Haier HT SERIES User manual

Frost-Free Top Mount
Refrigerator/Freezer
Réfrigérateur/congélateur sans
givre à compar superposés
Refrigerador/congelador sin
escarcha, de puertas horizontales
User Manual
Guide de
Manual del Usuario
Model HT SERIES
Design may vary by model number.
El diseño puede variar conforme al número de modelo.
P/N 0060517094 Rev A 05/13

HSILGNE
TABLE OF CONTENTS
PRODUCT REGISTRATION
Thank you for purchasing your Haier product.
best use of your product.
Remember to record the model and serial numbers.
They are on a label inside of the product.
Model number
Serial number
Date of purchase
Staple your receipt to your manual. You will need it
to obtain warranty service.
SAFETY INFORMATION
Important Safety 4
SET UP & USE
Electrical Requirements 5
Guide 5-6
for Unpacking 5
Parts Included
6
Accessories
7
Door Handle 8
Reversing the Doors
7
Features and Use
CLEANING & CARE
Proper Care and Maintenance
10-11
TROUBESHOOTING & WARRANTY
Normal Oper Sounds 11
Troubleshoo
12-13
Customer Service 13
Limited Warranty 14
8
9

NOTE: If the ref
before plugging it in.
1) Use this appliance only for its intended purpose as described in this use and care manual.
rotaregirfersihT)2 must be properly installed in accordance with the installa on in
used. See Electrical Re
T)3 his refrigerator should not be recessed or built-in an enclosed cabinet. It is designed for freestandingg
installa on only.
4) Never unplug your refrigerator by pulling on the power cord. Always grasp the plug firmly and pull
straight out from the outlet.
5) Repair or replace immediately all electric service cords that have become frayed or otherwise
damaged. Do not use a cord that shows cracks or abrasion damage along its length, at the plug or at the
connector end.
6) If your old refrigerator is not being used, we recommend that you remove the doors. This will reduce theri
possibility of danger to children.
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.
WHEN USING THIS APPLIANCE, ALWAYS EXERCISE BASIC SAFETY
PRECAUTIONS, INCLUDING THE FOLLOWING:
WARNING
AFTER YOUR REFRIGERATOR IS IN OPERATION, DO NOT TOUCH THE COLD
SURFACES IN THE FREEZER COMPARTMENT, PARTICULARLY WHEN HANDS ARE
DAMP OR WET SKIN MAY ADHERE TO THESE EXTREMELY COLD SURFACES.
WARNING
PAGE 4 •SAFETY INFORMATION
HSILGNE
7) Do not use any electrical device or any sharp instrument in defro ng your refrigerator.
8) Unplug your refrigerator before cleaning or making any repairs.
NOTE:
technician perform service.
9) Do not operate your refrigerator in the presence of explosive fumes.
SAVETHESE INSTRUCTIONS
RISK OFCHILD ENTRAPMENT. BEFORE YOUTHROW AWAY YOUR OLD
REFRIGERATOROR FREEZER, TAKE OFF THE DOORS. LEAVE THE SHELVES IN
PLACE SO THAT CHILDREN MAY NOT EASILY CLIMB INSIDE.
DANGER
If for any reason this product requires service, we strongly recommend that a certied

ELECTRICAL REQUIREMENTS
INSTALLATION GUIDE
PAGE 5 •SET UP & USE
HSILGNE
GROUNDING INSTRUCTIONS
• orG(gnorp3-,spmA51,stloV511.teltuorewopelbatiusasierehterusekaM unded) power outlet with
proper grounding to power the refrigerator.
• 3-prong adapters or removing the grounding prong from the power cord in order tofoesuehtdiovA
accommodate a 2-prong outlet. This is a dangerous prac ce since it provides no effec ve grounding
for the refrigerator and may result in a shock or fire hazard.
USE OF EXTENSION CORDS
• noisnetxenafoesuehtdiovA cord because of poten al safety hazards under certain condi ons.
If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-prong
grounding plug and a 3-slot outlet that will accept the plug. The marked ra ng of the extension cord
must be equal to or greater than the electrical ra ng of the appliance.
DO NOT USE EXTENSION CORD LONGER THAN 12 FT.
INSTALLATION LIMITATIONS
• acolelbatiusatceleS on for the refrigerator on a hard, even surface away from direct sunlight or heat
source, e.g. radiators, baseboard heaters, cooking appliances, etc. Any floor unevenness should be
corrected with the leveling legs located on the front bo om corners of the refrigerator.
UNPACKING YOUR REFRIGERATOR
R.1 emove all packaging material. This includes the corrugated base and all adhesive tape holding the
refrigerator accessories inside and outside.
2. Inspect and remove any remains of packing, tape or printed materials before powering on the
refrigerator.
NOTE: If your refrigerator comes with a snack pan, remove the blue adhesive tape from the rear of the
pan. The pan will not slide in and out without removing the tape.
USE OF EXTENSION CORD - POTENTIAL SAFETY HAZARD
WARNING
ELECTRICAL REQUIREMENT - SHOCK HAZARD
WARNING
NOTE: If your refrigerator comes with smooth or stainless steel doors, please remove the clear film before
turning it on for the first me. When removing film, do not pull the film straight down as this could
result in misaligned doors.

LEVELINGYOUR REFRIGERATOR
HSILGNE
PAGE6 •SET UP & USE
INSTALLATION GUIDE CONT.
FrontGrille
PROPERAIR CIRCULATION
• eoT nsure your refrigerator works at the maximum efficiency it was designed
for,you should install it in a locaon where there is proper air circulaon,
plumbing and electrical connecons. Your refrigerator is not designed to operate
in temperatures below
55˚F(12˚C) or above 95˚F (35˚C).
• Donot install your refrigerator in any loca onnot properly insulated or
heated,e.g.ga rage, etc..
Keepoutof direct sunlight and away from hea ng sources such as radiators,
heaters,and cooking appliances.
•Thefollowing are recommended clearances around the refrigerator:
Sidesand Top……………1” (25mm) Back..................2" (50mm)
• All fourcorners of the cabinet must rest firmly on the floor.
• The cabinetmust sit level from side to side.
seal properly.
• Turnleveling legs to raise or lower the cabinet.
TOOLSNEEDED FOR INSTALLATION
DONOT USE POWER TOOLS TO INSTALL DOOR HANDLES!
OVERTIGHTENINGTHE SCREWS COULD STRIP THE THREADS!
PhillipsScrewdriver Pliers 5/16 and 3/8 Wrenches or Adjustable Wrench
PARTS INCLUDED
PARTSINCLUDED MAY DIFFER BASED ONUNIT PURCHASED
Formode
screw installed on the faces of the doors, the parts
includedwill consist of:
•2Handles
•1Front grille
•4Door edg e handle screws
•Owner’smanual
Formodels that don’t come wit
screw installed on the face of the door, the parts
includedwill consists of:
•2Handles
•1Front grille
•2Door face handle moun ng screws
•4Door edge handle moun ng screws
•Owner’smanual
•2Handle cover/trim pieces

Door Stop
Bom Hinge
REVERSING THE DOORS
PAGE 7 • SET UP & USE
HSILGNE
DOOR REMOVAL/REVERSAL
1. Remove front grille (if already installed)
and set aside.
3. Unscrew center hinge pin. Be sure to r washer(s) for reinstall-
a Remove refrigerator door fr om hinge and set aside.
4. Remove cent cer(s) by unscrewing center bolt,
loosening side bolts and and sliding hinge to the center of the cabinet.
Tighten bolts.
5. Remove the center bolt on the opposite side, loosen side bolts and
slide center hinge and spacers behind side bolts. Reinstall center bolt and
ghten side bolts.
6. Remov om hinge bolts and relocat om hinge to the opposite
side of cabinet. Tighten bolts.
7. Unscr om hinge pin, move t hten.
8. Relocate door st om of both doors), hinge hole covers and
handle screw plugs (if reversing doors) on both doors to the opposite
side of the doors.
9. Place refrigerat om hinge pin. Align hinge hole in door
with hole in center hinge. Insert cent hten.
10. Place freezer door on center hinge pin and close.
11. Insert top hinge pin into hinge hole in top of freezer door. Align with
bolt holes in t hten bolts. Replace top hinge cover.
12. Flip over front grille and reinstall.
13. See door handle instruc to remove and reinstall handles.
Top Hinge
Door Hinge Hole
Center Hinge
ACCESSORIES
The following accessories are available:
• Ice maker kit HI5MK
• Wire shelf for freezer compartment
• Replacement light bulbs
To order accessories, call 1-877-337-3639 or visit us at www.haieramerica.com/support
• Replacement logo badge
• Plug for door handle screw
Handle Screw Plugs

PAGE 8 • SET UP & USE
ENGLISH
For models with pre-installed handle-moun rews on the faces of the doors:
1. Remove door handles and screws fr s.
3. Rotate door handle toward the space between the doors.
4. Install screws from par hten fully.
5. Repeat above steps for remaining door.
6. With both handles mounted, visually align handles, car hten screws.
DOOR HANDLE INSTALLATION
For models without pre-installed handle-moun rews on the faces of the doors:
1. Remove door handles, screws and handle trim pieces fr s.
2. Mount the tapered end of the handle to the door face using one of the two door face screws from the door
handle bag.
4. Repeat above steps for remaining door.
5. With both handles mounted, visually align handles, car hten screws.
6. A rim pieces to handles.
When reversing doors:
2. Immediately center the badge over screw hole in opposite side of door and press firmly
LOGO BADGE RELOCATION
to secure it. (Screw may need to be loosened slightly if handle is difficult to slide on).

FEATURES AND USE
PAGE 9 •SET UP & USE
HSILGNE
NOTE: All features not available on all models.
CONTROLS
Allow 24 hours for all adjustments.
24 hours to achieve desired temperature.
from the refrigerator.
Refrigerator Temperature Freezer Temperature Crisper
LIGHT COVERS (NOT ALLMODELS)
Main Refrigerator
(Not all Models)
Freezer
(Not All Models) Mid-Level Refrigerator
(Not All Models)
Leveling Legs
Front Grille
Crisper Bins
Crisper
Humidity
Controls
Full-Width
Shelves
Temperature
Control with
Interior Light
Air Flow
Control
Full-Width
Door Shelves
Freezer
Door Shelves
Dairy
Compartment
Design may vary by model number.

NOTE: Before using any cleaning products, be sure
to read the manufacturer’s instrucons
and warnings. This will help avoid personal
injury or damage to property.
INTERIOR CLEANING
Prepare a cleaning soluon of 3-4 tablespoons of
baking soda mixed with warm water. Use a sponge
or socloth, dampened with the cleaning soluon,
to wipe the inside of your refrigerator.
Avoid cleaning any cold glass (shelves, crisper
cover glass, etc.) with hot water. The glass can
break and cause personal injury. Handle all glass
parts with care at all mes.
Do not aempt to wash any parts in a dishwasher.
Do not use harsh chemicals, ammonia, chlorine
bleach, concentrated detergent, solvents,
abrasives or metal scouring pads to clean your
refrigerator, inside or out. They can damage and/
or discolor the refrigerator finish.
EXTERIOR CLEANING
Use a clean, so, lightly dampened cloth with
kitchen appliance wax or a mild detergent to clean
the exterior of the refrigerator.
Use a clean, so, lightly dampened cloth with
warm soapy water to clean the handles and trim.
Use a clean, sotowel to dry.
For stainless steel models, use a dry cloth and
stainless steel polish.
Door gaskets should be cleaned every three
months following the instrucons for interior
cleaning. Clean gaskets will maintain a beer seal
than dirty gaskets. Lightly apply petroleum jelly to
the hinge side of the gaskets to keep the gasket
pliable and assure a good seal.
Never use a dirty cloth to clean the exterior of
the refrigerator. Dirty cloths may leave residue
on the refrigerator that can damage the finish.
Also, avoid the use of harsh chemicals, ammonia,
chlorine bleach, concentrated detergent, solvents,
abrasives or metal scouring pads to clean the
outside of the refrigerator.
LIGHT BULB REPLACEMENT
1. In order to replace a light bulb, first unplug your
refrigerator from the power outlet.
2. Aer allowing bulb to cool, turn bulb counter-
clockwise in order to remove it from the socket.
3. Screw a new bulb into the socket by turning the
bulb clockwise.
4. Plug in your refrigerator and open the door to
check that the bulb is working.
PROPER CARE AND MAINTENANCE
PAGE 10 •CLEANING & CARE
ENGLISH
Before changing a bulb, ALWAYS unplug unit from
the power source. Failure to heed this warning
could result in injury or death from electric shock.
WARNING
Before cleaning your refrigerator, ALWAYS
unplug it from the power source. Failure to heed
this warning could result in injury or death from
electric shock.
WARNING
LIGHT BULB REPLACEMENT GUIDE
Use the guide below to determine the appropriate
bulb for each fixture:
Upper Refrigerator Light - 40 W Daylight Appliance
Bulb (1 or 2, depending on model) w/ medium base
Mid-Level Refrigerator Light - 25 W Appliance Bulb
w/ candelabra base
Freezer Light - 25 W Appliance Bulb w/ candelabra
base

HSILGNE
PAGE 11 •CLEANING & CARE
PROPER CARE AND MAINTENANCE
POWER INTERRUPTIONS
In the event of a power interrup on, unplug your
refrigerator from the power source. Avoid opening
the doors un l a er power has been restored.
Your refrigerator will maintain a cold temperature
for longer if door opening is avoided or kept to a
minimum.
Once power has been restored, plug your
refrigerator back into the power source and
inspect food in the refrigerator for spoilage
or thawing. Cleaning your refrigerator a er a
prolonged power outage is strongly recommended
to avoid odors and poten al health hazards due to
thawing.
VACATIONS
For long vaca ons or absences, unplug your
refrigerator and remove all food from it. Turn
the temperature control knob in the refrigerator
sec on to the OFF posi on and clean the
refrigerator, including the gaskets, according to
the Proper Care and Maintenance sec on. Leave
the doors propped open to allow air to circulate
inside the refrigerator.
MOVING
Before moving your refrigerator, empty the
food from it and use adhesive tape to secure all
loose items such as shelves, door bins and racks,
crispers and pans, etc. and unplug it. Always move
the refrigerator in an upright posi on in order to
avoid damaging the sealed refrigerant system.
NORMAL OPERATING SOUNDS
There are mul ple high-speed fans inside
your refrigerator which help it to maintain the
temperature you have selected. Whirring is
common when the refrigerator is first plugged in,
when the doors have been opened o en or for an
extended period of me and when a large amount
of food has been added.
This is a common sound that comes from
the compressor and is a part of making your
refrigerator run efficiently.
It is possible that you may hear a whooshing
sound when closing the doors. This is no cause
for concern. It is simply the pressure in the
refrigerator equalizing.
• ruoyninogniogsgnihtfotolaeraerehT
refrigerator at any given me. Addional sounds
you may hear, and possible causes include:
• gruG ling is most likely due to the circula on of
refrigerant through the cooling coils.
• zziS ling or popping sounds can be frost mel ng
and falling onto the defrost heater during the
defrost cycle.
• cilC king or chirping may be heard as the
compressor a empts to re-start.
• Cracking or popping sounds may be from the
expansion and contracon of cooling coils during
and a er the defrost cycle.
• ferruoynehw,oslA rigerator is first plugged
in, the foam insula on in the walls will cool and
contract, which can result in cracking or popping
sounds.
• tsorfedehT mer and thermostat control will
click as each cycles on and off.
WHIRRING
HUMMING
WHOOSHING
OTHER SOUNDS

ENGLISH
PAGE 12 • TROUBLESHOOTING & WARRANTY
PROBLEM POSSIBLE CAUSE(S) SOLUTION
Refrigerator does
not run
Temperature Control Knob is set to
OFF
Turn temperature knob clockwise to turn on
cooling system
Refrigerator is unplugged Plug power cord into power source
Breaker is tripped or turned off/ Fuse is
blown
Reset / Turn on breaker or replace fuse
Refrigerator is in defrost mode Wait about 40 minutes for defrost cycle to end
and cooling system to restart
Refrigerator or
freezer is too warm
Temperature control is not set low
enough
Turn temperature knob clockwise to adjust to a
lower temperature; allow 24 hours to adjust
Doors opened frequently or leopen Keep door closed / Check that a package isn’t
prevenng door from closing
Warm food added recently Allow me for food and refrigerator to cool
Items against back of compartments
are blocking proper airflow
Store items only inside the trim of the glass
shelves; don’t place items against sides of the
compartments or directly in front of any vents
Refrigerator or
freezer is too cold
Temperature control is set too low Turn knob counter-clockwise to change to a
warmer seng; allow 24 hours to adjust
Refrigerator runs
frequently or for
long periods of me
Normal when first plugged in Allow 24 hours for the refrigerator to cool down
Warm or large amounts of food addedThis is normal
Door is leopen Ensure that door is not being held open by an
item
Hot weather or frequent openings This is normal
Temperature control set to coldest
seng
Adjust knob to a warmer seng
Moisture on
exterior/interior of
refrigerator
High humidity This is normal; Dry surface and adjust
temperature knob to slightly colder seng
Doors opened frequently or leopen Keep door closed / Check that a package isn’t
prevenng door from closing
Open container of water in refrigerator Cover or seal container
Refrigerator has an
odor
Food is not sealed or packaged properly Re-seal packaging / Place an opened box of
baking soda in the refrigerator, replace every
three months
Interior needs to be cleaned Follow cleaning instrucons in Proper Care and
Maintenance secon
Light does not
come on
Refrigerator is unplugged Plug refrigerator in to power source
Bulb is loose Tighten bulb by turning clockwise
Bulb is burned out Follow instrucons in Light Bulb
Replacement secon
Not all models come with a freezer
or mid level light
TROUBLESHOOTING

TROUBLESHOOTING CONT.
PAGE 13 • TROUBLESHOOTING & WARRANTY
ENGLISH
PROBLEM POSSIBLE CAUSE(S) SOLUTION
Frost or ice crystals
on frozen food
Freezer door le open or opened
frequently
Turn knob counter-clockwise to change to a
warmer se ng; allow 24 hours to adjust
Items blocking freezer air vents and
preven ng proper air flow
Move items away from rear wall
Hot or warm air
from bo om of
refrigerator
Air flow coming from compressor
during refrigera on process
This is normal
Food freezing in
refrigerator
Food placed to close the air vent Move items away from back and top of the
refrigerator
Temperature control knob set too low Adjust the knob counter-clockwise to a warmer
se ng
Freezer door pops
open when closing
the refrigerator
door
Normal if freezer door closes
aerwards on its own
This indicates a good seal if freezer door closes
on its own
If freezer doesn’t close on its own a er
popping open, adjust leveling legs
See leveling leg feature instruc ons in Installing
Your Refrigerator sec on
Door does not
close properly
Refrigerator isn’t level See leveling leg feature instruc ons in Installing
Your Refrigerator sec on
Something is obstruc ng door closure Check for and remove obstruc ons
Vibra on or ra ling Refrigerator is not re ng firmly on
floor
See leveling leg feature instruc ons in Installing
Your Refrigerator sec on
IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product, please contact the Haier
Customer f Center at 1-877-337-3639.
DATED PROOF OF PURCHASE, MODEL # AND SERIAL #
REQUIRED FOR WARRANTY SERVICE
CUSTOMER
SERVICE
SERVICE DU
CENTRE DE
REPARATION
A LA CLIENTELE
SERVICIO
AL CLIENTE
Hotline
1-877-337-3639
CUSTOMER SERVICE

What is covered and for how long?
This warranty covers all defects in workmanship
or material for a period of:
12 Months on Parts and Labor
5 Years on Sealed System
This warranty commences on the date the item
was purchased and the original purchase receipt
must be presented to the authorized service
center before any warranty service is rendered.
Excepons: Commercial or Rental Use
90 Days on Labor (Carry-In Only)
90 Days on Parts
No Other Warranty Applies
What is Covered:
The mechanical and electrical parts, which serve
a funconal purpose of this appliance for a period
of 12 months from the date of purchase. This
includes all parts except finish and trim.
The components of the sealed system (e.g.
hermec compressor, condenser and evaporator)
from manufacturing defects for a period of 5
years from the date of purchase. Any damage to
such components caused by mechanical abuse
or improper shipping and handling will not be
covered.
What will be done?
We will repair or replace, at our discreon, any
mechanical or electrical part which proves to be
defecve in normal usage during the warranty
period as specified.
There will be no charge to the purchaser for parts
and labor on any covered items during the inial 12
month period. Beyond this period, only parts are
covered in the remaining warranty. Labor is not
provided and must be paid by the consumer.
What to do if you need service:
Contact your nearest authorized service center.
For the name of the nearest service center, please
call 1-877-337-3639.
THIS WARRANTY COVERS APPLIANCES WITHIN THE
CONTINENTAL UNITED STATES AND CANADA. THIS
WARRANTY DOES NOT COVER THE FOLLOWING:
• Service calls to correct the installaon on your
refrigerator
• Service calls to instruct you on proper use of your
refrigerator
• Service calls to replace or correct house wiring or
plumbing
•Service calls to replace light bulbs
•Damages from improper installaon
•Damages from shipping
•Defects other than manufacturing
• Damage from misuse, abuse, accident, alteraon,
lack of proper care and maintenance or incorrect
current or voltage
•Damage from use other than household use
• Damage from service performed by a non-
authorized dealer or service center
•Decorave trim
•Transportaon and shipping
•Labor (aer the inial 12 month warranty period)
THIS LIMITED WARRANTY IS GIVE IN LIEU OF ALL
OTHER WARRANTIES, EXPRESSER OR IMPLIED,
INCLUDING THE WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE
The remedy provided in this warranty is exclusive
and is granted in lieu of all other remedies.
The warranty does not cover incidental or
consequenal damages, so the above limitaons
may not apply to you. Some states do not allow
limitaons on how long an implied warranty lasts,
so the above limitaons may not apply to you.
This warranty gives you specific legal rights and
you may have other rights which vary from state to
state.
Haier America
New York, NY 10018
LIMITED WARRANTY
PAGE 14 • TROUBLESHOOTING & WARRANTY
ENGLISH
