Haier AD71S2SM7FA Installation and operating instructions

6
No.0150550063
7
8
9
10
14
15
16
Move and scrap the air conditioning ........21
AD71S2SM7FA
AD100S2SM7FA
AD125S2SM7FA
AD140S2SM7FA
Keep this operation man al for f t re reference.
Original instructions
This product must only be installed or serviced by ualified personnel.
Please read this manual carefully before installation.
Accessory 13

Your airconditioning productis marked with this
symbol.Thismeans that electricaland electronic
productsshall not be mixed with unsorted
household waste.Do not tryto dismantle the
systemyourself:the dismantling of the air
conditioning system,treatment of therefrigerant,of oil and of
other part must be done bya qualified installerin accordance
with relevant localand nationallegislation.Airconditioners
must be treated at a specialized treatment facility for reuse,
recycling and recovery.Byensuring thisproduct is disposed
of correctly,you willhelp to prevent potential negativecons-
equences for the environment and humen health.Please
contact the installer orlocalauthority for moreinformation.
Batterymust beremoved from theremote controllerand dis-
posed of separatelyin accordance withrelevant local and
nationllegislation.
DISPOSALREQUIREMENTS:
Containsfluorinatedgreenhouse gases
covered bythe KyotoProtocol
This product contains fluorinated greenhouse gases covered
by the Kyoto Protocol.Do not vent into the atmosphere.
GWP:675
Refrigerant type:R32
GWP=global warming potential
Please fill in with indelible ink,
1 the factory refrigerant charge of the product
2 the additionalrefrigerant amount chargedin the field
and
1+2 the totalrefrigerant charge
on the refrigerant chargelabelsupplied with the product.
The filled out labelmuset be adhered in the proximity of the
product charging port(e.g.onto the inside of thestop value
cover).
Acontains fluorinated greenhouse gases covered by the
KyotoProtocol
Bfatory refrigerant charge of the product:see unit name
plate
C additionalrefrigerant amount charged in the field
D totalrefrigerant charge
Eoutdoor unit
Frefrigerant cylinderand manifold forcharging
HaierIndustrialPark, No.1Haier road, Qingdao,P.R.China
A
B
C
D
kg
kg
kg
R32
WARNING
If the supplycordis damaged, it must be replaced by the manufacturer,itsservice agent orsimilarly qualified personsin
order to avoid a hazard.
This applianceisnotintended foruse bypersons(including children)with reduced physical,sensory ormentalcapabilities,
orlack ofexperience and knowledge, unless theyhavebeen given supervision orinstruction concerning useof the appliance
by a person responsible for theirsafety.
Children should be supervised to ensure that they do not play with the appliance.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision (Only for EU market).
The appliances are not intended to be operated bymeansof an externaltimer orseparateremote-controlsystem.
Keep the appliance andits cord out of reach of children less than 8 years.
EUROPEAN REGULATIONS
CONFORMITYFORTHEMODELS
IMPORTANT INFORMATION REGA-
RDINGTHE REFRIGERANTUSED

Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
The appliance must be stored in a room without continuously operating ignition sources(for examples: open flames, an operating gas appliance
or an operating electric heater).
Do not pierce or burn.
Be aware that refrigerants may not contain an odour.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance (For markets other than EU).
The wiring method should be in line with the local wiring standard.
All the cables shall have got the European authentication certificate. During installation, when the connecting cables break off, it must be
assured that the grouding wire is the last one to be broken off. The explosion-proof breaker of the air conditioner should be all-pole switch.
Distance between it’s two contacts should not be no less than 3mm. Such means for disconnection must be incorporated in the wiring.
Make sure installation is done according to local wiring regulation by professional persons.
Make sure ground connection is correct and reliable. A leakage explosion-proof breaker must be installed.
The installation and service of this product shall be carried out by professional personnel, who have been trainedand certified by national training
organizations that areaccredited to teach the relevant national competency standards that may be set in legislation.
Mechanical connectors used indoors shall comply with ISO 14903. When mechanical connectors are reused indoors, sealing parts shall be
renewed. When flared joints are reused indoors, the flare part shall be re-fabricated.
This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial use by lay persons。
Disconnect the appliance from its power source during service and when replacing parts
The maximum working pressure is 4.15 MPa.This maximum working pressure shall be considered when connecting the outdoor unit to indoor
units.
The refrigerant suitable for the indoor unit is R410A/R32. The indoor unit shall only be connected to outdoor unit suitable for the same refrigerant.
The unit is a partial unit air conditioner, complying with partial unit requirements of the International Standard, and must only be connected to
other units that have been confirmed as complying to corresponding partial unit requirements of the International Standard.
The A-weighted sound pressure level is below 70 dB.
WARNING

3
Cautions
Disposal o the old air conditioner
Be ore disposing an old air conditioner that goes out o use, please make sure it's inoperative and sa e. Unplug the air conditioner
in order to avoid the risk o child entrapment.
It must be noticed that air conditioner system contains re rigerants, which require specialized waste disposal. The valuable
materials contained in a air conditioner can be recycled. Contact your local waste disposal center or proper disposal o an old
air conditioner and contact your local authority or your dealer i you have any question. Please ensure that the pipework o your
air conditioner does not get damaged prior to being picked up by the relevant waste disposal center, and contribute to environmental
awareness by insisting on an appropriate, anti-pollution method o disposal.
Disposal o the packaging o your new air conditioner
All the packaging materials employed in the package o your new air conditioner may be disposed without any danger to the
environment.
The cardboard box may be broken or cut into smaller pieces and given to a waste paper disposal service. The wrapping bag
made o polyethylene and the polyethylene oam pads contain no luorochloric hydrocarbon.
All these valuable materials may be taken to a waste collecting center and used again a ter adequate recycling.
Consult your local authorities or the name and address o the waste materials collecting centers and waste paper disposal
services nearest to your house.
Sa ety Instructions and Warnings
Damaged air conditioners are not to be put into operation. In case o doubt, consult your supplier.
Use o the air conditioner is to be carried out in strict compliance with the relative instructions set orth in the User's Guide.
Installation shall be done by pro essional people, don't install unit by yoursel .
For the purpose o sa ety, the air conditioner must be properly grounded in accordance with speci ications.
Always remember to unplug the air conditioner be ore opening inlet grill. Never unplug your air conditioner by pulling on the
power cord. Always grip plug irmly and pull straight out rom the outlet.
All electrical repairs must be carried out by quali ied electricians. Inadequate repairs may result in a major source o danger or
the user o the air conditoiner.
Do not damage any parts o the air conditioner that carry re rigerant by piercing or per orating the air conditioner's tubes with
sharp or pointed items, crushing or twisting any tubes, or scraping the coatings o the sur aces. I the re rigerant spurts out and
gets into eyes, it may result in serious eye injuries.
Do not obstruct or cover the ventilation grille o the air conditioner. Do not put ingers or any other things into the inlet/outlet and
swing louver.
Do not allow children to play with the air conditioner. In no case should children be allowed to sit on the outdoor unit.
This appliance is not intended or use by persons (including children) with reducedphysical, sensory or mental capabilities, or
lack o experience and knowledge, unless they have been given supervision or instruction concerning use o the appliance by
a person responsible or their sa ety.
Children should be supervised to ensure that they do not play with the appliance.
Be ore starting the air conditioner, read the in ormation given in the User's Guide care ully. The User's Guide contains very
important observations relating to the assembly, operation and maintenance o the air conditioner.
The manu acturer does not accept responsibility or any damages that may arise due to non-observation o the ollowing
instruction.

4
Sa ety Precautions
Be ore starting to use the system, read care ully this "SAFETY PRECAUTIONS" to ensure a proper operation o the system.
Sa ety precautions described here are classi ied to " WARNING" and " CAUTION". Precautions which are shown
in the column o " WANING" means that an improper handing could lead to a grave result like a death, serious injury,
etc. However, even i precautions are shown in the column o " CAUTION", a very serious problem could occur depending
on situation. Make sure to observe these sa ety precautions aith ully because they are very important in ormation to ensure
the sa ety.
Symbols which appear requently in the text have ollowing meanings.
Strictly prohibited. Observe instructions aith ully.Provide a positive grounding.
When you have read through the manual, keep it always at hand or read consultation. I the operator is replaced, make
sure to hand over this manual to the new operator.
CAUTIONS FOR INSTALLATION
ON
OFF
WARNING
CAUTION
The system should be applied to places as o ice,
restaurant, residence and the like.
The system should be installed by your dealer or
a pro essional installer.
When you need some optional devices such as a
humidi ier, electric heater, etc., be sure to use the products
which are recommended by us. These devices should
be attached by a pro essional installer.
Application to in erior environment such as an
engineering shop, could cause equipment
mal unction and serious injury or death.
Installation by yoursel is not encouraged because
it could cause such problems as water leakage,
electrical shock or ire accident by some improper
handing.
Installation by yoursel is not encouraged because it could
cause such problems as water leakage, electrical shock
or ire accident by some improper handing.
Do not install nearby the place where may have
leakage o lammable gas.
Depending on the place o installation, a circuit
breaker may be necessary.
Drain pipe should be arranged to provide a positive
draining.
I the gas leakes and gathers around, it may cause
the ire.
Unless the circuit breaker is installed, it could cause
elecrical shocks.
Where strong winds may prevail, the system
should be ixed securely to prevent a collapse.
Install on the place where can endure the weight
o air conditioner.
Make sure the system is grounded.
I the pipe is arranged improperly, urniture or the
likes may be damaged by leaked water.
Bodily injury could result by a collapse. Bodily injury could result by a careless installation. Grounding cable should never be connected to
a gas pipe, city water pipe, lightning conductor
rod or grounding cable o telephone. I the
grounding cable is not set properly, it could cause
electric shocks.
WARNING
CAUTIONS FOR TRANSFER OR REPAIR
Modi ication o the system is strictly prohibited. When the system needs a
repair, consult your dealer.
When the air conditioner is relocated, contact your dealer or a pro essional
installer.
Improper practice o repair could cause water leakage, electric shock or
ire.
Improper practice o installation could cause water leakage, electric shock
or ire.

Do not wash the air conditioner with water. Do not install the system where the air outlet
reaches directly the lora and auna.
Make sure to use a use o proper electric rating.
Do not operate the system while the air outlet grill
is removed.
It is strictly prohibited to place a container o
combustible gas or liquid near the air conditioner
or to spray it directly with the gas or liquid.
Neither stand on the air conditioner nor
place something on it.
Do not use the power switch to turn on or o the
system.
Do not touch the air outlet section while the swing
louver is operating.
Do not use such equipment as a water heater, etc.
around the indoor unit or the wire controller.
ON
OFF
It could cause electric shocks. It will not be good or their health. Use o steel or copper wire in place o a use is
strictly prohibited because it could result in a trouble
or ire accident.
There is a risk o injury.It could cause a ire accident.There are risks o alling or injury by collapsed
object.
It could cause a ire or water leakage. There is a risk o injury. I the system is operated at the vicinity o such
equipment which generates steam, condensed
water may drip during cooling operation or it could
cause a ault current or short-circuit.
When operating the system simultaneously with
a combustion apparatus, indoor air must be
ventilated requently.
Check occasionally the support structure o the
unit or any damage a ter a use o long period o
time.
Insu icient ventilation could cause an oxygen
de iciency accident.
I the structure is not repaired immediately, the
unit could topple down to cause a personal injury.
When cleaning the system, stop the operation and
turn o the power switch.
Do not put water containers on the unit such as a lower vase, etc.
Cleaning should never be done while the internal
ans are running with high speed.
I the water enters into the unit and damages the electric insulation material, it may cause electric shock.
WARNING
CAUTION
CAUTIONS FOR OPERATION
You should re rain rom exposing your body directly
to cool wind or a long time.
Do not poke the air inlet or outlet with a bar, etc. When any abnormal condition (scorching smell or
others) is ound, stop the operation immediately
and turn o the power switch. Then consult your
dealer.
It could a ect your physical condition or cause
some health problems.
Since the internal an is operating with a high
speed, it could cause an injury.
I you continue the operation without removing the
cause, it could result in a trouble, electric shock
or ire.
The system should never be used or any other
purposes than intended such as or preservation
o ood, lora and auna, precision devices or work
o art.
Do not handle switches with a wet hand. Combustion apparatus should not be placed
allowing a direct exposure to wind o air conditioner.
Incomplete combustion could occur on the
apparatus.
It could cause electric shocks.It could cause deterioration o ood or other
problems.
5
Sa ety Precautions

1. Applicable ambient temperature range:
The machine is adaptive in following situation
Cooling
Heating
Indoor temperature
Outdoor temperature
Indoor temperature
Outdoor temperature
max. DB/WB
min. DB/WB
max. DB/WB
min. DB/WB
max. DB/WB
min. DB/WB
max. DB/WB
min. DB/WB
32/23 C
18/14 C
43/26 C
10/6 C
27 C
15 C
24/18 C
-15 C
2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similar qualified person.
3. If the fuse on the indoor PC board is broken please change it with the type of T 5A/250V(For AD100S2SM7FA/
AD71S2SM7FA/AD125S2SM7FA/AD140S2SM7FA)
4. The wiring method should be in line with the local wiring standard.
5. The power cable should be:
H05RN-F 3G 4.0mm²(outdoor unit 1U71S2SS5FA/1U100S2SN5FA),or H05RN-F 3G 6.0mm²(outdoor unit
1U125/140S2SP5FA),
The connecting cable should be:
H05RN-F 4G 2.5mm2
All the cables shall have got the European authentication certificate. During installation, when the connecting cables
break off, it must be assured that the grouding wire is the last one to be broken off.
6. The power cable and connect cable should be self-provided.
7. The breaker of the air conditioner should be all-pole switch, and the distance between its two contacts should be no
less than 3mm.
8. The indoor unit installation height is at least 2.5m.
9. A leakage breaker must be installed.
10.For AD71S2SM7FA/AD100S2SM7FA /AD125S2SM7FA/AD140S2SM7FA,we can get the 10 different ESP
through adjust wired controller YR-E17A, please refer below:
AD71S2SM7FA
AD100S2SM7FA
AD125S2SM7FA
AD140S2SM7FA
static presssure grade
static presssure(Pa)
0 25 37 50 70 90 100 120 130 150
0 25 37 50 70 90 100 120 130 150
25 37 50 70 90 100 110 120 130 150
AD71S2SM7FA
AD100S2SM7FA
AD125S2SM7FA
AD140S2SM7FA 25 37 50 70 90 100 110 120 130 150
Adjsutment metchod by wired controller YR-E17A：In the state of ON and non screen saving state, press Fan+ Set keys for
5 seconds to enter static pressure grade adjustment state with static pressure icon flashing and current static pressure
grade statically displaying. Press key↑↓ to change static pressure grade, then press Set key to confirm.
Details please refer to wired controller operation & installation manual.
Adjsutment metchod by Infrared remote controller+Infrared receiver RE-02：Step a:set the Infrared remote controller at
condition： FAN mode ，fan speed high Step b:then aim the remote controller at the infrared remote receiver RE-02，
press HEALTH button 4+N times（1≤N≤10，integer）within 12 seconds ，then the receiver will beep N+1 times ，the
static pressure level N is been set successfully.
Note：For Infrared remote controller YR-E17A, need press ON/OFF button make the controller’s at OFF status first，then
●
open the button cover press FRESH button will enter FAN mode interface.
91012
(factory default) 345678

Installation Manual For Wire Controller
7
There are three methods to connection wire controller and the indoor units:
A.One wired controller can control max. up to 16 sets of indoor units, and 3 pieces of polar wire must connect the wire
controller and the master unit (the indoor unit connected with wire controller directly), the others connect with the master
unit through 2 pieces of polar wire
B. One wire controller controls one indoor unit, and the indoor unit connects with the wire controller through 3 pieces of
polar wire.
C. Two wired controllers control one indoor unit. The wire controller connected with indoor unit is called master one, the
other is called slave one. Master wire controller and indoor unit; master and slave wire controllers are all connected
through 3 pieces of polar wire.
6. Communication wiring:
The wire controlleris equipped with specialcommunication wiring in the accessories. 3-core terminal(1-white 2-yellow 3-
red)is connected with the terminalA, B, C of wire controller respectively.
The communication wiringis 5 meterlong;if the actuallength is more than it, please distribute wiring according to below
table:
Communicationwiring length(m) Dimensions of wiring
< 100 0.3mm
2
x3-coreshielded wire
100and <200 0.5mm
2
x3-coreshielded wire
200and <300 0.75mm
2
x3-coreshielded wire
5.Wiring connections of wire controller:
WIRED CONTROLLER& INDOOR PCB CONNECTION(one for one wiring type):
.
Note：When do the wired controller & indoor PCB wiring work ,do not connect the shielded wired to the
unit’s shell,do not parallel wiring with strong electric lines within 0.3 meters, please keep strong lines and the
signal lines separately.
INDOOR UNIT PCB
CN22
WIRED
CONTROLLER
CON1
A
B
C
A
B
C

"HOT KEEP" unction
Heating Mode
8
"HOT KEEP" is operated in the ollowing cases.
When heating is started:
In order to prevent blowing out o cool wind, the indoor unit an stopped according to the room temperature which heating
operation is started. Wait or approx. 2 to 3 minute, and the operation will be automatically changed to the ordinary heating
mode.
De rosting operation (in the heating mode):
When it is liable to rost, the heating operation is stopped automatically or 5 to 12 minutes once per approx. one hour,
and de rosting is operated. A ter de rosting is completed, operation mode is automatically changed to ordinary heating
operation.
When the room thermostat is actuated:
When room temperature increases and room temperature controller actuates, the an speed is automatically changed to
stop under low temperature condition o indoor heat exchanger. When room temperature decreases, air conditioner
automatically changes over to ordinary heating operation.
Heat pump type warming
With the heat pump type warming, the mechanism o heat pump that concentrate heat o outdoor air with the help o
re rigerant to warm the indoor space, is utilized.
De rosting operation
When a room is warmed with a heat pump type air conditioner, rost accumulates on the heat exchanger o outdoor unit
along with the drop o indoor temperature. Since the accumulated rost reduces the e ect o warming, it is necessery to
automatically switch the operation to the de rosting mode. During the de rosting operation, heating operation is interrupted.
Atmospheric temperature and warming capacity
Warming capacity o heat pump type air conditioner decreases along with the drop o outdoor temperature.
When the warming capacity is not su icient, it is recommended to use another heating implement.
Period o warm-up
Since the heat pump type air conditioner employs a method to circulate warm winds to warm
the entire space o a room, it takes time be ore the room temperature rises.
It is recommendable to start the operation a little earlier in a very cold morning.
Warming operation

Points to observe
Turn o the power supply switch. Do not touch with wet hand. Do not use hot water or volatile liquid.
ON
OFF
Thinner
Do not
use!
Benzine
Tooth powder
Cleaning the air ilter
Do not dry the air ilter with ire.
Do not run the air conditioner without the air ilter.
Pre-Season Care
See that there are no obstacles blocking the air inlet and air outlet o both indoor and outdoor units.
Make sure that the air ilter is not dirty.
Cut in the power supply switch 12 hours be ore starting run.
Post-Season Care
Operate the unit with FAN mode on a air day or about hal a day to dry the inside o the unit well.
Stop operation and turn o the power supply switch. Electric power is consumed even the air conditioner is in stop.
Clean the air ilter and set it in the place.
Care and Cleaning o the unit
Clean with so t and dry cloth.
I it is very dirty, dissolve neutral detergent in the lukewarm water and make the cloth wet with the water. A ter wiping,
clean o the detergent using clean water.
1.Clean the air ilter by lightly tapping it or with the cleaner. It is more e ective to clean
the air ilter with water.
I the air ilter is very dirty, dissolve neutral detergent in the lukewarm water (approx. 30 C),
rinse the air ilter in the water, and thoroughly wash the air ilter o the detergent
in the plain water.
2.A ter drying the air ilter, set it up on the air conditioner.
Do not open the inlet grill until an stops completely.
Fan will continue rotating or a while by the law o inertia a ter operation is being stopped.
CAUTION
CAUTION
Care and Maintenance
9

Please check the ollowing things about your air conditioner be ore making a service call.
When the air conditioner does not operate properly a ter you have checked the above mentioned items or when the ollowing
phenomenon is observed, stop the operation o the air conditioner and contact your sales dealer.
The use or breaker o ten shuts down.
Water drops o during cooling operation.
There is a irregularity in operation or abnormal sound is audible.
When the CHECK LED (red) lickers, an irregularity has occurred in the air conditioner.
Unit ails to start
ON
OFF
Is the power source switch
adjust cut in?
Is city supply power in
normal?
Isn't the signal receiving
section exposed to the direct
sunlight or strong illumination?
Isn't the earth leakage breaker
in action?
It is dangerous. Turn o the
power supply switch
immediately and contact the
sales dealer.
Power supply switch is not
ON.
Cooling or heating is not su icient
Is the thermostat adjust as
required?
Isn't the air ilter dirty? Isn't any doors or windows
le t open?
Doesn't any obstacle exist at
the air inlet or outlet?
Cooling is not su icient
Isn't sun-shine invading direct? Isn't any unexpected heating
load generated?
Isn't the room much crowded?
Isn't the swing louver horizontal? (At HEATING mode)
I swing louver is horizontal, the blow wind does not reach loor.
The wind does not blow during
heating operation
Isn't it warming up?
Power
stoppage?
Troubleshooting
10

The ollowings are not mal unction
Shuru
Shuru
When the air conditioner is started, when the compressor starts or stops
during operation or when the air conditioner is stopped, it sometimes sounds
"shuru shuru" or "gobo gobo". It is the lowing sound o the re rigerant, and it
is not a trouble.
Water lowing sound is heard.
This is caused by heat expansion or contraction o plastics.Cracking sound is heard.
It smells. Air which blows out rom the indoor unit sometimes smells. The smell results
rom residents o tobacco smoke or cosmetics stuck inside o unit.
When the air conditioner is used at restaurant etc. where dense edible oil
ume is always exists, white og sometimes blows out o air outlet during
operation. In this case consult sales dealer or cleaning the heat exchanger.
During operation, white og comes out
o indoor unit.
Unit does
not start Wait or
three
minutes
It is switched into the FAN mode during
cooling.
To prevent rost rom being accumulated on the indoor unit heat exchanger,
it is sometimes automatically switched to the FAN mode,but it will soon return
to the cooling mode.
Even i the operation switch is turned on, cooling, dehumidi ying or heating
is not operable or three minutes a ter the conditioner is stopped. Because
the protecting circuit is activated. (During this time air conditioner operates
in an mode.)
The air conditioner can not be restarted
soon a ter it stops.
Air does not blow or the an speed can
not be changed during dehumidi ying.
During operation, operation mode has
changed over automatically.
Water or steam generates rom the outdoor
unit during heating.
When it is excessively cooled during dehumidi ying, the blower
automatically repeats reducing and lowering the an speed.
Isn't the AUTO mode selected?
In the case o AUTO mode, operation mode is changed automatically rom
cooling to heating or vise-versa according to the room temperature.
This results when rost accumulated on the outdoor unit is removed (during
de rosting operation).
Troubleshooting
11

INDOOR UNIT TROUBLE SHOOTING
AD71S2SM7FA/AD100S2SM7FA/AD125S2SM7FA/AD140S2SM7FA
Troubleshooting
LED flash times
of indoor PCB Contents of
Malfunction Possible reasons
LED4 LED3
0
0
0
1
2
4
Malfunction of indoor
unit ambient temper-
ature sensor
Sensor disconected,or brok-
en,or at wrong position,or
short circuit
Malfunction of indoor
unit piping temper-
ature sensor
EEPROM wrong of
indoor PCB
EEPROM chip disconected
or broken or wrong program-
med,or PCB broken
Abnormal communi-
cation between indo-
or and outdoor units
Wrong connection,or the
wires be disconected or wro-
ng adress setting of indoor
unit or faulty power supply
or faulty PCB or sub unit
malfunction in MAXI system
0
0
0
0
0
7
8
12
13
14
Abnormal communi-
cation between wired
controll
e
r and indoor
Wrong connection or wired
controller broken,or PCB
faulty
Malfunction of drain
system
Zero cross sigal
wrong
Zero cross sigal detected
wrong
Note:
1.The outdoor failure can also be indicated by t
h
e ind
oo
r u
n
it,the checking method as follo-
ws:
If the outdoor error code is M(DECIMAL)，the indoor unit’s wired controller display will
show the after converted hexadecimal code of “M+20“(
DECIMAL),for example,if the outdoor
error code is 2,the indoor unit wired controller display will flash the error code 16 (2→2+20=22
→change
decimal 22 to hexadecimal code,get 16）
2.To get much more details about the out door unit failure,ple
ase refer to
the outdoor unit trouble shooting list.
Sensor disconected,or brok-
en,or at wrong position,or
short circuit
Pump motor disconnected
or at wrong position,or the
float swit
,
ch disconnected ，
or at wrong position,or the
DC Fan motor disconnected
or DC Fan broken or circuit
broken or motor blocked
short circuit bridge disconne
ted
Indoor unit DC fan
motor abnormal
Wired
controller
display
01
02
04
07
0C
0D
0E
unit
07
flashing*
3.For YR-E17 communication error between I.D.PCB and wired controller
07 will flash in the main display not the check display interface .
12

Accessory
AccessorysuppliedwiththeindoorunitforAD71/100/125/140series.
No. Name Quantity Descriptions Shape
1 3/8″ Brass nut (liquid side) 1
For tightening the
Connecting pipe
2
3/4″Brass nut(gas
side) for AD140S2SM7FA 1
5/8″ Brass nut(gas side)
for others 1
3 Coupler heat insulation(gas
side) 1 For indoor side pipe
joint(gas side)
4 Coupler heat
insulation(liquid side)
● 1 For indoor side pipe
joint(liquid side)
5 Accessories group 1 Drainage fittings group
6 Instructions 1 Air conditioner
operation
13

WARNING
Please read these "Sa ety Precautions" irst and then accurately execute the installation work.
Though the precautionary points indicated herein are divided under two headings, and , those
points which are related to the strong possibility o an installation done in error resulting in death or serious injury are
listed in the section. However, there is also a possibility o serious consequences in relationship to the
points listed in the section as well. In either case, important sa ety related in ormation is indicated, so by all
means, properly observe all that is mentioned.
A ter completing the installation, along with con irming that no abnormalities were seen rom the operation tests, please
explain operating methods as well as maintenance methods to the user (customer) o this equipment, based on the owner's
manual. Moreover, ask the customer to keep this sheet together with the owner's manual.
This system should be applied to places as o ice, restaurant, residence and the like. Application to in erior environment
such as engineering shop could cause equipment mal unction.
Please entrust installation to either the company which sold you the equipment or to a pro essional contractor. De ects
rom improper installations can be the cause o water leakage, electric shocks and ires.
Execute the installation accurately, based on ollowing the installation manual. Again, improper installations can result
in water leakage, electric shocks and ires.
When a large air-conditioning system is installed to a small room, it is necessary to have a prior planned countermeasure
or the rare case o a re rigerant leakage, to prevent the exceeding o threshold concentration. In regards to preparing
this countermeasure, consult with the company rom which you perchased the equipment, and make the installation
accordingly. In the rare event that a re rigerant leakage and exceeding o threshold concentration does occur, there is
the danger o a resultant oxygen de iciency accident.
For installation, con irm that the installation site can su iciently support heavy weight. When strength is insu icient,
injury can result rom a alling o the unit.
Execute the prescribed installation construction to prepare or earthquakes and the strong winds o typhoons and
hurricanes, etc. Improper installations can result in accidents due to a violent alling over o the unit.
For electrical work, please see that a licensed electrician executes the work while ollowing the sa ety standards related
to electrical equipment, and local regulations as well as the installation instructions, and that only exclusive use circuits
are used. Insu icient power source circuit capacity and de ective installation execution can be the cause o electric
shocks and ires.
Accurately connect wiring using the proper cable, and insure that the external orce o the cable is not conducted to
the terminal connection part, through properly securing it. Improper connection or securing can result in heat generation
or ire.
Take care that wiring does not rise upward, and accurately install the lid/service panel. Its improper installation can
also result in heat generation or ire.
When setting up or moving the location o the air conditioner, do not mix air etc. or anything other than the designated
re rigerant
such mixing.
Always use accessory parts and authorized parts or installation construction. Using parts not authorized by this company
can result in water leakage, electric shock, ire and re rigerant leakage.
WARNING
CAUTION
Execute proper grounding. Do not connect the ground wire to a gas pipe, water pipe, lightning rod or a telephone ground
wire. Improper placement o ground wires can result in electric shock.
The installation o an earth leakage breaker is necessary depending on the established location o the unit. Not installing
an earth leakage breaker may result in electric shock.
Do not install the unit where there is a concern about leakage o combustible gas.
The rare event o leaked gas collecting around the unit could result in an outbreak o ire.
For the drain pipe, ollow the installation manual to insure that it allows proper drainage and thermally insulate it to
prevent condensation. Inadequate plumbing can result in water leakage and water damage to interior items.
CAUTION
WARNING
CAUTION
Precaution or Installation
14
within the re rigeration cycle. Rupture and injury caused by abnormal high pressure can result rom
R32

For inspection and maintenance
When you change your address or the installation place
Electric work
Con irm the ollowing items or sa e and com ortable use o air conditioner.
The installation work is to be burden on the sales dealer, and do not conduct it by yoursel .
Installation place
Avoid installing the air conditioner near
the place where possibility o
in lammable gas leakage exists.
Install the unit at well ventilated place. Install the air conditioner irmly on the
oundation that can ully support the
weight o the unit.
I not, it may cause vibration or noise.I some obstacle exist, it may cause
capacity reduction or noise increase.
Explosion (Ignition) may occur.
Select the place so as not to annoy
neighbor with the hot air or noise.
Snow protection work is necessary
where outdoor unit is blocked up by
snow.
It is advisable not to install the air con-
ditioner at the ollowing special place.
It may cause mal unction, consult the
sales dealer when you have to install
the unit on such a place.
The place where corrosive gas
generates (Hot spring area etc.)
The place where salt breeze blows
(Seaside etc.)
The place where dense soot smoke
exists
The place where humidity is
extraordinarily high
The place where near the machine
which radiates the electromagnetic
wave
The place where voltage variation is
considerably large
For details consult your sales dealer.
The electric work must be burden on the authorized engineer with quali ication or electric work and grounding work, and
the work must be conducted in accordance with electric equipment technical standard.
The power source or the unit is to be o exclusive use.
An earth leakage breaker should be installed.(This is necessary to prevent electric shock.)
The unit must be grounded.
Special technology is required or removal or reinstallation o air conditioner, consult the sales dealer. Besides, construction
expense is charged or removal or reinstallation.
The capacity o air conditioner will decrease by contamination o inside o unit when it is used or about three years although
depending upon the circumstances under which it is used, and so in addition to the usual maintenance service, special
inspection/maintenance service is necessary. It is recommended to make a maintenance contract (charged) by consulting
your sales dealer.
Is The Unit Installed Correctly
15

16
Avoidinstallationanduse at those places listed below.
Placesexposed to oilsplashes orsteam (e.g. kitchensand machine plants).
Installation and use at such placesincur deteriorationsin the performance orcorrosion with the heat exchangeror damage
in moldedsyntheticresin parts.
Placeswherecorrosive gas(such assulfurousacid gas) orinflammablegas(thinner,gasoline etc.)in generatedor
remains. Installation and use atsuch places causecorrosioninthe heat exchangeranddamage inmolded synthetic
resin parts.
Placesadjacentto equipment generating electromagneticwavesorhigh-frequencywaves such asinhospitals.
Generated noise may cause malfunctioning of the controller.
NOTE
All wiring of this installation mustcomply with NATIONAL, STATEANDLOCALREGULATIONS. These instructions
do notcoverallvariationsforeverykind ofinstallation circumstance.Shouldfurtherinformation be desired orshould particular
problems occur, the mattershould be referred to yourlocal distributor.
WARNING
BE SURETO READ THESEINSTRUCTIONSCAREFULLYBEFOREBEGINNINGINSTALLATION.FAILURETO FOLLOW
THESEINSTRUCTIONSCOULD CAUSESERIOUSINJURYORDEATH, EQUIPMENTMALFUNCTIONAND/OR
PROPERTYDAMAGE.
Preparation of indoorunit
Before or during the installation of the unit, assemble necessary optionalpanel etc. depending on the specific type.
Selectplaces forinstallation satisfyingfollowing conditions andat the sametime obtainthe consent on the part
ofyourclient user.
Placeswherechilledor heated aircirculatesfreely.When the installation height exceeds 3m warmedairstays close to
the ceiling. In such cases, suggest yourclient users to install aircirculators.
Placeswhere perfect drainage can be prepared and sufficient drainage.
Placesfreefromairdisturbancestothe suction portandblowout holeof the indoorunit, placeswherethe fire alarm
may not malfunction orshort-circuit.
Placeswith the environmentaldew-point temperature islower than 28 and the relative humidityislessthan 80 %.
(When installing at a place under a high humidity environment, paysufficient attention to the prevention of dewingsuch
as thermalinsulation of the unit. )
Ceiling height shallhave the following height.
50mm
Obstacle
Installationspace
C
Combination
withsilent panel 366mm
a.
b.
c.
d.
e.
a.
b.
c.
IndoorUnit
100mm 100mm
Pipe size
AD71S2SM7FA
AD100S2SM7FA
AD125S2SM7FA
AD140S2SM7FA
InstallationProcedure
Model Liquid side Gas side
9.52mm 15.88mm
AD71S2SM7FA
AD100S2SM7FA AD125S2SM7FA
AD140S2SM7FA 9.52mm 19.05mm

2.Installation o indoor unit
Fix the indoor unit to the hanger bolts.
I required, it is possible to suspend the unit to the beam, etc. Directly
by use o the bolts without using the hanger bolts.
When the dimensions o main unit and ceiling holes does not match,
it can be adjusted with the slot holes o hanging bracket.
Note
Adjusting to the levelness
(a) Adjust the out-o levelness using a level or by the ollowing method.
Make adjustment so that the relation between the lower sur ace
o the unit proper and water level in the hose becomes as given
below.
(b) Unless the adjustment to the levelness is made properly,
mal unctioning or ailure o the loat switch may occur.
PVC hose
Piping side
Supply water
Water level
0~5 mm
(0~0.2")
Bring the piping side slightly lower.
Hanging bolt
M10 nut
Main unit
M10 washer
M10 spring washer
1. Preparation or suspending the unit
a.Size o hole at ceiling and position o hanging bolts
<Combination with silent panel>
b.Hanger bolts installation
Use care o the piping direction when the unit is installed.
Hanging bolt M10
Hole-in anchor
Hole-in plug Insert
Concrete
Indoor Unit
150 A
B
C
Hanging bolt position
Ceiling hole size
Panel dimensions
300
30
30
Ceiling ~ panel
wrap dimensions
Ceiling ~ panel wrap dimensions
Hanging bolt position
Ceiling hole size
Panel dimensions
75
D E F
70
Pipe connection side
Installation Procedure
17
Dimensions A(mm) B(mm)C(mm)
Model D(mm) E(mm) F(mm)
1162 1612 1672 620 765 825
AD71S2SM7FA
1562 2012 2072 620 765 825
AD71S2SM7FA
AD100S2SM7FA
AD125S2SM7FA
AD140S2SM7FA
AD100S2SM7FA
AD125S2SM7FA
AD140S2SM7FA

Drain Piping
Drain piping should always be in a downhill grade (1/50~1/100) and avoid riding across an elevation or making traps.
Drain hose
Stage
di erence
part
Drain socket
Drain socket
Main unit
VP( ield purchased)
Pipe cover(large)
[ or insulation]
(accessory)
VP( ield purchased)
Pipe cover
[ or insulation]
( ield purchased)
Drain hose
(accessory)
Pipe cover(small)
[ or insulation]
(accessory)
Clamp
(accessory) Adhesion
Do not pipe under water
Keep ree rom traps
Avoid riding across an elevation
Air vent
Improper pipingGood piping
1.5m ~ 2m
Suspension
bolts
Heat
insulation
A downhill grade
o 1/100 or more
(b)
(c)
VP-30
Secure the elevation as high as possible
(approx. 100 mm)
A downhill grade o
1/100 or more
Right overhead
Drain hose
Joint or VP
(Local procurement)
700
(Maximum local drain up dimension)
290~325mm
(d)
(e)
( )
(h)
(a)
Drain Pipe
For unit without water pump
When connecting the drain pipe to unit, pay suffcient attention
not to apply excess force to the piping on the unit side. Also, fix
the piping at a point as close as possible to the unit.
For unit without water pump,please refer to the digram and select
drain pipe size according to drain opening inner diameter size.
The drain pipe shall be slant downwards (greater than 1/100).
The horizontal length of the drain pipe shall be less than 20 m
.In case of long pipe, supports shall be provided every 1.5~2m
to prevent wavy form.Central piping shall be laid out-
according to the right figure. Take care not to apply external force
onto the drain pipe connection part.
For unit with water pump drain pipeuse hard PVC general purpose
pipe VP which can be purchased locally. When connecting, insert a
PVC pipe end securely into the drain socket before tightening
-securely using the attached drain hose and clamp. Adhesive
must not be used for connection of the drain socket and
drain hose(accessory).
When constructing drain piping for several units, position the
common pipe about 1 00 mm below the drain outlet of each unit
as shown in the sketch. Use VP-30(11/4") or thicker pipe for this
purpose.
The hard PVC pipe put indoor side should be heat insulated. Do
not ever provide an air vent.
The height of the drain head can be elevated up to a point 700
mm above the ceiling, and when an obstacle exists in the ceiling
space, elevate the piping to avoid the obstacle using an elbow
or corresponding gadget. When doing this, if the stretch for the
needed height is higher than 700 mm, the back-flow quantity of
drain at the event of interruption of the operation gets too much
and it may cause overflow at the drain pan. Therefore, make the
height of the drain pipe within the distance given in the sketch
below.
Avoid positioning the drain piping outlet at a place where generation
of odor may be stimulated. Do not lead the drain piping direct into a
sewer from where sulfur gas may generate.
(g)
For unit with water pump
Installation Procedure
18
1.5m~2m Support
Insulation (supplied by the user)
Down slope above 1/100
25mm
AD71S2SM7FA
AD100S2SM7FA
AD125S2SM7FA AD140S2SM7FA
Unit model The size of drain opening
