Habitat Radius RADI-3D-SS15-A User manual

BC
BC
Radius 3 Drawer Chest
Dimensions
Tools required
0344 499 4686
If you need help or have damaged or missing parts, email:
[e-mail]
or call:
Note:
There are 'Batch Code' lables where shown on the indicated items, these should be retained.
Depth - 48cm
Width - 90cm
Height - 86cm
Dimensions
Assembly Instructions
— Please keep for future reference
Important
— Please read these instructions before assembly
RADI-3D-SS15-A

General care and maintenance
General information
Maximum weight limit
Safety and Care Advice
Warning:
Please do not overload drawers - and do not open multiple drawers at once as this could destabilise the unit!
Assemble on a soft level surface
to avoid damaging the unit or your
floor.
We do not
recommend the
use of power drill/
drivers f
for inserting
screws,
as this could
damage the unit. Only use hand
screwdrivers.
Dispose of all packaging carefully
and responsibly.
Do not stand or put weight on the
product, this could cause damage.
Assemble the item as close to its
final position (in the same room)
as possible.
Do not place furniture directly in
front of radiators, fires or any
other source of heat.
Parts of the
assembly will be
easier with 2
people.
Check you have all the
components and tools listed on
the front cover and pages 2 - 3.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals away
from the work area, small parts
could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Received, please contact the store
or Habitat Head Office via its web
site: www.habitat.co.uk
or write directly to:
Habitat Retail Ltd.
489-499 Avebury Boulevard,
Milton Keynes MK9 2NW
Please retain your receipt as
proof of purchase.
If you have any comment or
suggestions regarding this
product, assembly instructions
or service.
If for any reason you should have
problems with your Habitat
product, please contact the store
from which you purchased it.
1
Dust regularly with a clean dry
cloth.
Wipe up any spills immediately
with a damp cloth and then dry
the surface with a clean dry
duster.
Repeat this procedure for
periodic cleaning.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household waste.
Take to your local authority waste
disposal centre.
The use of furniture polish or
spray is not necessary or
recommended.
Always use place mats and
coasters to protect the surface
from moisture and heat.
Important
— Please read these instructions fully before starting assembly

Fitting Wall Strap
2
Warning :
Due to the height of this piece of furniture we strongly recommend that it is attached securely to
the wall using the wall strap provided.
We have provided a screw for attaching the wall strap to furniture but you must assess the type of
wall you want to fit it to and provide the appropriate type of wall fitting. If you are in any doubt
about which type of wall fitting to use please seek professional help or ask your local hardware
store.
Please refer the Wall Mounting and Fittings Guide at the back of this assembly instruction.
Before screwing or drilling into your wall always check for hidden pipes and cables.
R
x 1
Step 1

Important note:
Types of walls
Care &
Maintenance
No.1 “General Purpose” wall plug
No.6 “Shield Anchor” wall plug Heavy
loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty” wall
plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist fitting in this case. For light
loads, general purpose wall plugs can be
used.
For use with heavier loads such as TV &
HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
For use when fitting or supporting heavy
loads such as shelving, wall cabinets and
coat racks.
For use with walls stuck with plasterboard.
The hammer fixing allows it to be fixed
to the wall rather than the plasterboard.
Always check the fixing is secure to the
retaining wall.
For use when attaching light loads on to
plasterboard partitions.
Safety: Always check the fitting and
location to ensure your safety in and
around the home.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic tiles.
Ensure wall plugs are inserted beyond the thickness of the ceramic
tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well fitted and are a tight fit in the
drilled hole.
Wall Fixings: Make sure that the screws and wall plugs being used are suitable
for supporting your unit. Consult a qualified tradesperson if you are
unsure.
- because of the variety of
different wall types, Habitat
cannot provide you with the
exact fixings you will need to
fix this product to the wall.
You must first identify the
type of wall you intend to fix
product onto and then contact
your local hardware store to
get the appropriate fixings.
A Guide to - Wall Mounting & Fixings
