Hairy Bikers SDA2323 User manual

1
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to property
or persons.
The manufacturer or vendor cannot be held liable for damages or
injury incurred through improper or incorrect use.
•Read and familiarise yourself with all operating instructions
before using this Breadmaker.
•Before plugging your Breadmaker into the mains, visually check
that the steamer is intact and has not suffered any transit
damage.
•Check that the voltage indicated on the data plate corresponds
with that of the local network before connecting the appliance
to the mains power supply.
•Close supervision is required when using this appliance near
children.
•Never leave this appliance within reach of children.
•This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory and mental
capabilities or lack of experience or knowledge if they have
been given supervision or instruction concerning use if the
appliance in a safe way and understand the hazards involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by children
unless they are older than 8 and supervised.

3
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•Keep the appliance and its cord out of reach of children aged
less than 8 years.
•DO NOT leave the appliance unattended during use.
•DO NOT leave the appliance unattended whilst connected to
the mains supply.
•Always use this appliance on a solid, level, non-flammable
surface.
•DO NOT use this appliance outdoors.
•It is imperative to unplug the power cord after the appliance
has been used, before it is cleaned and whilst being repaired.
•If the power cable is damaged, it should only be replaced by
suitable qualified personnel in order to avoid a hazard.
•Repairs to electrical appliances should only be performed by
qualified personnel. Improper repairs may place user at serious
risk.
•DO NOT operate this appliance with a damaged plug or cord,
after a malfunction or after being dropped or damaged in any
way.
•Regular, periodic checks should be carried out on the mains
cable to ensure no damage is evident. Should there be any
signs of damage the appliance should not be used.
•DO NOT allow the mains cable to hang over sharp edges or
come in contact with hot surfaces.
•DO NOT run the mains cable under carpets, rugs, etc.
•Allow the unit to cool before storage.
•Never place the appliance near to flammable material or high
pressure containers.
•This appliance is intended for household use only and should
not be used for industrial purposes.
•DO NOT use any accessories or attachments with this appliance
other than those supplied or recommended by supplier.
•DO NOT immerse the appliance, base or its cord in water or
any other liquids.
•DO NOT use this appliance for anything other than its intended
use.

4
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
•Ensure appliance is situated in an open area, do not allow it to
come in contact with or place beneath cupboards, curtains,
wall coverings, clothing or other flammable materials.
•Unplug after each use. Grasp the plug, not the cord.
•DO NOT cover this appliance.
•Never place this appliance on an electric, gas, or any other type
of hob.
•Never fill the Breadmaker more than its capacity –ensure the
water level is between the min and max marks. If the
Breadmaker is overfilled, boiling water may be ejected.
•Always close the lid during use and do not open the lid whilst
the water is boiling.
•CAUTION: The outside surface of the Breadmaker will get hot
during use.
•THIS APPLIANCE MUST BE EARTHED

5
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste and not sent to
landfill. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for
recycling advice or visit www.recycle-more.co.uk, enter your
postcode to find out your nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol indicates that the surface is gets hot and care must
be taken.
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.

6
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of parts - Overview
Description of parts –Accessories
2
3
4
1
1. Lid Handle
2. Lid
3. Viewing Window
4. Automatic Dispenser
5. Display
6. Control Panel
7. Bread Basket
8. Outer Casing
5
6
7
8
a. Dual Spoon
The dual spoon measures both Teaspoons
(Tsp -small side) and Tablespoons (Tbsp –
large side), this can be used to measure
ingredients when following the below
recipe guide.
b. Measuring Cup
The measuring cup measures in both cups
and ml, this can be used to measure
ingredients when following the below
recipe guide.
a
b
c
d
a. Dual Spoon
b. Measuring Cup
c. Paddle
d. Paddle Hook

7
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
descr
Whilst the Breadmaker is running through the selected program it will run
through the following processes:
Time Delay –Preheat –Knead –Rest –Knead –Ferment –Bake –Keep Warm - End
Loaf: Press the Loaf button, the beeper will beep with each press,
select from the following loaf size options:
500g (1.0LB), 750g (1.5LB) or 1000g (2LB)
Loaf size can only be adjusted for options 1-9 from the above
Menu.
Colour: Press the Colour button, the beeper will beep with each
press, select from the following colour options:
Light/Medium/Dark
Start/Stop/Pause: Press the start/stop/pause button to start, stop
or pause the machine.
+: Press the + button to add 10 minutes to the cooking time, the beeper will
beep once for each button press. If the + button is pressed and then held the
time will rapidly increase in 10 minute increments.
-: Press the - button to reduce 10 minutes to the cooking time, the beeper
will beep once for each button press. If the - button is pressed and then held
the time will rapidly decrease in 10 minute increments.
Description of parts - Control Panel
Menu: Press the Menu button, a beep will be heard with each press,
select from the following menu options:
1.Soft Bread 11.Raw Dough
2.Sweet Bread 12.Leaven Dough
3.Natural Sourdough 13.Jam
4. French Bread 14.Bake
5. Whole Wheat 15.Yoghurt
6. Quick Bread 16.Gluten Free
7. Sugar Free 17.Ferment
8. Multigrain
9. Milky Loaf
10.Cake

8
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Time Delay: The Breadmaker has a time delay function, e.g. you placed all
the ingredients into the Breadmaker as per chosen recipe at 8:30pm and you
wanted to have fresh ready-made bread in the morning around 7:00am. The
time delay for this would be 10 hours and 30 minutes from 8:30pm to 7:00
am the following day, to set the time delay use the “+” and “–“ to set, after
setting the time press the Start/Stop/Pause button.
The time displayed on the screen is set to 10 hours and 30 minutes, this
includes cooking time.
This function is not suitable for recipes which call for the use of eggs.
For recipes using yeast, it is recommended to cover yeast under flour to
maintain the activity of the yeast.
Automatic Dispenser: The Breadmaker has an automatic dispersal tray for
Fruit, Seeds and or Nuts. To use this accessory where the recipe may call for
these ingredients, please follow these instruction:
1. Open the Lid (2) of the Breadmaker, hold the Automatic Dispenser (4)
and press the clip used to secure in place and carefully remove from the
lid housing (see fig. 1).
2. Open the cover of the Automatic Dispenser (4) (see fig. 2)
3. Add the desired ingredients e.g. Fruit, Nuts or Seeds and then close the
cover (see fig.3)
4. Replace the Automatic Dispenser (4) into the lid housing (see fig. 4)
fig.1 fig.2 fig.3 fig.4
Before the First Use of Your Breadmaker
1.Remove all packing materials and discard responsibly.
2.Ensure all parts are present (if applicable) see Description of Parts above.
3.Wash the Lid (2), the Bread Basket (7) in warm soapy water. Rinse and allow to
dry before use.

9
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Setting up Your Breadmaker
1.Do not yet insert the mains plug into the mains socket.
2.Place the bread maker on a solid, level heat resistant
surface at a comfortable height for the user.
3.Ensure that the Bread Basket (7) is firmly in place,
twist clockwise to lock into place. The Paddle (c) should
sit firmly on the spindle in the centre of the Bread
Basket (7).
4.Start adding the ingredients for your chosen bread
recipe to the Bread Basket (7) in the following sequence:
water, flour, eggs and others according to the recipe
(below) Add the yeast to the centre of the mixture if
using a program with the delay function otherwise if no
delay function is selected then place the yeast on the top
of the mixture in order not to mix the yeast with water,
salt and sugar, it is important that the yeast does not
come into contact with the wet ingredients; otherwise
the dough will not rise well enough.
When plugged into the mains, the Display (5) will display the default menu:
1.5LB/Medium Colour/Soft Bread
5.Close the Lid (2) of the bread maker.
6.Insert the mains plug (with dry hands) into the mains
socket, the unit will then beep to confirm the unit has
powered up. The LCD display will show 1.5LB/Medium
Colour/Soft Bread.
7.Select the Menu option (1-19) on the Control Panel (6),
select your Bread Colour and Loaf using the arrows on the
Display (5).
8.If desired at this point a time delay can be set, please refer
to above information regarding this function. If you are going straight to the cooking
process please skip this current step by pressing the Start/Stop button.

10
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9.Press the Start/Stop button on the Control Panel (6) and the bread maker will begin
to go through the process of kneading the dough.
10.Once the baking is complete, the bread maker will beep and
the Display (5) will show 0:00 and the unit will then go into keep
warm mode for a period of 1 hour. The symbol “:” will continue to
flash. After 1 hour the keep warm mode will beep and will then
return to its standby state. To cancel the keep warm mode at any
point, simply press and hold the On/Off button until a beep sound
is given and the unit will go into standby mode.
11.After the program has finished, unplug from the mains socket before taking out
the bread. Use an oven glove or similar, twist the Bread Basket (7) anti-clockwise and
lift from the machine.
12.Shake the Bread Basket (7) lightly and remove the bread, check that the Paddle (c)
has not come out with the bread.
If the Paddle (c) is stuck in the bread, it can be difficult to remove. You can use the
Paddle Hook (d) accessory to dislodge the Paddle (c) with ease,
A.Insert the Paddle Hook (d) into the centre hole of the
Paddle (c).
B.Gently pull the Paddle Hook (d) to dislodge the Paddle (c)
from the bread.

11
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Recipe Guide
1.Soft Bread
Ingredient
1LB/500g
1.5LB/750g
2LB/1000g
Water
160ml
240ml
290ml
Butter
2Tbsp
2Tbsp
3Tbsp
Table Salt
1/2Tsp
1/2Tsp
1/2Tsp
Sugar
1Tbsp
2Tbsp
3Tbsp
Milk Powder
2Tbsp
3Tbsp
5Tbsp
Flour
300g
400g
475g
Yeast Powder
1Tsp
1Tsp
1Tsp
2.Sweet Bread
Ingredient
1LB/500g
1.5LB/750g
2LB/1000g
Water
160ml
240ml
310ml
Butter
2Tbsp
2Tbsp
3Tbsp
Table Salt
1/2Tsp
1/2Tsp
1/2Tsp
Sugar
4Tbsp
6Tbsp
6Tbsp
Milk Powder
2Tbsp
3Tbsp
4Tbsp
Flour
300g
400g
500g
Yeast Powder
1Tsp
1Tsp
1Tsp
3.Natural Sourdough
Ingredient
1LB/500g
1.5LB/750g
2LB/1000g
Water
160ml
200ml
240ml
Sugar
1Tbsp
1Tbsp
2Tbsp
Milk Powder
2Tbsp
3Tbsp
4Tbsp
Butter
1Tbsp
1Tbsp
2Tbsp
Table salt
1/2Tsp
3/4Tsp
1Tsp
Flour
275g
350g
400g
Yeast Powder
1/3Tsp
1/3Tsp
1/3Tsp

12
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
4.French Bread
Ingredient
1LB/500g
1.5LB/750g
2LB/1000g
Water
200ml
260ml
320ml
Butter
2Tbsp
2Tbsp
3Tbsp
Table Salt
1/2Tsp
1/2Tsp
1/2Tsp
Milk Powder
2Tbsp
3Tbsp
4Tbsp
Flour
300g
400g
500g
Yeast Powder
1Tsp
1Tsp
1+1/4Tsp
5.Whole Wheat
Ingredient
1LB/500g
1.5LB/750g
2LB/1000g
Water
210ml
280ml
340ml
Butter
2Tbsp
2Tbsp
3Tbsp
Table Salt
1/2Tsp
1/2Tsp
1+1/2Tsp
Flour
150g
200g
250g
Whole Wheat Flour
150g
200g
250g
Sugar
2Tbsp
3Tbsp
4Tbsp
Yeast Powder
1Tsp
1+1/4Tsp
1+1/2Tsp
6.Quick Bread
Ingredient
1LB/500g
1.5LB/750g
2LB/1000g
Water 40-50C
180ml
240ml
300ml
Butter
2Tbsp
2Tbsp
3Tbsp
Table Salt
1/2Tsp
1/2Tsp
1+1/2Tsp
Flour
280g
375g
450g
Sugar
1Tbsp
2Tbsp
3Tbsp
Milk Powder
2Tbsp
3Tbsp
4Tbsp
Yeast Powder
2Tsp
3Tsp
4Tsp

13
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
7.Sugar Free
Ingredient
1LB/500g
1.5LB/750g
2LB/1000g
Water
120ml
180ml
240ml
Butter
2Tbsp
2Tbsp
3Tbsp
Table Salt
3/4Tsp
1Tsp
1+1/4Tsp
Flour
280g
375g
450g
Egg
1
1
1
Xylitol
3Tbsp
4Tbsp
5Tbsp
Milk Powder
2Tbsp
3Tbsp
4Tbsp
Yeast Powder
1Tsp
1Tsp
1Tsp
8.Multigrain
Ingredient
1LB/500g
1.5LB/750g
2LB/1000g
Water
120ml
170ml
210ml
Butter
2Tbsp
2Tbsp
3Tbsp
Table Salt
1/2Tsp
3/4Tsp
1Tsp
Whole Wheat Flour
50g
75g
100g
Oatmeal
50g
75g
100g
Flour
200g
250g
300g
Egg
1
1
1
Yeast Powder
1Tsp
1Tsp
1Tsp
9.Milky Loaf
Ingredient
1LB/500g
1.5LB/750g
2LB/1000g
Milk
120ml
180ml
240ml
Butter
2Tbsp
2Tbsp
3Tbsp
Sugar
2Tbsp
3Tbsp
4Tbsp
Flour
280g
375g
450g
Table Salt
1/2Tsp
3/4Tsp
1Tsp
Egg
1
1
1
Milk Powder
2Tbsp
3Tbsp
5Tbsp
Yeast Powder
1Tsp
1Tsp
1Tsp

14
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
10.Cake
Ingredient
Egg
4
Butter
100g
Sugar
150g
Cake Flour
380g
Table Salt
1Tsp
Baking Soda
3.5g
11.Raw Dough
Ingredient
Water
280ml
Butter
2Tbsp
*Egg
2
*Table Salt
1+1/3Tsp
*Sugar
1Tbsp
Flour
4Cups
*Indicates ingredients which are variable depending on your requirements.
12. Leaven Dough
Ingredient
Water
240ml
Butter
2Tbsp
Table Salt
1+1/2Tsp
Sugar
1Tbsp
Flour
3Cups
Yeast Powder
1+1/2Tsp
13. Jam
Ingredient
Orange
600g
Sugar
300g
Gelatine
50g
14.Bake
This function is used to bake already prooven doughs only.
15. Yoghurt
Ingredient
Milk
350ml
Yoghurt
50ml
Sugar
3Tbsp

15
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
16. Gluten Free
Ingredient
1LB/500g
1.5LB/750g
2LB/1000g
Water
120ml
180ml
240ml
Sugar
2+1/2Tbsp
3Tbsp
3+1/2Tbsp
Table Salt
1/2Tsp
1Tsp
1+1/2Tsp
Vegetable Oil
2Tbsp
2+1/2Tbsp
3Tbsp
Gluten Free Flour
140g
210g
280g
Corn Flour
140g
210g
280g
Yeast Powder
1Tsp
1+1/4Tsp
1+1/2Tsp
17. Ferment
This function is used to proof doughs only.
Tbsp denotes Tablespoon, Tsp denotes Teaspoon
WARNING! Take care when removing the bread basket as it will get hot
during use. Use heat resistant oven gloves to prevent injury.
WARNING! Voltage is still present even when the unit is in standby mode (off),
to completely turn off the bread maker remove the mains plug from mains power
supply.
Care and Maintenance
•Before carrying out any cleaning or maintenance, ensure that the Breadmaker is
unplugged from the mains power supply and has fully cooled.
•Do not clean any part of your Breadmaker in a dishwasher.
•Do not submerge any part of the main body or mains cable in water or any other
liquids.
•Wipe clean the outside of the main body and lid with a soft damp cloth.
•Remove the bread basket from the bread maker by twisting and pulling upwards
from the handle. Wash the bread basket in warm soapy water and dry
thoroughly afterwards.
•Never clean any part of the Breadmaker with harsh or abrasive chemicals.

16
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Non-Wireable Mains Plug
If your appliance is supplied with a non-wireable plug fitted to the mains lead and
should the fuse need replacing, you must use an ASTA approved one (conforming
to BS 1362 of the same rating). If in doubt, consult a qualified electrician who
will be pleased to do this for you. If you need to remove the plug –DISCONNECT
FROM THE MAINS –and then cut it off the mains lead and immediately dispose
of it safely. Never attempt to reuse the plug or insert it into a socket outlet as
there is a danger of electric shock.
Technical Data
Model No.
SDA2323
Rated Voltage
220-240V ~ 50-60Hz
Rated Power
710W
Protection Class
I (This Appliance must be Earthed)
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.

17
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Possible Fix
Breadmaker is not
working, failing to mix
flour
Mains plug not in socket.
Check that the mains plug is inserted into the
socket and is switched on. Press
“Start/Stop/Pause” button.
Is operation delayed.
Is the “:” indicator flashing.
Damaged parts.
Contact the retailer.
Abnormal Sound
Foreign objects are present in
the inner body.
Remove all foreign bodies, crumbs and
foodstuffs from the inner body
Bread basket is not firmly in
place.
Twist and lock the bread basket into place
Abnormal Smell/Taste
Wire cord is damaged.
Keep wire cord away from heated objects or
heat sources.
Foreign matter on or around
the heating element.
Remove any foreign matter, crumbs or debris
from around the heating element.
LED indicates “LLL”
Temperature inside the unit is
lower than -10 degrees C.
Ensure that product is used in an environment
with a constant ambient temperature
between -10 and 50 degrees C.
LED indicates “HHH”
Temperature inside the unit is
higher than 50 degrees C.
Ensure that product is used in an environment
with a constant ambient temperature
between -10 and 50 degrees C.
LED indicates “EE0” or
“EE1”
Sensor fault code.
Contact the retailer.
Bread is partly Raw
Bread is raw.
Use function 14. Bake to cook the contents
for a little longer until Bread is cooked
through.
The amount of ingredients in
dough mixture is wrong.
Ensure you refer to ingredients and recipe as
per the above guide.

18
Breadmaker
Model No. SDA2323
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
