Hamlet HN08GTX User manual

Gigabit Switch
8-Port 10/100/1000Mbit
User Manual
HN08GTX Rev. 2.0
www.hamletcom.com

2
Dear Customer,
thanks for choosing an Hamlet product. Please
carefully follow the instructions for its use and
maintenance and, once this item has run its life
span, we kindly ask You to dispose of it in an
environmentally friendly way, by putting it in the
separate bins for electrical/electronic waste, or
to bring it back to your retailer who will collect it for free.
We inform You this product is manufactured with materials
and components in compliance with RoHS Directive
2011/65/EU, WEEE Directive 2002/96/CE, 2003/108/CE
Italian Legislative Decree 2005/151 and EMC 2014/30/EU,
LVD 2014/35/EU Directives for the following standards:
EN 55022: 2010 + AC: 2011, Class B
EN 61000-3-2: 2006 + A1: 2009 + A2: 2009, Class A
EN 61000-3-3: 2013
EN 55024: 2010
EN 61000-4-2: 2009
EN 61000-4-3: 2006 + A1: 2008 + A2: 2010
EN 61000-4-4: 2012
EN 61000-4-5: 2006
EN 61000-4-6: 2014
EN 61000-4-8: 2010
EN 61000-4-11: 2004
EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011
+ A2: 2013
The complete CE declaration of conformity of the product
can be obtained by contacting Hamlet at e-mail address
[e-mail].
The information on the importer for your country are
available in the “About Us” section of the Hamlet website at
www.hamletcom.com.
Trademarks and changes
All trademarks and company names mentioned in this
manual are used for description purpose only and remain
property of their respective owners.
The material in this document is for information only and
subject to change without notice.

3
Introduction
Hamlet HN08GTX is a powerful, high-performance Gigabit
Ethernet switch with 8 ports capable of 10/100/1000 Mbps
auto-negotiation operation (NWay), which means the
switch could automatically negotiate with the connected
partners on the network speed and duplex mode.
It is ideal for micro-segmenting large networks into smaller,
connected subnets for improved performance, enabling the
bandwidth demanding multimedia and imaging
applications. Moreover, the 10/100/1000Mbps
auto-sensing ability provides an easy way to migrate
10/100Mbps to 1000Mbps network. Compared to the
shared 10Mbps or 100Mbps networks, the switch delivers
a dedicated 10/100/1000Mbps connection to every
attached client without bandwidth congestion issue.
This switch also supports auto MDI/ MDI-X function. Each
port could be used to connect to another switch or hub
without crossover RJ-45 cable.
Store-and-forward switching mode promises the low
latency plus eliminates all the network errors, including runt
and CRC error packets. To work under full-duplex mode,
transmission and reception of the frames can occur
simultaneously without causing collisions as well as double
the network bandwidth. Moreover, Green Ethernet and
IEEE 802.3az Energy Efficient Ethernet technologies are
supported to save power consumption.
The switch is plug and play without any software to
configure and also fully compliant with all kinds of network
protocols.

4
Package Contents
Before you start to install the switch, check the following
contents in this package.
• 8–Port Gigabit Ethernet switch
• External power adapter
• Rubber feet
• User’s Manual
Key Features
• Complies with 10BASE-T specifications of the
IEEE802.3 standard
• Complies with 100BASE-TX specifications of the
IEEE802.3u standard
• Complies with 1000BASE-T specifications of the
IEEE802.3ab standard
• 8 x 10/100/1000Mbps RJ-45 Nway ports
• Supports MDI/MDI-X auto crossover
• Supports full and half duplex operation on all ports
• Supports back-pressure (half duplex) and full duplex
flow control (IEEE 802.3x)
• Wire-speed packet filtering and forwarding rate
• Store-and-forward architecture filters fragment & CRC
error packets
• LED indicators for network diagnostics
• Supports Green Ethernet and IEEE 802.3az power
saving technologies

5
LEDs Definition
The Hamlet HN08GTX switch contains one power LED for
the device and 8 LED indicators (Link/Act) that show the
activity and connection status of each port.
Front panel view
Rear view
Please refer to the following table for LEDs definition.
LED
Status
Operation
Power
Steady Green
The switch is powered on
Off
The switch is powered off
Link/Act
Steady Green
Valid port connection
Blinking Green
Valid port connection and
there is data transmitting/
receiving
Off
Port disconnected

6
Station Connection
Connect each station to the switch by twisted-pair cable.
Plug one RJ-45 connector into a RJ-45 port of the switch,
and plug the other RJ-45 connector into the station’s
network adapter. Power on the switch and then system is
ready.
Switches Connection
In making a switch interconnection, you could use any port
to connect another switch with straight or crossover cable.
As all the ports support auto MDI/MDI-X function, using a
straight cable to make a switch-to-switch connection is
allowed.
For cable selection, refer to the following table.
Network Speed
Cable Type
Max. Length
10Mbps
Cat. 3, 4, 5 UTP/STP
100 meters
100Mbps
Cat. 5 UTP/STP
100 meters
1000Mbps
Cat. 5e, 6 UTP/STP
100 meters
Note
To ma ke thi s sw it ch p erf orm wel l, we str ong ly r eco mme n d
below installation environment:
1. The switch is placed with appropriate ventilation
environment. A minimum 25mm space around the unit is
recommended.
2. The switch and the relevant components are away from
sources of electrical noise such as radios, transmitters
and broadband amplifiers.
3. The switch is away from environments beyond
recommend moisture.

7
Product Specifications
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE802.3ab 1000BASE-T
IEEE802.3x full duplex flow control
IEEE802.3az
Interface
8x 10/100/1000 Mbps RJ-45 ports
Network
Data Rate
10/100/1000 Mbps Auto-negotiation
Transmission
Mode
10/100Mbps: Full-duplex, Half-duplex
1000Mbps: Full-duplex
Switching
Capacity
16Gbps
Switching
Forwarding
Rate
11.9Mpps
Buffer Memory
128K bytes
MAC Address
Table
8K
Jumbo Frame
9K bytes
Temperature
Operating: 0 ~ 40 °C (32 ~ 104 °F)
Storage: -40 ~ 70 °C (-40 ~ 158 °F)
Humidity
Operating: 10% ~ 90% RH,
non-condensing
Storage: 5% ~ 90% RH, non-condensing
LED
Indications
System: Power
Ports: Link/Act
Power Supply
External power adapter 5V/1A
Dimensions
155 x 85 x 26 mm
