HAMPTON BAY BRIAR RIDGE 3PC SECTIONAL SET BARE... User manual

USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item #
Model # Lounge
65-518333B;
Bench, FG19233S
We appreciate the trust and confdence you have placed in Hampto n Bay through the purchase of this Side table. We strive to
continually create quality products designed to enhance your ho me. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!
THANK YOU
BRIAR RIDGE 3PC SECTIONAL SET BARE

2
Table of Contents
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: FUELS USED IN LIQUEFIED PROPANE GAS APPLIANCES, AND THE PRODUCTS OF COMBUSTION OF SUCH FUELS, CAN EXPOSE YOU
TO CHEMICALS INCLUDING BENZENE, WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND CAUSE BIRTH DEFECTS OR OTHER
REPRODUCTIVEHARM. For more information go to: www.P65Warnings.ca.gov.
READ ALL INSTRUCTIONS BEFORE USE
1. Close supervision is necessary when this furnishing is used by or near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in these instructions. Do not use attachments not recommended by
the manufacturer.
SET UP YOUR FURNITURE PROPERLY
1. Ensure that all parts are assembled properly and fully tightened as per the instructions.
2. When placing in the desired location, ensure that all legs are resting on the same surface.
EXAMINE YOUR FURNITURE
Examine occasionally to ensure that there are no loose parts. If loose parts are found, they must be re-tightened fully
before additional use.
OBERVE WEIGHT LIMITS
The weight limits for the following products are listed below:
□Chair: 300 lbs
□Swivel Chair: 300 lbs
□Loveseat: 500 lbs
□Ottoman: 150 lbs
□Table: 50 lbs
□Sofa: 700 lbs
□Rocking Chair: 300 lbs
□Chaise Lounge: 300 lbs
□Dining Table: 100 lbs
□Dining Chair: 200 lbs
CAUTION: If you overload your furniture,injuries can
occur.
Table of Contents .................................. . 2
THD - TOC2...................................... . 2
Safety Information ................................. . 2
What is covered.................................. . 3
What is not covered............................... . 3
Warranty ......................................... . 3
Pre-Installation.................................... . 3
Hardware Included...................................... . 3
Installation. . . .................................... . 5
Care & Cleaning
Service Parts ................................... . . . . . .7
................................... . 6
Package Contents.................................. 4
WARNING: FUELS USED IN WOOD OR CHARCOAL BURNING APPLIANCES, AND THE PRODUCTS OF COMBUSTION OF SUCH FUELS, CAN EXPOSE
YOU TO CHEMICALS INCLUDING CARBON BLACK, WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, AND CARBON MONOXIDE,
WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.
For more information go to: www.P65Warnings.ca.gov
To reduce the risk of injury to persons:

3 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Warranty
Pre-Installation
PLANNING INSTALLATION
To prevent damage, place all parts on a soft surface during ass embly. Remove all protective caps before beginning assembly.
HARDWARE INCLUDED
TWO YEAR FRAME, WEAVE AND FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frame, weave and fabric to be free of manufacturing defects to the original purchaser for two years. For glass
table top we warrant 30 days from the date of purchase.
WHAT IS NOT COVERED
This w
are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.Hamptonbay.com.
Part Description Quantity
AA 6
BB Screw
Bolt M6x 70mm
AA BB CC
DD
CC
1
Hex wrench 4mm
DD M6x35mm 2
M6x 70mm 4
EE FF
FF
EE
Screw M6x 60mm 2
M6x15mmInsert nut
6
GG
M6x15mmInsert nut
2
GG
Bolt

4 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Installation( 255146)
PACKAGE CONTENTS(CHAISE)
Part Description Quantity
A 1
2
C
B
1
The back of chaise
Right arm
D
G
Left arm
A
D
G
1
E
The seat of chaise
Seat cushion
F
C Support bar 2
1
1
B
C
D
E
F
The foot base

5 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Installation ( 255146, Lounge 65-518333B)
1 2
Attaching the chaise seat to the back
□
Place the back (C) on a soft surface.
Attach the seat (D) to the back (C) using bolts (AA) and
(BB) with washer (DD) and hand tighten.
Do not tighten completely .
□
Attach the armrest (A) to the back (C) and seat (D) using
bolts (AA) with washer (DD) and hand tighten.
□
Attaching the chaise armrest to the seat
and back
3Attaching the armrest to the seat
□
Attach the armrest (A) to the seat (D) using
bolts (BB) with washer (DD) and hand tighten.
□
Tighten all bolts (AA）and (BB）with washers
(DD)completely.
C
A
C
B
D
GG
DD
GG
DD
AA
GG
FF
EE EE

6 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Installation ( 255146, Bench, FG19233S)
4Attaching the sofa armrest to the back
□
Place the back (E) on a soft surface.
Attach the armrest (B) to the back (E) using bolts (AA)
with washer (DD) and hand tighten.
Do not tighten completely .
□
5Attaching the back to the seat
□
Attach the back (E) to the seat (F) using
bolts (AA) with washer (DD) and hand tighten.
□
Tighten all bolts (AA）with washers
(DD)completely.
D
F
E
AA
GG
FF
BB
GG
CC
GG

7 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Installation
1
2
Attach the connect clip to the sofa
□
Attach the chaise and sofa with the U shaped connectors
□
Completing the assembly
Put the cushion on the sofa.
This sofa is now ready for your enjoyment.
□
G
BB
GG
CC
GG

Care and Cleaning
□
□
□
Before using, wipe with a clean, dry cloth. Do not use bleach or solvents. When not in use, store furniture in a cool, dry
place. If your set includes cushions or mesh fabric, they may be cleaned by hand with a mild solution of soap and water.
Rinse cushion thoroughly and allow to drip dry. Do not machine wash or tumble dry, as cushions may shrink.
Do not use bleach or solvents on fabrics. When cleaning the table top make sure to use a soft, clean cloth that does
not bleed color as well.
Care and Maintenance
Wash the frame with a mild solution of soap and water, rinse with clean water, and dry thoroughly.
Cushions may also be cleaned by hand with a mild solution of soap andwater. Rinse the cushion cover thoroughly and allow
to drip dry. Theback cushion and pillow should be spot cleaned with a soft cloth. Do not machine wash or tumble dry,
as cushions may shrink. Do not usebleach or solvents on fabrics. Never use cleaners that contain acid or abrasive materials.
Use and operation: To improve the lifespan of this furniture, cover when not use and store in a dry place in the off season.
10 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
□
□
□

MODEL TYPE
11 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Service Parts
H 2
J 3
Loveseat seat cushion
Back cushion
E 1
F 1
1
C
The back of loveseat
The back of chaise
The seat of loveseat
Legs
G
L2
1
Chaise seat cushion
Part Description Quantity
A 1
B 1
1
D
1
Left arm
The seat of chaise
Right arm
Table top
K
M 1 Lower shelf

1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
