Haier HL22K3 User manual

HL22K3

HDMI

Connect video inputfrom an externaldevice to thisjack.
Connect audio inputfrom an externaldevice to thesejacks.

SCAN
MENU
VOL-
EXIT
P.MODE ARC
CCD MTS/SAP
PIP SWAP MOVE
1 2 3
4 5 6
7 8 9
CH+
CH-
VOL+
OK
SLEEP
H.LOCK
0
HDMI
S.MODE
FREEZE
FAVORITE
MUTE
RECALL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
1.Power
2.SCAN
3.Not available
4. Input selection
5.MENU
6.Volume/Channel Selection
7.Exit On Screen Display
8.Adjust Picture Mode
9.Select the aspect ratio
10.CC ( closed caption)
11.Select MONO, STEREO, SAP in NTSC system
12.Not available
13.Shows program schedule in TV
14.HDMI mode
15.Program Number
16.Program Information
17.Mute
18.Confirm button
19.Return to previous channel in TV mode
20.Adjust sound mode
21.Sleep button
22.Not available
23.Hotel Lock
24.Open the favorite channel list in TV
25.Not available
INPUT DISPLAY

SCAN
MENU
VOL-
EXIT
P.MODE ARC
CCD MTS/SAP
PIP SWAP MOVE
1 2 3
4 5 6
7 8 9
CH+
CH-
VOL+
OK
SLEEP
H.LOCK
0
HDMI
S.MODE
FREEZE
FAVORITE
MUTE
RECALL
INPUT DISPLAY

Press H.LOCK to enter itand input thepassword correctly, the H.LOCK menu
will appear onthe screen(The initialpassword is 0000).
Change password: The password can bechanged. Press CH+/-to select
Change password andVOL+/OK to enter. The screen will display New PW:----,
then enter thenew password andthe screen displayConfirm PW:----, if the same
password is input correctly twice, the old password will be changed.
Tuner Lock: The tuner can belocked. Press CH+/-to select.
Preset Source: Preset the source.
Preset CH.: Preset the channel.
Source Lock: The source can belocked. Press CH+/-to select.
Child Lock: Press CH+/- to select it .Press VOL+/- to set on or off mode. If lock
on mode is set, child lock is inactivated automatically. In such case, buttons
on the television is useless and only buttons on remote control can be used,
if buttons onthe television arepressed, the screenwill display ChildLock.
The child lock mode can be resumed by entering lock set menu, set child lock on.
Unlocked: Press to turn to the unlocked mode.

Not available inPC
Not available
PICTURE MODE STANDARD
CONTRAST
BRIGHTNESS
HUE
CHROMA
SHARPNESS
PICTURE MODE STANDARD
CONTRAST
BRIGHTNESS
HUE
CHROMA
SHARPNESS
Only available inNTSC system
In this manual,the OSD (OnScreen Display) maybe different from your TV s
because it is just an example to illustrate the TV operation.
Press INPUT to select theinput source, and the menu for each source is different.
1. Press MENU button to display the main menu, and VOL+/-to select the main
menu.
2. Press CH+/-to scroll throughthe parameters.
3. Press VOL+/- buttons tomake changes tothe parameters.
4. Press EXIT button to exit the menu.
Picture Menu Options
Picture quality can be adjusted for any input separately.
The picture qualityon the screencan be adjustedas follows:
1. Press MENU button and VOL+/- until the following menu appears on the
screen.
Note: Symbols on top of the menu in this manual may be different from the actual
set.

Picture Menu Options continued
2. Press CH+/-button to enterthe picture menuand to goup and downto
select the desired option.
3.Press VOL+/- button to increase and decrease the level to adjust the
selected option to your preference.
4. Repeat step 2 and step 3 until desired picture quality has been achieved.
Function:
Picture Mode: Press VOL+/- to select: Standard Soft Bright User.
Contrast : Adjust the contrast of the picture . The contrast becomes higher as
the number increase.
Brightness :Adjust the brightness of the picture. By increasing the level, it will
add more light to dark parts of the picture and by decreasing the level ,it will add
more dark to light parts of the picture.
TUE: Adjust the picture tone.
Chroma : Press VOL+/- to adjust the color.
Sharpness : Adjustthe amount ofthe detail enhancement, the image sharpness
rises as the number increases (By increasing the level, it will show cleaner and
clearer images andby decreasing the level, it will make picture smoother).
Color Temp. : Press to select the color temperature from Standard/Warm/Cool.
Reset: Reset all settings to factory mode.

Sound Menu Options
Sound can beadjusted for anyinput as follows:
1. Press MENU and VOL+/- button until the following menu appears on
the screen.
You can adjust sound options to the levels you prefer.
2. Press CH+/-button to enterthe audio menuand to goup and downto
select the desired option .
3.Press VOL+/- button to increase and decrease the level to adjust the
selected option toyour preference .
4. Repeat step 2 and step 3 until desired sound quality has been achieved.
Function :
Sound Mode: Press VOL+/- to select: Standard/Theater/Music/User.
Balance : Adjustthe balance ofthe audio outputfrom left toright . When
indication value of balance increases toward +50 , sound of the left speaker
becomes weaker . When indication value of balance decreases toward -50 ,
sound of the right speaker become weaker. Can only be adjust under User mode.
Bass : Adjust the bass of the sound . Can only be adjust under User mode.
Treble: Adjust the treble of the sound . Can only be adjust under User mode.
Surround: To turn thesimulated surround soundon or off.
Reset: Reset all settings to factory mode.
SOUND MODE STANDARD
BALANCE
BASS
TREBLE
SURROUND OFF
RESET
SOUND

LANGUAGE ENGLISH
ASPECT RATIO FULL
MENU TIME 15S
HALFTONE 50
BLUE SCREEN OFF
C. CAPTION OFF
2. Press CH+/-button to enterthe function menuand to goup and downto
select the desired option .
3. Press VOL+/- button toadjust theselected option to your preference .
Functions:
Language: This item displays the language of the OSD.
Pic. Size: To select thedisplay mode :4:3/Full/Zoom.
Menu Time: To select 5S/10S/15S.
Halftone: To select themenu transparency.
Blue screen :Press VOL+/- to select On or Off. To set On, screen willbe in
blue screen after 3 seconds if there is no signal.
DNR: Digital NoiseReduction. Reduces the appearance of digitizing errors
caused by compression.Press VOL+/- toselect On orOff.
Menu Language Selection:
The menus canbe shown onthe screen inthe selected language. First select
your language.
1. Press MENU button and VOL+/- until the following menu appears on the screen.
FUNCTION

1. Press MENU and VOL+/- button until the following menu appears on the
screen.
Note: This menu is only appears in TV mode .
2. Press CH+/-button to enterthe turning menuand to goup and downto select
the desired option .
3.Press VOL+/- button to adjust the selected option to your preference .
Functions:
Auto Search: Autosearch and savethe channel .Pressthe VOL+ button to start
automatic search function operation. All channelsnow available will be
automatically preset in order .After the search has finished, the first program
number will displayon the screen.This search automatically adds onlythe active
channels in yourarea to theTV's memory. It deletes any channels on which there
is no broadcast or a poor signal.
Channel: Show the channel number.
Color System: Press VOL+/- to select Auto,PAL, NTSC, SECAM.
Sound System: Press VOL+/-to select D/K,M, B/G, I.
Manual Search: Manual search and save the channel.
Fine Tune : If the image and/ or sound received is not very good , you can press
CH+/- to select Fine Tune inthe menu . Then , press VOL+/- button to adjust and
improve the image quality. Do not use this feature unless reception is poor.
Skip : If you want skip a channel , press VOL+/- to select On , and this channel
will be skipped next time when you press CH+/- . Youcan press the digit buttons
to select thechannel . Ifyou want torestore the channel, select Off.
Tuner Menu Options
AUTO SEARCH
CHANNEL 2
COLOR SYSTEM AUTO
SOUND SYSTEM D/K
MANUAL SEARCH
FINE TUNE 42.12MHZ
TUNING
