Haier HL19KN1 User manual

LCD TV
USER MANUAL
Please read this manual carefully
before using this TV set and leep it
for future reference.
HL19KN1/HL22KN1

IMPORTANT SAFETY INSTRUCTIONS

HDMI

Connect video inputfrom an externaldevice to thisjack.
Connect audio inputfrom an externaldevice to thesejacks.

SCAN
MENU
VOL-
EXIT
P.MODE ARC
CCD MTS/SAP
PIP SWAP MOVE
1 2 3
4 5 6
7 8 9
CH+
CH-
VOL+
OK
SLEEP
H.LOCK
0
HDMI
S.MODE
FREEZE
FAVORITE
MUTE
RECALL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
1.Power
2.SCAN
3.Not available
4. Input selection
5.MENU
6.Volume/Channel Selection
7.Exit On Screen Display
8.Adjust Picture Mode
9.Select the aspect ratio
10.Close caption
11.Select Mono/SAP/Stereo
12.Not available
13.Not available
14.HDMI mode
15.Program Number
16.Program Information
17.Mute
18.Confirm button
19.Return to previous channel in TV mode
20.Adjust sound mode
21.Sleep button
22.Not available
23.Hotel Lock
24.Not available
25.Not available
INPUT DISPLAY

SCAN
MENU
VOL-
EXIT
P.MODE ARC
CCD MTS/SAP
PIP SWAP MOVE
1 2 3
4 5 6
7 8 9
CH+
CH-
VOL+
OK
SLEEP
H.LOCK
0
HDMI
S.MODE
FREEZE
FAVORITE
MUTE
RECALL
INPUT DISPLAY

Press H.LOCK to enter itand input thepassword correctly, the H.LOCK menu
will appear onthe screen(The initialpassword is 0000).
Change password: The password can bechanged. Press CH+/-to select
Change password andVOL+/OK to enter. The screen willdisplay New PW:----,
then enter thenew password andthe screen displayConfirm PW:----, if the same
password is input correctly twice, the old password will be changed.
Tuner Lock: The tuner can belocked. Press CH+/-to select.
Preset Source: Preset the source.
Preset CH.: Preset the channel.
Source Lock: The source can belocked. Press CH+/-to select.
Child Lock: Press CH+/- to select it .Press VOL+/- to set on or off mode. If lock
on mode is set, child lock is inactivated automatically. In such case, buttons
on the television is useless and only buttons on remote control can be used,
if buttons onthe television arepressed, the screenwill display ChildLock.
The child lock mode can be resumed by entering lock set menu, set child lock on.
Unlocked: Press to turn to the unlocked mode.

Not available inPC
Not available
In this manual,the OSD (OnScreen Display) maybe different from your TV s
because it is just an example to illustrate the TV operation.
Press INPUT to select theinput source, and the menu for each source is different.
1. Press MENU button to display the main menu, and VOL+/-to select the main
menu.
2. Press CH+/-to scroll throughthe parameters.
3. Press VOL+/- buttons tomake changes tothe parameters.
4. Press EXIT button to exit the menu.
Note: Symbols on top of the menu in this manual may be different from the actual
set.

Reset : Reset all settings to factory mode.

Reset : Reset all settings to factory mode.

Menu Language Selection:
The menus canbe shown onthe screen inthe selected language.First select
your language.
1. Press MENU button and VOL+/- until the following menu appears on the screen.
2. Press CH+/-button to enterthe function menuand to goup and downto select
the desired option .
3. Press VOL+/- button toadjust the selectedoption to yourpreference .
Functions:
Language: This item displays the language of the OSD.
Pic. Size: To select thedisplay mode :4:3/Full/Zoom.
Menu Time: To select 5S/10S/15S.
Halftone: To select themenu transparency.
Blue screen :Press VOL+/- to select On or Off. To set On, screen will be in blue
screen after 3 seconds if there is no signal.

DNR: Digital NoiseReduction. Reduces theappearance of digitizingerrors
caused by compression.Press VOL+/- toselect On orOff.
