HAMPTON BAY FRS80865BL-ST1C User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this sectional. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Model # FRS80865BL-ST1C
Item # 1004 041 595
USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
BEACON PARK LEFT AND RIGHT ARM SECTIONAL - TOFFEE

2
Table of Contents
Pre-Assembly................................................................3
Hardware Included..............................................................3
Planning Assembly..............................................................3
Left Loveseat Package Contents.........................................5
Right Loveseat Package Contents.......................................4
.............................10
Assembly-Right Arm Loveseat .. .................................6
Set Assembly...............................................................14
Care and Cleaning.......................................................14
WARNING: Do not place heavy objects on the product.
WARNING: This product unit is heavy, and may require
two adults for safe assembly.
CAUTION: Do not locate the product near any
heat source.
!
WARNING: Weight limit is 300 lbs (136.07 Kg) for each
chair.
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: This sectional was made for the explicit purpose of providing outdoor functions and is not to be used as a toy.
This product is intended for normal outdoor use; however, the manufacturer recommends storing and / or covering this product
when any formidable / severe weather is approaching.
W
product. Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is
NOT intended for commercial use and will void the warranty.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this product is used by or
near children, or disabled persons, if applicable.
2. Use this product only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chair while the chair is occupied. Failure
to obey this caution could result in injury.
4. Do not rock in the chair as you may fall and cause serious injury.
5. Please keep children out of the assembly area during assembly.
Table of Contents..........................................................2
Important Safety Instructions ................................... 2
Save These Instructions ........................................................2
Read All Instructions Before Use .............................................. 2
Warranty .........................................................................3
What is Covered .......................................................................3
What is Not Covered .................................................................3
Assembly-Left Arm Loveseat .......

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance
AA CC
BB
Warranty
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for three years, and a three year limited warranty for the fabric.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing, and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
3 YEAR FRAME AND 3 YEAR FABRIC LIMITED WARRANTY
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
DD
Part Description Quantity
M6x20 combination bolt 10+1
AA
M6x50 combination bolt
6+1
BB
Hex wrench 1
CC
Metal clip 2
DD

4
Pre-Assembly (continued)
Part Description Quantity
Right arm 1
A
Right arm loveseat seat 1
B
Right arm loveseat backrest 1
C
Loveseat back cushion 2
D
Loveseat seat cushion 2
E
A
B
C
D
E
RIGHT LOVESEAT PACKAGE CONTENTS

Part Description Quantity
Loveseat back cushion 2
D
Loveseat seat cushion 2
E
Left arm 1
F
Left arm loveseat seat 1
G
Left arm loveseat backrest 1
H
5
Pre-Assembly (continued)
LEFT LOVESEAT PACKAGE CONTENTS
H
F
G
D
E
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance

1
6
Place the right arm (A) on a soft surface.
Attach the right arm loveseat seat (B) to the right arm (A) using M6x20 combination bolts (AA).
ATTACHING THE RIGHT ARM LOVESEAT SEAT TO THE RIGHT ARM
1
Do not fully tighten all the bolts at this step.
Assembly-Right Arm Loveseat
AA
B
A
NOTE: Loosely tighten all bolts using the hex wrench (CC).

2
7
ATTACHING THE RIGHT ARM LOVESEAT BACKREST TO THE RIGHT ARM
LOVESEAT SEAT AND THE RIGHT ARM
Assembly-Right Arm Loveseat (continued)
Attach the right arm loveseat backrest (C) to the right arm loveseat seat (B) using M6x50 combination bolts (BB).
Attach the right arm loveseat backrest (C) to the right arm (A) using one M6x20 combination bolt (AA).
Do not fully tighten all the bolts at this step.
C
B
AA
BB
A
NOTE: Loosely tighten all bolts using the hex wrench (CC).
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance

3
8
CONNECTING THE RIGHT ARM LOVESEAT BACKREST TO THE RIGHT ARM
Assembly-Right Arm Loveseat (continued)
Connect the right arm loveseat backrest (C) to the right arm loveseat seat (B) using M6x20 combination bolts (AA).
Connect the right arm loveseat backrest (C) to the right arm (A) using one M6x50 combination bolt (BB).
Do not fully tighten all the bolts at this step.
A
BB
B
AA
C
NOTE: Loosely tighten all bolts using the hex wrench (CC).
LOVESEAT SEAT AND THE RIGHT ARM

9
4TIGHTENING THE BOLTS
D
E
Assembly-Right Arm Loveseat (continued)
Once all of the bolts are in place, fully tighten the bolts.
Turn the right arm loveseat right side up.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance
Place the loveseat back cushions (D) and the loveseat seat cushions (E) onto the chair to nish the assembly of the chair.

10
1
Place the left arm (F) on a soft surface.
Attach the left arm loveseat seat (G) to the left arm (F) using M6x20 combination bolts (AA).
Do not fully tighten the bolts at this step.
ATTACHING THE LEFT ARM LOVESEAT SEAT TO THE LEFT ARM
Assembly-Left Arm Loveseat
G
F
AA
NOTE: Loosely tighten all bolts using the hex wrench (CC).

11
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance
2
Attach the left arm loveseat backrest (H) to the left arm loveseat seat (G) using M6x50 combination bolts (BB).
Attach the left arm loveseat backrest (H) to the left arm (F) using one M6x20 combination bolt (AA).
Do not fully tighten the bolts at this step.
ATTACHING THE LEFT ARM LOVESEAT BACKREST TO THE LEFT ARM LOVESEAT
SEAT AND THE LEFT ARM
Assembly-Left Arm Loveseat (continued)
H
G
AA
BB
F
NOTE: Loosely tighten all bolts using the hex wrench (CC).

12
3CONNECTING THE LEFT ARM LOVESEAT BACKREST TO THE LEFT ARM
LOVESEAT SEAT AND THE LEFT ARM
Assembly-Left Arm Loveseat (continued)
Connect the left arm loveseat backrest (H) to the left arm loveseat seat (G) using M6x20 combination bolts (AA).
Connect the left arm loveseat backrest (H) to the left arm (F) using one M6x50 combination bolt (BB).
Do not fully tighten the bolts at this step.
BB
F
G
AA
H
NOTE: Loosely tighten all bolts using the hex wrench (CC).

13
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance
4TIGHTENING THE BOLTS
D
E
Assembly-Left Arm Loveseat (continued)
Once all of the bolts are in place, fully tighten the bolts.
Turn the left arm loveseat right side up.
Place the loveseat back cushions (D) and the loveseat seat cushions (E) onto the chair to nish the assembly of the chair.

14
Care and Cleaning
For best results, clean the chair with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Keep the sectional away from fire, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Store the sectional in a dry, sheltered place when not in use.
Do not clean with abrasive materials, bleach, or solvents.
1
Attach the left arm loveseat and the right arm loveseat to the corner chair using the metal clips (DD), as shown below.
ATTACHING THE LEFT ARM LOVESEAT AND THE RIGHT ARM LOVESEAT TO
THE CORNER CHAIR
Set Assembly
DD
NOTE: The corner chair is not included, and this step is only
considerable when the corner chair is purchased from
HomeDepot.com.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Retain this manual for future use.
1-855-HD-HAMPTON
HAMPTONBAY.COM
Factory chair ID # FRS80865BL-ST

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
BEACON PARK CORNER SECTIONAL CHAIR TOFFEE
Model # FRS80865BL-ST1M
Item # 1004 041 571
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Table of Contents
Table of Contents..........................................................2 Pre-Assembly ................................................................3
Planning Assembly .................................................................. 3
Hardware Included ................................................................
Package Contents ..................................................................
3
4
Assembly ........................................................................5
Care and Cleaning ........................................................ 9
WARNING: Do not place heavy objects on the chair.
WARNING: This chair unit is heavy, and may require
two adults for safe assembly.
CAUTION: Do not locate the product near any
heat source.
!
WARNING: Weight limit is 300 lbs (136.07 Kg) for the
chair.
Important Safety Instructions ................................... 2
Save These Instructions ........................................................2
Read All Instructions Before Use .............................................. 2
Warranty .........................................................................3
What is Covered .......................................................................3
What is Not Covered .................................................................3
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: This chair was made for the explicit purpose of providing outdoor functions and is not to be used as a toy.
This product is intended for normal outdoor use; however, the manufacturer recommends storing and / or covering this product
when any formidable / severe weather is approaching.
W
product. Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is
NOT intended for commercial use and will void the warranty.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this product is used by or
near children, or disabled persons, if applicable.
2. Use this product only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chair while the chair is occupied. Failure
to obey this caution could result in injury.
4. Do not rock in the chair as you may fall and cause serious injury.
5. Please keep children out of the assembly area before assembly.
Assembly ................................................................ 9Set

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance
AA CC
BB
Part Description Quantity
M6x20 combination bolt 6+1
AA
M6x50 combination bolt
4+1
BB
Hex wrench 1
CC
Warranty
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for three years, and a three year limited warranty for the fabric.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
3 YEAR FRAME AND 3 YEAR FABRIC LIMITED WARRANTY
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
Metal clip 2
DD
DD

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
Corner chair backrest 1 1
A
Corner chair backrest 2 1
B
Corner chair seat 1
C
Corner chair back cushion 1 1
D
Corner chair back cushion 2 1
E
Corner chair seat cushion 1
F
A
C
D
E
F
B

1
l
5
Assembly
Place the corner chair backrest 1 (A) on a soft surface.
Do not fully tighten all the bolts at this step.
ATTACHING THE CORNER CHAIR SEAT TO THE CORNER CHAIR BACKREST 1
NOTE: Loosely tighten all bolts using the hex wrench (CC).
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Attach the corner chair seat (C) to the corner chair backrest 1 (A) using M6x20 combination bolts (AA) and
M6x50 combination bolts (BB).
AA
BB
A
C
