Haas HSCV-5-05 User manual

45.0°
.236in
6mm
.236in
6mm
.630in
16mm
Jaw Detail
4.921in
125mm
JW
.531in
13.5mm
1.654in
42mm
.591in
15mm
.787in
20mm
SECTION A-A
8.268in
210mm
8.433in
214.2mm
OAL
0-4.96in
[0-126mm]
.48-5.19in
[12-132mm]
J1
7.480in
190mm
7.717in
196mm
J3
3.504in
89mm
OAH
2.244in
57mm
.472in
12mm
Wrench
Jaw shown
mounted 180°
4.961in
126mm
OAW
4.134in
105mm
4.000in
101.6mm
3.780in
96mm
3.780in
96mm
M10x1.5
20mm
16mm 6mm
(4x)
M8x1.25x 30mm
(4x)
M8x1.25 15mm
(4x)
Work Stop Mounting

Detail A
.080in
.005
[2.0mm .13mm]
Dovetail Depth
R.015in
[R.38mm]
Maximum
.010in
[.25mm]
Flat or Chamfer
Gap
Part should only contact
top of jaw and dovetail
Clamping Guidelines
3.0in
[75mm]
4.0in
[100mm]
Dovetail width is recommended
to be 75% of material width
HAAS AUTOMATION, INC.
Workpiece must be centered in jaws,
or counter balanced on the opposite side
Off center clamping
NOT ALLOWED
Vise Operation and Maintenance
1. Keep lead screw well lubricated with Copper based
Anti-Seize lubricant
2. Keep the lead screw clean and free of chips and
other debris. Use a soft wire or nylon brush to clean
the screw regularly
3. Do NOT over torque. Stay below the maximum
torque marked on vise. Excess torque may result in
damage not covered under warranty
4. Never use power tools to operate the vise
5. Never strike the vise handle with a mallet
6. If machining soft jaws, clamp a spacer block
between the jaws at the desired operating torque for
maximum precision and repeatability
7. If the vise will not be used for an extended period
of time, clean thoroughly and liberally apply rust
inhibitor to all surfaces
Dovetail Detail Dovetail Detail
Detail A
Note - Dovetail clamping is not required, but can
be utilized for more secure clamping as needed

05-0051 Standard
jaws shown
2.00in
[50.8mm]
2.50in
[63.5mm]
4.92in
[125mm]
Optional 05-0049 and 05-0050 jaw shape

7.441in
189mm
7.6°
3.937in
100mm
6.181in
157mm
11.000in
279.4mm
9.921in
252mm
BHC
4X90°
33.8°
05-0090 100mm Riser Assembly shown with 05-0004 125mm Self Centering Manual Vise
Bolt pattern mounts directly to all UMC platters
05-0090 100mm Riser for use with 05-0004
