Haier Z360 User manual

Haier Z360
User Manual

Table of contents
Safety and use.........................................................................................................................................4
General information................................................................................................................................7
Protection against theft....................................................................................................................7
Your mobile..............................................................................................................................7
1.1 keys.......................................................................................................................7
1.2 Main screen icons (1).............................................................................................8
Getting started.........................................................................................................................................9
2.1 Set-up................................................................................................................................9
2.2 Switching your telephone ON.................................................................................................11
2.3 Switching your telephone OFF ...............................................................................................11
Calls.......................................................................................................................................... 11
3.1 Making a call................................................................................................................... 11
3.2 Calling your voicemail (1)........................................................................................................12
3.3 Receiving a call.......................................................................................................................13
3.5 Conference calls (1)...............................................................................................14
Call memory..........................................................................................................................................14
Menu.....................................................................................................................................................15
5.1 Accessing the menu.............................................................................................15
5.2 Organisation of functions................................................................................15
Directory...............................................................................................................................................18
6.1 Consulting your directory (2) ...................................................................................................18
6.1.1 Searching for a name by its first letter .................................................................................19
6.1.2 Read a contact file................................................................................................................19
6.1.3 Making the call.....................................................................................................................19
6.2 Creating a file..........................................................................................................................19
6.2.1 SIM Directory......................................................................................................................19
6.2.2 Phone directory (Z300 only)................................................................................................19
6.3 Available options in the SIM directory ...................................................................................20
6.4 Available options in the phone directory (Z300 only)..........................................................20
6.5 My phone number.................................................................................................21
Messages...............................................................................................................................................21
7.1 Create an SMS ........................................................................................................................21
7.3 Outbox...........................................................................................................................22
7.4 Canned messages..................................................................................................22
7.5 Archives (Z300 only).........................................................................................23
7.6 Parameters..................................................................................................................23
7.7 SMS CB (Cell Broadcast)..............................................................................23
Customise..............................................................................................................................................23
8.1 Ring tones...................................................................................................................24
8.3 Graphical environment (Z300 only).......................................................24

8.4 Settings..........................................................................................................................24
8.6 Keys setup Keys.....................................................................................................25
8.7 Security.........................................................................................................................25
Tool.......................................................................................................................................................26
9.1 Calculator....................................................................................................................26
9.2 Alarm..............................................................................................................................27
9.3 Diary (Z300 only).................................................................................................27
9.4 Converter (1)...............................................................................................................28
Call services............................................................................................................28
10.1 Voicemail..................................................................................................................28
10.2 Call memory...........................................................................................................29
10.5 Call forward............................................................................................................30
10.6 Call barring.............................................................................................................31
Album (Z300 only) ...............................................................................................................................31
11.1 Images album........................................................................................................31
11.2 Melodies album...................................................................................................32
11.3 Available memory..............................................................................................32
WAP (Z300 only)..................................................................................................................................32
12.1 Accessing WAP services (1).........................................................................32
12.3 My bookmarks.....................................................................................................33
Games ...................................................................................................................................................34
13.1 Snake............................................................................................................................34
13.2 Bricks...........................................................................................................................34
Telephone warranty...............................................................................................................................36
Accessories (1) .......................................................................................................................................38
Troubleshooting ....................................................................................................................................38

Safety and use
We recommend that you read this chapter carefully before using your phone. The manufacturer
disclaims any liability for damage, which may result as a consequence of improper use or use
contrary to the instructions contained in this manual.
TRAFFIC SAFETY
Given recent studies, which show that using a mobile phone while driving a vehicle
constitutes a real risk, even when the hands-free kit is used (headset...), drivers are
requested to refrain from using their mobile when the vehicle is not parked
When switched on, your phone emits electromagnetic waves that can interfere with the
vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure that
there is no problem:
-Do not place your phone on top of the dashboard or within an airbag deployment area.
-Check with your dealer or car manufacturer to make sure that the car electronics is
well insulated.
CONDITIONS OF USE
- Always treat the phone with care and in a clean and dust-free place.
- Switch off the phone before boarding an aircraft to avoid prosecution.
- Switch off the phone when you are in health care facilities, except in designated
areas.
- As with other types of equipment now in regular use, mobile phones can interfere
with the operation of other electric, electronic or radio frequency devices in their
vicinity.
- When the telephone is on, it should not be placed in a part of the clothing close to a
medical device (i.e. cardiac pacemaker, hearing aid, insulin pump, etc.).
- Switch the phone off when you are near gas or flammable liquids. Strictly obey the
rules relating to the use of mobile phones at fuel depots, petrol stations, chemical
plants or in any potentially explosive atmosphere.
- Do not allow children to use your mobile phone without supervision.
- Do not open or attempt to repair your mobile phone yourself. Only use your
telephone with Haier batteries, chargers and accessories compatible with your model
(see page 70). The manufacturer disclaims any liability for damage caused by the use
of other chargers or batteries.
- Do not allow your phone to be exposed to adverse weather or environmental
conditions (dampness, rain, infiltration, dust, sea air, etc.). The minimum and
maximum temperatures recommended by the manufacturer are between -10°C and
+55°C. Beyond 55°C, the legibility of the display may be impaired, but this is
temporary and not serious.

BATTERY
- Before removing the battery from your phone, please make sure that the phone is
switched off.
- Observe the following precautions for battery use:
 Do not attempt to open the battery (due to the risk of toxic fumes and burns);
 Do not puncture, disassemble or cause a short-circuit;
 Do not burn batteries or dispose of them in household rubbish;
 Do not expose to temperatures in excess of 60°C. Batteries must be disposed of
in accordance with locally applicable environmental regulations;
 Only use the battery for the purpose for which it was designed.
 Never use damaged batteries.
CHARGERS
Mains powered chargers will operate within the temperature range: 0°to 40°.
The chargers designed for your mobile phone meet with the standard for safety of
information technology equipment and office equipment use. They should be used
for this purpose only.
RADIO WAVES
Proof of compliance with international standards (ICNIRP) or with European Directive
1999/5/EC (R&TTE) is required of all mobile phone models before they can be put on
the market. The protection of the health and safety for the user and any other person is
an essential requirement of these standards or this directive.
THIS MOBILE PHONE COMPLIES WITH INTERNATIONAL AND EUROPEAN
REQUIREMENTS REGARDING EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter/receiver. It was deigned and manufactured to
comply with the radiofrequency (RF) exposure thresholds recommended by
international requirements (ICNIRP) (1) and by the Council of the European Union
(Recommendation 1999/519/EC) (2).
These limits are part of a set of requirements and establish authorised radiofrequency
levels for the public. These limits were established by groups of independent experts
on the basis of regular and detailed scientific assessments. They include a significant
safety margin intended to ensure the safety of all, regardless of age or state of health.

The exposure standard for mobile phones is determined by a measurement unit known
as the Specific Absorption Rate or “SAR”. The SAR limit is set by international
requirements or by the Council of the European Union at 2 watts/kilogram (W/kg)
averaged over ten grams of body tissue. The tests used to determine SAR levels were
carried out on the basis of standard usage modes with the phones transmitting at their
maximum power level over the entire range of frequency bands.
Although the SAR was established at the highest certified level, the actual SAR level
for the phone during use is generally much lower than the maximum values. In fact,
since mobiles are designed to operate at many different power levels, they only use the
minimum level of power required to provide a connection to the network. In theory,
the closer you are to a base station antenna, the lower the power level required by the
mobile phone.
The highest tested SAR value for this mobile phone for use at the ear and compliance
against the standard is XXX W/kg. While there may be differences between the SAR
levels on various phones and at various positions, they all meet the relevant
international guidelines and EU requirements for RF exposure.
The World Health Organisation considers that “present scientific information” does
not indicate the need for any special precautions for use of mobile phones. If
individuals are concerned, they might choose to limit their own or their children’s RF
exposure by limiting the length of calls, or using “hands-free” devices to keep mobile
phones away from the head and body.” (fact sheet n°193). Additional information
about electromagnetic fields and public health are available on the following site:
http://www.who.int/peh-emf
(1) The ICNIRP requirements are applicable in the following regions: Central America (except
Mexico), South and North Africa, Pacific Asia (except Taiwan, Korea and Australia).
(2) The European recommendation (1999/519/EC) is applicable in the following regions: Europe,
Eastern Europe, Israel.

General information
Website: www.haier.com
Haier Hot Line Number: see the “Haier Services” leaflet
Your telephone operates on GSM networks within bandwidths of
900/1800MHz or 850/1900MHz.
The mark certifies that your telephone complies with 1999/5/EC (R&TTE) directive
and that the applicable accessories comply with current EC directives.
Protection against theft
Your mobile phone has an identification number called IMEI (phone serial number) shown on the
packaging label and in the product’s memory. We recommend that you note this number the first time
you use your telephone by entering *, #, 0, 6, # and keep it safely. It may be requested by the police or
your operator if your telephone is stolen. This number allows your mobile telephone to be blocked,
preventing a third person from using it, even with a different SIM card.
Your mobile
1.1 keys

Switch on the phone (short keypress) from the main screen
Switch off the phone (long keypress) from the main screen
Hang up
Reject an incoming call
Return to the main screen (long keypress)/one step in the menu
Call / Pick up
Access the call memory (short keypress)
Navigation key:
Scroll to select an option
: Previous item/Access to Messages (from the main screen)
: Next item/Access to Directory (from the main screen)Main screen
, , , Move
, Adjust the volume during a call
Access the menu
Menu / Confirm
Display a message received
Delete a character (short keypress) keypress)
Delete all characters (long keypress)
Return to the previous screen (short keypress)
Mute the ringtone of an incoming call
Consult your voicemail (long keypress)
Activate/Deactivate the vibrator (long keypress)
Upper case/Lower case/Automatic capitals in toggle mode
Automatic keypad lock/unlock (long keypress)
Predictive mode/Normal mode/Digits in toggle mode
Access the symbols in toggle mode
1.2 Main screen icons (1)

Battery charge level.
Vibrator mode: your phone vibrates but neither rings nor beeps except for
the alarms (see page ).
Silence mode: your phone neither rings, beeps nor vibrates except for the alarms.
Unread message.
Message list is full: your terminal cannot accept any new messages. You must
access the message list and delete at least one message on your SIM card (see page).
Voicemail message arrived
Unanswered call
WAP alert (Z300 only).
Call forwarding activated: your calls are forwarded (see page).
Timer or alarm clock programmed (see page ).
Signal strength indicator.
Preferred tariff areas
(2).
Keypad lock.
Roaming out of your country of subscription.
(1) The icons and illustrations in this guide are provided for informational purposes only.
(2) Contact your network operator to check service availability.
Getting started
2.1 Set-up
Inserting the SIM Card (1)
You must insert your SIM card in order to use your phone. To insert your
SIM card, turn off your phone with a long keypress on the key.
Before inserting the SIM card into the slot, push the SIM card catch to release it as shown
in the fig above. Lift the catch and place the SIM card into the slot with care.

Make sure the cardnotch is on the upper left hand side.
Press and hold down the catch and push it until it is locked.
(1) Check with your network operator to make sure that your SIM card is 3V
compatible. The old 5 Volts cards can no longer be used. Please contact your operator.
Inserting the battery
Align the tab on top of the battery with the slot in the battery compartment of your phone.
Press down the battery until the latch is completely locked.
Charging the battery
Connect the charger
- An animation will be on while charging.
- It may take several minutes before the charging starts.
