Hameg HM8150 User manual

Frequency range from 10 mHz to 12.5 MHz
Output voltage 20 mVpp to 20 Vpp (open circuit)
Waveforms: Sine wave, square wave, triangle, pulse, sawtooth,
arbitrary
Rise and fall time ‹ 10 ns
Pulse width adjustment: 100 ns to 80 s
Arbitrary waveform generator 40 MSa/s
Burst, gating, external triggering, sweep
Software for remote control and for creation of
Arbitrary waveforms
External amplitude modulation (bandwidth 20 kHz)
Intuitive operation with one touch of a button –
quick change of signals
RS-232 Interface, optional: USB, IEEE-488
12.5 MHz Arbitrary Function Generator
HM8150
HM8150
Triggered arbitrary signal
Amplitude-modulated
sine wave
Gated sine wave,
PC-Software included

Accessories supplied: Operator’s Manual and power cable, Software
Optional accessories:
HZ33/HZ34 Test Cable 50 Ω (BNC-BNC)
HZ24 Attenuators 50Ω 3/6/10 and 20 dB
HZ42 19” Rackmount kit 2RU
HZ20 Adapter plug
HO870 USB Interface
HO880 IEEE-488 (GPIB) Interface
12.5 MHz Arbitrary Function Generator HM8150
Valid at 23 °C after a 30 minute warm-up period
Frequency
Range: 10 mHz to 12.5 MHz
Resolution: 5 digit, max. 10 mHz
Accuracy: ± (1 digit + 5 mHz)
Temperature coeffizient: 0.5 ppm/°C
Aging: 2 ppm/year
Waveforms
Sine wave
Frequency range: 10 mHz to 12.5 MHz
Amplitude: 20 mVpp –20Vpp (open circuit)
Harmonic Distortion @1Vpp:
f ‹ 500 kHz: -65 dBc
500 kHz ≤f ‹ 5 MHz: -50 dBc
5 MHz ≤f ≤12.5 MHz: -40 dBc
Total Harmonic Distortion @1Vpp:
f ‹ 100 kHz: typ. 0.05%
Spurious (Non-Harmonic) @1Vpp:
f ‹ 500 kHz: -65 dBc
500 kHz ≤f ≤12.5 MHz: -65 dBc + 6 dBc/octave
Square wave
Frequency range: 10 mHz to 12.5 MHz
Amplitude: 20 mVpp – 20 Vpp (open circuit)
Rise / fall time: ‹ 10 ns
Overshoot: ‹ 5 % (Uout ≤200 mV)
Symmetry: 50 % ± (5 % +10 ns)
Pulse
Frequency range: 10 mHz to 5 MHz
Amplitude: 10 mV...+10 V or -10 mV...-10 V
Rise / fall time: ‹ 10 ns
Pulse width: 100 ns to 80 s
Duty cycle: max. 90 %
Sawtooth
Frequency range: 10 mHz to 25 kHz
Amplitude: 20 mVpp – 20 Vpp (open circuit)
Linearity: better than 1 %
Triangle
Frequency range: 10 mHz to 250 kHz
Amplitude: 20 mVpp – 20 Vpp (open circuit)
Linearity: better than 1 %
Arbitrary generator
Frequency range: 10 mHz to 250 kHz
Amplitude: max. 20 Vpp (open circuit)
Output rate: 40 MSa/s
Resolution: X: 1024 (10 bit), Y: 1024 (10 bit)
or X: 4096 (12 bit), Y: 4096 (12 bit)
Inputs
Gate/Trigger: BNC connector
Impedance: 5kΩII100pF
Max. input voltage: ± 30 V
Modulation Input: BNC connector
Impedance: 10 kΩ
Max. input voltage: ± 30 V
Outputs
Signal output: BNC connector, short circuit proof,
ext. voltage up to ± 15 V
Impedance: 50 Ω
Output voltage:
Range 1: 2.1 – 20 Vpp (open circuit)
Range 2: 0.21 – 2.0 Vpp (open circuit)
Range 3: 20 – 200 mVpp (open circuit)
Resolution:
Range 1: 100 mV
Range 2: 10 mV
Range 3: 1 mV
Setting accuracy (1 kHz):
Range 1: ± 2 %
Range 2: ± 3 %
Range 3: ± 4 %
3 % additional for pulse and square wave
Frequency response: ‹ 100 kHz ± 0.2 dB
0.1 – 12.5 MHz: ± 0.5 dB
Offset error: Range 3: ± 50 mV
Display: 21⁄2digits (LCD)
Trigger output: BNC connector
Level: 5 V / TTL
Impedance: 50 Ω
Sawtooth output: BNC connector
Output voltage: 0 to 5 V, synchronous to sweep
Impedance: 1 kΩ
DC offset
Output voltage: Range 1: -7.5...+7.5 V (open circuit)
Range 2: 0.75...+0.75 V (open circuit)
-Range 3: 75...+75 mV (open circuit)
Sweep (internal)
Setting of start and stop frequency
Internal sweep: all waveforms
Sweep time: linear, 20 ms to 100 s
continuous or triggered
(ext. signal, interface)
Amplitude Modulation:
Modulation via external signal
Modulations depth: 0 to 100 %
Bandwidth: DC – 20 kHz (-3 dB)
Gate (asynchronuous)
Modulation on/off via external TTL signal
Delay time: ‹ 150 ns
Input singal: TTL
Trigger Function (synchronuous)
Burst mode via ext. trigger input or interface
Frequency range: ‹ 500 kHz
Miscellaneous
Interface: RS-232 (standard), IEEE-488 (optional)
or USB (optional)
Display: 16 characters, LCD with backlight
Memory: for the last device settings and for
1 arbitrary signal
Safety Class: Safety Class I (EN61010-1)
Power supply: 115/230 V ± 10 %; 50/60 Hz
Power consumption: approx. 20 Watt
Operating temperature: +10 °C to +40 °C
Max. rel. humidity: 10 % to 90 % (without condensation)
Dimensions (W x H x D): 285 x 75 x 365 mm
Weight: approx. 5 kg
