Hamlet HDOCKS100C User manual

USB 3.0 MINI DOCKING STATION TYPE-C
HDMI - USB 3.0 + USB 2.0 - Gigabit LAN
Quick Installation Guide
HDOCKS100C
www.hamletcom.com

Dear Customer,
thanks for choosing an Hamlet product. Please carefully
follow the instructions for its use and maintenance and,
once this item has run its life span, we kindly ask You to
dispose of it in an environmentally friendly way, by putting it in the
separate bins for electrical/electronic waste, or to bring it back to
your retailer who will collect it for free.
We inform You this product is manufactured with materials and
components in compliance with RoHS Directive 2011/65/EU,
WEEE Directives 2002/96/EC, 2003/108/EC Italian Legislative
Decree 2005/151, EMC Directive 2014/30/EU and LVD Directive
2014/35/EU for the following standards:
EN 55032: 2012 / AC: 2013, CISPR 32: 2012, EN 61000-3-2: 2014,
EN 61000-3-3: 2013, EN 55024: 2010 + A1: 2015,
EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + A2: 2013,
IEC 60950-1: 2005 (Second Edition) + AM1: 2009 + AM2: 2013.
The complete CE declaration of conformity of the product can be
obtained by contacting Hamlet at [e-mail].
Visit www.hamletcom.com for complete information on all Hamlet
products and to access downloads and technical support.
Imported by: CARECA ITALIA SPA - Scandiano (RE) . Italy.
Trademarks and changes
All trademarks and company names mentioned in this manual are
used for description purpose only and remain property of their
respective owners.
The material in this document is for information only. Contents,
specifications and appearance of the product are indicative and
may change without notice.

1. Introduction
Hamlet HDOCKS100C Mini Docking Station expands the working
area of your screen and your notebook's connectivity with a single
USB Type-C cable. USB-C connection supports Windows 10
Continuum function that turns your phone in a PC. HDMI video
output with 4K Ultra HD support allows you to connect an external
display to extend your PC desktop. One USB 3.0 port provide
connectivity for high-performance devices such as external hard
disks and USB flash drives while the two USB 2.0 ports allow you
to connect keyboard and mouse. Docking station connectivity is
completed by Gigabit Ethernet port for Internet and LAN
connection.
NOTE: Continuum function is available only on select new phones
running Windows 10 Mobile.
Specifications
• USB 3.0 Type-C port for computer or smartphone connection
• Compliant with USB 3.0 standard up to 5 Gbps
• 1 USB 3.0 Type A port (5 Gbps)
• 2 USB 2.0 Type A ports (480 Mbps)
• Video output: HDMI female connector
• Max video resolution: 1920 x 1080 @60Hz (smartphone),
3840 x 2160 @30Hz (PC)
• Ethernet port (LAN): RJ-45 10/100/1000 Mbps
• Power adapter: 100-240V AC input, 5V DC 4A output
• Dimensions (without cables): 65 x 59 x 36,5 mm
• Compatible with Windows 10, Mac OS X 10.11 or above
Package Content
• USB 3.0 Type-C Mini Docking Station
• USB 3.0 Type-C cable (1 m)
• External power adapter
• Quick installation guide

2. Product Overview
The following illustration shows the arrangement of ports and
connectors on the front and back side of the Docking Station.
1. USB Type-C port for computer/smartphone connection
2. USB 2.0 ports (x2)
3. USB 3.0 port
4. Power input
5. HDMI connector
6. Gigabit Ethernet (RJ-45) port

3. Docking Station Installation
The Docking Station is automatically recognized by the operating
system once connected to the USB Type-C port of the computer
without the need to install any driver.
1. Connect the Docking Station to the computer using the USB
Type-C cable included.
2. Plug the power adapter into the power jack of the docking.
3. Connect the Docking Station to an HDMI monitor. The screen
may temporarily go black or flicker during this process.
4. Connect the USB peripherals and the Ethernet cable to the
corresponding connectors on the device.
5. The Docking Station is now ready for use.
The diagram below shows an example of use of the Docking
Station with different external devices.

4. Multi-monitor Configuration
Once an external monitor is connected, it can be configured to use
either “Extend mode”, “Mirror mode” or be the “Primary” display.
Windows
To open the Windows display settings, right-click with the mouse
anywhere on the Windows Desktop, and select Screen
Resolution from the menu.
Extended mode
1. Open the Screen Resolution configuration window.
2. In the Display drop-down menu, select the preferred monitor.
3. In the Multiple displays menu, select Extend these
displays.
4. Click OK to confirm and exit.
5. Once the setting is completed, simply drag and drop the
application icons or the opened windows to the add-on
monitor. However, please note that some applications may
not support to be displayed on the extended desktop.

Cursor disappeared
In extended mode operation, if the add-on display is disconnected,
the desktop will still be extended to the add-on monitor. In this
case, the cursor may not be visible on the main display.
If it happens, reconnect the add-on monitor and move the mouse
cursor on the primary monitor.
Video playback in extended mode
If the quality of video or DVD playback is poor or slow in extended
mode, please playback the video or DVD on the primary monitor
instead of the external monitor.
Mirror mode
1. Open the Screen Resolution configuration window.
2. In the Display drop-down menu, select the preferred monitor.
3. In the Multiple displays menu, select Duplicate these
displays.
4. Click OK to confirm and exit.
Set the Primary Monitor
1. Open the Screen Resolution configuration window.
2. In the Display drop-down menu, select the preferred monitor.
3. Check the box Make this my main display.
4. Click OK to confirm and exit.

Mac OS
To configure display settings on Mac OS computer proceed as
described in below steps.
1. Click on the Apple menu in the top left corner of the screen
and choose System Preferences.
2. In the System Preferences panel, click on Displays icon.
3. Click on the Arrangement tab to view and configure the
displays connected to your Mac.
4. The external monitor works now in extended desktop mode. If
you want to use mirroring mode, simply select the Mirror
Displays checkbox.
To change the lo c ati o n o f a disp la y, c lic k and drag it s bl u e box to
where you want it.
The white bar at the top of the blue box identifies your primary
display. To set a different display as your primary display, drag the
white bar to the box that represents that display.
