Hach DR300 User manual

DOC022.L2.90639
DR300
02/2019, Edition 2
User Manual
Brugervejledning
Instrukcja obsługi
Bruksanvisning
Käyttöopas
Руководство пользователя
Kullanıcı Kılavuzu
Εγχειρίδιο χρήσης

English.................................................................................................. 3
Dansk.................................................................................................. 25
Polski ................................................................................................... 48
Svenska.............................................................................................. 73
Suomi.................................................................................................. 96
Русский............................................................................................. 119
Türkçe............................................................................................... 145
Ελληνικά............................................................................................ 168
2

Table of contents
Product components on page 6 Calibration on page 15
Install the batteries on page 7 Maintenance on page 20
User interface and navigation
on page 8
Troubleshooting on page 21
Do a test on page 11 Replacement parts and accessories
on page 24
Specifications
Specifications are subject to change without notice.
Specification Details
Dimensions (W x H x D) 6.9 x 15.7 x 3.4 cm (2.7 x 6.2 x 1.3 in.)
Enclosure IP67, waterproof at 1 m (3.3 ft) for 30 minutes when
battery compartment is closed and locked.
Light source Light emitting diode (LED)
Detector Silicon photodiode
Display LCD with backlight
Weight 0.25 kg (0.55 lb)
Power requirements 4 AAA batteries; approximate life of 5000 tests (use of
backlight decreases this number)
Rechargeable batteries are not recommended.
Operating environment 0 to 50 °C (32 to 122 °F), 0 to 90% relative humidity
non-condensing
Storage temperature –20 to 55 °C (–4 to 131 °F), 0 to 80% relative humidity
non-condensing
Wavelength Fixed wavelength ±2 nm, different for each model
Filter bandwidth 15 nm
Absorbance range 0 to 2.5 Abs
Sample cell 25 mm (10 mL) and 1 cm (10 mL)
Data storage Last 50 measurements
English 3

Specification Details
Bluetooth® 1Bluetooth® is on when the optional Hach
Communication Dongle is installed.
Certifications CE
Warranty 1 year (EU: 2 years)
General information
In no event will the manufacturer be liable for direct, indirect, special,
incidental or consequential damages resulting from any defect or
omission in this manual. The manufacturer reserves the right to make
changes in this manual and the products it describes at any time,
without notice or obligation. Revised editions are found on the
manufacturer’s website.
Safety information
NOTICE
The manufacturer is not responsible for any damages due to misapplication or
misuse of this product including, without limitation, direct, incidental and
consequential damages, and disclaims such damages to the full extent
permitted under applicable law. The user is solely responsible to identify critical
application risks and install appropriate mechanisms to protect processes
during a possible equipment malfunction.
Please read this entire manual before unpacking, setting up or
operating this equipment. Pay attention to all danger and caution
statements. Failure to do so could result in serious injury to the
operator or damage to the equipment.
Make sure that the protection provided by this equipment is not
impaired. Do not use or install this equipment in any manner other than
that specified in this manual.
1The Bluetooth® word mark and logos are registered trademarks
owned by the Bluetooth SIG, Inc. and any use of such marks by
HACH is under license.
4 English

Use of hazard information
DANGER
Indicates a potentially or imminently hazardous situation which, if not avoided,
will result in death or serious injury.
W A R N I N G
Indicates a potentially or imminently hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation that may result in minor or moderate
injury.
NOTICE
Indicates a situation which, if not avoided, may cause damage to the
instrument. Information that requires special emphasis.
Precautionary labels
Read all labels and tags attached to the instrument. Personal injury or
damage to the instrument could occur if not observed. A symbol on the
instrument is referenced in the manual with a precautionary statement.
This symbol, if noted on the instrument, references the instruction
manual for operation and/or safety information.
Electrical equipment marked with this symbol may not be disposed
of in European domestic or public disposal systems. Return old or
end-of-life equipment to the manufacturer for disposal at no charge
to the user.
Certification
Canadian Radio Interference-Causing Equipment Regulation,
IECS-003, Class B:
Supporting test records reside with the manufacturer.
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
English 5

Cet appareil numérique de classe B répond à toutes les exigences de
la réglementation canadienne sur les équipements provoquant des
interférences.
FCC Part 15, Class "B" Limits
Supporting test records reside with the manufacturer. The device
complies with Part 15 of the FCC Rules. Operation is subject to the
following conditions:
1. The equipment may not cause harmful interference.
2. The equipment must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications to this equipment not expressly approved by
the party responsible for compliance could void the user's authority to
operate the equipment. This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference, in which case
the user will be required to correct the interference at their expense.
The following techniques can be used to reduce interference problems:
1. Move the equipment away from the device receiving the
interference.
2. Reposition the receiving antenna for the device receiving the
interference.
3. Try combinations of the above.
Product overview
This instrument is a portable filter photometer used for testing water.
Note: This instrument has not been evaluated to measure chlorine and
chloramines in medical applications in the United States.
Product components
Make sure that all components have been received. Refer to Figure 1.
If any items are missing or damaged, contact the manufacturer or a
6 English

sales representative immediately. Figure 1 is an example and shows
the parts supplied with LPV445.99.00110. Other instruments come with
different components.
Figure 1 Product components
1 DR300 5 Storage case
2 AAA alkaline batteries 6 Reagents
3 Sample cells, 25 mm (10 mL),
glass
7 Hach Communication Dongle
(optional, supplied separately)
4 Sample cells, 1 cm (10 mL), plastic
Install the batteries
W A R N I N G
Explosion hazard. Incorrect battery installation can cause the release
of explosive gases. Be sure that the batteries are of the same
approved chemical type and are inserted in the correct orientation.
Do not mix new and used batteries.
Refer to Figure 2 to install the batteries. Then, push to set the
instrument to on.
English 7

Figure 2 Install the batteries
1 Coin 3 Plastic insert for dongle2
2 Battery cover
User interface and navigation
Keypad description
Figure 3 shows the keypad and gives the key functions.
2Only remove the plastic insert to install the Hach Communication
Dongle. Refer to the installation instructions supplied with the
dongle.
8 English

Figure 3 Keypad
1 Range key: Selects the
measurement range (e.g., LR or
HR).
Push and hold for 3 seconds to
enter or exit menu mode.
In menu mode, scrolls up or
increases the value of the selected
digit.
4 Backlight key: Sets the backlight
to on and off.
In menu mode, scrolls down or
decreases the value of the selected
digit.
2 Zero key: Sets the zero value
before a measurement.
In menu mode, goes back one
menu level or moves the cursor to
the previous digit.
5 Read key: Starts a sample
measurement.
In menu mode, selects the menu
option shown or moves the cursor
to the next digit.
3 Power key: Sets the power to on
and off.
Push and hold for 5 seconds to
reset the instrument. The
calibration is not deleted.
English 9

Display description
Figure 4 shows the values and icons shown on the display.
Figure 4 Display
1 Numeric display: Measured value
or menu options
5 Battery icon: Battery power level.
Flashes when the battery power
level is low.
2 Range icon: Points to the selected
measurement range
6 Parameter and measurement
ranges
3 Measurement ranges or
parameters
7 Calibration adjusted icon: The
factory default calibration was
adjusted or a user-entered
calibration curve was entered.
4 Bluetooth® icon: Bluetooth® is
on3.
Set the time
Set the time (24-hour format).
1. Push and hold for 3 seconds to enter menu mode.
The time shows (or 00:00).
2. Push to set the time.
3. Push the or to change the number that flashes. Push to go
to the next digit. Push to go to the previous digit.
3Shows when the Hach Communication Dongle is installed.
10 English

Do a test
DANGER
Chemical or biological hazards. If this instrument is used to monitor a
treatment process and/or chemical feed system for which there are
regulatory limits and monitoring requirements related to public health,
public safety, food or beverage manufacture or processing, it is the
responsibility of the user of this instrument to know and abide by any
applicable regulation and to have sufficient and appropriate
mechanisms in place for compliance with applicable regulations in
the event of malfunction of the instrument.
DANGER
Chemical exposure hazard. Obey laboratory safety procedures and
wear all of the personal protective equipment appropriate to the
chemicals that are handled. Refer to the current safety data sheets
(MSDS/SDS) for safety protocols.
CAUTION
Chemical exposure hazard. Dispose of chemicals and wastes in
accordance with local, regional and national regulations.
The generic steps to do a test follow.
To do a test for a specific parameter (e.g., chlorine), download the test
procedure from the manufacturer's website. Refer to Download a test
procedure on page 14.
1. Push to select the applicable measurement range (e.g., LR or
HR).
2. Prepare the blank. Refer to the test procedure.
3. Clean the sample cell with a no-lint cloth.
4. Insert the blank sample cell into the cell holder. Make sure to install
the blank sample cell in the correct and consistent orientation so
that the results are more repeatable and precise. Refer to Figure 5.
5. Install the instrument cap over the cell holder. Refer to Figure 6.
6. Push to set the instrument zero.
English 11

7. Remove the blank sample cell.
8. Prepare the sample. Refer to the test procedure.
9. Clean the sample cell with a no-lint cloth.
10. Insert the sample cell into the cell holder. Make sure to install the
sample cell in the correct and consistent orientation so that the
results are more repeatable and precise. Refer to Figure 5.
11. Install the instrument cap over the cell holder. Refer to Figure 6.
12. Push . The display shows the results in concentration units or
absorbance.
Note: The result flashes if the result is less or more than the instrument
range.
13. Remove the sample cell from the cell holder.
14. Immediately empty and rinse the sample cell. Rinse the sample cell
and cap three times with deionized water (or distilled water).
Note: As an alternative, use tap water to rinse the sample cell if the samples
measured have a higher concentration than the tap water.
12 English

Figure 5 Sample cell orientation
1 Orientation mark42 Sample cell, 25-mm
(10 mL), glass53 Sample cell, 1-cm (10 mL), plastic6
4Some variants of the instrument have sample cells without an
orientation mark.
5Use the glass sample cell for low-range chlorine tests.
6Use the plastic sample cell for high-range chlorine tests.
English 13

Figure 6 Install the instrument cap over the cell holder
Download a test procedure
1. Go to http://www.hach.com.
2. Enter "DR300" in the Search box.
3. Select the applicable instrument from the list.
4. Click the Downloads tab.
5. Scroll down to "Methods/Procedures".
6. Click the link for the applicable test procedure to download it.
14 English

Show measurements
Note: The instrument saves a maximum of 50 measurements. After
50 measurements are done, new measurements replace the oldest
measurements.
1. Push and hold for 3 seconds.
2. Push until "rCL" (recall) shows, then push .
"– 01 –" shows. Measurement 01 is the last measurement done.
3. Push to scroll forward.
The measurement number is followed by the measurement value
and then the time.
4. To go to a measurement number, push until a measurement
number shows, then push or .
Note: Measurements cannot be deleted.
5. Push and hold for 3 seconds to go back to measurement mode.
Calibration
This instrument is calibrated at the factory. No user calibration is
necessary.
Standard calibration adjust
Use the standard calibration adjust (SCA) option when a calibration
must be adjusted to meet regulatory requirements. The factory
calibration is adjusted slightly with the standard calibration adjust
(SCA) option so that the instrument shows the expected value of the
standard solution. The adjusted calibration is then used for all test
results. This adjustment can increase the test accuracy when there are
slight variations in the reagents or instruments.
Note: For instruments with factory-calibrated ranges or methods, the standard
calibration adjust (SCA) feature is disabled when a user-entered calibration is
entered into the instrument. To set SCA back to on, set the instrument to the
factory default calibration. Refer to Set to the factory default calibration
on page 20.
English 15

Do a standard calibration adjust
1. Complete the test procedure for the range to calibrate. For the
sample, use the standard solution concentration given in the test
procedure documentation.
Note: If a standard solution concentration is not given in the test procedure
documentation, a different known standard can be used.
2. When the test procedure is completed, push and hold for
3 seconds.
3. Push until “SCA” shows, then push .
The display shows the standard calibration adjust value.
4. If a different known standard is used, enter the value of the
standard:
a. Push until "Edit" shows, then push .
b. Enter the value of the standard.
Push the or to change the number that flashes. Push to
go to the next digit. Push to go to the previous digit.
5. Push to add the standard calibration adjust value to the factory
calibration curve.
Set the standard calibration adjust to off
To use the factory default calibration again, set standard calibration
adjust (SCA) to off.
1. Push and hold for 3 seconds to enter menu mode.
2. Push until "SCA" shows, then push .
3. Push until "OFF" shows, then push .
Note: To set the SCA function to on again, do a standard calibration adjust.
User-entered calibration curve
This instrument accepts a user-prepared calibration curve. The
calibration curve can be from 0 to 2.5 absorbance. Make sure that the
calibration curve includes standard values that are less and more than
the range of interest.
The instrument range will be the same as the calibration range. For
example, when the standards that are used are 1.00, 2.00 and 4.00.
The instrument range is 1.00 to 4.00.
16 English

There are two options to enter a user calibration curve:
•Enter a calibration curve with standards—The standard solution
values are entered with the keypad and the absorbance values are
measured.
•Enter a calibration curve with the keypad—The standard solution
values and absorbance values are entered with the keypad.
Note: If the instrument is set to off or the instrument power is removed before a
user-entered calibration curve is completed, the calibration curve is not saved.
The instrument automatically switches off in user-entered calibration entry mode
after 60 minutes of no activity. User-entered calibrations are completed when the
user goes out of calibration (cal) mode or edit mode.
Enter a calibration curve with standards
W A R N I N G
Chemical exposure hazard. Obey laboratory safety procedures and
wear all of the personal protective equipment appropriate to the
chemicals that are handled. Refer to the current safety data sheets
(MSDS/SDS) for safety protocols.
CAUTION
Chemical exposure hazard. Dispose of chemicals and wastes in
accordance with local, regional and national regulations.
Note: As an alternative, deionized water can be used for the blank unless the
sample is significantly more turbid or has more color than deionized water.
1. Push to set the instrument to the range to calibrate (e.g., LR or
HR).
2. Prepare the blank. Refer to the test procedure.
3. Clean the sample cell with a no-lint cloth.
4. Set the instrument to zero.
a. Insert the blank sample cell in the cell holder.
b. Install the instrument cap over the cell holder.
English 17

c. Push . The display shows “- - - -”, then “0.00”.
5. Push and hold for 3 seconds to enter menu mode.
6. Push until "USEr" shows, then push .
7. Push until "CAL" shows, then push .
8. When "S0" shows on the display, push .
9. Enter 00.00 (or 000.0) for the blank value.
Push the or to change the number that flashes. Push to go
to the next digit. Push to go to the previous digit.
10. When “A0” shows on the display, push to measure the
absorbance of the blank.
The display shows the absorbance value for "S0".
11. Remove the sample cell from the cell holder.
12. Prepare the sample. Refer to the test procedure. For the sample,
use the standard solution concentration given in the test procedure
documentation.
13. Clean the sample cell with a no-lint cloth.
14. Push to show "S1" (or "Add"), then push .
15. Enter the concentration value of the first calibration standard, then
push .
16. When "A1" shows on the display, do the steps that follow to
measure the absorbance:
a. Insert the reacted standard sample cell in the cell holder.
b. Install the instrument cap over the cell holder.
c. Push . The display shows the absorbance value for "S1".
17. The calibration is completed with two calibration points. If additional
standards are necessary for calibration:
Do steps 11 and 16 again to measure more calibration standards.
18. Remove the sample cell from the cell holder.
18 English

19. Immediately empty and rinse the sample cell. Rinse the sample cell
and cap three times with deionized water (or distilled water).
Note: As an alternative, tap water can be used to rinse the sample cell if the
concentration of the parameter in the tap water is less than the samples
measured.
20. Push and hold for 3 seconds to go back to measurement mode.
Enter a calibration curve with the keypad
At least two data pairs are necessary to enter a user-prepared
calibration curve. A concentration value and the absorbance value for
the given concentration is necessary for each data pair. A maximum of
10 data pairs can be entered.
1. Push to set the instrument to the range to calibrate (e.g., LR or
HR).
2. Push and hold for 3 seconds to enter menu mode.
3. Push until "USEr" shows, then push .
4. Push until "Edit" shows, then push .
5. When "S0" shows on the display, push .
6. Enter the first data pair.
The first data pair is S0 (concentration value) and A0 (absorbance
value).
• Push or to change the number that flashes.
• Push to go to the next digit.
• Push to go to the previous digit.
7. Do steps 5 and 6 again to enter the second data pair (S1 and A1).
8. The calibration is completed with two data pairs. If additional data
pairs are necessary for calibration:
a. When “Add” shows, push .
b. Do steps 5 and 6 again to enter more data pairs.
9. Push and hold for 3 seconds to go back to measurement mode.
English 19

Set to the factory default calibration
To remove a user-entered calibration curve from the instrument and
use the factory calibration, do the steps that follow:
1. Push and hold for 3 seconds to enter menu mode.
2. Push until "USEr" shows, then push .
3. Push until "dFL" (default) shows, then push .
Maintenance
CAUTION
Multiple hazards. Only qualified personnel must conduct the tasks
described in this section of the document.
NOTICE
Do not disassemble the instrument for maintenance. If the internal components
must be cleaned or repaired, contact the manufacturer.
Clean the instrument
Clean the exterior of the instrument with a moist cloth and a mild soap
solution and then wipe the instrument dry as necessary.
Clean the sample cells
CAUTION
Chemical exposure hazard. Obey laboratory safety procedures and
wear all of the personal protective equipment appropriate to the
chemicals that are handled. Refer to the current safety data sheets
(MSDS/SDS) for safety protocols.
CAUTION
Chemical exposure hazard. Dispose of chemicals and wastes in
accordance with local, regional and national regulations.
Most laboratory detergents are used at recommended concentrations.
Neutral detergents, such as Liquinox, are safer to use when regular
20 English
