an SSH client···················································································································127
Specifying a source IP address/interface for the SSH client ··········································································127
Configuring whether first-time authentication is supported·············································································127
Establishing a connection between the SSH client and the server·································································128
Displaying and maintaining SSH ·······························································································································129
SSH server configuration examples ···························································································································129
When switch acts as server for password authentication···············································································130
When switch acts as server for public key authentication··············································································131
SSH client configuration examples·····························································································································137
When switch acts as client for password authentication ················································································137
When switch acts as client for public key authentication ···············································································140
SFTP service····························································································································································· 143
SFTP overview·······························································································································································143
Configuring an SFTP server·········································································································································143
Configuration prerequisites ································································································································143

12
Enabling the SFTP server ····································································································································143
Configuring the SFTP connection idle timeout period ·····················································································143
Configuring an SFTP client··········································································································································144
Specifying a source IP address or interface for the SFTP client······································································144
Establishing a connection to the SFTP server····································································································144
Working with the SFTP directories ····················································································································145
Working with SFTP files······································································································································146
Displaying help information ·······························································································································147
Terminating the connection to the remote SFTP server ····················································································147
SFTP client configuration example ·····························································································································147
SFTP server configuration example ····························································································································151
IP source guard configuration ································································································································ 153
IP source guard overview············································································································································153
Configuring a static IP source guard binding entry··································································································154
Configuring the dynamic IP source guard binding function····················································································155
Displaying and maintaining IP source guard············································································································155
IP source guard configuration examples ···················································································································156
Static IP source guard binding entry configuration example··········································································156
Dynamic IP source guard binding function configuration example I·····························································157
Dynamic IP source guard binding function configuration example II····························································159
Troubleshooting IP source guard ································································································································160
Failed to configure static binding entries and dynamic binding function ·····················································160
IP source guard configuration ································································································································ 161
IP source guard overview············································································································································161
Configuring a static IP source guard binding entry··································································································162
Configuring the dynamic IP source guard binding function····················································································163
Displaying and maintaining IP source guard············································································································163
IP source guard configuration examples ···················································································································164
Static IP source guard binding entry configuration example··········································································164
Dynamic IP source guard binding function configuration example I·····························································165
Dynamic IP source guard binding function configuration example II····························································167
Troubleshooting IP source guard ································································································································168
Failed to configure static binding entries and dynamic binding function ·····················································168
URPF configuration·················································································································································· 169
URPF overview······························································································································································169
What is URPF ·······················································································································································169
How URPF works ·················································································································································169
Configuring URPF·························································································································································170
URPF configuration example·······································································································································171
URPF configuration·················································································································································· 172
URPF overview······························································································································································172
What is URPF ·······················································································································································172

13
How URPF works ·················································································································································172
Configuring URPF·························································································································································173
URPF configuration example·······································································································································174
Obtaining support for your product······················································································································· 175
Register your product···················································································································································175
Purchase value-added services···································································································································175
Troubleshoot online······················································································································································175
Access software downloads········································································································································176
Telephone technical support and repair····················································································································176
Contact us ·····································································································································································176
Appendix A : RADIUS attributes ···························································································································· 177
Commonly used standard RADIUS attributes············································································································177
Proprietary RADIUS sub-attributes of H3C ················································································································178
Acronyms································································································································································· 180
Index ········································································································································································ 195

14
AAA configuration
The switch operates in IRF mode or standalone, (the default), mode. For more information about the IRF
mode, see IRF in the IRF Configuration Guide.
Introduction to AAA
Authentication, authorization, and accounting (AAA) provide a uniform framework for configuring
these three security functions when implementing network security management.
AAA usually uses a client/server model, where the client runs on the network access server (NAS)
and the server maintains user information centrally. In an AAA network, a NAS is a server for
users but a client for the AAA servers. See Figure 1.
Figure 1 AAA networking diagram
When attempting to establish a connection to the NAS and to obtain the rights to access other
networks or network resources, the NAS authenticates you or the corresponding connection. The
NAS can transparently pass your AAA information to the server (RADIUS server or HWTACACS
server). The RADIUS/HWTACACS protocol defines how a NAS and a server exchange use
information.
In the AAA network, there is a RADIUS server and an HWTACACS server. See Figure 1. You can
determine the authentication, authorization, and accounting methods according to the actual
requirements. For example, you can use the HWTACACS server for authentication and
authorization, and the RADIUS server for accounting.
The three security functions are described as follows:
•Authentication: Identifies remote users and determines if they are legal.
•Authorization: Grants user’s rights. For example, a user logging into the server can be
granted the permission to access and print the files on the server.

15
•Accounting: Records all network service usage information of users. This includes the service
type, start and end time, and traffic. In this way, accounting can be used for charging and
network security surveillance.
You can use AAA to provide one or two security functions. For example, if your company only
wants employees to be authenticated before they access specific resources, you only need to
configure an authentication server. If network usage information is needs to be recorded, you must
also configure an accounting server.
AAA provides a uniform framework to implement network security management. It is a security
mechanism that enables authenticated and authorized entities to access specific resources and
records operations of the entities. The AAA framework thus allows for scalability and centralized
user information management.
AAA can be implemented through multiple protocols. Currently, the switch supports using RADIUS,
and HWTACACS for AAA, and RADIUS is often used in practice.
Introduction to RADIUS
Remote authentication dial-in user service (RADIUS) is a distributed information interaction protocol
in a client/server model. RADIUS can protect networks against unauthorized access and is often
used in network environments where both high security and remote user access are required.
Based on UDP, RADIUS uses UDP port 1812 for authentication and 1813 for accounting. RADIUS
defines the RADIUS packet format and message transfer mechanism.
RADIUS was originally designed for dial-in user access. With the diversification of access
methods, RADIUS now supports additional access methods, such as Ethernet and ADSL access.
RADIUS uses authentication and authorization when providing access services and uses
accounting to collect and record usage information of network resources.
Client/Server model
•Client: The RADIUS client runs on the NASs located throughout the network. It passes user
information to designated RADIUS servers and acts on the responses (for example, rejects or
accepts user access requests).
•Server: The RADIUS server runs on the computer or workstation at the network center and
maintains information related to user authentication and network service access. It listens to
connection requests, authenticates users, and returns the processing results (for example,
rejecting or accepting the user access request) to the clients.
In general, the RADIUS server maintains three databases: Users, Clients, and Dictionary. See
Figure 2:

16
Figure 2 RADIUS server components
•Users: Stores user information such as the username, password, applied protocols, and IP
address.
•Clients: Stores information about RADIUS clients, such as the shared keys and IP addresses.
•Dictionary: Stores information about the meanings of RADIUS protocol attributes and their
values.
Security and authentication mechanisms
Information exchanged between a RADIUS client and the RADIUS server is authenticated with a
shared key that is never transmitted over the network. This enhances information exchange security
and prevents user passwords from being intercepted in non-secure networks. RADIUS encrypts
passwords before transmitting them.
A RADIUS server supports multiple user authentication methods. Moreover, a RADIUS server can
act as the client of another AAA server to provide authentication proxy services.
Basic message exchange process of RADIUS
Figure 3 shows the interaction of the host, the RADIUS client, and the RADIUS server.

17
Figure 3 Basic message exchange process of RADIUS
RADIUS operates in the following way:
1. The host initiates a connection request carrying the username and password to the RADIUS
client.
2. Having received the username and password, the RADIUS client sends an authentication
request (Access-Request) to the RADIUS server, with the user password encrypted by using
the Message-Digest 5 (MD5) algorithm and the shared key.
3. The RADIUS server authenticates the username and password. If the authentication succeeds,
it sends back an Access-Accept message containing the user’s authorization information. If
the authentication fails, it returns an Access-Reject message.
4. The RADIUS client permits or denies the user according to the returned authentication result.
If it permits the user, it sends a start-accounting request (Accounting-Request) to the RADIUS
server.
5. The RADIUS server returns a start-accounting response (Accounting-Response) and starts
accounting.
6. The user accesses the network resources.
7. The host requests the RADIUS client to tear down the connection and the RADIUS client
sends a stop-accounting request (Accounting-Request) to the RADIUS server.
8. The RADIUS server returns a stop-accounting response (Accounting-Response) and stops
accounting for the user.
9. The user stops access to network resources.
RADIUS packet format
RADIUS uses UDP to transmit messages. UPD ensures a smooth message exchange between the
RADIUS server and the client through a series of mechanisms, including the timer management

18
mechanism, retransmission mechanism, and slave server mechanism. Figure 4 shows the RADIUS
packet format.
Figure 4 RADIUS packet format
Descriptions of the fields are as follows:
1. The Code field (1-byte long) indicates the type of the RADIUS packet. Table 1 shows
potential values and their meanings.
Table 1 Main values of the Code field
Code Packet type Description
1 Access-Request
From the client to the server. A packet of this type carries
user information for the server to authenticate the user. It
must contain the User-Name attribute and can optionally
contain the attributes of NAS-IP-Address, User-Password,
and NAS-Port.
2 Access-Accept
From the server to the client: If all the attribute values
carried in the Access-Request are acceptable (the
authentication succeeds), the server sends an Access-
Accept response.
3 Access-Reject
From the server to the client. If any attribute value
carried in the Access-Request is unacceptable, the server
rejects the user and sends an Access-Reject response.
4 Accounting-Request
From the client to the server: A packet of this type carries
user information for the server to start/stop accounting
for the user. It contains the Acct-Status-Type attribute,
which indicates whether the server is requested to start
the accounting or to end the accounting.
5 Accounting-Response
From the server to the client: The server sends the client
a packet to notify client that it has received the
Accounting-Request and has started recording the
accounting information.
2. The Identifier field (1-byte long) matches request packets and response packets and detects
retransmitted request packets. The request and response packets of the same type have the
same identifier.

19
3. The Length field (2-byte long) indicates the length of the entire packet, including the Code,
Identifier, Length, Authenticator, and Attribute fields. The value of the field ranges from 20 to
4096. Bytes beyond the length are considered padding and ignored. If the length of a
received packet is less than that indicated by the Length field, the packet is dropped.
4. The Authenticator field (16-byte long) authenticates replies from the RADIUS server, and is
also used in the password hiding algorithm. There are two kinds of authenticators: request
authenticator and response authenticator.
5. The Attribute field, with a variable length, carries the specific authentication, authorization,
and accounting information for defining configuration details of the request or response. This
field is represented in triplets of Type, Length, and Value.
•Type: One byte, in the range 1 to 255. It indicates the type of the attribute. See Table 2 for
commonly used attributes for RADIUS authentication, authorization and accounting.
•Length: One byte for indicating the length of the attribute in bytes, including the Type, Length,
and Value fields.
•Value: Value of the attribute, up to 253 bytes. Its format and content depend on the Type and
Length fields.
Table 2 RADIUS attributes
No. Attribute No. Attribute
1 User-Name 4
5Acct-Authentic
2 User-Password 4
6Acct-Session-Time
3 CHAP-Password 4
7Acct-Input-Packets
4 NAS-IP-Address 4
8Acct-Output-Packets
5 NAS-Port 4
9Acct-Terminate-Cause
6 Service-Type 5
0Acct-Multi-Session-Id
7 Framed-Protocol 5
1Acct-Link-Count
8 Framed-IP-Address 5
2Acct-Input-Gigawords
9 Framed-IP-Netmask 5
3Acct-Output-Gigawords
1
0 Framed-Routing 5
4(unassigned)

20
No. Attribute No. Attribute
1
1 Filter-ID 5
5Event-Timestamp
1
2 Framed-MTU
5
6
-
5
9
(unassigned)
1
3 Framed-Compression 6
0CHAP-Challenge
1
4 Login-IP-Host 6
1NAS-Port-Type
1
5 Login-Service 6
2Port-Limit
1
6 Login-TCP-Port 6
3Login-LAT-Port
1
7 (unassigned) 6
4Tunnel-Type
1
8 Reply-Message 6
5Tunnel-Medium-Type
1
9 Callback-Number 6
6Tunnel-Client-Endpoint
2
0 Callback-ID 6
7Tunnel-Server-Endpoint
2
1 (unassigned) 6
8Acct-Tunnel-Connection
2
2 Framed-Route 6
9Tunnel-Password
2
3 Framed-IPX-Network 7
0ARAP-Password
2
4 State 7
1ARAP-Features
2
5 Class 7
2ARAP-Zone-Access
2
6 Vendor-Specific 7
3ARAP-Security
2
7 Session-Timeout 7
4ARAP-Security-Data
