Haier LC-133K Technical manual

OPERATION
INSTRUCTION
(Keep it for your reference)
Product appearance depends on goods
Beverage Chiller
LC-133K

1
INSTRUCTION CONTENTS
· Product safety precautions ................................................
· Preparation before use .......................................................
· Use steps for the first time .................................................
Main functions of the product: .............................................
Control Panel ................................................................................................
1.Lock/unlock function ....................................................................................
2.Temperature regulation ...............................................................................
3.Lighting function ..............................................................................................
..
Other function ..............................................................................................
2
4
5
6
7
8
10
Daily maintenance of product ..............................................
If you have any question, please look here ..........................
Technical data packing list ...................................................
6
6
6
1.Beverage Chiller clean .....................................................................................
(If you have any question, please solve follow this section)
7
2.Beverage Chiller moving ................................................................................ 7
3.Beverage Chiller disuse ................................................................................... 7
6
6
6
4.Temperature power o memory function ..............................................
6
6
6
5.Open door timeout alarm function ...........................................................
6.Sterilization function ......................................................................................
7.Fruit box moisture function ..........................................................................

2
If operating mistake, may cause accidental
physical harm
If operating mistake, may damage goods and
property loss.
Notice
Warning
Distinguished Haier user:
Operating must be prohibited.
Operating must be observed.
About electrical
Power
Earthing
Power and plug
Gas and other flammable gases leak out
PRODUCT SAFETY PRECAUTIONS
Thank you for using haier product. In order to read the operating instruction and use the product
better, prevent personal injury and damage to goods, please read the instruction carefully and
observe the content of following logo.
This product uses 220-240V/50HZ alternating voltage, if large voltage fluctuation
of supply power voltage (over 187-242V range), it may cause wine cellar broken or
even damaged. This moment you have to add automatic voltage regulator which
power is greater than one kilowatt.
Prohibit dismantling the third prong of plug in any case, its acts as the ground.
1.Do not damage the power line. Don’t put the Beverage Chiller on the power line
and don’t step on the power line. When clean the Beverage Chiller please be careful
do not roll the power line.
2.Do not brute force pulling power plug, must hold the plug and then pull the plug.
3.When the power line or plug was damaged, must disuse, and change to the
designated maintenance point.
The gas leakage valve should be closed immediately, and open the door and
windows, don’t pull out Beverage Chiller plug and other household appliances.
1.Use three-hole socket, check the power plug and socket are fastened, or else a
fire or electric shock may occur.
2.After Beverage Chiller is installed, the plug should be put on the place that easy to
touch in order to pull out plug in time when accident occurs.
3.Before clean, maintain, and replace the lighting bulb, must be power off.
4.If the power line has to be lengthened, the wire section surface must greater than
0.75m².

About use
About maintenance
3
Location
Use
Clean
Maintain
Special attention to children
1.Inflammable and explosive items are strictly prohibited in the Beverage Chiller and
corrosive acid-base chemicals are also prohibited.
2.To ensure safety, advise user don’t put socket and other electric device on the
Beverage Chiller also don’t use small appliances inside in Beverage Chiller, in case of
electromag netic interference and other accidents.
3.Don’t put unstable goods on the Beverage Chiller top, to prevent fall down and hurt.
4.Do not place inflammable and explosive articles near the Beverage Chiller, in case of
fire.
This product use for household and similar use appliances, for example:
1.Shop, office, and kitchen area of other working places.
2.Farm, hotel, and motel, residential guest.
3.Family inn environment.
4.Catering industry and similar applications.
1.Avoid the children hanging play on the Beverage Chiller door, in case of door incline
and topple to hurt people.
2.When Beverage Chiller pass into disuse, please take down the door and Send it to
the
1.Don’t use water spray wash Beverage Chiller, also don’t put Beverage Chiller on
the wet place or some places easy to splash, rust protection.
2.When power off or clean, need to pull out plug, interval at least 5 minutes to start
again, avoid frequent startup damage the compressor.
It is strictly prohibited to disassemble or renovate Beverage Chiller, also prohibited to
damage the refrigeration pipeline, Maintenance must be carried out by professionals.
Do not put hand, foot into the cabin, many metal parts in cabin easy to hurt body.

4
1
2
3
6
5
Remove all packaging components.
If need to bolster, choose
a stable, smooth setting
block, be sure to keep in
mind the foam base never
use for setting block.
Note: Product technical data reference each series of models
Clockwise rotation to increase the Beverage Chiller height.
Contrarotate to reduce the Beverage Chiller height.
D
W
d
c
b
a
H
4Beverage Chiller open door size. (Unit: mm)
Cleaning the Beverage Chiller before use.
MODEL abc d
LC-133K 658 1050 1025 500
Above 10cm
Above 10cm
Above 10cm
L
Adjustable
H
PREPARATION BEFORE USE
Including thin lm, box cover, foam base, and xed tape must be removed.
Well-placed, it’s better to clean the Beverage Chiller, use soft close to wipe the
Beverage Chiller.
On standing
After installed and cleaned, please don’t power on right away, on standing at
least 30 minutes, and then power on, to ensure normal operation.
Check the attachments and datum.
Check the contents according to the packing list.
Put the Beverage Chiller on the suitable position.
Don’t put on to cold environment.(less than 10°C)
Don’t put in the rain or outside the room.
Don’t put Beverage Chiller on the wet place or some places easy to splash, if wet
use close to wipe, rust protection, inuence on insulation performance.
Put Beverage Chiller keep away from the heat source, don’t direct sunlight, to
avoid aecting performance.
If put the Beverage Chiller on the carpet, wood oor, the heat may distain the
oor, so must mat interlayer.
Around the Beverage Chiller need to empty 10cm space to rejection of heat.
Put Beverage Chiller on the at oor, if uneven oor Beverage Chiller running
produces vibration and noise, cause failure. We can adjust the sole of the
Beverage Chiller according to the oor atness, decrease the vibration and noise.
Attention

5
POWER ON
Power on, look at
screen, if there is
display, the power
is ok, Beverage Chiller
working.If there is no
display please check
the plug and power
line.
1 2 3
Beverage Chiller constituent part
LED lamp
Tabletop
Display
(on front of the door)
Glass door
Steel wire wine shelf
Glass shelf
Glass shelf
Glass shelf
Fruit box
Sterilization
indicator light
USE STEPS FOR THE FIRST TIME
PILOT RUN
When power on,
don’t put goods
immediately, after
30 minutes running
open the glass door,
if there’s a cooling
eect, the Beverage
Chiller proper
functioning.
WAITING FOR
COOLING
Before sucient
cooling, try to keep
door closed, run
empty for an house,
sucient cooling,
put beverage,
normal use.

6
MAIN FUNCTIONS OF THE PRODUCT
Power off memory, open door timeout alarm, sterilization, moisturize…
1. Lock/unlock function
2. Temperature regulation
3. Lighting function
Beverage Chiller temperature can be set between 2°C-18°C.
In order to protect the setting temperature and working condition, this product is designed with
panel automatic lock function specially. Stop buttons operation 30 seconds, the panel locks,
and only lighting button can be operated, others can’t be operated. In the locking situation,
press
1.Press【lock/unlock】button keep 3 seconds, the temperature display starts flickering,
system enters to temperature setting, the temperature inside Beverage Chiller can be changed
by temperature regulation, to press button at a time to adjust one degree centigrade.
2.No operating more than 10 seconds, the temperature confirms automatically and stops
flashing . Temperature defaults the current setting.
When the Beverage Chiller door is opened, the lamp inside lights up automatically. When the
door is closed, we can also switch on/off the lamp by 【lighting】button.
4. Temperature power off memory function
5. Open door timeout alarm function
6. Sterilization function
7. Fruit box moisturize function
Under the situation of power off, the temperature is remembered. When repower on, Beverage
Chiller works on the basic of previously set temperature.
When the door is opened more than 1 minute, the display alarm will sound “du du …” to warn.
In order to extension Beverage Chiller food preservation time, there is sterilization module behind
the fan windshield, computer controlled to insure fresh air inside the Beverage Chiller. When
sterilization working the blue light belt on the windshield bright.
On the top of the Beverage Chiller fruit box, designed airtightness moisture box lid, which with
moisture permeable membrane and carry intelligent temperature sensor. This module can keep
the garden stuff in optimum environment, extended storage time, avoid extravagance.
Notice: All the other functions have no memory except temperature .
Lock/
unlock
T
Down
T
Display
T
Up Lighting
Control Panel

Beverage Chiller clean
Beverage Chiller moving
Beverage Chiller disuse
7
Before moving
During moving
Less than 45°
Cleaning steps:
DAILY MAINTENANCE OF PRODUCT
1.Pull power plug, power off.
2.Take out the food.
3.Dip a soft towel in hot water to wipe Beverage Chiller.
4.After using detergent, please clean with water immediately.
5.Cleaning the dirt of Beverage Chiller both side and backboard.
6.Cleaning outfall, there is one hole pin in the information kits, the
first time use this product, put the hole pin in the outfall, take out hole pin when blocking, than replace.
Note: The hole pin can’t use for cleaning tool, only can put on the outfall to prevent clogging.
7.Finish cleaning Beverage Chiller.
Notice: The Door sealing strip is easy dirty, please always pay attention to keep it clean, cleaning door
dealing strip can insure good sealing effect.
1.To prevent electric shock, must pull plug power off before cleaning Beverage Chiller.
2.It’s forbidden to spray Beverage Chiller back cabin.
To prevent damage Beverage Chiller, never use follow material to clean Beverage
Chiller:
1.Organic and acid-base solvent
2.Abrasive powder washing products
3.Stiff brush
1.Please take out all the food, and pour out the water or ice of the ice-making box.
2.Use packaging tape to fix Beverage Chiller door, shelves, fruit box and so on,to avoid damage during.
If Beverage Chiller is going to disuse long time, please pull out plug power off, and take out all the food,
pour out the water and ice in the ice-making box, and clean the Beverage Chiller. Open the Beverage
Chiller door during the disuse time, to avoid odor.
In no instance can upend Beverage Chiller, and during moving the inclination should not
exceed 45°.
Normally, don’t disuse the wine cellar, avoid affect service time.
When pull out the plug or power off, must be at least 5 minutes apart to repower the
Beverage Chiller.
It’s available to use back caster to move and adjust short distance, long distance is forbidden.
Warning
Notice
Notice
Notice
Water outlet

Q1: Something special show in
the display panel?
Q2:Whether Beverage Chiller works?
Feature
Reason
Solution
Temperature display “L “
Beverage Chiller ambient temperature
too low, result Beverage Chiller inside
temperature too low.
Improve the environment temperature
or put the Beverage Chiller on the
preference temperature.
Q3: Beverage Chiller compressor
working hours?
Feature
Reason
Solution
Compressor working time too long.
1.Long-time use for the first time.
2.High environment temperature or
poor ventilation.
3.Opening door frequently or the
door doesn’t close well.
4.Direct sunshine or near the heat
source.
5.Temperature setting too low.
Put the Beverage Chiller on the
preference environment temperature,
setting preference temperature, close
door well, the problems will be solved.
Q4: Normal temperature inside
Beverage Chiller?
Feature
Reason
Solution
Beverage Chiller inside temperature is
not low enough.
1.Setting temperature too high.
2.Opening door frequently.
3.Direct sunshine or near heat source.
Lower the setting temperature,
close door well, put on preference
place.
Q5: Beverage Chiller glass door
condensation?
Feature
Reason
Solution
Glass door with condensation.
1.The door is opened frequently, or
the door is opened for long time.
2.Setting the temperature too low or
the environment temperature too
high.
Close the door well, raise the setting
temperature, system auto solves.
Feature
Reason
Solution
Light isn’t working inside Beverage Chiller.
1.It is power off.
2.lamp bulb was broken.
Check the LED lamp, plug, fuse
whether damaged.
Feature
Reason
Solution
Beverage Chiller doesn’t working.
1.It is power off.
2.Power supply voltage is too low.
3.Environment temperature below
setting temperature.
1.check plug, fuse whether damaged.
2.Ask the electric maintenance staff
to check.
3.Setting preference temperature.
8
IF YOU HAVE ANY QUESTION, PLEASE LOOK HERE

9
Q6: Beverage Chiller inside is odorous?
Feature
Reason
Solution
Glass door with condensation.
New Beverage Chiller has plastic smell.
Automatically volatile after use a
little time.
Q8: Some sounds of working
normally.
Feature
Reason
Solution
Buzzing when it's working.
The sound of compressor working.
Normal phenomenon.
Feature
Reason
Solution
Clicking when switch on and off.
The sound of compressor and relay
start working.
Normal phenomenon.
Feature
Reason
Solution
Poop when working.
Temperature changes cause
evaporator swell-shrink.
Normal phenomenon.
Feature
Reason
Solution
Bicker when working.
Liquid refrigerant flow.
Normal phenomenon.
Feature
Reason
Solution
Noisy when working.
1.Uneven ground.
2.Beverage Chiller touches with wall or
other objects.
3.The packagings were not removed
completely.
1.Move Beverage Chiller to flat ground.
2.Move objects or not touch with wall.
3.Remove all the packagings.
Q7: Beverage Chiller both side box
temperature?
Feature
Reason
Solution
Both side box temperature is high.
Rejection of heat when wine cellar
working.
Normal phenomenon.

10
Technical data
Packing list
LC-133K
Name
Instruction Information
kits
Glass
shelf Wine shelf
Pcs
Model
1 31 1
LC-133K
Name
Moisturizing
lid
Hole pin
Pcs
Model
1 1
Fruit box
1
Model Climate
type
Supply cord
connection mode
Temp
range
Input
power
Rated voltage
Rated frequency
Available
capacity
LC-133K ST Y 137(L) 2~18(°C) 100(W)
0.60
(Kw*h/24h)
52kg 575*520*1100(mm)
220~240(V)
50(Hz)
Power
consumption
Overall dimension
D*W*H
Weight
R600a
Refrigerant

Verison:V1 Date:201809
0070511142A
专用号条码
