HealthyCook Dual Air Fryer
Operating and Safety Instructions
Model： HB4006
-FOR INDOOR
HOUSEHOLD USE ONLY-
Specification ＆ Features:
-----Voltage:220-240VAC 50-60Hz
-----Wattage: 2850 Watts(max)
-----Capacity of basket: 4 Litre*2
-----Adjustable temperature:
Air Fryer: 80—200℃ 1-60MIN Dehydrated
function: 40-80℃ 1-24H

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed including the following:
1. Read all instructions.
2. Do not touch hot surfaces.
3. To protect against electric shock do not immerse cord, plugs, or base in water
or other liquid.
4. WARNING: This electrical appliance contains a heating function. Surfaces, also
different than the functional surfaces, can develop high temperatures. Since
temperatures are differently perceived by different persons, this equipment shall be
used with CAUTION. The equipment shall be touch only at intended handles and
gripping surfaces, and use heat protection like gloves or similar. Surfaces other than
intended gripping surfaces shall get sufficiently time to the cool down before
getting touched.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts.
6. Type Y:If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
7. The use of accessory attachments not recommended by the appliance manufacturer
may cause injuries.
8. Do not use outdoors
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving an appliance containing hot oil or other
hot liquids.
12. Always attach plug to appliance first, then plug cord in the wall outlet. To
disconnect, turn any control to "off," then remove plug from wall outlet.
2
13. Do not use appliance for other than intended use.
14. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by
children unless they are old than 8 and supervised.
15. Keep the appliance and its cord out of reach of children less than 8 years.
16. The appliances are not intended to be operated by means of an external timer or
separate remote-control system.
SAVE THESE INSTRUCTIONS
This appliance is intended to be used in household and similar applications such as:
-staff kitchen areas in shops, offices and other working environments;
-farm houses;
-by clients in hotels, motels and other residential type environments;
-bed and breakfast type environments.
Introduction
This all now Hot-air fryer provides an easy and healthy way of preparing your
favorite ingredients. By using hot rapid air circulation and a top grill, it is able to
make numerous dishes. The best part is that the Hot-air fryer heats food at all
directions and most of the ingredients do not need any oil.
General description (Fig.1)
1. Lid
2. Housing
3. Control panel
4. Pot
5. Gridiron
6. Basket handle
7. Air outlet
8. Power cord
3

Important
Please read this manual carefully before you use the appliance and save it for future
reference.
Danger
-This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
4
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are older than 8 and
supervised.
-Keep the appliance and its cord out of reach of children less than 8 years.
-Never immerse the housing, which contains electrical components and the heating
elements, in water nor rinse it under the tap.
-Do not let any water or other liquid enter the appliance to prevent electric shock.
-Always put the ingredients to be fried in the basket, to prevent it from coming into
contact with the heating elements.
-Do not cover the air inlet and the air outlet while the appliance is operating.
-Do not fill the pan with oil as this may cause a fire hazard.
-Never touch the inside of the appliance while it is operating.
The temperature of accessible surfaces may be high when the appliance is operating
Warning
-Check if the voltage indicated on the appliance fits the local mains voltage.
-Do not use the appliance if there is any damage on plug, mains cord or other
parts.
-Do not go to any unauthorized person to replace or fix damaged main cord.
-Keep the mains cord away from hot surfaces.
-Do not plug in the appliance or operate the control panel with wet hands..
-Do not place the appliance against a wall or against other appliances. Leave at
least 10cm free space on the back and sides and 10cm free space above the appliance.
-Do not place anything on top of the appliance.
-Do not use the appliance for any other purpose than described in this manual.
-Do not let the appliance operate unattended.
-During hot air frying, hot steam is released through the air outlet , Keep your hands
and face at a safe distance from the steam and from the air outlet. Also be careful of hot
steam and air when you remove the pan from the appliance.
-Any accessible surfaces may become hot during use (Fig.2)
5

-Immediately unplug the appliance if you see dark smoke coming out of the
appliance. Wait for the smoke emission to stop before you remove the pay from the
appliance.
Caution
-Ensure the appliance in placed on a horizontal, even and stable surface.
-This appliance is designed for household use only. It may not suitable to be safely
used in environments such as staff kitchens, farms, motels, and other non-residential
environments. Nor is it intended to be used by clients in hotels, motels, bed and
breakfasts and other residential environments.
-If the appliance is used improperly or for professional or semi-professional purposes
or if it is not used improperly or for professional or semi-professional purposes or it is
not used according to the instructions in the user manual, the guarantee becomes
invalid and we could refuse any liability for damage caused.
-Always unplug the appliance while not using.
-The appliance needs approximately 30 minutes to cool down for handle or cleaning
safely.
Before first use
1. Remove all packaging materials.
2. Remove any stickers or labels from the appliance .
3. thoroughly clean the Gridiron and pot with hot water, some washing-up liquid
and a non-abrasive sponge.
4. Wipe inside and outside of the appliance with a moist cloth.
This is an oil-free fryer that works on hot air, Do not fill the pan with oil or
frying fat.
Preparing for use
1 Place the appliance on a stable, horizontal and even surface.
Do not place the appliance on non-heart-resistant surface.
2 Place the basket in the pan (Fig.3).
3 Pull the cord from the storage compartment which locates on the bottom of
the appliance
6
Do not fill the pan with oil or any other liquid.
Do not put anything on top of the appliance, the airflow will be disrupted and
affects the hot air frying result.
Using the appliance
The oil-free can prepare a large range of ingredients. The recipe booklet
included helps you get to know the appliance.
Hot air frying
1. Connect the mains plug into an earthed wall socket.
2. Carefully pull the pan out of the Hot-air fryer (Fig.6)
3. Put the ingredients in the basket. (Fig.5)
4. Slide the pan back into the Hot-air fryer (Fig 4)
Noting to carefully align with the guides in the body of the fryer.
Never use the pan without the basket in it.
Caution: Do not touch the pot during and some time after use, as it gets very
hot. Only hold the pot by the handle.
5.Determine the required preparation time for the ingredient ( see section
‘Settings’ in this chapter).
6.Some ingredients require shaking halfway through the preparation time (see
section “Settings” in this chapter). To shake the ingredients, pull the pan out of the
appliance by the handle and shake it. Then slide the pan back into the I fryer
7

7. When you hear the timer bell, the set preparation time has elapsed. Pull the
pan out of the appliance and place it on a the trial framework.
8.
9.
Check if the ingredients are ready.
If the ingredients are not ready yet, simply slide the pan back into the appliance
and set the timer to a few extra minutes.
To remove ingredients (e.g. fries), pull the pot out of the Hot-air fryer and place
it on trial framework.
The pan and the ingredients are hot and hot fryer. Depending on the type of the
ingredients in the I fryer, steam may escape from the pan.
10. Empty the pot into a bowl or onto a plate.
Tip: To remove large or fragile ingredients, lift the ingredients out of the basket
by a pair of tongs
11. When a batch of ingredients is ready, the Hot-air fryer is instantly ready for
preparing another batch.
Control Panel Instructions
Power on
SyncPre-heatSync EndStart/pause
8
Operation Instructions:
1. Plug in power, all icons light on for 1 sec. and off soonest. The buzzer will be
on. Icon for power on is light on
2. Press the Power on icon, icons L,R and L=R are light on. They can be selected.
3. If press L=R, icon L=R is flashing ，If press L, icon L is flashing. If press R, icon
R is flashing. and six pre-set foods icons will be on.
4. Icons operation.
4.1 Press timer side “+” and “-“ adjust cooking time up and down. It’s one
minute iterval.
4.2 Press temperature “+” and “-“ adjust temperature up and down. It’s 5℃
interval. When setting the max. and min. temperature, the up and down icon will
be off.
4.3 If press the pre-heat icon, default setting 200℃ 5min (not suitable for
Dehydrated function). Press icon L, left container will be pre-heated. Press R, right
container will be pre-heated. If press L=R, both containers will be pre-heated
together. The max pre-heat time is 60 min.
4.4 After time and temperature set, press “start/pause” icon, unit start to
work. The seleted icons are on and others are off.
4.5 After setting, if press “POWER ON”, unit will be back to “OFF” situation. 4.6 When
both containers are working together, press “start/pause” icon,
buzzer will on for one time, unit stop working. Press again “start/pause” icon, unit
will be keep on working.
4.7 If want to pause one of the container, press L or R first, then press
“start/pause” icon.
4.8 When unit into “paused” mode, unit will work again until press
“start/pause” icon.
4.9 When unit working, timer and temperature can be adjusted again. Press L
or R and set timer or temperature. In 5mins, unit will work again.
4.10 When unit working, if press “POWER ON”, unit will be back to “OFF”
mode with buzzer on one time.
4.11 When unit no working (setting time arrived) or paused, unit will be in
“OFF” mode in 5mins.
4.12 When finish cooking, buzzer with 5 times and into mode “OFF”. Screen is
showing “End” for 5mins. “POWER ON” icon is light on.
9

5. Sync End function (not suitable for Dehydrated function)
5.1 Press L or R icon first, select function, time and temperature.
5.2 Press “Sync End” icon, it’s flashing.
5.3 When in mode “Sync End”, one container’s cooking not set, unit will not work for
set container. Not set container is icon L or R is flashing. Or the
“ Sync End” function should be canceled.
5.4 When unit working, adjust the longer cooking time shorter than the other one,
“HOLD” pot will start working and the “ Sync End” icon off.
5.5 When unit working, adjust the shorter cooking time side longer than the other one,
“HOLD” pot will start working and the “ Sync End” icon off.
6 L=R mode
6.1 Press L and R, and set time and temperature one side, press “L=R” icon,
the not set side will be copy the setup.
6.2 If press “L=R” icon first, and press to select functions, both sides are in
same setup.
6.3 Press “start/pause” icon, two containers are working together. Two screens
are showing the same temperature and time. L and R icons are one.
6.4 In working situation, press “+” or “-“ icons, both side will be adjusted same. 6.5
After above adjustment, unit will work again and icon “L=R” off.
7 Pot out mode
7.1 When in “Sync end” and “L=R” mode, put out one of the container, unit stop
working and the screen for the container out showing “Out”
7.2 If the container inserted back within 90 seconds, unit will working as the
original setup.
7.3 If the container can’t be inserted back after 90 seconds but within 5 mins,
the container not put out will be continued to work as original setting. The
no container side will be not heating up. Icons”Sync end” and “L=R” are off. 7.4 If
the container inserted back after 90 seconds but within 5 mins, both
10
containers keep to work as original setting, but Sync end and L=R function
inactive.
7.5 If any container or both containers not inserted back after 5mins, the no
container side is into standby mode. The one not pulled out will keep working.
8 Fan working
8.1 When fan turning, fan icon is light on always.
8.2 When fan not turning, fan icon is off.
8.3 Fan icon flashing during delayed time when finish working, press power icon
or press start/pause icon.
Settings
This table below will help you to select the basic settings for the ingredients.
Note: Keep in mind that these settings are indications. As ingredients differ in
origin, size, shape as well as brand, we cannot guarantee the best setting for your
ingredients.
Because the Rapid Air technology instantly reheats the air inside the appliance
instantly
Pull the pan briefly out of the appliance during hot air frying barely disturbs the
process.
Tips
-Smaller ingredients usually require a slightly shorter preparation time than larger
ingredients.
-A larger amount of ingredients only requires a slightly longer preparation time, a
smaller amount of ingredients only requires a slightly shorter preparation time.
-Shaking smaller ingredients halfway through the preparation time optimizes the
end result and can help prevent unevenly fried ingredients.
-Add some oil to fresh potatoes for a crispy result. Fry your ingredients in the
Hot-air fryer within a few minutes after you added the oil.
11

-Snacks that can be prepared in a oven can also be prepared in the Hot-air
fryer
-The optimal amount for preparing crispy fries is 500 grams.
-Use pre-made dough to prepare filled snacks quickly and easily. Pre-made
dough also requires a shorter preparation time than home-made dough.
-Place a baking tin or oven dish in the Hot-air fryer basket if you want to bake
a cake or quiche or if you want to fry fragile ingredients or filled ingredients
-You can also use the Hot-air fryer to reheat ingredients. To reheat ingredients, set
the temperature to 150℃ for up to 10 minutes.
Min-max
Amount
(g)
Time
(min.)
Temp
(/℃)
Shake
Extra information
Potato & fries
Thin frozen fries
500-600
18-25
200
Yes
Thick frozen fries
500-600
20-25
200
Yes
Potato gratin
600
20-25
200
Yes
Meat & Poultry
Steak
100-600
12-18
180
No
Pork chops
100-600
12-18
180
No
Hamburger
100-600
10-20
180
No
Sausage roll
100-600
13-15
200
No
Drumsticks
100-600
25-30
180
No
Chicken breast
100-600
18-25
180
No
Snacks
Spring rolls
100-600
8-10
200
Yes
Frozen chicken nuggets
100-600
8-12
180
Yes
Frozen fish fingers
100-500
6-10
200
No
Frozen bread crumbed
cheese snacks
100-500
8-10
180
No
Stuffed vegetables
100-500
12-20
160
No
Baking
12
Cake
500
8-15
180
No
Quiche
500
20-22
180
No
Muffins
500
15-18
200
No
Sweet snacks
500
20
160
No
Note: Add 3 minutes to the preparation time when you start frying while the Hot-air
fryer is still cold.
Cleaning
Clean the appliance after every use.
The pan and the non-stick coating basket. Do not use metal kitchen utensils or
abrasive cleaning materials to clean them, as this may damage the non-stick
coating.
1 Remove the mains plug from the wall socket and let the appliance cool down.
Note: Remove the pan to let the Hot-air fryer cool down more quickly.
2 Wipe the outside of the appliance with a moist cloth.
You can use degreasing liquid to remove any remaining dirt.
Tip: If dirt is stuck to the basket or the bottom of the pan, fill the pan with hot
water with some washing-up liquid. Put the basket in the pan and let the pan and
the basket soak for approximately 10 minutes.
3 Clean the inside of the appliance with hot water and non-abrasive sponge. 4
Clean the heating element with a cleaning brush to remove any food residues.
Storage
1 Unplug the appliance and let it cool down.
2 Make sure all parts are clean and dry.
13

Environment
Do not throw away the appliance with the normal household waste when it is
exhausted,, but hand it in at an official collection point for recycling. By doing this,
you help to preserve the environment
Guarantee and Service
If you need service or information or if you have a problem, please contact:
[email protected]
Troubleshooting
problem
Possible cause
Solution
The Hot-air fryer
does not work
The appliance is not
plugged in.
Put the mains plug in an earthed wall socket.
You have not set the
timer.
Turn the timer knob to the required preparation time
to switch on the appliance.
The ingredients
fried with the air
fryer are not done.
The amount of
ingredients in the basket
is too big.
Put smaller batches of ingredients in the basket.
Smaller batches are fried more evenly.
The set temperature is
too low.
Turn the temperature control knob to the required
temperature setting (see section ‘settings’ in
chapter ‘Using the appliance’).
The preparation time is
too short.
Turn the timer knob to the required preparation time
(see section ‘Settings’ in chapter’ Using the
appliance’).
The ingredients are
fried unevenly in
the air fryer.
Certain types of
ingredients need to be
shaken halfway through
the preparation time.
Ingredients that lie on top of or across each other
(e.g. fries) need to be shaken halfway through the
preparation time. See section ‘Settings’ in chapter
‘Using the appliance’.
Fried snacks are
not crispy when
they come out of
the air fryer.
You used a type of
snacks meant to be
prepared in a traditional
deep fryer.
Use oven snacks or lightly brush some oil onto the
snacks for a crispier result.
14
I cannot slide the
pan into the
appliance properly.
There are too much
ingredients in the
basket.
Do not fill the basket beyond the MAX indication.
The basket is not placed
in the pan correctly.
Push the basket down into the pan until you hear a
click.
White smoke
comes out of the
appliance.
You are preparing
greasy ingredients.
When you fry greasy ingredients in the air fryer, a
large amount of oil will leak into the pan. The oil
produces white smoke and the pan may heat up
more than usual. This does not affect the appliance
or the end result.
The pan still contains
grease residues from
previous use.
White smoke is caused by grease heating up in the
pan . make sure you clean the pan properly after
each use.
Fresh fries are fried
unevenly in the air
fryer.
You did not use the right
potato type.
Use fresh potatoes and make sure they stay firm
during frying.
You did not rinse the
potato sticks properly
before you fried them.
Rinse the potato sticks properly to remove starch
from the outside of the sticks.
Fresh fries are not
crispy when they
come out of the air
fryer.
The crispiness of the
fries depends on the
amount of oil and water
in the fries.
Make sure you dry the potato sticks properly before
you add the oil.
Cut the potato sticks smaller for a crispier result.
Add slightly more oil for a crispier result.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this product for environmental safe
recycling.
15
