HAMPTON BAY FRS80812CRS User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Item # 1001 074 621
1001 170 235
Model # FRS80812CRS
FRS80812CRS-O
USE AND CARE GUIDE
BEACON PARK STEEL WOVEN SWIVEL CHAIR WITH GLIDING FUNCTION
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
1001 407 169
FRS80812CRS-G

2
Table of Contents
Table of Contents..........................................................2 Pre-Assembly ................................................................3
Planning Assembly .................................................................. 3
Hardware Included ................................................................
Package Contents ..................................................................
3
4
Assembly ........................................................................5
Care and Cleaning ....................................................... 11
WARNING: Do not place heavy objects on the chair.
WARNING: This chair unit is heavy, and may require
two adults for safe assembly.
CAUTION: Do not locate the product near any
heat source.
!
WARNING: Weight limit for chair is 300 lbs (136.07 Kg)
for each seat.
Important Safety Instructions ................................... 2
Save These Instructions ........................................................2
Read All Instructions Before Use .............................................. 2
Warranty .........................................................................3
What is Covered .......................................................................3
What is Not Covered .................................................................3
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: This swivel chair was made for the explicit purpose of providing outdoor functions and is not to be used as a toy.
This product is intended for normal outdoor use; however, the manufacturer recommends storing and / or covering this chair
when any formidable / severe weather is approaching.
W
product. Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is
NOT intended for commercial use and will void the warranty.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this product is used by or
near children, or disabled persons, if applicable.
2. Use this product only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chair while the chair is occupied. Failure
to obey this caution could result in injury.
4. Please keep children out of the assembly area before assembly.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
AA M6x20 combination bolt
Description QuantityPart
BB M6x50 combination bolt
6+1
4+1
BB
AA CC DD EE
NOTE: Hardware not shown to actual size.
CC M6x18 countersunk bolt
4
DD M6 plastic washer
4
EE Hex wrench
1
Warranty
2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty. We
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.Homedepot.ca.
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part
Description
Quantity
Right arm 1
1
1
1
1
1
1
1
Left arm
Seat
Backrest
Glider base
Swivel base
Back cushion
Seat cushion
A
B
C
D
E
F
G
H
H
G
A
B
C
D
E
F

1
l
5
Assembly
Place the right arm (A) on a soft surface.
Do not fully tighten all bolts at this step.
Align the holes on the right panel of the seat (C) to the holes on the front of the right arm (A), and secure by using M6x20
combination bolts(AA).
CONNECTING THE RIGHT ARM TO THE SEAT
C
AA
A
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.

2
l
6
Assembly (continued)
Attach the backrest (D) to right arm (A) the and the seat (C) using an M6x20 combination bolt (AA) and M6x50 combination bolts (BB).
Do not fully tighten all bolts at this step.
ATTACHING THE BACKREST TO THE SEAT AND THE RIGHT ARM
AA
BB
C
D
A

3
l
7
Assembly (continued)
CONNECTING THE LEFT ARM TO THE SEAT AND THE BACKREST
AA
AA B
D
C
Connect the left arm (B) to the seat (C) and the backrest (D) using M6x20 combination bolts (AA).
Do not fully tighten all bolts at this step.
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.

4
l
8
Assembly (continued)
Connect the back of the right and the left arm (A & B) to the backrest (D) by inserting M6x50 combination bolts (BB).
Do not fully tighten all bolts at this step.
CONNECTING THE ARMS TO THE BACKREST
BB
B
A
D

5
l
9
Assembly (continued)
Attach the glider base (E) to the arms (A & B) using M6x18 countersunk bolts (CC) and M6 plastic washers (DD).
ATTACHING THE GLIDER BASE TO THE ARMS
Do not fully tighten all bolts at this step.
CC
DD
AB
E
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.

6
l
10
Assembly (continued)
Once all of the bolts are in place, fully tighten the bolts using the hex wrench (EE).
Turn the chair right side up, and insert the support bar to the swivel base (F).
TIGHTENING ALL BOLTS, CONNECTING THE SUPPORT BAR TO THE SWIVEL BASE
F
Support bar

7
l
11
Assembly (continued)
Place the seat and the back cushion (H & G) to finish the assembly of the chair.
Ensure all connections are secure before use.
CHECKING THE CHAIR
Care and Cleaning
For best results, clean the chair with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Keep the chair away from fire, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Store the chair in a dry, sheltered place when not in use.
Do not clean with abrasive materials, bleach, or solvents.
H
G
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Retain this manual for future use.
Factory ID # FRS80812CRS
1-855-HD-HAMPTON
HOMEDEPOT.CA
