Haemonetics MCS+ Installation instructions

Haemonetics®
MCS®+ Device
LN 9000 Operator and
Maintenance Manual
Printed in U.S.A.
©1995, Haemonetics Corporation
400 Wood Road
Braintree, Massachusetts 02184
[phone]
All Rights Reserved
June 2001
Part No. 39551, Rev. F
+
MCS
®

P/N 39551-00, Rev. F

i
P/N 39551-00, Rev. F
PROPRIETARY
Information and descriptions contained herein are the property of Haemonetics
Corporation. Such information and descriptions may not be copied or repro-
duced by any means, or disseminated or distributed without written permission
of Haemonetics Corporation, 400 Wood Road, Braintree, Massachusetts 02184,
U.S.A. Haemonetics and MCS are registered trademarks of the Haemonetics Cor-
poration.
WARNING!
Buyer’s Use of
Products Haemonetics Corporation warrants only the Haemonetics MCS®+ device as sup-
plied by it. When properly assembled, maintained and operated by a qualified
operator, the MCS+ device has the capacity of safely and adequately performing
both collection protocols and therapeutic procedures.
Refer to Chapter 2, System Description, for the machine symbol chart.
Caution Federal (USA) law restricts this device to sale by or on the order of a physician.
WARNING!
This manual provides certain basic information concerning the maintenance and
operation of the Haemonetics MCS+ device and is intended to be used in con-
junction with and as a supplement to the training supplied by a Haemonetics
ClinicalSpecialistorotherqualifiedpersonnel.Departuresordeviationsfromthe
procedures contained in this manual should not be made except in conformity
with official changes made to the manual by Haemonetics Corporation. Other
departures or deviations are at the operator’s own risk.
Safe and effective use of Haemonetics products requires application of proper
techniques of setup and operation, and accordingly, should be undertaken only
by trained personnel.

ii
P/N 39551-00, Rev. F
Any Buyer that intends to use Haemonetics products should:
•Read carefully the instructions supplied herewith.
•Secure training in the procedures to be used.
•Apply in vitro studies to verify the ability to use the products safely in
vivo.
Information with respect to the availability of such training can be obtained by
writing to Haemonetics Corporation, Attention: Customer Service, or contact
your local sales representative.
The uses to which the Haemonetics®products may be applied, and the results
obtained therefrom, shall be the sole responsibility of the Buyer. Haemonetics
expressly disclaims responsibility for the use of the products by the Buyer.
INQUIRIES
Please direct any written inquiries to the appropriate address:
Haemonetics
U.S.A. Haemonetics Corporation
400 Wood Road
Braintree, Massachusetts 02184, U.S.A.
[phone]
In the United States, telephone inquiries may be made by using
the dedicated MCS/MCS+ Device Hot Line: [phone].

iii
P/N 39551-00, Rev. F
Haemonetics
International Austria
Haemonetics (Austria) GmbH
Berlagasse 45/B2-02
Austria - WIEN
Telephone: [phone]
Fax: [phone]
Belgium
Haemonetics (Belgium) SA
Chaussée de Louvain/
Leuvensesteenweg 542 - B.14
Planet II Complex
Belgium - 1930 ZAVENTEM
Telephone: [phone]
Fax: [phone]
France
Haemonetics (France) SARL
46 bis, rue Pierre Curie
Z.1. Les Gatines
France - 78370 PLAISIR
Telephone: [phone]
Fax: [phone]
Germany
Haemonetics (Germany) GmbH
Staeblistrasse 6
Germany - 81477 MUNICH
Telephone: [phone]
Fax: [phone]
Hong Kong
Haemonetics (U.K.) Ltd.
Suite 1314, 13F
Two Pacific Place
88 Queensway
HONG KONG
Telephone: [phone]
Fax: [phone]

iv
P/N 39551-00, Rev. F
Haemonetics International (Cont.)
Italy
Haemonetics (Italia) S.r.l.
Via Donizetti, 30
Italy - 20020 LAINATE (Milano)
Telephone: [phone]
Fax: [phone]
Japan
Haemonetics Japan Co. Ltd.
Shin-Kojimachi Building, 1F + 2 F
4-3-3, Kojimachi
Japan - Chiyoda-ku, Tokyo 102
Telephone: [phone]
Fax: [phone]
Netherlands
Haemonetics (Nederland) S.A.
Zuidergracht 12
Netherlands - 3763 LV SOEST
Telephone: [phone]
Fax: [phone]
Scandinavia
Haemonetics (Scandinavia) AB
Ekholmsvagen 36
P.O. Box 183
Sweden - 12724 SKARHOLMEN
Telephone: [phone]
Fax: [phone]
Switzerland
Haemonetics S.A.
Route de Divonne 46
Switzerland - 1260 NYON
Telephone: [phone]
Fax: [phone]
United Kingdom
Haemonetics (U.K.) Ltd.
Deacon House
Seacroft Avenue, Seacroft
GB - Leeds LS 14 6JD
Telephone: [phone]
Fax: [phone]

P/N 39551-00, Rev. F
Table of Contents
CHAPTER ONE, INTRODUCTION
OVERVIEW OF THE MCS+ Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
CHAPTER TWO, SYSTEM DESCRIPTION
GENERAL SYSTEM DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
POWER ENTRY MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
USER PANEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
DONOR/PATIENT FLOW INDICATORS. . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Donor Flow Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
SCREENS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Main Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
HaemoCalculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
HaemoUpdate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
Modify . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
Operator Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
KEYS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12
Mode Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12
Pump Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-13
Cuff Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14
Programming Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14
PROTOCOL CARD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-15
Protocol Card Pouch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17
VALVES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17
PRESSURE MONITORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17
Donor Pressure Monitor (DPM). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17
System Pressure Monitor (SPM). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-19
WEIGHER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-19
AIR DETECTORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-19
Anticoagulant Line Air Detector (ACAD). . . . . . . . . . . . . . . . . . . . . . . .2-19
Blood Line Air Detector (BLAD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-19
Donor Line Air Detector 1 (DLAD 1) . . . . . . . . . . . . . . . . . . . . . . . . . .2-20
Donor Line Air Detector 2 (DLAD 2) . . . . . . . . . . . . . . . . . . . . . . . . . .2-20
PUMPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-21
Blood Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-21
White Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-21
Anticoagulant Pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-22
ANTICOAGULANT DRIP MONITOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-22
CENTRIFUGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-23
Mechanical Chuck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-23
Vacuum Chuck. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-25

ii Table of Contents
P/N 39551-00, Rev. F
Manual Vacuum Release Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-26
Bowl Optics Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-26
Fluid Detectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-26
LINE SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-26
PRESSURE CUFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27
MACHINE ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27
List No. 9010 Transport Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27
List No. 7010 Machine Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
Dimensions (approximate) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
Machine Symbol Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
CHAPTER THREE, DISPOSABLES
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
DISPOSABLE SET STORAGE AND HANDLING . . . . . . . . . . . . . . . . . . . . . .3-2
INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
BOWLS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
Latham Bowl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
The Latham Bowl “Surge” Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5
The Role of the White Pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
HARNESS COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8
Elements of the Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8
Other Disposable Set Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11
CHAPTER FOUR, SAFETY AND DONOR/PATIENT
CARE PRECAUTIONS
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Storage and Handling of Disposables . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Flammable Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Electrical Shock Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
Rotating Machinery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Communicable Disease . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Restrictions to Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Twists and Kinks in Tubing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4
CHAPTER FIVE, NOTICE MESSAGES AND TROUBLESHOOTING
PROCESS MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
INTERLOCK MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
NOTICE MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
RECOVERY PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
REPEAT VENIPUNCTURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
GRAVITY REINFUSION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
TABLE 5-1, NOTICE MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8

Table of Contents iii
P/N 39551-00 , Rev. F
CHAPTER SIX, MAINTENANCE
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
MAINTENANCE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Centrifuge Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3
Cleaning the Optics Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Cleaning the Line Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Cleaning the Disposable Identification Window . . . . . . . . . . . . . . . . . . .6-8
Cleaning the Blood, White, and Anticoagulant Pumps . . . . . . . . . . . . . .6-9
Cleaning the Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9
Cleaning the Air Detectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
Cleaning the Air Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
Cleaning the Exterior Surfaces and User Panel . . . . . . . . . . . . . . . . . . .6-11
Cleaning the DPM and SPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-11
Leakage Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12
FIELD SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12
CLINICAL SERVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12
Installation and Training. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12
Hot Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-12
RETURNED GOODS AUTHORIZATION (RGA) SYSTEM . . . . . . . . . . . . . .6-13
RGA Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-13
MAINTENANCE SCHEDULE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-14
MAINTENANCE RECORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-15
CHAPTER SEVEN, REFERENCE INFORMATION
REFERENCE CALCULATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2
Anticoagulant in Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2
AC Volume Returned to the Donor or Patient. . . . . . . . . . . . . . . . . . . . .7-3
Total Blood Volume Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-4
Expected Extracorporeal Volume.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-7
Determining Product Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-8
Calculating Platelet Yields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-8
Calculating Platelet Efficiencies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-9
ANTICOAGULANTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-10
ACD-A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-10
ACD-B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-10
Sodium Citrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-10
Heparin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-10

P/N 39551-00, Rev. F
Chapter One
INTRODUCTION
OVERVIEW OF THE MCS®+ DEVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

1-2 Introduction
P/N 39551-00, Rev. F
OVERVIEW OFTHE MCS+ DEVICE
Using the latest computer and blood processing technology, the Haemonetics
MCS®+ Device LN 9000 (see Figure 1-1) collects blood components, including
platelets, and plasma.
The MCS+ Device combines advanced technology with portability and ease-of-
use. The system is lightweight and compact. A removable program card, called
the Protocol Card, makes it possible to upgrade the operating program of your
machine without opening the cabinet.
Figure 1-1, The Haemonetics MCS+ Device LN 9000
+
MCS
®

Introduction 1-3
P/N 39551-00, Rev. F
Among the characteristics of the MCS+ device are:
•A third pump, referred to as the White Pump, that enables the MCS+ de-
vice to maintain a more consistent “critical flow,” gaining better control
of the platelet collection process.
Note: The White Pump has also been referred to as the Plasma Pump and the
Surge Pump.
•A large, interactive user interface that provides ample feedback and
on-line help.
•The “HaemoCalculator” function, which is an integral part of the com-
puter control. The HaemoCalculator allows the operator to input donor
or patient information to optimize the blood component collection pro-
cess.
•The “HaemoUpdate” function, which gives the operator a full running
update of all procedure details at any time.
•A removable Protocol Card that makes it possible to change or
upgradethe collection protocols performed by the MCS+ device without
opening the cabinet and without the help of a service technician.
•A drip monitor that monitors the flow of anticoagulant.
•An identification system that checks the disposable type and ensures that
the appropriate protocol is selected.
✍

P/N 39551-00, Rev. F
Chapter Two
SYSTEM DESCRIPTION
GENERAL SYSTEM DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
POWER ENTRY MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
USER PANEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
DONOR/PATIENT FLOW INDICATORS. . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Donor Flow Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
SCREENS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
Main Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7
HaemoCalculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
HaemoUpdate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
Modify . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
Operator Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
KEYS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12
Mode Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12
Pump Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-13
Cuff Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14
Programming Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-14
PROTOCOL CARD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-15
Protocol Card Pouch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17
VALVES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17
PRESSURE MONITORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17
Donor Pressure Monitor (DPM). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17
System Pressure Monitor (SPM). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-19
WEIGHER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-19
AIR DETECTORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-19
Anticoagulant Line Air Detector (ACAD). . . . . . . . . . . . . . . . . . . . . . . .2-19
Blood Line Air Detector (BLAD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-19
Donor Line Air Detector 1 (DLAD 1) . . . . . . . . . . . . . . . . . . . . . . . . . .2-20
Donor Line Air Detector 2 (DLAD 2) . . . . . . . . . . . . . . . . . . . . . . . . . .2-20
PUMPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-21
Blood Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-21
White Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-21
Anticoagulant Pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-22
ANTICOAGULANT DRIP MONITOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-22
CENTRIFUGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-23
Mechanical Chuck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-23
Vacuum Chuck. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-25
Manual Vacuum Release Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-26
Bowl Optics Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-26
Fluid Detectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-26
LINE SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-26
PRESSURE CUFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27
MACHINE ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27
List No. 9010 Transport Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27
List No. 7010 Machine Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-27

2-2 System Description
P/N 39551-00, Rev. F
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
Dimensions (approximate) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
Machine Symbol Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28

System Description 2-3
P/N 39551-00, Rev. F
GENERAL SYSTEM DESCRIPTION
The MCS+is a lightweight, compact, blood processing instrument. The system
consists of two parts: the machine and the single-use blood processing dispos-
able.
On the inside of the MCS+ device cover, there is a Display Screen on which mes-
sages regarding the operation of the system are shown. Located directly beneath
the Display Screen is a Control Panel through which the operator selects proto-
cols and enters information.
Figure 2-1, System Components
On the front of the MCS+ device cabinet (Figure 2-1)are a Blood Filter Holder
and two pressure monitors that check the pressure in the disposable set. On the
left side of the cabinet is an anticoagulant drip monitor, which monitors the flow
of anticoagulant. On the right side of the cabinet is the Protocol Card door.
In various locations on the cabinet are four air detectors that check for the pres-
ence of fluid or air in the tubing.
On the MCS+ device deck (Figure 2-2) are a Centrifuge in which the processing
chamber is placed and three rotary pumps that move fluids through the system.
+
MCS
®
Dual IV Pole
Protocol Card
Blood Filter Holder
Donor Line Air
Donor Line Air
Detector #2
Detector #1
(DLAD 1)
(DLAD 2)
Donor Lights
Door
Control Pane
l
Centrifuge
Pumps
On/Off Switch
Weigher Valve System Pressure
Line Sensor
Pressure Cuff
Monitor
Donor Pressure
Monitor
(on side)
Display Screen

2-4 System Description
P/N 39551-00, Rev. F
In various locations on the deck are seven valves that control the fluid pathway.
A Line Sensor monitors the density of fluid in the effluent line of the bowl.
Several disposables are available. Each is designed to provide optimal results
when collecting the specific component required.
All disposables include the following:
a. Tubing harness through which blood flows
b. Centrifuge bowl in which blood is separated into its components
c. Collection bag(s) into which component(s) are collected
POWER ENTRY MODULE
The Power Entry Module, located on the left side of the machine, performs three
functions.
a. ON/OFF. The first function is to power the machine on and off. In case
of an emergency, this button stops all machine function.
b. FUSE PANEL. The second function is to act as a fuse panel to interrupt
power to the machine in the event of excessive current draw.
Figure 2-2, Top View of Deck
White
AC Pump Centrifuge
Blood Pump
Donor Pressure Monitor Valves
Valves
Blood Line
Air Detector
Donor
Flow
Lights
Dono
r
Flow
Lights
Drip
Monitor
Weigher
Line
Senso
r
Disposable Identification
(DPM) System Pressu
re
Monitor (SPM
)
Cover Latch
A/C Air
Detector
(ACAD)
Pump Well
Power
Entry
Module
(BLAD)

System Description 2-5
P/N 39551-00, Rev. F
c. INPUT POWER RECEPTACLE. This machine component allows the con-
nection to the power cord.
USER PANEL
The MCS+ device is operated through the User Panel; the system provides infor-
mation regarding the status of procedures through Donor Flow Lights and
through the Display Screen. All keys are covered by a washable plastic cover to
protect them from spills.
The MCS+ device User Panel (Figure 2-3) consists of three main sections: the Do-
nor Flow Lights, the Display Screen, and the Control Panel.
DONOR/PATIENT FLOW INDICATORS
Donor Flow
Lights During Draw, the Donor Flow Lights (Figure 2-4), located on both sides of the
deck and on the cover, indicate the status of the flow to and from the donor/pa-
tient. If the programmed pump speed is not compatible with the flow, adjust the
Blood Pump speed using the pump keys located on the control panel to meet the
individual donor/patient requirement.
During Draw, one of the Donor Flow Lights is illuminated.
Figure 2-3, MCS+ Device User Panel
Prime Return STOPDraw
Modify
Cuff
Yes No
Save
Help
Haemo
Calculator
+–
Pump
Start/
Stop
ReturnNoneLowNormal
Donor Flow
Lights
Display
Screen
Control
Panel

2-6 System Description
P/N 39551-00, Rev. F
Figure 2-4, Donor Flow Lights
The four sets of Donor Flow Lights are located at the top of the panel, the sides
of the cabinet, and the outside of the cover.
These lights indicate status of the flow: Normal (green), Low (yellow), None (red),
or Return (yellow).
NORMAL FLOW
The green lights are illuminated to indicate that the Blood Pump is able to main-
tain a speed greater than 2/3 of the programmed speed. The Blood Pump’s speed
decreases by 5 ml/min each second if the donor/patient pressure falls below -50
mmHg. Once the donor/patient pressure increases again, the pump speed in-
creases at a rate of 5 ml/min each second. This pressure is measured and com-
municated to the MCS+ device computer by the Donor Pressure Monitor (DPM).
LOW FLOW
The yellow Donor Flow Lights are illuminated to indicate that the donor/patient
flow rate is below 2/3 of programmed speed.
NONE
The red light is illuminated to indicate that there is no flow. When the flow stops,
the Blood Pump and AC Pump automatically stop. The Centrifuge continues to
spin to maintain separation. The Blood and AC Pumps automatically restart
when the donor/patient blood flow is restored. The White Pump remains active.
RETURN
During Return, the only donor/patient flow indicator lights that illuminate are
yellow in color and are at the outermost end of the indicator panels.
These yellow lights indicate to the donor/patient and to the operator that the re-
maining components are being returned to the donor/patient.
ReturnNoneLowNormal
