Hach sensION+ MM150 User manual

© HACH Company, 2010, All rights reserved. Printed in Spain
DOC022.97.90259
Manual
Manual
Manual de instruções
Manuel utilisateur
操作手册
07/2010, Edition 1
07/2010, Edición 1
07/2010, Edição 1
07/2010, Edition 1
2010年7月，第一版
sensION+ MM150 HACH 0710.indd 1sensION+ MM150 HACH 0710.indd 1 7/9/10 13:02:507/9/10 13:02:50

sensION+ MM150 HACH 0710.indd 2sensION+ MM150 HACH 0710.indd 2 7/9/10 13:02:507/9/10 13:02:50

ENGLISHESPAÑOLFRANÇAIS PORTUGUÊSCONTACT
中文
中文
sensION+ MM150 HACH 0710.indd 3sensION+ MM150 HACH 0710.indd 3 7/9/10 13:02:507/9/10 13:02:50

sensION+ MM150 HACH 0710.indd 4sensION+ MM150 HACH 0710.indd 4 7/9/10 13:02:507/9/10 13:02:50

1
ENGLISH
Table of contents
1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. General information . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1. Safety information . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1.1. Use of hazard information . . . . . . . . . . . . . . 5
2.1.2. Precautionary labels . . . . . . . . . . . . . . . . . . 5
2.2. General information. . . . . . . . . . . . . . . . . . . . . . . . 5
3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1. Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1.1. Component list . . . . . . . . . . . . . . . . . . . . . . 6
3.1.2. Accessories . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2. Battery power . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2.1. Inserting the batteries . . . . . . . . . . . . . . . . . 7
3.3. Disconnecting/connecting the sensor . . . . . . . . . . . . 8
3.4. Carrying case . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4. Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1. General information. . . . . . . . . . . . . . . . . . . . . . . . 9
4.2. User interface and navigation . . . . . . . . . . . . . . . . . 9
4.2.1. Keyboard and display. . . . . . . . . . . . . . . . . 9
5. Set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.1. Temperature coefficient (TC) . . . . . . . . . . . . . . . . . . 10
5.2. Reference temperature (TR) . . . . . . . . . . . . . . . . . . . 10
5.3. TDS factor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.1. Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.1.1. Stability measuring . . . . . . . . . . . . . . . . . . . 11
6.1.2. Continuous measuring. . . . . . . . . . . . . . . . . 11
6.2. Changing units (TDS/mV) . . . . . . . . . . . . . . . . . . . . 11
6.3. pH calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.3.1. Preparation . . . . . . . . . . . . . . . . . . . . . . . . 12
6.3.2. One-point calibration . . . . . . . . . . . . . . . . . 12
6.3.3. Two- and three-point calibration . . . . . . . . . . 13
6.4. Conductivity calibration . . . . . . . . . . . . . . . . . . . . . 14
6.4.1. Preparation . . . . . . . . . . . . . . . . . . . . . . . . 14
6.4.2. One-point calibration . . . . . . . . . . . . . . . . . 14
6.4.3. Two- and three-point calibration . . . . . . . . . . 15
6.5. Redox calibration (only with sensor 5048) . . . . . . . . 16
6.5.1. Preparation . . . . . . . . . . . . . . . . . . . . . . . . 16
6.5.2. Calibration . . . . . . . . . . . . . . . . . . . . . . . . 16
6.6. Readjusting temperature . . . . . . . . . . . . . . . . . . . . . 17
6.7. Manual calibration. . . . . . . . . . . . . . . . . . . . . . . . . 18
6.7.1. Preparation . . . . . . . . . . . . . . . . . . . . . . . . 18
6.7.2. Calibration . . . . . . . . . . . . . . . . . . . . . . . . 18
6.8. Displaying calibration data. . . . . . . . . . . . . . . . . . . 19
6.9. Restoring factory settings. . . . . . . . . . . . . . . . . . . . . 20
6.10. Disabling auto power off . . . . . . . . . . . . . . . . . . . . 20
6.11. Changing temperature units . . . . . . . . . . . . . . . . . . 20
6.12. Display backlighting. . . . . . . . . . . . . . . . . . . . . . . . 21
6.13. Shutting down the instrument. . . . . . . . . . . . . . . . . . 21
7. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.1. Cleaning the measuring instrument and accessories . . 22
7.2. Storing the instrument . . . . . . . . . . . . . . . . . . . . . . 22
7.3. Changing batteries. . . . . . . . . . . . . . . . . . . . . . . . . 22
8. Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
9. Accessories and spare parts . . . . . . . . . . . . . . . . . . 24
10. Standard solutions. . . . . . . . . . . . . . . . . . . . . . . . . . . 25
10.1. pH buffer solutions . . . . . . . . . . . . . . . . . . . . . . . . . 22
10.2. Conductivity standard solutions . . . . . . . . . . . . . . . . 22
11. Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Contact Information
sensION+ MM150 HACH 0710.indd ANG:1sensION+ MM150 HACH 0710.indd ANG:1 7/9/10 13:02:507/9/10 13:02:50

sensION+ MM150 HACH 0710.indd ANG:2sensION+ MM150 HACH 0710.indd ANG:2 7/9/10 13:02:507/9/10 13:02:50

3
Specifications
Display Liquid crystal, backlit, with pictograms
Keypad Membrane , 5 keys
Measuring ranges pH –2.00 to 19.99
mV ± 1400
Conductivity 0.01 µS/cm to 500 mS/cm
TDS 0 mg/L to 500 g/L
Temperature –20.0 to 150.0 °C (–4.0 to 302.0 °F)
Resolution pH 0.01
mV 1 (0.1 mV from -199.9 to 199.9 mV)
Conductivity Depends on range of measurement
TDS Depends on range of measurement
Temperature 0.1 °C (0.1 °F)
Measuring error (± 1 digit) pH ≤0.01
mV ≤1
Conductivity ≤0.5 %
TDS ≤0.5 %
Temperature ≤0.2 °C (≤0.4 °F)
Reproducibility (± 1 digit) pH ± 0.01
mV ± 1
Conductivity ± 0.1 %
TDS ± 0.1 %
Temperature ± 0.1 °C (± 0.1 °F)
Temperature compensation With built-in Pt1000 temperature sensor
Reference temperature (RT) 20 or 25 °C (68 or 77 °F). Factory settings: 25 °C (77 °F)
Temperature coefficient (TC) 0.00 to 5.00%/°C (factory settings: 2%/°C)
Calibration standards pH 2.00, 4.01, 7.00, 9.21, 10.01 (at 25 °C)
Theoretical calibration (factory settings)
Redox 220 mV (a 25 °C)
Theoretical calibration (factory settings)
Conductivity 147 µS/cm, 1413 µS/cm,12.88 mS/cm and 111.8 mS/cm
(at 25 °C/77 °F)
Accepted cell constant Between 0.05 and 50 cm-1 (factory settings: 1.0 cm-1)
TDS conversion factor 0.00 to 4.44 (factory settings: 0.64)
Input impedance > 1012 . The switch from high to low impedance is made in the sensor con-
nector.
Additional technical data
Energy management Automatic power off after 5 minutes of inactivity
Type of protection IP 67
Power supply (batteries) 3 x 1.5V, type AA batteries. Autonomy of over 250 hours
Conector MP-8, eight-contact multipin
ENGLISH
1. Specifications
Subject to change without notice.
sensION+ MM150 HACH 0710.indd ANG:3sensION+ MM150 HACH 0710.indd ANG:3 7/9/10 13:02:507/9/10 13:02:50

4
Dimensions of the measuring instrument and ambient conditions
Operating temperature 0 °C to 50 °C (32 °F to 122 °F)
Storage temperature –15 °C to 65 °C (5 °F to 149 °F)
Ambient conditions 80% relative humidity (non-condensing)
Weight 300 g
Size 186 x 73 x 38 mm
Warranty
Warranty 3 years
1. Especificaciones
sensION+ MM150 HACH 0710.indd ANG:4sensION+ MM150 HACH 0710.indd ANG:4 7/9/10 13:02:507/9/10 13:02:50

5
2. General information
As a result of constant improvements to our products sometimes differences may exist between this manual
and the instructions supplied with the instrument.
2.1. Safety information
Please, read carefully this information before installing and using the instrument !
Pay attention to all danger and caution statements.
ENGLISH
2.1.1. Use of hazard information
DANGER
Indicates a potentially or imminently hazardous situation that, if not avoided, will result in death
or serious injury.
WARNING
Indicates a potentially or imminently hazardous situation that, if not avoided, may result in death
or serious injury.
CAUTION
Indicates a potentially hazardous situation that, if not avoided, may result in minor or moderate
injury.
Important note: Indicates a situation that, if not avoided, could lead to damage to the instrument.
Important information that requires special emphasis.
Note: Information that supplements points in the main text.
2.1.2. Precautionary labels
Read all labels and tags attached to the instrument. Personal injury or damage to the instrument could
occur if not observed.
This symbol references the instruction manual for operation or safety information.
Electrical equipment marked with this symbol may not be disposed of in European public disposal
systems after 12 August of 2005. In conformity with European local and national regulations (EU
Directive 2002/96/EC), European electrical equipment users must now return old or end-of life
equipment to the Producer for disposal at no charge to the user.
Note: For return for recycling, please contact the equipment producer or supplier for instructions on
how to return end-of-life equipment, producer-supplied electrical accessories, and all auxiliary items
for proper disposal.
2.2. General information
The sensION™+MM150 is a portable pH, Redox, Conductivity, TDS and temperature meter. To be
able to read these values, you will need to connect a sensor (Fig. 3, pg. 8).
sensION+ MM150 HACH 0710.indd ANG:5sensION+ MM150 HACH 0710.indd ANG:5 7/9/10 13:02:507/9/10 13:02:50

6
3. Installation
3.1.1. Component List
Code Instrument Sensor Accessories Batteries Manual
LPV4000.97.0002
sensION™+MM150
–– ––
✓✓
LPV4059.97.0002
sensION™+MM150
LZW5059.97.0002
✓✓✓
LPV4048.97.0002
sensION™+MM150
LZW5048.97.0002
✓ (1) ✓✓
3.1.2. Accessories
• Carrying case.
• Buffer solutions, 125 mL, pH 4.01,
pH 7.00 and pH 9.21 (25 °C).
Calibration tubes pH 4.01,
pH 7.00 and pH 9.21.
• Standard solutions, 125 mL, 147 µS/cm,
1413 µS/cm and 12.88 mS/cm (25 °C).
Calibration tubes, 147 µS/cm,
1413 µS/cm and 12.88 mS/cm.
• Two 90-mL bottles for sample and sensor cleaning.
(1) Also included:
• Redox standard solution, 125 mL, 220 mV
(25 °C).
• Tube for redox standard calibration 220 mV.
After removing the instrument, check each part for possible damage. All components on the attached list
must be present. If there are any missing or damaged parts, contact the manufacturer or distributor.
WARNING
Risk of falling. Measurements are made directly in situ with this instrument. To prevent the risk of
falling, ensure compliance with all local safety regulations on securing with ropes and on the use of
adequate protective clothing and footwear.
Risk of injury. Do not attach the measuring instrument to your body. The measuring sensor could be
accidentally caught in a motor or stirrer and could endanger the user through the connected sensor
cable.
3.1. Content of the sensION™+MM150
Fig. 1. Equipment composition
sensION+ MM150 HACH 0710.indd ANG:6sensION+ MM150 HACH 0710.indd ANG:6 7/9/10 13:02:507/9/10 13:02:50

7
3. Installation
ENGLISH
3.2. Battery power
WARNING
Risk of fire or explosion. Use only AA alkaline batteries for the measuring instrument and ensure that
the batteries are correctly inserted in their compartment. Inserting batteries incorrectly can damage
the instrument and cause fires or explosions.
The measuring instrument works with three batteries (1.5 V, AA).
The batteries supplied have a useful life of approximately 250 hours.
Important note: Never use different types of batteries together.
Note: If the measuring instrument is not going to be used for a long period of time, remove the
batteries to prevent leakage in the instrument.
3.2.1. Inserting the batteries
1. Open the lid of the battery compartment by pressing and pulling on the tab.
2. Insert the batteries supplied (1.5 V AA). Note the polarity markings inside the battery compartment.
3. Close the lid of the battery compartment
Fig. 2. Inserting the batteries
1Tab
2Battery compartment lid
3Batteries
4Battery compartment
+
+
+
2
1
3
4
sensION+ MM150 HACH 0710.indd ANG:7sensION+ MM150 HACH 0710.indd ANG:7 7/9/10 13:02:537/9/10 13:02:53

8
3. Installation
3.3. Disconnecting/connecting the sensor
The sensION™+MM150 kits are supplied with the sensor attached to the instrument.
Fig. 3. Disconnecting/connecting the sensor to the measuring instrument
Sensor disconnection
Sensor connection
Important note: do not unscrew the connector.
3.4. Carrying case
The carrying case can be used as a support for both, instrument and sensor, see figure.
Electrode position when
it is not in use.
sensION+ MM150 HACH 0710.indd ANG:8sensION+ MM150 HACH 0710.indd ANG:8 7/9/10 13:02:537/9/10 13:02:53

9
4. Start-up
ENGLISH
4.1. General information
Important note: Before start-up, make sure that the sensor is connected to the measuring instrument.
1. Connect the sensor (if necessary) to the measuring
instrument (Fig. 3, pg. 8).
2. Turn on the instrument.
3. Perform calibration (see pg. 12-16).
4. Perform the measurement (see pg. 11).
Note: With the instrument switched off,
- Press the key and the instrument will begin
measuring.
- Press the key and the instrument will begin calibration.
Fig. 4. Keypad description
4.2 User interface and navigation
4.2.1 Keyboard and display
Figure 4 indicates the instrument keys and display.
8
7
1
2
3
4
5
6
Display
1 Measured pH value.
2 Measured conductivity value.
3 Reference temperature.
4 Measured TDS/Redox (mV) value.
5 Temperature of the sample.
6 Measuring time (hh:mm:ss).
7 Units of measurement.
8 Battery indicator.
Keypad
- Instrument on/off.
- Display light on.
- Start of measuring.
- Start of calibration.
- Selection of parameter and stan-
dard to calibrate.
- Selection of temperature units.
- Start of set-up.
Software version &
Instrument serial
number.
Standby screen.Sensor connected.
sensION+ MM150 HACH 0710.indd ANG:9sensION+ MM150 HACH 0710.indd ANG:9 7/9/10 13:02:557/9/10 13:02:55

10
5. Set-up
The sensION™+MM150 is supplied configured with the following parameters:
- Temperature coefficient: 2.00%/°C.
- Reference temperature: 25°C.
- TDS calculation factor: 0.64.
To display and/or modify these parameters, follow the diagram below.
5.1. Temperature
coefficient (TC)
Enter the relevant coefficient value (0.00
to 9.99%/°C).
Recommended value for aqueous sam-
ples: 2.00%/°C.
5.2. Reference
temperature (RT)
Select a value between 20 and 25°C.
5.3. TDS factor (F)
Enter the relevant value
(0.00 to 4.44).
2 s
2 s
2 s
2 s
2 s
2 s
2 s
2 s
2 s
sensION+ MM150 HACH 0710.indd ANG:10sensION+ MM150 HACH 0710.indd ANG:10 7/9/10 13:02:557/9/10 13:02:55

11
6. Operation
ENGLISH
6.1. Measurement
Note: The instrument must be calibrated before taking the
first reading.
1. Press to turn on the instrument.
2. Remove the sensor protector.
3. Clean the sensor with deionized water.
4. Stir the sensor uniformly in the sample, holding it by the
top.
6.1.1. Stability measuring
Follow the diagram.
The reading is not locked on the screen until the sensor sig-
nal varies less than:
- pH: 0.01 pH for 6 sec.
- EC: ± 1 digit for 6 sec.
- Redox: 0.5 mV for 6 sec.
Once the reading has stabilized, the screen lights up for
2 sec.
6.1.2. Continuous measuring
Once stability measuring has begun, press the key
twice.
The instrument displays the measured value directly on
screen at all times.
The continuous reading should always be started after be-
ginning a stability reading (see diagram).
To end a continuous reading, press .
The display will light up for 2 sec.
Note: If the measuring instrument is not used for 5 minutes,
it will shut itself off automatically.
2 s
+
Stability
measuring
With sensor 50 48 With sensor 50 59
Continuous
measuring
6.2. Units of measurement
The sensION™+MM150 automatically recognizes the sen-
sor connected and displays the relevant values and units on
screen:
- Sensor 50 59: pH, conductivity, TDS and temperature.
- Sensor 50 48: pH, conductivity, redox (mV) and temperature.
sensION+ MM150 HACH 0710.indd ANG:11sensION+ MM150 HACH 0710.indd ANG:11 7/9/10 13:02:557/9/10 13:02:55

12
6. Operation
6.3.2. One-point calibration
Stir gently holding the sensor by the handle. Do not hold it by the tube to avoid
heating of the buffer solution.
Follow the diagram on the next page.
One-point calibration is acceptable when pH values around that of the buffer
used are being measured.
One-point calibration only corrects the asymmetry potential of the electrode.
Notes: If the measuring instrument is not used for 5 minutes, it shuts off
automatically.
If an anomaly occurs during calibration, an error message will appear on
screen (see pg. 23).
Fig. 6. Preparation
6.3. pH calibration
Important note: Before turning on the instrument, check that the sensor is connected.
The instrument must be calibrated before taking the first pH reading.
The calibration can be performed with 1, 2 or 3 points.
6.3.1. Preparation
1. Fill the tubes with the buffer solutions (note the fill level).
2. Unscrew the protector containing the electrolyte and rinse the sensor with deionized water.
3. Screw the sensor on to the tube containing the first buffer.
5 ml P/N. LZW9460.99
5 ml P/N. LZW9461.98
5ml P/N. LZW9462.99
ml
ml
ml
ml
P/N.
LZW94
94
ml
ml
P/N.
LZW94
94
ml
ml
ml
ml
P/N.
LZW94
94
1 2 3
sensION+ MM150 HACH 0710.indd ANG:12sensION+ MM150 HACH 0710.indd ANG:12 7/9/10 13:02:567/9/10 13:02:56

13
6. Operation
ENGLISH
6.3.3. Two- and three-point calibration
Follow the diagram below.
The equipment will repeat the process described for the first
buffer solution with the second and third.
Stir gently holding the sensor by the handle. Do not hold it by
the tube to avoid heating of the buffer solution.
Notes: if the measuring instrument is not used for 5 minutes, it
shuts off automatically.
If errors occur during calibration, an error message will appear
on screen (see pg. 23).
When you switch buffers, rinse the sensor with deionized water.
The buffer solutions in the calibration tubes can be used for
approximately four or five calibrations. It is recommended to
use fresh buffers.
Screw the
sensor
to the 1st tube.
Screw the
sensor
to the 2nd tube. To exit
calibration
(One point
calibration)
sensION+ MM150 HACH 0710.indd ANG:13sensION+ MM150 HACH 0710.indd ANG:13 7/9/10 13:02:577/9/10 13:02:57

14
6. Operation
6.4.2. One-point calibration
Dip the sensor into the tube several times to homogenize the liquid. Do not
hold it by the tube to avoid heating of the standard solution.
Follow the diagram on the next page.
This form of calibration is acceptable when conductivity values around that
of the standard solution used are being measured.
Note: if the measuring instrument is not used for 5 minutes, it shuts off
automatically.
If errors occur during calibration, an error message will appear on screen
(see pg. 23).
Fig. 6. Preparation
6.4. Conductivity calibration
Important note: before turning on the instrument, check that the sensor is connected.
The instrument must be calibrated before taking the first conductivity reading.
The calibration can be performed with 1, 2 or 3 points.
6.4.1. Preparation
1. Fill the tubes with the standard solutions (note the fill level).
2. Unscrew the protector and rinse the sensor with plenty of deionized water.
3. Screw the sensor on to the tube containing the first standard.
50 60
0.2... 200.000 μS/cm -30... 80ºC
50 60
0.2... 200.000 μS/cm -30... 80ºC
50 60
50 60
0 60
6
0 2 200 000 μS/c
0.2... 200.000 μS/c
m308
m -30... 8
0
0
ºC
C
50 60
50 60
0 60
6
0 2 200 000 μS/c
0.2... 200.000 μS/c
m308
m -30... 8
0
0
ºC
ºC
1 2 3
sensION+ MM150 HACH 0710.indd ANG:14sensION+ MM150 HACH 0710.indd ANG:14 7/9/10 13:02:597/9/10 13:02:59

15
6. Operation
ENGLISH
6.4.3. Two- and three-point calibration
Follow the diagram below.
The equipment will repeat the
process described for the first
standard solution with the second
and third.
Dip the sensor into the tube several times to homogenize the
liquid. Do not hold it by the tube to avoid heating of the stan-
dard solution.
Note: if the measuring instrument is not used for 5 minutes, it
shuts off automatically.
If errors occur during calibration, an error message will appear
on screen (see pg. 23).
When you switch standards, rinse the sensor with deionized
water.
(1) Press or to go to the required option.
Important: before beginning calibration, rinse the
sensor with plenty of deionized water, followed by
the first conductivity standard.
Screw the
sensor
to the 1st tube
Screw the
sensor to the
2nd tube
To exit calibration
Two-point calibration
To exit calibra-
tion.
One-point cali-
bration
(1)
sensION+ MM150 HACH 0710.indd ANG:15sensION+ MM150 HACH 0710.indd ANG:15 7/9/10 13:03:017/9/10 13:03:01

16
6. Funcionamiento
6.5. Redox calibration (only with sensor 5048)
Important note: before turning on the instrument, check that the electrode is
connected.
Redox electrodes do not have a significant drift of the potential, which is why
they are not typically not calibrated. However, some deviations of potential
may occur after continued use of the electrode as a result of changes to the
metal surface or contamination of the reference electrode.
6.5.1. Preparation
1. Fill the tube with the 200 mV standard solution (note the fill level).
2. Unscrew the protector containing the electrolyte and rinse the electrode
with deionized water.
3. Screw the electrode on to the tube containing the standard.
6.5.2. Calibration
Stir gently holding the sensor by the handle. Do not hold it by the tube
to avoid heating of the standard solution.
Follow the diagram.
Note: if the measuring instrument is not used for 5 minutes, it shuts off
automatically.
If errors occur during calibration, an error message will appear on
screen (see pg. 23).
ml P/N. LZW9462
ml
ml
m
ml
P/N.
LZW94
94
2 3
Screw the
electrode to
the standard
tube.
1
sensION+ MM150 HACH 0710.indd ANG:16sensION+ MM150 HACH 0710.indd ANG:16 7/9/10 13:03:017/9/10 13:03:01
