HAMPTON BAY GRAYSON GT-689 0-SSS User manual

THANK YOU
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
GRAYSON CHOW TAB LE ( GRAY)
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Model #GT-689 0-SSS
lounge chair

2
Table of Contents
Table of Contents .................................. . 2
Important Safety Instructions ................................. . 2
Warranty ......................................... . 2
What is covered .................................. . 2
What is not covered ............................... . 2
Important Safety Instructions
2.
Warranty
SAVE THESE INSTRUCTIONS
Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
THIS IS A RESIDENTIAL WARRANTY ONLY AND THIS WARRANTY DOES NOT APPLY TO COMMERCIAL
USE
2 YEAR FRAME AND FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frame to be free of manufact
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.hamptonbay.com.
WHAT IS NOT COVERED
It remains the customer's responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, re, freezing, and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
For a copy of our full limited warranty, please contact our customer service team below.
Close supervision is necessary when this furnishing is used by or
near children, or disabled persons, if applicable.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1.
Pre-Assembly. .................................. ..3
Planning Assembly
............................. ..3
Hardware Included ................................3
Package Contents .................................3
Assembly ...................................... ..4
Care and Clea.ning ..................................5

HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
3
_AA _BB _CC _DD
_EE
NOTE: More than one person may be required to
complete the assembly of this product.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA M6*15 mm bolt 2
BB M6*2 0 mm bolt 8
CC M6 Washer 10
DD M6 bolt cap 10
EE M6-M8 Wrench 1
Part Description Quantity
A Table top 1
B Table leg 2
C Connecting bar 1
PLANNING ASSEMBLY
Please read this entire instruction manual prior to assembly.
Identify all parts packed in the carton against the parts list. Remove all protective materials and place the parts on a non-abrasive surface to
avoid scratching.
PACKAGE CONTENTS
A
BC

4
Assembly
□□Attach the table legs(B) to table top(A) using M6x2 0mm
bolts (BB) and M6washers (CC).
□Tighten all M6x2 0 bolts (BB) with the M6- M8 wrench (EE).
□
□
Cover the bolt heads with M6 bolt caps (DD).
□Cover the bolt heads with M6 bolt caps (DD).
DD
B
CC
Tighten all M6x1 5 bolts (AA) with the M6- M8 wrench (EE).
1Attaching the connecting bar 2
Attaching the table legs
3
□
□
AA
C
B
Attach the connecting bar (C) to table legs (B) using
DD
CC
BB
A
B
Positioning the table
Turn the table over and set it down on its legs.
The table is now ready for use.
M6x 5mm bolts(AA) and M6 washers(CC).
1

HAMPTONBAY.COM
5
Please contact 1-855-HD-HAMPTON for further assistance.
Care and Cleaning
Do notallow water to buildupinthe frames.Thiswillcausecorrosionandpossible freezingdamageincoldclimates.
Use a mildsoapand waterfornormalcleaning. Do notusejanitorial or alcoholbasedcleaners.Somecleaners may be marked as
natural,butsomeingredients may causediscoloration or have an adverse reaction to yourfinish.
Rinse with cleanwateranddry with a soft,absorbent clothtowel.
Treatthe frames with a liquid wax for maximumprotectionagainst UV raysand/orsalty,dampair.
□
□
□
□

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
