HAGS NG223S User manual

© Playpower Inc
E-post:[email protected]
www.hags.com
1 / 11
NG223 Bermuda Triangle Issue G - 16/06/2017
Installation Instructions
NRG Bermuda Triangle
NG223S

1
3
7
9
11
2
5
8
6
12
10
4
30 kg!
B T
B T
B T
30 kg!
B T
http://www.alansonsuk.com/downloads.asp
78804035
1 No
NRG Arch Spiggot
RYADHBK
1 No
Bollard Adhesive
78804090
1 No
Board Connecting Plate
RYBL300
2 No
300mm Black Bollard
10291000
16 No
M10 Form ‘A’ Washer
78803108
1 No
Bermuda Triangle Board Arch
78803109
1 No
Bermuda Triangle Rope Arch
10121030
12 No
M10x30mm Resistorx
78804031
1 No
Tube Clear Silicone Sealant
803703
2 No
300mm Bollard Fix Post
78803005
1 No
Curved Board Support
78802015
1 No
BT Top Climbing Board
23 kg!
2 / 11
NG223 Bermuda Triangle Issue G - 16/06/2017

10301005
12 No
M10x40mm Barrel Nut
78904012
24 No
Yellow Climbing Grip
78805040
1 No
432mm Long Rope Assembly
10051025
24 No
1” Self Tapping Screw
10309999
12 No
Large M10 Washer
78802016
1 No
BT Base Climbing Board
78805041
1 No
515mm Long Rope Assembly
78803014
1 No
Climbing Ring
78805043
1 No
625mm Long Rope Assembly
78805042
1 No
476mm Long Rope Assembly
78805039
1 No
740mm Long Rope Assembly
78805038
1 No
T-Rope Assembly
23
21 22
24
14
13
16
15
18
17
20
19
23 kg!
Ø30mm
3 / 11
NG223 Bermuda Triangle Issue G - 16/06/2017

10941000
20 No
M10 T-Nuts BZP
10121040
12 No
M10x40mm Resistorx
10931000
1 No
M10 Brass T-Nut
10121020
13 No
M10x20mm Resistorx
10391200
1 No
M12 Shakeproof Washer
10304010
9 No
M10 Form ‘C’ Washer
78804044
4 No
1220mm Long Cable Tie
950104
1 No
M6 Resistorx Tool
950100
1 No
M10 Resistorx Tool
10121001
1 No
M12 Resistorx Tool
Ø25mm
28
3029
31
25 26
27
32 33 34
4 / 11
NG223 Bermuda Triangle Issue G - 16/06/2017

2
3
4
27 30 3028 26 4 29
20 19 18
5
21 17 101516 1
12
11
13
7
8
25 24
22
2314
GB - Verify ropes fit – remove before concreting
ES – Utilizar las cuerdas para verificar la distancia entre
los postes - quitarlas antes de poner el hormigón
FR – Utiliser les cordes pour vérifier la distance entre
les poteaux - les retirer avant bétonnage
DE – Überprüfen Sie, dass die Seile passen - vor der
Betonierung
IT – Usare le corde come distanziali – rimuoverle prima
di cementare i pali
SE – Kontrollera att de linorna passa - flyttas innan
betongarbete
5 / 11
NG223 Bermuda Triangle Issue G - 16/06/2017

0,0
50
850
1250 2350
3500
6501450400
3020
450
0.60
m³
100
144
TYPE 1
Sand
144
TYPE 2
Bark
144
TYPE 3
Synthetic
144
TYPE 5
Grass mat
0,0 0,0
S2 (50mm)
≥C20-25
7 x 24h
101
H
EN1176
H=2.4m
6 / 11
NG223 Bermuda Triangle Issue G - 16/06/2017

42 Nm!
5
1
4
3
2
7 / 11
NG223 Bermuda Triangle Issue G - 16/06/2017

GB - Protect from concrete
FR - Protéger contre le beton
DE - Schutz vom Beton
IT - Proteggere dal cemento
ES - Proteger contra el hormigón
SE- Skyddas mot betong
8 / 11
NG223 Bermuda Triangle Issue G - 16/06/2017

12
13
27
2
30
29
10
25 24 22 14
14
2751129
24 23
30
42628 30 29
4 1
9 / 11
NG223 Bermuda Triangle Issue G - 16/06/2017

H
EN1176
H=2.4m
T = 8 hr
X 2 = T
LxWxH (m)
4.09 x 0.25 x 2.36
kg
177 0.60
m³
10 x 10
m²
BB
7090
1625
4290
2145
10 / 11
NG223 Bermuda Triangle Issue G - 16/06/2017

BB
BB
BB
144
TYPE 3
Synthetic
144
TYPE 5
Grassmat
8000
5000
4500
7139
4339 2882 1268
8000
5525
1521
11 / 11
