HAMPTON BAY Barclay EQ628O User manual

USE AND CARE GUIDE
Barclay Metal 6 pk Sectional Set - Right Armed Chair - Grey
y through the purchase of this conversation set.We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
THANK YOU
Thank you for choosing Hampton Bay!
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item # 1005091679
Model # EQ628O

Assembly-Right Armed Chair
Pre-Assembly-Right Armed Chair 3................................
Planning Assembly .................................................................. 3
.......................................5
Care and Cleaning-Right Armed Chair ........................6
stnetnoCegakcaP ....................................................................4
Hardware Included .................................................................. 3
Important Safety Instructions.......................................2
2
Table of Contents
Table of Contents..........................................................2
Warranty ........................................................................2
What is Covered ......................................................................2
What is Not Covered ................................................................2
Important Safety Instructions
Save These Instructions ........................................................ 2
Read All Instructions Before Use .............................................2
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
When using a furnishing, basic precautions should always be followed,
including the following:
To reduce the risk of injury to persons:
a) Close supervision is necessary when this furnishing is used by,
or near children, or disabled persons.
b) Use this furnishing only for its intended use as described in these
instructions. Do not use attachments not recommended by the
manufacturer.
WARNING: Never use this product as a support. Do not shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the product.
CAUTION: Do not locate the product near any
!
heat source.
CAUTION: When not in use, secure the product in a
!
cool and covered location.
This single chair was made for the explicit purpose of providing outdoor
functions and is not to be used as a toy. This product is not intended for
inclement / severe weather in any form including, but not limited to: rain,
hail, sleet, snow and / or wind. The manufacturer recommends storing and
/ or covering this product when formidable weather is approaching. Do
not locate the product near open flames. Children under the age of 10, near
the product, should be supervised by a competent adult at all times. This
product is NOT intended for commercial use and will void the warranty.
Warranty
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
2YEAR LIMITED WA RRANTY
WHAT IS COVERED
We warrant the single chair to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty. We

3
Pre-Assembly-Right Armed Chair
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED- RIGHT ARMED CHAIR
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Part
Description
Quantity
AA
Bolt M6x15
1
Quantity
BB
CC
Bolt M6x40
Bolt M6x55
1
1
DD
Hex Wrench 1
CC
BB
AA
NOTE: Hardware not shown to actual size.
DD

4
Pre-Assembly(continued)
Part
Description
Quantity
mrestrAthgiR 1
B
A
Seat 1
PACKAGE CONTENTS
A
B

1
5
Assembly-Right Armed Chair
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Attaching the right armrest and seat to the back
Attach the right armrest (A) to the seat back using bolts (AA/BB/CC). Loosely tighten using the hex wrench (DD).
Repeat for the seat (B).
BB
CC
AA
A
B

Checking the right armed chair
6
Assembly (continued)
Fully tighten all bolts.
Ensure all connections are secure before use.
For best results, clean the chair with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that
may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the chair in a dry, sheltered place when not in use.
Keep the chair away from , extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Care and Cleaning-Right Armed Chair
2

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
For certification use only
Factory ID # 2007206

USE AND CARE GUIDE
Barclay Metal 6 pk Sectional Set - Left Armed Chair - Grey
y through the etaercyllaunitnocotevirtseW.tesnoitasrevnocsihtfoesahcrup
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
THANK YOU
Thank you for choosing Hampton Bay!
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m.,EST, Monday - Friday, 9 a.m. - 6 p.m.,EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item # 1005091679
Model # KQ628O

Pre-Assembly-Left Armed Chair 3..................................
Planning Assembly .................................................................. 3
Care and Cleaning-Left Armed Chair 6
5...........................
............................
...............Assembly-Left Armed Chair
stnetnoCegakcaP ....................................................................4
Hardware Included .................................................................. 3
Important Safety Instructions.......................................2
2
Table of Contents
Table of Contents..........................................................2
Warranty ........................................................................2
What is Covered ......................................................................2
What is Not Covered ................................................................2
Important Safety Instructions
Save These Instructions ........................................................2
Read All Instructions Before Use ............................................. 2
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
When using a furnishing, basic precautions should always be followed,
including the following:
To reduce the risk of injury to persons:
a) Close supervision is necessary when this furnishing is used by,
or near children, or disabled persons.
b) Use this furnishing only for its intended use as described in these
instructions. Do not use attachments not recommended by the
manufacturer.
WARNING: Never use this product as a support. Do not shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the product.
CAUTION: Do not locate the product near any
!
heat source.
CAUTION: When not in use, secure the product in a
!
cool and covered location.
This single chair was made for the explicit purpose of providing outdoor
functions and is not to be used as a toy. This product is not intended for
inclement / severe weather in any form including, but not limited to: rain,
hail, sleet, snow and / or wind. The manufacturer recommends storing and
/ or covering this product when formidable weather is approaching. Do
not locate the product near open flames. Children under the age of 10, near
the product, should be supervised by a competent adult at all times. This
product is NOT intended for commercial use and will void the warranty.
Warranty
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
2YEAR LIMITED WA RRANTY
WHAT IS COVERED
We warrant the single chair to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty. We

3
Pre-Assembly -Left Armed Chair
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED- LEFT ARMED CHAIR
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Part
Description
Quantity
Bolt M6x15
AA 1
Quantity
BB
CC
Bolt M6x40
Bolt M6x55
1
1
DD
Hex Wrench 1
CC
BB
AA
NOTE: Hardware not shown to actual size.
DD

4
Pre-Assembly (continued)
Part
Description
Quantity
Left Armrest 1
B
A
Seat 1
PACKAGE CONTENTS
A
B

1
5
Assembly - Left Armed Chair
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Attaching the left armrest and seat to the back
Attach the left armrest (A) to the back (B) using bolts (AA/BB/CC). Loosely tighten using the hex wrench (DD).
BB
CC
AA
A
B

6
Assembly (continued)
2Checking the left armed chair
Fully tighten all bolts.
Ensure all connections are secure before use.
For best results, clean the chair with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that
may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the chair in a dry, sheltered p lace when not in use.
Keep the chair away from , extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Care and Cleaning- Left Armed Chair

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
For certification use only
Factory ID # 2007206

y through the etaercyllaunitnocotevirtseW.tesnoitasrevnocsihtfoesahcrup
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
USE AND CARE GUIDE
Barclay Metal 6 pk Sectional Set - Coffee Table
THANK YOU
Thank you for choosing Hampton Bay!
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item # 1005091679
Model # TQ628P

Pre-Assembly-Coffee Table 3.........................................
Planning Assembly .................................................................. 3
Care and Cleaning-Coffee Table ..................................6
...5..............................................Coffee Table-ylbmessA
stnetnoCegakcaP ....................................................................4
Hardware Included .................................................................. 3
Important Safety Instructions.......................................2
2
Table of Contents
Table of Contents..........................................................2
Warranty ........................................................................2
What is Covered ......................................................................2
What is Not Covered ................................................................2
Important Safety Instructions
Save These Instructions ........................................................2
Read All Instructions Before Use ............................................. 2
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
When using a furnishing, basic precautions should always be followed,
including the following:
To reduce the risk of injury to persons:
a) Close supervision is necessary when this furnishing is used by,
or near children, or disabled persons.
b) Use this furnishing only for its intended use as described in these
instructions. Do not use attachments not recommended by the
manufacturer.
WARNING: Never use this product as a support. Do not shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the product.
CAUTION: Do not locate the product near any
!
heat source.
CAUTION: When not in use, secure the product in a
! cool and covered location.
This table was made for the explicit purpose of providing outdoor
functions and is not to be used as a toy. This product is not intended for
inclement / severe weather in any form including, but not limited to: rain,
hail, sleet, snow and / or wind. The manufacturer recommends storing and
/ or covering this product when formidable weather is approaching. Do
not locate the product near open flames. Children under the age of 10, near
the product, should be supervised by a competent adult at all times. This
product is NOT intended for commercial use and will void the warranty.
Warranty
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
2YEAR LIMITED WA RRANTY
WHAT IS COVERED
We warrant the table to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty. We

Hex Wrench
3
Pre-Assembly - Coffee Table
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED- COFFEE TABLE
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Part
Description
Quantity
AA
Bolt M6x15
8
DD
1
DD
AA
NOTE: Hardware not shown to actual size.
Quantity

Pre-Assembly(continued)
Part
Description
Quantity
Table Glass 1
B
A
Table Top 1
CTable Leg 2
PACKAGE CONTENTS
BC
A

5
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
1
l
Assembly-Coffee Table
Attaching the table legs to the table top
Attach the table legs (B) to the table top (A) using bolts (AA). Loosely tighten using the hex wrench (DD).
C
B
B
C
AA
AA
AA
AA
AA
AA

2Installing the glass and checking the table
Place the glass (A) into table top (B).
Fully tighten all bolts.
Ensure all connections are secure before use.
For best results, clean the table with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that
may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the table in a dry, sheltered place when not in use.
Keep the table away from , extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Care and Cleaning-Coffee Table
l
6
Assembly (continued)
A
