H3C S9804 User manual

Flat-head screwdriver
一字螺丝刀
Tool list 工具参考
Installation accessories 安装附件介绍
The installation tools are not provided with the switch. Prepare them yourself.
交换机不随机提供安装工具，请用户根据实际安装需求自己准备安装工具。
Phillips screwdriver
十字螺丝刀
ESD wrist strap
防静电腕带
Diagonal pliers
斜口钳
Marker
记号笔
Grounding
cable接地线
M6 screw (user supplied)
M6 螺钉（请用户自备）
Cable tie
可拆卸式扎带
The installation accessories required depend on the switch mounting methods. Select the
installation accessories as required. 交换机在不同的安装场景下，用户所需要的附件组
合也有所差异。本图仅作示意，请用户以实际的安装场景为准，选择合适的附件组合进
行安装。
Chassis rail
滑道导轨
2U mounting bracket and
cable management bracket
2U挂耳和走线架
Before installation, wear an ESD wrist strap, and make sure the wrist strap makes good
skin contact and is well grounded. 在安装交换机的过程中，操作者需佩戴防静电腕带，
请确保防静电腕带已经正确接地并与皮肤良好接触。
M4 screw
M4螺钉
1
Grounding
screw接地螺钉
Cage nut (user supplied)
浮动螺母（请用户自备）
Slide rail
滑道
Installation positions for accessories 安装方式介绍
When you use slide rails and chassis rails to install a switch in a 19-inch rack, first
determine the installation positions for the mounting bracket, slide rails, and ground cable
on the switch.利用滑道、滑道导轨配合挂耳将交换机安装到19英寸机柜时，可以根据实际
需求调整附件在交换机上的安装位置。
Position a or b near the network ports
靠近端口侧，可以安装在a处或b处
Primary grounding point
(near the power modules)
主接地点（靠近电源侧）
Auxiliary grounding point
(near the network ports)
备用接地点（靠近端口侧）
1
2
3
2
b
a
Position c or d near the power modules
靠近电源侧，可以安装在c处或d处
d
c
The switch comes with the mounting bracket and cable management bracket attached
together. You can de-attach them as required. 交换机发货时挂耳和走线架是安装在一起
的，用户可根据实际需求进行拆卸。
Near the network ports
安装在靠近端口侧
Near the power modules
安装在靠近电源侧

Mounting the switch to a 19-inch rack 安装交换机到19英寸机柜
12
4
The distance between the front and rear rack posts depends on the switch mounting
methods. For other installation methods, you need to adjust the distance as required.
安装方法不同，对机柜前后方孔条的间距要求也有所差异，下面以使用滑道为例，对
交换机的安装进行介绍。使用其他安装方法时，请用户根据实际情况调整机柜方孔条
之间的距离。
When you use guide rails and chassis rails to install a switch in a cabinet, make sure：
采用滑道、导轨和挂耳安装时，对机柜要求：
90mm
720mm
The distance between the front post and front door is greater than100 mm (3.94 in).
机柜的前方孔条到前门的距离不应小于100mm。
The distance between the front post and rear door is greater than 840 mm (33.07 in).
机柜的前方孔条到后门的距离不应小于840mm。
66mm

Connect the other end of the grounding cable to the grounding point of the rack
请将接地线另一端连接到机柜接地点
Airflow direction of the switch交换机的风道设计
The switch can provide airflow from the port side to power module side or from the
power module side to port side depending on the fan tray type. 交换机采用前后风道设
计，通过配置不同的风扇模块，可提供“电源侧到端口侧”和“端口侧到电源侧”两种
气流方向，满足不同环境下的散热要求。
LSVM1S9800FAN
LSVM2S9800FAN
3
5
Installing and removing FRUs 模块的安装与拆卸
Installing a power module安装电源模块 Removing a power module拆卸电源模块
Remove the filler panel before you install a field replaceable unit (FRU) and keep the
removed filler panel for future use.安装模块前，请先取下假面板，并妥善保存拆卸下
来的假面板。
After removing an FRU, install a filler panel to the empty slot to prevent dust from
entering the switch.若模块拆卸完成后无须安装新的模块，请及时安装假面板，以防止
灰尘进入。
Before installing a fan tray, make sure the airflow direction marked on the fan tray
meets the ventilation requirement of the installation site. 在安装风扇模块前，请根据
风扇模块的风向标识，确认气流方向和安装环境的通风要求一致。
Installing a fan tray 安装风扇模块 Removing a fan tray 拆卸风扇模块
6
1
2
The installing and removing procedures for the LSVM1S9800FAN and
LSVM2S9800FAN are similar. LSVM1S9800FAN风扇模块和LSVM2S9800FAN风扇
模块的安装和更换方法相同，安装和更换时按如下步骤进行。
Disconnect the power cord before you remove a power module.
拆卸电源模块前，请先拔掉电源线。
2
11
2
You must install two fan trays of the same model on a switch.为保证交换机正常运行，
请用户务必安装两块同型号的风扇模块。

Copyright © 2017, New H3C Technologies Co., Ltd.
For more information about the product and installation procedures, log in to www.h3c.com.hk
Copyright © 2017 新华三技术有限公司 版权所有，保留一切权利。
如需了解产品及安装方面的更多信息，请登录 H3C 网站 www.h3c.com
Connecting the power cord 连接电源线
Installing an interface card 安装业务板
7
1
2
31
23
Removing an interface card 拆卸业务板
If both fan trays on a switch fail, finish replacing the fan trays within 3 minutes. If one
fan tray fails, finish replacing the fan tray within 5 minutes.当交换机的两个风扇模块同
时发生故障时，为保证交换机正常运行，请在三分钟内完成更换。当交换机的一个风
扇模块发生故障时，为保证交换机正常运行，请在五分钟内完成更换。
Before connecting the power cord, connect the grounding cable and make sure the
switch is correctly grounded. 连接电源线前，需先连接保护地线，保证交换机正确接地。
Connect the power cord to the switch first and then to the power source to avoid
bodily injury.连接电源线时，请先完成电源线与交换机侧的连接，再进行电源线与
供电系统的连接，以免造成人身伤害。
12
3
