Haier PZ16E101 User manual

Shared screen user manual
Model：PZ16E101
Haier (Beijing) IC Design CO.,Ltd.

* Please read the product manual carefully before using the product
Thank you for purchasing and using the shared screen. For your safety
and interests, please read this product manual carefully before using the
product. The company will not be liable for any personal injury, property
or other loss caused by the failure to operate in accordance with the
product manual or follow the precautions.
* About this product manual
The copyright, trademark and trade name of the manual belong to the
company and its related parties. If the contents of the manual are inconsis-
tent with the actual products, the actual products shall prevail.
* Note
The battery with the wrong model may explode. Please use the battery
correctly according to the precautions. Dispose the used battery prop-
erly and throw it to the designated recycling point.(see page 24 for
battery precautions)
Users can log in http://www.haier-ic.com, select the product introduc-
tion, click the product instruction to enter, and download the electronic
version of the instruction.

Contents
1、Product introduction ..............................................................1
2、Product list ............................................................................1
3、Schematic diagram of sharing screen....................................2
4、Shared screen specifications .................................................3
5、Remote control function ........................................................4
6、Menu structure description....................................................5
7、Function instructions..............................................................5
7.1、Homepage ....................................................................5
7.2、Miracast ........................................................................6
7.3、Airplay ...........................................................................9
7.4、DLNA ......................................................................... 11
7.5、HDMI ......................................................................... 14
7.6、Setting........................................................................ 16
7.7、IPTV ............................................................................ 17
7.8、Youtube ....................................................................... 17
7.9、USB............................................................................ 20
7.10、WIFI Settings ........................................................... 21
7.11、Attached table 1: (refer to the same screen setting of
all brands of mobile phones)..................................... 22
8、Warranty ............................................................................. 23
9、Battery Precautions............................................................. 24

- 1 -
The shared screen is a portable LCD with a screen size of 15.6
inches and a resolution of 1920×1080/1366×768. It has the following
functions:
1. Support the same screen function of Android phone, Apple
phone and tablet computer.
2. Support the video projection function of mobile film app software.
3. Support the function of playing multimedia files (pictures,
music, and video) on USB flash disk.
4. Connect the host computer through the HDMI cable, which can
be displayed on the computer screen.
5. Connect TV set-top box or network set-top box through HDMI
cable, and watch TV programs on TV screen.
1、Product introduction
2、Product list
host×1 remote control×1 instructions×1
Typec charger×1
Please check the product list carefully after opening the package：
7 dry cell×2
Shared screen user manual
Model：PZ16E101
Haier (Beijing) IC Design CO.,Ltd.

3、Schematic diagram of sharing screen
- 2 -

4、Shared screen specifications
Screen size
Screen resolution
Visible area
Display scale
Host thickness
Appearance size
Refresh rate
Storage capacity
WIFI band
Transmission protocol
Input interface
Output interface
Produce accessories
15.6 inches
1920×1080/1366×768
length :345×height:195（mm）
16 : 9
12mm
length:370×height:265（mm）
50/60Hz
1Gb DDR 、 1Gb Flash
2.4G
Miracast、DLNA、Airplay
USB interface×1、HDMI interface×1、
TypeC power supply port×1
3.5mm headphone jack×1
host×1、remote control×1、instructions×1、
Typec charger×1、No.7 dry cell×2
- 3 -

- 4 -
5、Remote control function
Switch
Mute
OK
Navigation key
Back
Menu
Home
Volume + / -
standby switch
turn sound off or on
select OK
move up / down / left / right in menu or option
to previous menu
enter setup menu
to main menu
volume level adjustment
Mute
Navigation key
Switch
OK
Home
Back
Volume -
Menu
Volume +

- 5 -
6、Menu structure description
7、Function instructions
7.1 Homepage
Menu item
Miracast
Airplay
DLNA
HDMI
USB
IPTV
Setting
Youtube
function description
Android phone on screen
Apple phone on screen
mobile film app projection
HDMI signal source
signal source
Low Cost IPTV
Set up WIFI connection
Youtube

7、Function instructions
7.2 Miracast
Function Description:
After the shared screen is powered on, the main menu is
displayed, with eight items in total: Miracast、Airplay、DLNA、
HDMI、 USB、 IPTV、Setting、Youtube.
Operating instructions:
[left / right] key: cycle left / right between menu icons.
[OK] key: enter the next menu interface of the selected item.
Function Description:
In the “Miracast” interface, please follow the instructions on the
interface to synchronously project the mobile screen to the shared
screen for display. It can simultaneously browse photos, file display,
play videos, large game screen display, etc;
* Note: Please select “Airplay” function for Apple mobile phone, see
Section 7.3.
- 6 -
Miracast
Device Name：KeTing_9465

- 7 -
7、Function instructions
Operating instructions:
（1）On the sharing screen: select “Miracast” from the homepage,
enter the “Miracast” interface, and press the [OK] key to start "Miracast ".
（2）On the mobile terminal: turn on the wireless display function
of the mobile phone. According to different brands of mobile phones, in
the mobile phone pull-down menu or the mobile phone "Settings"
interface, open "wireless screen projection", "multi screen interaction",
etc. (Note: the function names of different brands of mobile phones are
different, please refer to attached table 1). When this function is turned
on, the mobile phone will automatically search for available devices and
select the local devices searched, such as "KeTing_9465". After the
connection is successful, the mobile phone screen will be synchronized
to the shared screen.
Device connection
Wireless screen Wireless screen
KeTing_9465

- 8 -
7、Function instructions
（3）Turn off “Miracast”.
On the mobile terminal: in contrast to step (2), disconnect
"wireless projection", "multi-screen interaction" and other connec-
tions in the mobile phone setting interface.
On the shared screen: press the [Back] key to exit the " Miracast "
function.
Example of the “Miracast” (as shown below):

- 9 -
7、Function instructions
7.3 Airplay
Function Description:
The same screen to shared screen display for Apple mobile phone.
Operating instructions:
（1）On the sharing screen: select "Airplay" from the homepage, enter
the “Airplay” interface, and press the [OK] key to start “Airplay”.
Airplay

- 10 -
（2）Connect the Apple phone to the same WIFI as the sharing
screen.
（3）On the mobile terminal: open the control center of Apple
mobile phone, click "screen image" or "airplay image", and click to select
the name of the shared screen device in the device list, such as "
hi2611airplay_9465". After the connection is successful, the mobile
screen can be put on the shared screen for display.
* Note: if WIFI is not connected, press the [up / down] key of the
remote control to select the button, and press the [OK] key to
enter the WIFI setting interface to connect WIFI (see section 7.9).
WIFI
7、Function instructions
hi2611airplay_9465
tv
Screen image

7、Function instructions
7.4 DLNA
Function Description:
Realize the video sharing and playing of mobile film and television
app, that is, the mobile phone sends the link address of the video
source to the sharing screen, which plays independently.
Network is required, and mobile phone and sharing screen are
required to be connected to the same WIFI.
This function is related to the video app installed in the mobile
phone, i.e. Youku, Tencent video, iqiyi, LETV and other video apps all
support this function, and any video with a projection icon in the video
can be projected.
Android phone, Apple phone and tablet are all supported.
Operating instructions:
（1）On the shared screen: select "DLNA" from the homepage,
and press the [OK] key to enter the “DLNA” menu.
DLNA
- 11 -

（2）On the shared screen: if WIFI is not connected, press the [up
/ down] key of the remote control to select the button, and
press the [OK] key to enter the WIFI setting interface to connect WIFI
(see section 7.9). Make sure that the mobile phone and the sharing
screen are connected to the same WIFI.
（3）On the shared screen: press the [OK] key to start the DLNA.
The interface displays: "DLNA has been started, WIFI has been con-
nected": for example, " TP_LINK_3522 "and wait for the user to connect"
hi2611dlna_9465 ".
- 12 -
7、Function instructions
DLNA
DLNA has been started, WIFI has been connected: "TP_LINK_3522 "
wait for the user to connect" hi2611dlna_9465 "
WIFI

（5）Exit DLNA
On the shared screen: press the [Back] key to exit DLNA function
of the mobile phone.
Example of DLNA effect (as shown below)
7、Function instructions
（4）On the mobile side:open the video app interfaces of Youku,
Tencent video, iqiyi, etc and select a video to play; then click the
screen icon on the mobile phone playing interface, and the mobile
phone prompts to find the sharing screen: such as "hi2611dlna_9465"
and connect; after the connection is successful, the video will be played
on the sharing screen.
TV
选择想要投屏的设备
hi2611dlna_9465
- 13 -

Function Description:
The shared screen uses HDMI cable to connect the computer and
TV set-top box, which can be displayed as a computer screen or TV
screen.
Operating instructions:
（1）Connect the HDMI cable to the HDMI connector of the
shared screen and the computer or TV set-top box.
7、Function instructions
7.5 HDMI
HDMI cable
- 14 -
Connect HDMI cable
to set top box
or

（2）Enter the HDMI menu item in the homepage of the shared
screen to switch to the HDMI video source.
（3）Press the [Back] key: exit the HDMI and return to the homepage.
（4）Video parameter setting: press the remote control [menu]
key to enter the parameter setting interface of the shared screen (as
shown below).
（5）Press the [up / down] key: move the cursor up and down.
（6）Press the [OK] key to enter the next level menu.
7、Function instructions
- 15 -

7.6 Setting
- 16 -
7、Function instructions
（7）Press the [left / right] key: move the cursor to the left / right
to adjust the parameters.
Function Description:
It can be set for network, function, image, sound, timing on / off,
about local machine, remote control learning, binding with family, etc.
（1）Press the [up / down / left / right] key: move the cursor to
select the option.
（2）Press the [OK] key to enter the next menu for setting.

- 17 -
7、Function instructions
7.7 IPTV
Function Description:
After network connection, live network video programs can be
watched.
IPTV program list (Over 1000 shows in 42 countries):
·Kurd
·Brazil Esportes/Noticias
·Brazil Publico
·Brazil Fimes/Series
·Brazil Infantis
·Brazil Others
·Brazil HD
·Brazil 4K
·Portugal
·Latin America Laz
·Spain
·Peru
·UnitedKingdom
·France
·Spain
·German
·Italya
·Turkish Fta
·Turkish
·Pakistan
·India Tamil
·India Sony
·India Star
·India Zee
·India Karnataka
·India Others
·Test
·China
·AR BeIN Sports SD Low
·AR BeIN Sports SD
·AR BeIN Sports HD
·AR BeIN Sports 4K
·AR Bein Sports
·Morocco
·Arabic Al
·Arabic MBC
·Arabic OSN
·Arabic Others
·Algerian
·Libyas
·Africa
·Dstv
