Habitat TILDA BOOKSHELF User manual

TILDA BOOKSHELF
Assembly Instructions - Please keep for future reference TILD-BS-SS18-A
Dimensions
Width-90cm
Depth-35cm
Height-185cm
Important – Please read these instructions before assembly
If you need help or have damaged or missing parts, email:
[e-mail] or call: 0344 499 4686
1

General care and maintenance
nce
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
General information
Keep children and animals away
from the work area, small parts
could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Assemble the item as close to its
final position(in the same
room)as possible.
Do not stand or put weight on
the product, this could cause
damage.
Do not place furniture
directly in front of
radiators,fires or any other
source of heat.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Dispose of all packing carefully
and responsibly
Take care when moving this
glass topped table - always lift it
off the floor first! Never drag it
across the floor as this could
cause it to crack or shatter!
Avoid exposing your glass
furniture to direct and prolonged
periods of sunlight and heat
sources.
Take care to prevent sharp
objects e.g. Toys,buckles and
heels from coming into contact
with your furniture, and avoid
contact with chemicals e.g.
Cosmetics or hairs products
which may permanently mark
the surface.
Always use coasters or table
mats to protect the surface
from very hot or cold items.
If for any reason you should have
problems with your Habitat
product, please contact the store
from which you purchased it.
Please retain your receipt as
proof of purchase.
If you have any comments or
suggestions regarding this
product, assembly
instructions or service
received, please contact
the store or Habitat Head
Office via its web site:
www.habitat.co.uk
or write directly to: Habitat
Retail Ltd. 489-499 Avebury
Boulevard,
Milton Keynes MK9 2NW
2

3
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
IMPORTANT INFORMATION
ABOUT TEMPERED GLASS
Tempered glass is made using a
rapid cooling process that not only
increases its strength but also
changes the way in which it
breaks. Unlike “ordinary”
annealed glass, which can shatter
into jagged shards when broken,
tempered glass fractures into
smaller, less angular fragments.
This product is made with 10mm
thick (table top) tempered glass.
GLASS WARNING
Always handle glass with care.
Always supervise young children
around glass products.
Never sit or stand on glass
surfaces.
Do not use the glass surface as a
chopping surface.
Do not strike the glass with hard
or pointed items.
In exceptional circumstances a
scratched surface or damaged
edge may cause the glass to break
unexpectedly. The glass in this
product is designed to break into
small fragments rather than
large/sharp pieces. Avoid impacts
on the side or edges of the glass,
as this is where the glass is most
vulnerable.
Never place hot or cold items
directly onto the glass surface as
this could cause thermal shock
and could trigger the glass to
shatter. Always use placemats
and coasters to protect the glass
surface from heat, cold and
moisture.
If your glass furniture gets
chipped or damaged stop using it
and dispose of it safely. Small
chips or damages may not cause
the glass to break immediately
but they will weaken it.
Temperature fluctuations in your
home (e.g. when your home cools
down at night) could trigger it to
shatter later.
CLEANING INSTRUCTIONS
Dust regularly with a clean
dry cloth.
Wipe up any spills with a
damp cloth and then dry the
surface with a clean dry
duster.
Repeat this procedure for
periodic cleaning.
Remove stubborn stains and
greasy marks with a glass-
cleaner and a damp cloth or
leather shammy, and dry
with a clean cloth.
The use of furniture polish or
spray is not necessary or
recommended.
Never use abrasive cleaning
agents as these can scratch
and damage the glass
surface.
KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE!

4
Components -Panels
Please check you have all the panels listed below
Note: There are ‘Batch Code’ label where shown on the indicated items, these should be retained.
If you have damaged or missing components,
Call the Customer hel
p
line:
03
44 499 4
686
GLASS
FRAME

gx5

5
Components -Fitting
Please check you have all the panels listed below
If you have damaged or missing components,
Call the Customer hel
p
line:
03
44 499 4
686
Note: The quantities below are the correct amount to complete the assembly.
In some cases more fittings may be supplied than are required.

6
Assembly Instructions
Step 1
Step 2

7
Assembly Instructions
Step 3
Step 4

Assembly Instructions
Step 5
Step6
8

Assembly Instructions
Step 7
Step8
9

Assembly Instructions
Step 9
Anti-topple device
The wall fi xings supplie
are for solid brick,
masonry and direct stud fi
xing only. For
plasterboard or any other
wall type, please seek the
advice of a professional
builder.
Warning! Before you drill,
check to ensure there are
no hidden pipes or cables
in the wall.
a: With help, place the unit
against the wall in its final
location and mark the drill
hole position.
b: Remove the unit and
drill a 7mm diameter hole
to a depth of 55mm in the
marked position.
c: Insert Wall plug and
attach the Wall bracket
using Screw
d: using the plastic strip,
cross the holes and fix the
feet to the wall
10
G

Important note:
Types of walls
Care &
Maintenance
No.1 “General Purpose” wall plug
No.6 “Shield Anchor” wall plug Heavy
loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty” wall
plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
a specialist fitting in this case. For light
loads, general purpose wall plugs can be
used.
For use with heavier loads such as TV &
HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
For use when fitting or supporting heavy
loads such as shelving, wall cabinets and
coat racks.
For use with walls stuck with plasterboard.
The hammer fixing allows it to be fixed
to the wall rather than the plasterboard.
Always check the fixing is secure to the
retaining wall.
For use when attaching light loads on to
plasterboard partitions.
Safety: Always check the fitting and
location to ensure your safety in and
around the home.
Fitting: From time to time check
the fitting to ensure the wall plugs
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic tiles.
Ensure wall plugs are inserted beyond the thickness of the ceramic
tiles to avoid the tiles splitting or cracking.
5: Ensure wall plugs are well fitted and are a tight fit in the
drilled hole.
If plastic wall plugs are
supplied with your product:
Make sure that the screws and wall plugs being used are suitable
for supporting your unit. Consult a qualified tradesperson if you are
unsure.
- these are only suitable for use
in masonry walls.
If you are in any doubt about the
correct wall plugs for your wall,
seek professional advice.
Failure of the product due to
using incorrect fixings is the
responsibility of the installer.
A Guide to - Wall Mounting & Fixings
