Haier HP200S1 Specification sheet

Heat pump Water Heater
Operation and Installation Manual
Model
HP200S1
HP300S1
Please read this manual carefully prior to
your use of this water heater.
The appearance of the water heater given
in this manual is for reference only.
English
ELECTRICITE
C
E
R
T
I
F
I
É
P
A
R
L
C
I
E

English
24
Operation and functions
Display
:/3+8
9+:
(559:
35*+
BOOST
HW
SET
ACT
START
STOP
VAC
ERROR
ECO ECO+
AUTO
a
1
2
HP HC
!
a
HP
H
SET
E
T
P
ACT
$
Symbol Description
Timer adjust:press this key, then Press the + and - to adjust the
time.
Power ON/OFF switch
When turned off, the display shows the time and the actual water
temperature. When turned on, the display shows the working
mode.
The default temperature setting is 55°C in the factory. It can be
adjusted simply by pressing + & - directly on the default display.
Working mode selection:Press the key, the AUTO mode, ECO
mode, ECO+ mode,VAC mode is displayed in turn.
Press SET or wait 6 seconds the mode is selected.
Confirm button
Turn on or offfast heating function：Heat pump and Auxiliary
electrical heater are activated at same time.
Description of the pictograms

25
- In this mode ,priority using heat pump,start the Auxiliary
electrical heater only in off-peak time;
- In two ways using heat pump,should set in the installer
settings in advance ;
01- timer refer to LP parameter;
02-switch signals by power companies.
- In 01 mode, Press SET, press + and - to set Start time of first
Low price L1. Than,set Colsed time of L1.
And than, press SET, to defined for L2.
- In 02 mode, HC light up in Time of use hours, HP light up in
Peak hours.
ECO (off-peak) mode
Symbol Description
Auto mode
-Optimised management of the heat pump and the electrics
for guaranteed comfort；
- Prior using heat pump;
- If compressor works more than the default 8 hours , start
the auxiliary power；
- The compressor maximum continuous working time( )
can be adjust in the installer settings.
Description of the pictograms
- In this mode ,priority using heat pump, heat pump and Auxiliary
electrical heater are activated only in off-peak time;
- In two ways using heat pump,should set in the installer
settings;
01- timer refer to LP parameter;
02-switch signals by power companies.
- In 01 mode, The Start time and Colsed time settings as the
ECO (off-peak) mode .
ECO+ (off-peak) mode
- According to the vacation dates in advance to prepare
hot water;
- For example, you leave home for vacation on January 1st and
return home on January 5th. The date shall be set as
(5-1) =4 days, and corresponding temperature shall also be set.
The heat pump will start heating on 00:00 o’clock of January
5th automatically.
Holiday mode
English

English
Symbol Description
Description of the pictograms
26
Hot water volume display.
Boost mode. Heat pump and Auxiliary electrical heater
are activated at the same time.
Heat pump working icon．
Auxiliary electrical heater working icon．
Time of peak/off-peak hours. In Time of peak/off-peak hours
mode, the symbol corresponding to the mode is displayed.
Alarm display icon．
Anti-legionella
- Anti-legionella function will be activated every 7 days to
heat the tank to 65°C automatically .
Note: Under certain conditions, ECO mode and ECO+ mode may result in shortages of hot
water (mainly due to air temperatures outside the operating range).

Operating functions
Installer settings
Parameters
,
Description
- To open the installer settings, press switch offthe system, then press and
at the same time for 10 seconds.
- When menu is open, press or to change the value of the settings.
- Press to confirm the settings.
- Press to close the menu.
Off-peak signal type
Off-peak logic type
When you use off-peak time clock control, first determine
the type of signals,Only allow professional installers to operate.
- In two ways using heat pump,should set in the installer
settings
-01 manually set off-peak time;
-02 switch signals by power companies.
NO
01
ON
NO , NC
01 , 02
ON , OF
,
,
8h 5-10h
Compressor maximum continuous working time
- If the maximum continuous working time of the compressor
more than Set Time, start auxiliary power.
-
Factory
setting
Adjustment
range
Avoid Legionella
- This parameter is used to activate the legionella protection
mode.
- Once every 7 days, all domestic hot water is heated to 65℃.
- NO corresponds to Normally Open Signal.
- NC corresponds to Normally Close Signal.
27
Auxiliary Heating in off-peak time
- ON corresponds to turned on uxiliary Heating.
- OF corresponds to turned off uxiliary Heating.
,
ON ON , OF
English

Checking and maintenance
Checking of the Safety valve
- Installation and maintenance of the appliance must be done by a qualified
professional .
- Before working on the appliance,Shut down the machine and cut offthe power
supply .
- Do not touch with wet hands.
- Maintenance operations are important to guarantee optimum performance
and extend the life of the equipment.
Checking of the hydraulic circuit
Cleaning of the fan
- Check the watertightness of the water connections.
- Because the evaporator fins is very sharp.Risk of injury on your finger.
- Do not damage the fins. Avoid affecting the performance.
- Check the cleanliness of the fan one time per year.
Checking of the evaporator
- Clean the evaporator at regular intervals using a soft-haired brush.
- If they are bent.Carefully realign the evaporator using a suitable comb.
- Operate the safety valve at least once a month to check if it is running
correctly. Otherwise check for blocking and replace the safety valve if necessary.
Checking of the condensates discharge pipe
Checking of the Magnesium rod
- Check the pipe cleanliness .
- An obstruction by dust may cause poor condensates flow or even a risk accumulation of
water in the heat pump plastic base.
- The magnesium anode should be replaced in time, avoid tank corrosion.
- Checking magnesium anode once every 2 years .In poor water areas need to shorten the
time.
28
Drain the water tank to empty
-Cut offpower supply and shut down water inlet valve, then drain the water tank to empty
via the sewage outlet. Please stay away from the sewage outlet if there is hot water inside
the water tank to avoid injury.
English

Faults and protection
Digital
indication Release
Compressor protection
Operating temperature protection
After fault is solved,
switch on power
supply for release
Air exhaust temperature protection
Evaporation high temperature
protection
Compressor over-current
protection Over-current protection
Electricity leakage alarming The system will automatically cut off
power supply if any line fault occurs E1
After fault is solved,
switch on power
supply for release
Over temperature alarming The actual water temperature≥85℃E2
Fault of the inner
temperature sensor
If short circuit or circuit break occurs
to the sensor E3
Fault of the ambient
temperature sensor
If short circuit or circuit break occurs
to the sensor E4
Fault of the evaporation
temperature sensor
If short circuit or circuit break occurs
to the sensor E5
Fault of the air exhaust
temperature sensor
If short circuit or circuit break occurs
to the sensor E6
Communication fault Communication of main control panel
and display panel is abnormal E7
Pressure switch protection Action of the pressure switch at the
exhaust outlet E8
Ambient temperature
protection
Ambient or outdoor temperature
<-7℃or>45℃E9
F2
F3
F5
F6
The symbol on the product or on its packaging indicates that this product is
not to be treated as regular household waste. Instead, it must be taken to a
recycling collection point for electrical and electronic equipment. By properly
disposing of this product, you are contributing to the preservation of the
environment and the wellbeing of your fellow citizens. Improper disposal is
hazardous to health and environment. You can obtain further information on how to
recycle this product from your municipality, your waste management service or the
shop where you purchased it.
Fault type Action
29
Fault of the Off-peak power
switching signal
If not received the Off-peak signal
when selecting switch signals by
power companies
EF
Fault of the air intake
temperature sensor
If short circuit or circuit break occurs
to the sensor ED
