HAMPTON BAY TCS64PK User manual

Crestridge Tile Top Rectangular Dining Table
1003155146
Model TCS64PK
USE AND CARE GUIDE
THANK YOU
y through the purchase of this dining set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
HAMPTONBAY.COM
1-855-HD-HAMPTON

Table of Contents
Warranty ........................................................................2
What is Covered ...................................................................... 2
What is Not Covered ................................................................ 2
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
Safety Informat oni
PRODUCT CAUTION
This set was made for the explicit purpose ofproviding outdoor functions and is not to be used as a toy. This productis intended fornormal
outdoor use; however, the manufacturer recommends storing and / or covering this set when any formidable/ severe weather is approaching.
hildren under
the age of 10, near the product, should be supervised by a competent adult at all times.
SAFETY WARNINGS
Table Assembly.............................................................5
Table Package Contents.......................................................... 4
Safety Information .......................................................2
ProductCaution .................................................................... 2
WARNING: Please keep children out of the assembly
area before assembly.
CAUTION: When not in use, secure the product in a cool
and covered location.
!
WARNING: Do not place heavy objects on thetable top.
Safety Warnings .................................................................... 2
Table of Contents..........................................................2
Pre-Assembly ................................................................3
Care and Cleaning........................................................8
2
Warranty
2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.hamptonbay.com.
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty. We
reserve theright to make substitutions with similar merchandise, if the model in question is no longer in production.
WARRANTY PRINTED IN THE MANUAL IS NOT VALID FOR USA.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware notshown to actual size.
AA M6x16 BOLT 14+1
BB
CC
DD
AA BB CC DD
Part
Description Quantity
2+1
16+1
1
M6x25 BOLT
d6.5xD13x1.0 WASHER
4 mm ALLEN KEY WRENCH
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

4
Pre-Assembly (continued)
TABLE PACKAGECONTENTS
Part Description Quantity
ATable top 1
B Table leg 4
C
D
E
Center connector with ring 1
600x300x10 Tile
Support
6
2
A
B
C
D
E

5
l
Table Assembly
1Connecting the table legs and supports to the table top
Place the table top (A) upside down on a soft surface.
Attach the table legs (B) and supports (C) to the table top (A) using M6x16 bolts (AA) and d6.5xD13x1.0 washers (CC).
NOTE: Loosely tighten all the bolts using the hex wrench (DD).
A
AA
CC
B
B
C
C
B
B
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

l
Table Assembly (continued)
2Attaching the leg connector
Attach the center connector with ring (D) to the table legs (B) using M6x16 bolts (AA) and d6.5xD13x1.0 washers (CC).
6
B
B
D
B
B
AA AA
CC CC
NOTE: Loosely tighten all the bolts using the hex wrench (DD).

7
l
Table Assembly (continued)
3Attaching the support connector
Attach the center connector with ring (D) to the supports (C) using M6x25 bolts (BB) and d6.5xD13x1.0 washers (CC).
Loosely tighten all of the the bolts using the hex wrench (DD).
C
C
D
BB
CC
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

8
4
l
Tightening the bolts and placing the tiles
Turn the table right side up.
Then put the tiles (E) onto the table top (A) carefully.
Ensure all connections are secure before use.
Table Assembly (continued)
Once all of the bolts are in place, fully tighten the bolts.
Care and Cleaning
For best results, clean the set with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the set in a dry, sheltered place when not in use.
Keep the set away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet,
snow, or wind.
E
A

Questions,problems,missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m.,EST, Monday - Friday, 9 a.m. - 6 p.m.,EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
